Zte MF971V User manual

1
MF971V
Quick Start Guide
ZTE CORPORATION
NO. 55, Hi-tech Road South, Shenzhen, P.R.China
Postcode: 518057
FCC ID: SRQ-ZTE-MF971V

2
Getting to Know Your Device
Appearance
The following figure is for your reference only.
1. Power key
2. FUNC key
3. External antenna connector
4. LCD screen
5. External antenna connector
6. Charging/micro-USB jack
7. micro-SIM card slot cover and reset hole

3
Getting to Know Your Device
Indicators
When the device is powered on, the following icons may be
displayed on the LCDscreen. For a description of the icons, refer
to the following table.
Icon Description
Network signal strength
/ / Network type
The user is in roaming status.
Connected to the Internet.
Connected to the Internet in the Internet Wi-
Fi mode.
New message(s)
Wi-Fi status and the number of connected
users

4
Battery level
Getting to Know Your Device
Connection Scenarios
The device can access the Internet in two ways and it allows
multiple clients to surf on the Internet at the same time. The
following figures are for your reference only.
 4G Mode: A micro-SIM card can be used to access the
Internet.
 Internet Wi-Fi Mode: Your device can be connected to a
WLAN device (such as a hotspot device or wireless router)
through Wi-Fi to access the Internet. The WLAN device must
be already connected to the Internet.
NOTE:

5
Your device and the WLAN device must be in different subnets.

6
Installing the micro-SIM Card
1. Open the micro-SIM card slot cover, and install a micro-SIM
card to the micro-SIM card slot.
NOTE:
Do not remove the cover rudely, because it isconnected with the
device.
WARNING!
To avoid damage to the device, do not use any other kind of SIM
cards, or any non-standard micro-SIM card cut from a SIM card.
You can get a standard micro-SIM card from your service
provider.
2. Close the micro-SIM card slot cover.

7
Connecting to Your Device
Using Wi-Fi
1. Power on your device.
2. Ensure that your computer or other client devices have
enabled Wi-Fi, and search for available wireless networks.
NOTE:
Refer to your Wi-Fi enabled client device manual for further
details on how to search for wireless networks. If you use a
computer, you need to set your computer to obtain an IPaddress
automatically.
3. Select the Wi-Fi name (SSID) of your device, and click
Connect.
4. Enter the Wi-Fi password if necessary, and click OK.
NOTE:
Refer to the chapter Getting to Know the Wi-Fi SSID and
Password to get the default Wi-Fi SSID and password.
5. Wait until the client device is connected to your device
successfully.
Using a USB Cable
1. Connect a computer to your device with a USB cable.
2. Power on your device. The operating system detects and
identifies new hardware, and automatically installs the
hardware.

8
NOTE:
If the system does not automatically launch installation, you can
Double-click the device installation icon in My Computer to
install the software.
3. Wait until the computer is connected to your device
successfully.

9
Getting to Know the Wi-Fi SSID and
Password
You can use the following methods to get the default Wi-Fi SSID
and password.
View the label on the device.
Press the FUNC key to access the options menu. Select
Device Info and the Wi-Fi SSID and password are
displayed on the screen.

10
Logging in to the 4G Mobile Hotspot
Configuration Page
1. Ensure that the connection between your device and the client
device is correct.
2. Launch the Internet browser and enter http://192.168.0.1 or
http://ufi.ztedevice.com in the address bar.
3. Enter the password to log in to the 4G Mobile Hotspot
configuration page.
NOTE:The default password is admin.

11
Changing the Wi-Fi SSID or
Password
1. Log in to the 4G Mobile Hotspot configuration page.
2. Select Settings below Wi-Fi and then click Main SSID.
3. Change the Network Name (SSID) or the Password in the
Main SSID area.
4. Click Apply.

12
Accessing the Internet
4G Mode
After a client device is successfully connected to your device, you
can access the Internet in Automatic or Manual mode. The
default mode is Automatic.
Mode Operation
Automatic Your device is automatically connected to
the Internet, and you can surf on the
Internet through the client.
Manual 1.Log in to the 4G Mobile Hotspot
configuration page.
2. Select Settings > Connection Mode >
Manual, and then click Apply.
3. Click to back to the home page,
and click or .
You can also press the FUNC key and
select Data Connection. Select Yes or
No.
NOTE:
To modify the parameters of your device, log in to the 4G Mobile
Hotspot configuration page.

13
Internet Wi-Fi Mode
1. Log in to the 4G Mobile Hotspot configuration page.
2. Select Settings below Wi-Fi and then click Internet Wi-Fi.
3. Set the Internet Wi-Fi Switch as Enable and then click
Apply.
4. Set the Preferred Network as Wi-Fi and then click Apply.
5. Connect to the Wi-Fi hotspot.
The following two methods are for your reference.
Select a Wi-Fi hotspot listed in the Wi-Fi Hotspot area and
click Connect. Enter a password in the Password text box
and click Yes.
Click Add Network, enter the Wi-Fi hotspot information in
the Add Wi-Fi Hotspot area, and click Apply. Click the Wi-
Fi hotspot you have added and then click Connect.

14
After the client device is connected to the Wi-Fi hotspot
successfully, you can access the Internet.

15
Using the FUNC Key
When the screen is off:
Press the FUNC key to turn on the screen.
When the screen is on:
Press the FUNC key to access the options menu. You
can connect or disconnect with the Internet, view device
information or Wi-Fi QR code, activate WPS function,
enable/disable global roaming or quick boot function
without logging in to the 4G Mobile Hotspot Configuration
Page.

