Zte MF93D User manual

1
MF93D
Let’s go
Getting started with your device.
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057

2
LEGAL INFORMATION
Copyright © 2013 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced,
translated or utilized in any form or by any means, elec-
tronic or mechanical, including photocopying and micro-
lm, without the prior written permission of ZTE Corpora-
tion.
The manual is published by ZTE Corporation. We re-
serve the right to make modications on print errors or
update specications without prior notice.
Version No. : R1.0
Edition Time : 2013.12
NOTE:
Do not use the device in an enclosed environment or
where heat dissipation is poor. Prolonged work in such
space may cause excessive heat and raise ambient
temperature, which may lead to automatic shutdown of
the device for your safety. In the case of such event, cool
the device in a well-ventilated place before turning on for
normal use.

3
Getting to Know Your Device
Appearance
The following gure is only for your reference. The actual
product may be different.
External Antenna Connector
Micro USB Port
OLED Screen
Power Switch
(U)SIM Card Slot
RESET Button / microSD Card Slot
WPS Button

4
NOTES:
• microSD logo is a trademark of SD-3C, LLC.
• Please use the original external antenna if neces-
sary.
Indicators
When the device is powered on, the following icons will
appear on the OLED screen, with the corresponding indi-
cates listed in the table below:
Icon Indication
Network signal strength.
2G/3G/4G
Network type. 2G, 3G, 4G icon will ap-
pear on the OLED screen according to
the network being connected.
Connect to the Internet automatically.
Connect to the Internet manually.
Roaming network indication.
New message received.

5
Wi-Fi Status and number of the connect-
ed users.
Battery power indication.
Connection Scenario
Your device supports two methods to go to Internet and
supports multi-clients for surfing on the Internet at the
same time. The following gure is only for your reference.
• 4G Mode: Use your (U)SIM card to access the Inter-
net.
• Internet Wi-Fi Mode: Your device will connect to
other WLAN device (hotspot device, wireless router,
etc.) via Wi-Fi to access the Internet. The WLAN de-
vice has already connected to the Internet.

6
NOTE:
The subnet must be deferent between your device and
other WLAN device.
Installing Your Device
1. Insert the SIM card.

7
2. Insert the microSD card.
1) Open the microSD card cover.
NOTE:
Do not pull the cover rudely, as it is connected with the
device.
2) Insert the microSD card into the microSD slot. The
following picture shows the correct inserting direc-
tion. You will hear a click when the microSD card
locks in place.
3) Close the microSD card cover.

8
Connecting to Your Device
Via Wi-Fi
1. Power on your device directly. It will take 1~2 min-
utes to initialize.
2. Use your normal Wi-Fi application on the client to
search for the available wireless networks.
NOTE: Please set the client to obtain an IP address
automatically referring to the chapter “Conguring Your
PC”, and then the client will get an IP address like
“192.168.0.100”.

9
3. Select the SSID of your device, and then click Con-
nect. The following picture is only for your reference.
4. Input the password, and then click Connect.
NOTE:
• There may require the password for Wi-Fi connec-
tion, please check the label on your device to get the
default.
• Double press the WPS button, and then the SSID
and Wi-Fi key will display on the OLED screen.

10
5. Wait a moment, and then the client will connect to
your device successfully.
Via USB Cable
1. Connect to the device.
2. Power on your device.
3. The OS detects and recognizes new hardware and
nishes the installation automatically.
NOTE: If the Windows operating system does not launch
installation automatically, you can run the installation pro-

11
gram in path of My Computer > ZTEMODEM.
4. Wait a moment, and then the client will connect to
your device successfully.
Accessing the Internet
4G Mode
After the client connected to your device successfully,
you can access the Internet in the Automatic or Manual
mode. The default mode is Automatic.
Mode Operations
Automatic
Your device will connect to the Internet
automatically, and your clients can surf on
the Internet directly.
Manual
Login the webGUI conguration page,
and select Settings > Network Settings
> Dial-up Settings > Manual, and then
click Home > Connect / Disconnect.
NOTE:
If you want to modify the detailed parameters of your
device, please login the webGUI conguration page by
visiting http://192.168.0.1 or http://m.home. The default
password is admin.

12
Internet Wi-Fi Mode
1. Login the webGUI conguration page.
2. Select Settings > Internet Wi-Fi.
3. Set the Internet Wi-Fi Switch and Preferred Net-
work, and then click Apply.
NOTE: You need to Enable the Internet Wi-Fi Switch and
select Wi-Fi.
4. Connect to the WLAN device.
There are two methods for your reference.
uSelect the listed SSID, and then click Connect.
uClick Add, input the WLAN device information in
the Add Wi-Fi Hotspot area, and then click
Apply.

