1Overview
1.1 Introduction
ZK-D1065/2180 metal-detector is a walk-through metal-detector that is used for
security screening at access points in the prisons, courthouses, and airports.
Metal-detectors are highly sensitive to magnetic metals and have a high detection
capability, with less ability to detect non-magnetic metals. They are used to detect
the concealed metal weapons on a person’s body. It offers high-speed detection
capability. It can detect large metal objects like knives and guns. Its screening
capacity is very large when compared to hand-held metal detectors.
1.2 Appearance

ZK-D1065/2180 User Manual
Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Page | 8
1.3 Components
1. Beam 2. LED Alarm Zones 3. Built-in Probe
4. Infrared Sensors 5. Waterproof Foot Cover 6. Power-line Interface

ZK-D1065/2180 User Manual
Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Page | 9
2Product Specifications
2.1 Dimensions
ZK-D1065

ZK-D1065/2180 User Manual
Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Page | 10
ZK-D2180

ZK-D1065/2180 User Manual
Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Page | 11
2.2 Technical Specifications
Feature Specifications
Power 100V to 240V
Operating Temperature -20°C to 55°C
Operating Frequency 5.7KHz to 9.6KHz
Dimensions
External
ZK-D1065: 2213(H)x831(W)x471(D)mm
ZK-D2180: 2226(H)x844(W)x579(D)mm
Channel
ZK-D1065: 2000(H)x710(W)x399(D)mm
ZK-D2180: 2001(H)x710(W)x499(D)mm
Weight
ZK-D1065: 35kg
ZK-D2180: 45kg

ZK-D1065/2180 User Manual
Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Page | 12
3Installation Setup
3.1 Safety Precautions
•Install the detector in a stable and smooth area. Make sure that the
detector is installed firmly in the selected area.
•It can be used for both indoor and outdoor purposes. If used outdoor,
cover it with a canopy to protect against rain.
•Before installation, make sure the left and right door panels are placed at
the corresponding location. Avoid high temperatures and wet
environments.
•Wait for 1 minute for the self-diagnosis of the detector when it starts. Do
not touch the detector during a security check to avoid false alarm.
•Install the detector away from radio-frequency devices to avoid
interference. Make sure that there is no large metal object or strong
magnetic field around the detector for at least 2 meters.
•Do not hit the detector hardly, as it may cause false alarms.
•Do not disassemble the unit without the guidance of a professional
technician.
•Each device has a warranty card, with which users can have their devices
maintained or repaired free of charge within the warranty period.
3.2 Instructions to Pedestrians
•A line must be drawn at 50cm away from the detector. The pedestrians
must pass through the detector one-by-one.
•Pedestrians should line up one-by-one to ensure the smooth operation of
the detector.
•Pedestrians should walk at a normal speed. They must not intentionally
form a crowd, rush, walk slowly, or crush the door panel.

ZK-D1065/2180 User Manual
Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Page | 13
•Before passing through the metal detector, the pedestrians must remove
all the carried metal objects (such as keys, mobile phone, watch, coins, etc.),
and place it on the security chute or a table, and pick it up after the security
check.
•If the detector alarms when someone passes through, that means there
is/are some metal object(s) hidden in the body. The security guard can use
a hand-held metal detector to accurately detect the hidden position
according to the alarm zones.
3.3 Installation Site
The following section describes the requirements of the installation environment.
3.3.1 Stationary Metallic Items
The detector must be installed away at 50cm from the stationary metallic items
such as aluminum alloy/stainless-steel windows, doors, etc. to prevent false alarms
and affecting the sensitivity of the detector.
3.3.2 Portable Metallic Items
The portable metallic objects must be kept away at 2 meters from the detector to
avoid false alarms.
3.3.3 Floor Vibration
The installation floor must be flat and fixed to avoid false alarm from the movement
of the people walking through the detector.
3.3.4 Electromagnetic Radiation and Interference
Since the detector uses Bilateral receiver technology, the detector must be installed
away at a distance of at least 1 meter from the sources of electromagnetic radiation
or electromagnetic interference. The parameters that define the distance are
determined by the installation environment and the parameters vary for different
installation environments.

ZK-D1065/2180 User Manual
Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Page | 14
The sources of electromagnetic radiation and electromagnetic interference are
given below:
Electrical Control Box, Radiofrequency equipment, Interphone, High Power Motor,
Power Transformer, Ac Power Lines, Thyristor Control Circuit (High Power Switching
Power Supply, Inverter Welder), Engine, Motor, etc.
3.3.5 Parallel Installation
When two detectors are installed parallel to each other, the distance between two
detectors must be greater than 50cm. When three detectors are installed parallel to
each other, the distance between each detector must be greater than 80cm. They
must operate at a different frequency to avoid interference. The distance varies
according to the actual working environment, it is not recommended to mount
three detectors in parallel, the frequency can be adjusted according to the
environment.
3.4 Installation Steps
Make sure that the device is installed as per the following installation instructions. If
you want to open the chassis, you should contact the agent for permission.
Otherwise, you will bear any consequence resulting from your actions.

