ZNEX Notstrom User manual

notstrøm
USER GUIDE | BENUTZERHANDBUCH
Para consultar este modo de uso en español, vaya al sito
Pour le mode d'emploi en français, veuillez vous rendre sur le site
Per le istruzioni per l’uso in lingua italiana visitate
日本語の取り扱い説明書は、下記をご覧下さい。
http://www.znex.de/downloads
ES
FR
IT
JP

notstrøm – Your new outdoor power battery
Thank you for choosing notstrøm. Finally you can charge your devices everywhere. Whether on the bicycle, on boat or at the beach. Notstrøm
provides sufficient power of 10,000mAh so that you do not have to plug your devices into a power outlet for a few days. Due to its excellent
weather resistance, it is the ideal companion for your next outdoor adventure.
Please note: To ensure that your notstrøm is waterproof, the cover of the micro USB-port and the charge port must always be closed tightly
with protective caps. Screw-on the charging cable tightly so that when it is raining, water cannot enter the charging port. Do not keep the device
in dusty or moist environments. Due to wear and any damages, your notstrøm can become less dust or moisture-repellent with time. Never
immerse notstrøm into sea water or carry it along while swimming. Never expose it to liquid chemicals. Do not keep it in moist environments
with extremely high or low temperatures. If water comes into contact with the micro-USB port or the charging port, wipe it off with a dry cloth.
The water proofness of your micro USB-port and the charging port cannot be guaranteed in all environmental conditions.
If you have further questions regarding the use of your product, please contact our customer service.
Please read the user guide carefully and pay particular attention to the listed instructions so that you can enjoy your new, mobile notstrøm
reserve for as long as possible.
EN
Scope of delivery:
notstrøm-Outdoor battery / Waterproof Y-charging cable
Micro USB charging cable / Bike mount
2 Velcro retaining straps
Technical data:
10.000mAh/36Wh
Input 5V/1.5A
Output 5V/2.1A

Opening the cap Connecting the charging
cable
Connect the supplied micro-USB cable with the
input. Now you can charge notstrøm in any
USB-interface (PC/MAC, USB power adapter*,
car, solar panel).
Note:
Don’t forget to screw on
the protective cap again
after charging.
60 - 80 %
LED blinks
LED constantly
LED display
0 - 20 %
20 - 40 %
40 - 60 %
80 - 100 %
100 %
Note:
During charging, you switch off or on the
LEDs anytime with a single click (see stealth
mode).
Unscrew the rear
protective cap
How to charge notstrøm
Warning:
Screw on the protective cap again after
charging everytime. Only in this way, the
electronics can be prevented from being
damaged irreversibly by water, moisture or
dirt particles.
*USB power adapter is
not included in the
scope of the delivery
During charging, the LEDs blink and display
the current state of charge. If all LEDs
constantly illuminate, notstrøm is then
charged.
EN

Screwing-on the plug
How to charge a mobile USB-device with notstrøm
Select connection Switch on the nostrøm
Remove the protective cap from the charge
port of notstrøm and screw on the water-
proof plug of the charging cable.
Note:
Please ensure that the notstrøm is switched
on so that charging process can start.
Warning:
Ensure that the union nut is tightened. Only
then a significant connection is developed
with the notstrøm.
Connect the micro-
USB-plug of Y-cable
with the device you
want to charge.
(e.g. all Android
& Windows
Smartphones).
Press the On/Off switch for 2 seconds to turn
on the notstrøm. The LED-display is now
activiated and the connected device is now
charged.
Warning:
If you press the On/Off switch for a very short
time, the LED-display is only activated - the
notstrøm is however not switched on
(see stealth mode)!
Connect your USB-charging cable with the
USB-coupling of Y-cable. (e.g. iPhone/iPad,
devices with mini-USB connection).
EN
Union nut
Micro-USB plug
On/Off switch
USB coupling

How to switch off the NS
By clicking on the Off/On button, you can
view the charge status at any time.
Note:
The charge status can be viewed at any time
irrespective of whether notstrøm is currently
switched off or on.
40 - 20 %
100 - 80 %
80 - 60 %
60 - 40 %
20 - 10%
< 10%
LED blinks
LED constantly
If only a single LED light blinks, notstrøm has less than
10% of its charging capacity and needs to be recharged.
Checking the capacity
Charging an iPad or iPhone EN
You can switch off notstrøm by:
Either pressing the On/Off switch for 2
seconds
or
drawing the cable from notstrøm.
In the latter case, notstrøm automatically
switches off after 10 seconds.
Note:
If the charging cable is unscrewed and
notstrøm is switched on, it will be present in
>Stand-by Mode.
If a device is connected now, it will be
immediately supplied with power.
If you are uncertain whether you have
switched off notstrøm or not, we recommend
you to disconnect the charging cable.
By clicking again on the On/Off button,
you can switch off the LED display.
LED off
Use your original Apple charging cable to
connect your Apple device with the
USB-coupling part of the Y-charging cable.
If you prefer a waterproof cable with
a Lightning or 30-Pin connector, you can find
both cables in our shop under Accessories.