16
Configuring Your PC
The following describes how to configure the Internet Protocol in
the Windows 7 for your Wi-Fi connection.
1. Right-click Network and select Properties.
2. Select Change adapter settings.
3. Right-click Wireless Network Connection and select
Properties.
4. Select Internet Protocol Version 4 (TCP/IPv4),and click
Properties.
5. Select Obtain an IP address automaticallyand Obtain DNS
server address automatically, and click OK.

17
Warning and Notice
To the Owner
• If inadequatelyshielded, some electronic devices, for example,
the electronic system of vehicles, may be affected by the
electromagnetic interference caused by the device. Consult
the manufacturers of such devices before using the device if
necessary.
• Operating the device may interfere with medical instruments
such as hearing aids and pacemakers. Always keep the
device more than 20 centimeters away from such medical
instruments when your device is powered on. Power off the
device if necessary. Consult a physician or the manufacturers
of medical instruments before using the device if necessary.
• Be aware of the usage limitation when using the device at
places such as oil warehouses or chemical factories, where
there are explosive gases or explosive products being
processed. Power off the device if necessary.
• Do not use electronic transmission devices in aircrafts, at
petrol stations or in hospitals. Observe and obey all warning
signs, and power off the device in these conditions.
• Do not touch the inner antenna area unless necessary.
Otherwise the performance of the device may be affected.
• Do not use the device in an enclosed environment or where
heat dissipation is poor. Prolonged work in such space may
cause excessive heat and raise ambient temperature, which
may lead to automatic shutdown of the device for your safety.
In the case of such event, cool the device in a well-ventilated
place before turning on for normal use.
• Keep the device out of the reach of small children. The device
may cause an injury if used as a toy.

18
• When the device is operating, do not touch the metallic parts.
Failing to do so may cause burns.
To the Users
• Use original accessories or accessories that are authorized.
Using any unauthorized accessories may affect the
performance of the device and violate the related national
regulations about telecom terminals.
• Avoid using the device near or inside metallic constructions or
establishments thatcan emit electromagnetic waves, because
signal reception may be affected.
• The device is not waterproof. Keep the device dry and store it
in a shady and cool place.
• Do not use thedevice immediately after a sudden temperature
change, because dew may be generated inside and outside
the device. Do not use it until it becomes dry.
• Handle the device carefully. Do not drop, bend or strike it.
Otherwise the device may be damaged.
• Only qualified personnel can dismantle and repair the device.
• The humidity between 5% and 95% is recommended.
• Do not connect the charger while using the device for a long
period. Failing to do so will trigger the protection mechanism
of the battery, and the battery will not be charged. If you want
to charge the battery, please reconnect the charger.
• Do not connect the charger while using the device for a long
period or use the device and battery in non-operating
temperature. Failing to do so will shorten battery life or cause
battery swelling or leakage. If the battery shows signs of
swelling or leakage, please stop use immediately.
• For pluggable equipment, the socket-outlet shall be installed
near the equipment and shall be easily accessible.

19
Using Battery
WARNING!
The battery is not removable. Removal may cause fire or
explosion.
• Using ZTE-unapproved or incompatible battery, charger or
power adapter may damage your device, shorten its lifespan
or cause a fire, explosion or other hazards.
• Therecommendedoperatingtemperatures are -10 °C to 55°C
and the storage temperatures are -20 °C to +60 °C. Extreme
temperatures can damage the device and reduce the charging
capacity and lifespan of your device and battery.
• Do not change or replace the built-in rechargeable battery in
your device by yourself. The battery can only be changed or
replaced by ZTE or ZTE authorized service provider.
• Do not place the device or the battery in or near heating
equipment, such as microwave ovens, stoves or radiators.
Keepthe device and the batteryaway fromexcessiveheatand
direct sunlight. If not, the device or the battery may overheat
and cause explosion or fire.
• Do not disassemble, squeeze or puncture the device, as this
can cause explosion or fire.
• Do not throw the device into a fire to avoid explosion.
• Please disconnect the charger when the battery is fully
charged. Overcharging may shorten the battery life.
• When not using the device for a long period, please charge
the battery about half and then store the device in a cool dry
place.
• If the battery damages or shows signs of swelling or leakage,
please stop use immediately and contact ZTE or ZTE

20
authorized service provider for replacement.
Limited Warranty
This warranty does not apply to defects or errors in the product
caused by:
i. Reasonable abrasion.
ii. End users’ failure to follow ZTE’s installation, operation or
maintenance instructions or procedures.
iii. End users’ mishandling, misuse, negligence, or improper
installation, disassembly, storage, servicing or operation of
the product.
iv. Modifications or repairs not provided by ZTE or a ZTE-
certified individual.
v. Power failures, surges, fire, flood, accidents, and actions of
third parties or other events outside ZTE’s reasonable
control.
vi. Usage of third-party products or usage in conjunction with
third-party products if such defects are due to the combined
usage.
vii. Any other cause beyond the range of normal usage
intended for the product.
End users have no right to reject or return theproduct, or receive
a refund for the product from ZTE under the above-mentioned
situations.
This warranty is end users’ sole remedy and ZTE’s sole liability
for defective or nonconforming items, and is in lieu of all other
warranties, expressed, implied or statutory, including but not
limited to the implied warranties of merchantability and fitness for
a particular purpose, unless otherwise required under the
mandatory provisions of the law.
Limitation of Liability