13
5. After your device connected to the WLAN device
successfully, you can access the Internet.
Conguring Your PC
Follow the following steps and gures for Windows XP to
congure the Internet Protocol for your Wi-Fi connection.
1. Right-click My Network Places, and then select
Properties.
2. Right-click Wireless Network Connection, and then
select Properties.

14
3. Select Internet Protocol(TCP/IP), and then click
Properties.

15
4. Select Obtain an IP address automatically and
Obtain DNS server address automatically, and
then click OK to nish the conguration.

16
Warning and Notice
To the Owner
• Some electronic devices are susceptible to electro-
magnetic interference sent by your device if inad-
equately shielded, such as the electronic system of
vehicles. Please consult the manufacturer of your
device before using if necessary.
• Operating your device may interfere with medical
devices like hearing aids and pacemakers. Please
always keep them more than 20 centimeters away
from such medical devices when they are turned on.
Turn your device off if necessary. Consult a physician
or the manufacturer of the medical device before us-
ing your device.
• The device complies with RF specications when the
device is used at 1cm from your body.
• Be aware of the usage limitation when using your
device at places such as oil warehouses or chemical
factories, where there are explosive gases or explo-
sive products being processed. Turn off your device
if required.

17
• The use of electronic transmitting devices is forbid-
den in aircrafts, at petrol stations and in hospitals.
Please observe and obey all warning signs and
switch off your device in these conditions.
• Do not touch the inner antenna area if not necessary.
Otherwise it will affect your device’s performance.
• Store your device out of the reach of little children.
Your device may cause injury if used as a toy.
• Do not touch the metallic parts of your device so as
to avoid a burn, when your device is working.
Using Your Device
• The device is for indoor use only. Do not use the de-
vice outside. The device does not support DFS.
• Please use original accessories or accessories that
are authorized. Using any unauthorized accessories
may affect your device’s performance, and violate
related national regulations about telecom terminals.
• Avoid using your device near or inside metallic
structures or establishments that can emit electro-
magnetic waves. Otherwise it may inuence signal
reception.
• Your device is not waterproof. Please keep it dry and
store in a shady and cool place.

18
• Do not use your device immediately after a sudden
temperature change. In such case, it will produce
dew inside and outside your device, so don’t use it
until it becomes dry.
• Handle your device carefully. Do not drop, bend or
strike it. Otherwise your device will be damaged.
• No dismantling by non-professionals and only quali-
ed technicians can undertake repair work.
• Operating temperature range of 0°C ~ +35°C and
humidity range of 5% ~ 95% are recommended.
About your Adapter
• Adapter shall be installed near the equipment and
shall be easily accessible.
• Model: ZTE MF93D
• Manufacturer: ZTE Corporation
• The plug considered as disconnect device of
adapter. The plug is removable, which can be disas-
sembled from the adapter.

19
Using Battery
• Do not short-circuit the battery, as this can cause ex-
cessive heat and re.
• Do not store the device in hot areas or dispose of it
in a re to avoid explosion.
• Do not disassemble or modify the battery.
• Never use any charger or battery damaged or worn
out.
• Return the wear-out battery to the provider or put it in
the appointed recycle place. Do not put it in familial
rubbish.
WARNING:
Do not change the built-in rechargeable battery in your
device by yourself. The battery can only be changed by
ZTE or ZTE authorized service provider.
Limited Warranty
• This warranty does not apply to defects or errors in
the Product caused by:
i. Reasonable abrasion.
ii. End User’s failure to follow ZTE’s installation,
operation or maintenance instructions or proce-
dures.

20
iii. End User’s mishandling, misuse, negligence, or
improper installation, disassembly, storage, ser-
vicing or operation of the Product.
iv. Modications or repairs not made by ZTE or a
ZTE-certied individual.
v. Power failures, surges, re, ood, accidents, ac-
tions of third parties or other events outside ZTE’
s reasonable control.
vi. Usage of third-party products, or usage in con-
junction with third-party products provided that
such defects are due to the combined usage.
vii. Any other cause beyond the range of normal us-
age intended for the Product.
End User shall have no right to reject or return the Prod-
uct, or receive a refund for the Product from ZTE under
the above-mentioned situations.
• This warranty is End User’s sole remedy and ZTE’s
sole liability for defective or nonconforming items,
and is in lieu of all other warranties, expressed, im-
plied or statutory, including but not limited to the im-
plied warranties of merchantability and tness for a
particular purpose, unless otherwise required under
the mandatory provisions of the law.
