Zonet ZSR4154WE User manual

Copyright Statement
is the registered trademark of Zonet Technology Inc. All the
products and product names mentioned herein are the trademarks or
registered trademarks of their respective holders. Copyright of the whole
product as integration, including its accessories and software, belongs to Zonet
Technology Inc. ithout the permission of Zonet Technology Inc., any individual
or party is not allowed to copy, plagiarize, imitate or translate it into other
languages.

Table of Contents
Chapter 1 Introduction......................................................................... 1
elcome.............................................................................................. 1
Contents of Package .............................................................................. 1
System Requirement ............................................................................. 1
Getting to Know Your ZSR4154 E .......................................................... 2
Chapter 2 Hardware Installation......................................................... 4
Chapter 3 Connect Your ZSR4154 E ................................................... 6
How to Check the Network Connection..................................................... 9
Chapter 4 Basic Configurations ...........................................................10
How to Access the eb-based Configuration Utility ..................................10
Setup izard.......................................................................................11
Chapter 5 Advanced Settings ..............................................................15
LAN Settings .......................................................................................15
AN Settings ......................................................................................16
MAC Address Clone ..............................................................................20
DNS Settings .....................................................................................20
Chapter 6 ireless Settings ................................................................21
Basic Settings......................................................................................21
Security Settings .................................................................................22
Advanced Settings ...............................................................................25
PS Settings.......................................................................................26
DS Settings ......................................................................................27
Access Control .....................................................................................28
Connection Status ................................................................................29
Chapter 7 DHCP Server .......................................................................30
Server List & Binding ............................................................................31
Chapter 8 Virtual Server......................................................................32
Port Range Forwarding..........................................................................32
DMZ Settings.......................................................................................33
UPnP Settings......................................................................................33
Chapter 9 Traffic Control ...................................................................34
Chapter 10 URL Monitor.....................................................................35

Chapter 11 Security Settings...............................................................37
Client Filter .........................................................................................37
URL Filter............................................................................................38
MAC Filter ...........................................................................................39
Prevent Network Attack ........................................................................39
Remote eb Management.....................................................................40
an Ping ............................................................................................40
Chapter 12 Routing Settings ...............................................................42
Routing Table .....................................................................................41
Chapter 13 System Tools.....................................................................42
Time Settings ......................................................................................42
DDNS .................................................................................................42
Backup/Restore ...................................................................................43
Firmware Upgrade................................................................................43
Restore to Factory Default Settings ........................................................44
Reboot................................................................................................44
Change Password.................................................................................45
System Log .........................................................................................45
Appendix 1: Product Features & Specifications .................................46
Appendix 2: Troubleshooting .............................................................48

1
Chapter 1 Introduction
elcome
Thank you for purchasing Zonet ZSR4154 E – 802.11n wireless broadband
router! This high cost-efficiency router is the best choice for Small office / Home
office users, all computers and network devices can share a single xDSL / cable
modem internet connection at high speed. Easy install procedures allows any
computer users to setup a network environment in very short time - within
minutes, even inexperienced. hen the number of your computers and
network-enabled devices grow, you can also expand the number of network slot
by simple attach a hub or switch, to extend the scope of your network!
All computers and IEEE 802.11b/g/n(Draft 4.0) wireless-enabled network
devices (including PDA, cellular phone, game console, and more!) can connect
to ZSR4154 E without additional cabling. The MIMO technology also gives you
the highest speed of wireless experience ever! ith a compatible wireless card
installed in your PC, you can transfer file for up to 150Mbps! The radio coverage
is also doubled, so don’t worry if your office or house is really big!
Moreover, the Zonet ZSR4154 E also can be managed or configured through
Local/Remote easy-to-use eb-based utility.
Contents of Package
One ZSR4154 E
One Detachable Antenna
One Power Adapter
One User Manual CD
One Quick Installation Guide
Contact your local authorized reseller or the store purchased from for any items
damaged and/or missing.
System Requirements
Internet connection, provided by xDSL or cable modem with a RJ-45
Ethernet port.
Computer or network devices with wired or wireless network interface card.
eb browser (Microsoft Internet Explorer 5.5 or above, Firefox 1.0 or
above).
An available power socket (100–240V, 50/60Hz)

2
Getting to Know Your ZSR4154 E
Top Panel
LED Indicator
Status Description
PO ER ON ZSR4154 E is switched on and correctly powered
SYS Flashing Indicates the system works normally.
ON Indicates AN port is connected
AN Flashing Indicates AN activity (transferring or receiving
data)
LAN Flashing Indicates the wireless signal is OK.
ON Indicates LAN port is connected
LAN(1/2/3/4) Flashing Indicates LAN activity (transferring or receiving
data)
PS Flashing Indicates ZSR4154 E is negotiating with PS
clients in PS Mode (PBC or PIN).

3
Rear Panel
Item Name Description
PO ER Power connector, connects to power adapter
AN ide Area Network ( AN / Internet) port.
1-4 (LAN Ports) Local Area Network (LAN) ports 1 to 4
RESET
Reset ZSR4154 E to factory default settings (clear all
settings). Press this button and hold for 7 seconds to
restore all settings to factory defaults.
PS Start PS function. Press this button for 1 second to start
PS function.
Antenna The antenna is 3dBi dipole antenna.

