Zodiac ZS500 User manual

H0493400.C - 2021-07
EN
Technical room Kit - ZS500, Z550 iQ
Spare Parts/Accessories Instructions Manual - English
Translation of the original instructions in french

1
EN
Only a person qualied in the technical elds concerned (electricity, hydraulics or refrigeraon) is authorised to
perform this procedure. The qualied technician working on the appliance must use/wear personal protecve
equipment (such as safety goggles and protecve gloves, etc.) in order to reduce the risk of injury occurring
when working on the appliance.
Before handling the machine, ensure that it is switched o and isolated.
Parts supplied
1 metal sheet to aach the duct
to the heat pump
1 strip of aluminium adhesive
tape
4 long screws + 4 washers
1 duct (3.3 meters maximum) +1 metal sheet to aach the
duct to the heat pump + 1 frame to aach the duct to the wall
in the technical premises
1 metal cable + 1 plasc duct + 1 tensioner
4 self-boring screws
2 grill aachment frames (to be
sealed)
2 grills
Installaon procedure
• It is vital that this procedure is carried out to the end to ensure that the appliance operates correctly,
• The appliance must be installed in a venlated technical room, free from freezing temperatures, all traces
of damp and stored pool maintenance products.
• Only the connecon kit supplied must be mounted on the blowing machine.
• Bring in the fresh air using the second grill provide in the kit; this fresh air must come directly from the
exterior ambient air and not from a room adjacent to the technical room.
• The exterior air must be brought in by lowering the pressure in the technical room.
• Check that this type of assembly does not hinder the other technical appliances in this room.

2
Final layout
For the best results, make sure that the duct is as straight as possible (avoid elbow joints and chicanes).
Do not extend the duct (3,3 meters maximum).
The aspiraon and blowing grills must be at least 1.5 metres apart to avoid recycling the air.
Installing the external grills
Seal the grill frame on the external wall of the technical
premises. Put the sides with 2 holes respecvely at the top
and boom, never on the side.
Aach the grill to the frame of the external wall of
the technical premises. Cauon: point the vents down
for the water to ow out.
Installaon de la gaine
Remove the cover from the heat pump. Block the air outlet with the aluminium tape.

3
EN
Run the cable around the duct and posion
the plasc duct so that it protects the blowing
duct.
Reposion the cover and aach it to the
frame on the heat pump using the 4 long
screws and washers provided.
Posion the duct on the frame and secure it using the 4 self-boring screws
provided (there are holes in the duct framework).
Run the metal cable into the tensioner (following the arrow) then into the plasc duct.
Run the end of the cable into the other hole in the tensioner and adjust
its height.
Aach the cable to the ceiling using the loop at the other end of the cable.
Power up the heat pump.

4
Use the following table to congure the appliance, depending on its model.
ZS500 Z550 iQ
Enter the menu by pressing the key:
Press and hold for 3 seconds to access the advanced
sengs.
Select the “Parameters” menu and access
level 2:
• Select “CODE“ using the and arrows.
• Press to conrm.
• Enter “-19“ using and arrows.
• Enter code “-19” to enter the menu?
• Set parameter P80 to 10 (to increase
the venlator operang speed).
• Select the “P60“ parameter using the and
arrows.
• Press to conrm.
• The “OFF“ message is displayed without ashing.
• Press or : the “OFF“ message ashes.
• Press or : the “ON“ message ashes.
• Press to conrm.
Please state during communicaons with third pares (by post, e-mail or telephone) that the original appliance
has been modied to the “equipment room” version.