ZK-D1065/2180 User Manual
Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Page | 15
1. Open the Control unit and Door panel package.
2. Install the control unit and the door panels as shown in the above diagram.
Connect the door panels to the control unit with bolts and nuts and tighten the
screws.
3. Insert the probe-lines of the left and right door panels to the corresponding
sockets on the mainboard.
4. Then lift the Walk-through metal detector vertically and place it in the required
area.
5. Finally, plug in the power cable to start working.
Left Door Panel Right Door Panel

ZK-D1065/2180 User Manual
Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Page | 16
4Performance and Technical Features
Accurate Positioning: There are 6/18 overlapping detection zones with bilateral
transmit and receive technology. The detection zones can accurately detect the
objects with an intuitive display of the target location.
Micro Processor Technology: The Microprocessor Control Unit generates the
electromagnetic waves for scanning and the scanning rate can be precisely
controlled.
Adjustable Sensitivity: ZK-D1065 detection zones have 100 sensitivity levels (1 to
100), ZK-D2180 detection zones have 256 sensitivity levels (1 to 256). You can preset
the metal size, by excluding the false alarm of coins, keys, jewelry, belt buckle, etc.
Digital Pulse Technology: Digital signal processing and filtering system in the
detector has excellent anti-interference ability.
Count Statistics: The detector displays the number of pedestrians passed and Alarm
count accurately.
Harmless: The detector is harmless to heart pacemakers, pregnant women,
magnetic floppy disks, recording tapes, etc.
Waterproof Foot Cover: The waterproof foot cover not only can fix the device firmly
but also protect the device against water.
Safety: The Control Unit case and the panels are waterproof. The cover is made of
PVC synthetic material which makes the detector waterproof, fireproof, and
shockproof.
Easy to install: The detector has an integrated design and it can be effortlessly
installed or disassembled in 15 minutes.

ZK-D1065/2180 User Manual
Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Page | 17
5Control Panel
The components of the Control Panel are given below:
1. LCD: Displays the Pass count, Alarm count, Password settings, and other
information.
2. ESC: Press to discard the settings and exit the menu.
3. :Adjustment (decrement) key to decrease the parameter values.
4. : Adjustment (increment) key to increase the parameter values.
5. OK: Opens the Menu interface, saves the settings, and exits the menu.
Note: There is a network interface on the back of ZK-D2180.

ZK-D1065/2180 User Manual
Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Page | 18
6Detection Zones
The ZK-D1065/2180 detectors can detect a wide range of threat objects/weapons
composed of magnetic, non-magnetic metals and alloys.
Chassis panel: The screen shows the number of people passing the detector and
the number of alarms.
Alarm zones:
6 zones: The zones are classified as 1 to 6 from bottom to top.
18 zones: The zones are classified as 1 to 18 from bottom to top (default).

ZK-D1065/2180 User Manual
Copyright©2021 ZKTECO CO., LTD. All rights reserved.
Page | 19
There are six unique sets of precise positioning LED’s evenly distributed on the door
panels, which means 18 detection zones. If the metal composition reaches or
exceeds the preset value, the red LED glows and an alarm will be triggered. If there
are multiple alarm targets, the LED of each target location will glow with alarm.
Infrared Sensor
After connecting the power supply, the metal detector starts to work. When there is
no person or object passes through the detector, the infrared sensors can
effectively stop alarming to avoid false alarms. It also helps to maintain an accurate
count of pedestrians and alarms.
6.1 Adjustment of Detection Zone’s Sensitivity
1. The device must be in a stable position to achieve the best detection effect
(refer Installation Site). To check whether the device is in a stable state,
perform the following steps:
a) Power on the detector and check whether it is not shaking after one
minute.
b) The device should not alarm when the testing person did not carry any
metal items while walking through the detector.
2. You can exclude the small portable metal objects such as rings, key, belt
buckle, shoes, and so on, by following the steps given below:
a) Choose a small metal as a sample. Increase the sensitivity, so that when
the testing person carries the sample and pass through the detector, and
it would alarm.
b) Decrease the sensitivity a little, carry the sample, and pass through the
detector again. If it still alarms, once again reduce the sensitivity, until the
device does not alarm when the sample is passed through.
Note: If you want to decrease the sensitivity in a certain zone, you must only adjust
the sensitivity of the relative zone. After implementing the above adjustments, the
metal which smaller than the sample will not alarm, but the metal objects bigger
than the sample can be detected accurately.