Tarn (Stealth) Mode Stand-by Mode EN
You can hide the LED display at any time.
If notstrøm is being charged or a device is
connected to it for getting charged, the LED
display will automatically switch on.
In certain situations, you might want to make
the LED lights invisible.
If you prefer to switch off the LEDs, simply
click on the ON/OFF button. The LED lights
will now disappear without affecting the
charging function of notstrøm.
Note:
The LED display can be switched on again
by clicking again on the ON/OFF button.
If the charging cable is screwed on and you
switch on notstrøm, it will automatically enter
the active stand-by mode.
Connect a device for charging now and it will
be continuously supplied with power.
Automatic switch-off does not take place after
the device is completely charged.
The stand-by mode makes it convenient to
use the ØM3 on a bicycle and also guarantees
continuous power supply of outdoor
monitoring equipment for long periods of
time such as GPS-Trackers, USB motion
detectors, wild cameras etc.
Note:
If the stand-by mode is disabled, you should
either switch off notstrøm or remove the
connected cable.
Weather resistance
notstrøm is only protected against rain, snow,
dust and sludge when both its protective caps
are closed
or the connection cable is tightely screwed.
iP67
Input protective cap
iP68
Output protective cap
iP68
Plug connection
Warning:
Malfunctioning or short circuit might occur
if water or even very small quantities of
impurities (sand, dust, dirt) enter the device.
Clean the plug connection and protective
cap therefore after using it. Please ensure
that the plug and the protective cap are
always kept dry and clean when you connect
the plug with notstrøm or put the protective
cap on.

Warning:
notstrøm must always be secured with the
velcro fastener!
Please never ride the bicycle without this
fastener. Otherwise, it might fall off while
you are riding the bicycle.
Attaching notstrøm
Attach notstrøm to the bracket and fasten it
securely with the velcro strap.
You can fit notstrøm to your bicycle as follows
Mount the bracket
Almost all bicycles have two drill holes at
the lower tube for the bottle holder. Here,
you can also fit the notstrøm bracket: loosen
the screws, place the bracket and retighten
the screws.
Note:
If you have already fitted a bottle holder
to your bicycle, you can fit in the notstrøm
bracket additionally.
Ready to go
EN

Safety instructions
Entsorgung/Recycling
Other EN
+Do not keep notstrøm for a long time at a
place where the temperature may rise above
60° C (e.g. on the dashboard of a car).
This could lead to irreversible damage of the
cells.
+Do not charge notstrøm at temperatures
below 0°C and over 45°C
+If you do not require notstrøm for a long
time, keep it in a cool and dry place. The
storage temperature range is 10° - 25° C
+ The optimal charging status for storage is
40% of its capacity. Please check the charging
status after every 8 weeks and recharge it if
required.
+Please never try to open or repair notstrøm.
The battery does not contain any components
that can be repaired by the user.
CE-certification and conformity declaration
notstrøm is CE certified, RoHS-conforming and
corresponds to the European disposal guidelines.
We declare that the product notstrøm complies to the
guidelines set out in EMV 2004/108/EC and that a copy
of this declaration is available on www.znex.de.
Exclusion of liability
We have made all efforts to ensure that the
information provided in this manual is correct and
complete. However, we do not accept liability for any
errors and/or omissions. As the manufacturer, we
reserve the right to make modifications or enhance-
ments to all of the functions described in this manual
without any prior announcement.
Since notstrøm contains Li-Ion
cells, we would like to point out:
Please return your old battery to
a municipal collection centre or a
local retailer as prescribed by
Disposal/Recycling
All rights reserved
Without the written consent of ZNEX, no part of this
manual can be copied, reproduced or transferred to a
third party or stored on a storage medium of any kind
for any purpose.
statutory regulations.
The disposal through normal household waste
is forbidden and would violate the battery
legislation. The battery can be returned free
of charge. You can also return your battery to
us free of charge after using it.
The battery, along with sufficient postage,
should be returned to the following address:
ZNEX Deutschland |Münchhofstr.12 | 79106 Freiburg

øm3
950 Lumens

OM3 Bicycle/Outdoor/Helmet lamp
Get the perfect light for your waterproof notstrøm battery.
When the sun goes down and you want to keep going, you can always depend on the power
and versatility of your ØM3/notstrøm lighting system. Bright enough to illuminate everything
in your path, the ØM3 runs with 4+ hours burn-time in the highest brightness level.
Paired with the notstrøm battery, this water resistant, lightweight and durable power lamp
will meet your needs by mounting to a bar, any type of helmet, using as a flashlight or setting
on a flat surface to use as a lantern.
learn more at: www.znex.de

z:nex
visit us at www.znex.de
ZNEX Deutschland GmbH & Co. KG | Muenchhofstr. 12 | 79106 Freiburg | Germany
Phone: [phone] | Email: [email protected]