4
Chapter 2 Hardware Installation
Please follow the following instruction to build the network connection between
your ZSR4154 E and your computers, network devices:
1. Connect the A/C power adapter to the wall socket, and then connect it to the Power
socket of ZSR4154 E.
2. Connect all your computers, network devices (network-enabled consumer devices
other than computers, like game console, or switch / hub) to the LAN port of
ZSR4154 E.

5
3. Connect your xDSL / cable modem to the AN port of ZSR4154 E by Ethernet
cable.
4. Please check all LEDs on the top panel. PO ER LED should be steadily on, AN and
LAN LEDs should be on if the computer / network device connected to the
respective port of ZSR4154 E is powered on and correctly connected. If any LED
you expected is not on, please recheck the cabling, or jump to “Troubleshooting”
for possible reasons and solution.

6
Chapter 3 Connect Your ZSR4154 E
How to Set the Network Configurations for My Computer
1. Right click My Network Places and select Properties
2. Right click Local Area Network Connection and select Properties.

7
3. Select Internet Protocol (TCP/IP) and click Properties.
4. Select Obtain an IP address automatically and Obtain NS server
address automatically. Click OK to save the configurations.

8
5. Or select Use the following IP address and enter the IP address, Subnet
mask, Default gateway. Of course, you need to input the DNS server address
provided by your ISP. Otherwise, you can use the ZSR4154 E’s default
gateway as the DNS proxy server. Click OK to save the configurations.

9
How to Check the Network Connection
1. Select Start →
→→
→ Programs →
→→
→ Accessories →
→→
→ Command Prompt.
2. Input ping 192.168.0.1 and press Enter. If the screen displays as below, it
means your PC is connected to your router successfully.
If not, please make sure the hardware installation and network adapter are
OK.

10
Chapter 4 Basic Configurations
This section is to show you how to configure your new ZSR4154 E through the
eb-based Configuration Utility.
How to Access the eb-based Configuration Utility
1. After your computer obtained an IP address from ZSR4154 E, please start
your web browser, and input the default IP address of ZSR4154 E
http://192.168.0.1 in address bar.
2. Please input user name and password and then click OK.
Both default user name and password is admin.

11
Setup izard
1. hen Welcome to Setup Wizard pop out, Click Next to continue.
2. Select one Internet connection type you’re using. If you’re not sure, click
etect or contact your Internet Service Provider.
Click Next.

12
a. ADSL Virtual Dial-up (Via PPPoE)
Enter the Account and Password provided by your ISP, and click Next.
b. Dynamic IP (Via DHCP)
If your connection type is Dynamic IP, it means your IP address keeps
changing every time you connect. You do not need to enter the
information.
c. Static IP
Fill the network address information from your ISP in the IP Address,
Subnet Mask, Gateway and Primary DNS server fields and click Next.

13
d. L2TP
Enter the Account and Password provided by your ISP.
L2TP(Layer 2 Tunneling Protocol) provides two address modes.
Dynamic IP: If the L2TP offered by your ISP is Dynamic IP, please select
Dynamic IP.
Static IP: Please fill in the parameters provided by your ISP.
After configuration, please click Next.
e. PPTP
Enter the Server IP Address, User Name, and Password provided by your ISP
PPTP(PP Tunneling Protocol) provides two address modes.
Dynamic IP: If the PPTP offered by your ISP is Dynamic IP, please select
Dynamic IP.
Static IP: Please fill in the parameters provided by your ISP.
After configuration, please click Next.

14
3. Click Apply and reboot ZSR4154 E, or select Reboot in System Tools of
the left menu and click Reboot the router button.
4. hile rebooting, please wait for few minutes and DO NOT power off.
5. Select Network Status of the left menu to find out the current network and
system information.

15
Chapter 5 Advanced Settings
LAN Settings
MAC Address: ZSR4154 E’s physical MAC address on your local network
is unchangeable.
IP Address: ZSR4154 E’s LAN IP address (not your PC’s IP address).
Once you modify the IP address, you need to remember it for the
eb-based Utility login next time. Default value is 192.168.0.1
 Subnet Mask: ZSR4154 E’s subnet mask for measurement of the
network size. Default value is 255.255.255.0.

16
AN Settings
a. PPPoE
Connection Mode: Show your current connection mode.
Account: Provided by your ISP.
Password: Provided by your ISP.
MTU: Maximum Transmission Unit. It is the size of largest datagram that
can be sent over a network. The default value is 1492. Do NOT modify it
unless necessary.
Service Name: It is defined as a set of characteristics that are applied to
a PPPoE connection. Enter it if provided. Do NOT modify it unless necessary.
AC Name: Enter it if provided. Do NOT modify it unless necessary.
Internet Connection Option:
Connect Automatically: Connect automatically to the Internet after
rebooting system or connection failure.
Connect Manually: Connect to the Internet by the user manually.
Connect on Demand: Re-establish your connection to the Internet after
the specific time (Max Idle Time). Zero means your Internet connection at
all time. Otherwise, enter the minutes to be elapsed before you want to
disconnect the Internet access.
Connect on Fixed Time: Connect to the Internet during the time you fix.
