DRAIN PUMP SYSTEM
MODEL132 (Preassembled)
INSTALLATION INSTRUCTIONS
PREINSTALLATION CHECKLIST
P/N 015765
SECTION: 6.10.046
FM2113
0111
Supersedes
1004
Product information presented
here reflects conditions at time
of publication. Consult factory
regarding discrepancies or
inconsistencies. MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347
SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961
[phone] • 1 (800) 928-PUMP • FAX [phone]
visit our web site:
www.zoeller.com
Notice to Installer: Instructions must remain with installation.
© Copyright 2011 Zoeller Co.All rights reserved.
1. Inspect your unit. Occasionally, products are damaged during shipment. If the unit is damaged, contact your dealer before using. DO NOT remove
the test plugs from the pump.
2. Carefully read the literature provided to familiarize yourself with specific details regarding installation and use. These materials should be retained
for future reference.
1. Toreducetheriskofelectricalshock,aproperlygroundedreceptacleof
groundingtypemustbeinstalledandprotectedbyagroundfaultcircuit
interrupter(GFCI)andinaccordance with National Electrical Code and
local codes. (SEE WARNING BELOW).
2. Makecertainthatthereceptacleiswithinthereachofthepump’spower
supply cord. DO NOT USEAN EXTENSION CORD. Extension cords
thataretoo longortoolight do notdeliversufficient voltage tothepump
motor. But more important, they could present a safety hazard if the
insulation were to become damaged or the connection end were to fall
into the sump.
3. Testing for Ground. As a safety measure, each electrical outlet should
be checked for ground using an Underwriters Laboratory Listed circuit
analyzer which will indicate if the power, neutral and ground wires are
correctly connected to your outlet. If they are not, call a qualified elec-
trician.
4. For Added Safety. Pump must be connected to a 3-prong grounded
outlet interrupter device (ground fault circuit interrupter).
5. FOR YOUR PROTECTION, ALWAYS DISCONNECT PUMP FROM
ITS POWER SOURCE BEFORE HANDLING. Single phase pumps
are supplied with a 3-prong grounded plug to help protect you against
the possibility of electrical shock. DO NOT, UNDER ANY CIRCUM-
STANCES,REMOVETHE GROUNDPIN. Toreducetheriskofelectri-
cal shock, a properly grounded receptacle of grounding type must be
installed and protected by a ground fault circuit interrupter (GFCI) in
accordance with national electrical code and local codes.
6. Installationand checkingofelectricalcircuitsand hardwareshouldonly
be performed by a qualified licensed electrician.
7. Risk of electric shock - These pumps have not been investigated for
use in swimming pool areas.
8. According to the state of California (Prop 65), this product contains
chemicals known to the state of California to cause cancer and birth
defects or other reproductive harm.
1. Checktobesureyourpowersourceisadequateforhandlingthevoltage
requirements of the motor, as indicated on the pump or basin plate.
2. Make sure the pump electrical supply circuit is equipped with fuses or
circuit breakers of proper capacity.A separate branch circuit is recom-
mended,sizedaccordingtotheNationalElectricalCode for the current
shown on the pump name plate.
3. All plumbing (discharge and vent lines) must be installed to meet local
codes.Unitmustbevented.Somestatesrequirethisunittobeinstalled
byaqualifiedlicensedplumber.DONOTUSEANAUTOMATICPLUMB-
ING VENT DEVICE SIMILAR TO A "PRO-VENT".
4. Repair and service should be performed by Zoeller Pump Company
Authorized Service Station only.
5. CHECK VALVE MUST BE USED TO REDUCE UNNECESSARY CY-
CLING OF PUMP.
6. Dewatering pumps are not designed or intended for handling raw sew-
age.
7. Maximumoperatingtemperaturefor132DrainPumpsmustnotexceed
110°F (43°C).
8. For health reasons, do not unplug, turn off, or disable pump and use
pump tank system as a way to fill up a sink or laundry tray, etc.
NOTE: Pumps with the "UL" mark and pumps with the "US" mark are
tested to UL Standard UL778. CSA Certified pumps are certified to
CSA Standard C22.2 No. 108.
SEE BELOW FOR LIST OF WARNINGS SEE BELOW FOR LIST OF CAUTIONS
MODEL:_______________________
DATE CODE: __________________
DATE INSTALLED: _____________
REFER TO WARRANTY ON PAGE 2.

2
© Copyright 2011 Zoeller Co.All rights reserved.
ELECTRICALPRECAUTIONS- Before servicing a pump, always shut off the main power breaker and then unplug the pump - mak-
ing sure you are not standing in water and wearing insulated protective sole shoes. Under flooded conditions, contact your local electric company or a
qualified licensed electrician for disconnecting electrical service prior to pump removal.
Submersible pumps can become pressurized under normal operating conditions — allow 2½ hours after disconnecting before attempting
service.
CONDITION COMMON CAUSES
A. Pump will not start or run.
Check fuse, low voltage, overload open, open or incorrect wiring, open switch, impeller or seal bound mechanically, defec-
tive capacitor or relay when used, motor or wiring shorted. Float assembly held down. Switch defective, damaged, or out
of adjustment.
B. Motor overheats and trips over-
load or blows fuse.
Incorrectvoltage,negativehead(dischargeopenlowerthannormal)impellerorsealboundmechanically,defectivecapacitor
or relay, motor shorted.
C. Pump starts and stops too often.
Floatswitchtetherlengthtooshort(model104only),floattootightonrod,checkvalvestuck,ornoneinstalledinlongdistance
line, overload open, switch defective.
D. Pump will not shut off. Debrisunder float assembly,floator float rodbound by basin sidesor other, switch defective,damaged or out ofadjustment.
E. Pump operates but delivers little
or no water.
Check strainer housing, discharge pipe, or if check valve is used, the vent hole must be clear. Discharge head exceeds
pump capacity. Low or incorrect voltage. Incorrect motor rotation. Capacitor defective. Incoming water containing air or
causing air to enter pumping chamber.
F. Drop in head and/or capacity
after a period of use.
Increased pipe friction, clogged line or check valve. Abrasive material and adverse chemicals could possibly deteriorate
impeller and pump housing. Check line. Remove base and inspect.
G. If tank or fittings leak.
Carefullytightenpipe joints(usepipe dope)andscrews. Checkgasket location, tightenlid evenly.Donotover tightenfittings
or screws.
If the above checklist does not uncover the problem, consult the factory - Do not attempt to service or otherwise disassemble pump. Service must
be by ZoellerAuthorized Service Stations.
Service Checklist
Manufacturerwarrants, to the purchaser andsubsequent owner dur-
ing the warranty period, every new product to be free from defects
in material and workmanship under normal use and service, when
properly used and maintained, for a period of one year from date of
purchase by the end user, or 18 months from date of original manu-
facture of the product, whichever comes first. Parts that fail within
thewarranty period, oneyear fromdate of purchaseby theend user,
or 18 months from the date of original manufacture of the product,
whichever comes first, that inspections determine to be defective in
materialorworkmanship,willberepaired,replacedorremanufactured
at Manufacturer's option, provided however, that by so doing we will
notbeobligated to replace an entire assembly,theentiremechanism
orthecompleteunit. Noallowancewillbemadeforshippingcharges,
damages,labororotherchargesthatmayoccurduetoproductfailure,
repair or replacement.
This warranty does not apply to and there shall be no warranty for
anymaterialor product thathasbeen disassembled without priorap-
provalofManufacturer, subjectedtomisuse, misapplication, neglect,
alteration,accidentoractofGod;thathasnotbeeninstalled,operated
or maintained in accordance with Manufacturer's installation instruc-
tions;that hasbeen exposed to outside substances including but not
limitedtothefollowing: sand,gravel,cement,mud,tar,hydrocarbons,
hydrocarbonderivatives(oil,gasoline,solvents,etc.),orotherabrasive
or corrosive substances, wash towels or feminine sanitary products,
etc.inallpumpingapplications. Thewarrantysetoutintheparagraph
above is in lieu of all other warranties expressed or implied; and we
donotauthorize anyrepresentativeor otherpersonto assume forus
any other liability in connection with our products.
ContactManufacturer at, 3649Cane RunRoad, Louisville, Kentucky
40211,Attention:CustomerServiceDepartmenttoobtainanyneeded
repair or replacement of part(s) or additional information pertaining
to our warranty.
MANUFACTUREREXPRESSLYDISCLAIMSLIABILITYFORSPE-
CIAL,CONSEQUENTIALORINCIDENTALDAMAGESORBREACH
OF EXPRESSED OR IMPLIED WARRANTY; AND ANY IMPLIED
WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND
OF MERCHANTABILITYSHALL BE LIMITED TO THE DURATION
OF THE EXPRESSED WARRANTY.
Some states do not allow limitations on the duration of an implied
warranty, so the above limitation may not apply to you. Some states
do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights and you may also have
other rights which vary from state to state.
Limited Warranty

3
© Copyright 2011 Zoeller Co.All rights reserved.
1. Read all instructions before beginning installation.
2. Be certain that basin is on a firm level surface.
3. Do not use an automatic plumbing vent device.
4. Always use a check valve on the discharge line.
5. Test operation of pump per STEP 3.
Helpful Hints For Easy Installation
6. Always provide some means to disconnect basin from
plumbing for maintenance purposes.
7. Run unit at least once a month to verify proper operation.
8. The model number and date code can be found on the lid
warning label.
9. Plug pump into a properly grounded GFCI receptacle.
STEP 1 Determine Installation Configuration
NOTE: This preassembled unit is designed for use with an
external trap.
Figure 1 is a typical configuration for installation of the drain
system. The actual configuration will vary depending on your
cabinet and sink configuration.
Figure 1
STANDARD INSTALLATION
1. DO read all installation material included with the pump.
2. DO inspect unit for any visible damage caused by shipping.
Contact dealer if unit appears to be damaged.
3. DO always disconnect pump from power source before
handling. DO always connect to a separately protected and
properly grounded ground fault protected circuit. DO NOT
ever cut, splice or damage power cord. DO NOTcarry or lift
pump by its power cord. DO NOT use an extension cord.
Do’s And Don't’s For Installing A Unit
4. DONOTuseadischargepipesmallerthanthepumpdischarge
size.
5. DO test pump immediately after installation to be sure that
the system is working properly.
6. DO review all applicable local and national codes and verify
that the installation conforms to each of them.
Performance Characteristics
SK2001
015766
PIPING SHOWN ONLY
FOR CLARITY.

© Copyright 2011 Zoeller Co.All rights reserved.
STEP 2 Final Assembly
NOTE: External plumbing con-
figuration will vary depending
onthelocationofbasin,location
of main stack and available
space.
Placethebasinassemblyinitsfinal
position and complete plumbing.
Secure all connections shown in
Figure 2.
Illustrated Parts Breakdown
*When ordering this item, order the hardware pack item #6.
MODEL 132 Rev. A Rev. B
ITEM DESCRIPTION QTY 08/02 thru
12/10
01/11
thru
Current
1 Drain Pump 1 132-0001 132-0001
2 M72 (See FM1722) 1 72-0001 72-0001
3 Basin - Tank 1 013017 013017
4 Discharge Tube 1 013732 013732
5 Basin - Lid 1 013018 013018
6 Hardware Pack 1 013731 013731
7 Basin Seal 1 N/A* N/A*
8 Unicheck 1 30-0181 019768
9 ¼ - 20X1" lg. RHM Screw S.S. 8 N/A* N/A*
10 ¼ - Flat Washer S.S. 16 N/A* N/A*
11 ¼ - 20 Hex. Hd. Nut - S.S. 8 N/A* N/A*
12 Pipe Cap w/o-ring 1 N/A* N/A*
13 O-Ring 1 N/A* N/A*
SK2832
Figure 2
Drain Pump 132 SK2833
STEP 3 Initial Testing of Drain Basin System
1. Plug the cord into a properly grounded GFCI receptacle.
2. Fill the basin with 2-3 gallons of water and let sit for 3-4
minutes to enable the environmentally safe peanuts to begin
dissolving.
3. Slowly fill the basin with water.
4. Check all plumbing for leaks as the basin fills.
5. Verify that the pump starts and stops.
6. Check the discharge line for leaks as the pump empties
the basin.
7. Repeat steps 2 through 6 as necessary to ensure proper
operation.
8. If problems persist, refer to the troubleshooting guide
located on page 2 of this manual.
