User Guide
Mobile Hotspot

i
Welcome to AT&T
Thank you for purchasing the ZTE Mobley. To get the most from your
new device, check out our videos and interactive tutorials at
att.com/Tutorials.
Copyright © 2015 ZTE CORPORATION. All rights reserved. ZTE,
Mobley, and the ZTE logos are trademarks of the ZTE Corporation.
No part of this publication may be excerpted, reproduced, translated
or utilized in any form or by any means, electronic or mechanical,
including photocopying and microfilm, without the prior written
permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to
make modifications on print errors or update specifications without
prior notice.
Version No. : V1.0
Edition Time: August 2015

ii iii
Contents
Get Started...............................................................1
Know Your Device .....................................................1
Install Your Mobile Hotspot ...........................................3
Status LED Indicator ..................................................3
Connect to the Internet...............................................4
Manage Your Mobile Hotspot and Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connect Devices to Your Mobile Hotspot’s Wi-Fi®..................5
Use Your Mobile Hotspot ...............................................6
Lite AT&T Wi-Fi Manager Home Page.................................6
Full AT&T Wi-Fi Manager Home Page .................................7
Security Credentials...................................................8
Manage Wi-Fi ..........................................................9
Messages .............................................................14
Security ...............................................................15
Configure Data Network Options................................... 22
View Details .......................................................... 24
Replace the micro-SIM Card........................................26
Reset the Mobile Hotspot........................................... 27

iv 1
Advanced Settings ....................................................28
Manage Wi-Fi ........................................................28
Change Advanced Settings .........................................29
Troubleshooting .......................................................34
Problems and Suggested Solutions ................................34
Compatible Vehicles ................................................36
Working Voltage ..................................................... 37
Working State and Transition .......................................38
Specifications ........................................................39
Regulatory and Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
To the Owner.......................................................40
Using Your Device..................................................40
Radio Frequency (RF) Energy ..................................... 41
FCC Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Warranty..............................................................44
Consumer Limited Warranty ......................................44
Get Started
This chapter provides an overview of the features of your ZTE Mobley
Mobile Hotspot and instructions on how to set it up and connect to
the Internet.
Know Your Device
Your mobile hotspot enables you to create a Wi-Fi network in your
vehicle. You can use that Wi-Fi network to connect your smartphone
and other Wi-Fi-capable devices to your network provider’s mobile
broadband network and connect to the Internet.
OBD II interface
SIM card cover
LED 1 LED 2
Reset key

2 3
Additional features include:
• OBD II Interface — Connect with the On-Board Diagnostics
(OBD II) connector port on your vehicle to power on your mobile
hotspot. The OBD II connector port is usually located on or under
the dash, on the driver’s side. Other possible locations are the
center console area or inside the glove compartment.
• Reset Key — Restore the device to the factory default
configurations.
• Guest Wi-Fi – Set up a guest Wi-Fi network for temporary users, and
use the main network for trusted devices.
Install Your Mobile Hotspot
Make sure your vehicle is parked outside in a safe location and the
engine is turned off.
Insert your mobile hotspot into the OBD II connector port (or
into the extension cable if it is required). Ensure that your mobile
hotspot is inserted in the correct direction.
Note: Insert the mobile hotspot carefully to avoid damaging it.
Status LED Indicator
The LED indicates the device’s connection status:
LED 1
(Power)
Off Sleep mode (Wi-Fi off)
Green solid Power on
Red blinking Factory reset
Red solid SIM locked
LED 2
(Signal)
Off No network service available
Red solid FOTA updating
Green solid Connected to mobile network,
Wi-Fi network available
Red blinking FOTA update failure
Green blinking FOTA update success

4 5
Connect to the Internet
Start your mobile’s engine and let
it run for at least 30 seconds. Once
powered up, your mobile hotspot
automatically searches for and
connects to your network provider’s
mobile broadband network.
Connect your smartphone or
other Wi-Fi-enabled devices to
your network.
a) Use your normal Wi-Fi application
on the device to search for the
available wireless network.
b) Select the Wi-Fi network name.
c) Input the Wi-Fi network password
as it appears on the label on your
mobile hotspot.
Launch your browser to surf
the Internet.
Note: Once the vehicle’s engine has been off for half an hour, the
ZTE Mobley Mobile Hotspot will disconnect and enter Sleep mode.
Manage Your Mobile Hotspot and Settings
You can use the lite or full AT&T Wi-Fi Manager home page to
manage your mobile hotspot and change settings. In both cases,
log in as Administrator to make changes. The web address is
http://attwifimanager and the default Administrator login
is attadmin.
• To personalize the mobile hotspot and change basic settings, use
a smartphone to connect to the mobile hotspot and then use a
browser to display the lite AT&T Wi-Fi Manager home page.
• For advanced settings, use a Wi-Fi-enabled device such as a
laptop to connect to the mobile hotspot and then use a browser
to display the full AT&T Wi-Fi Manager home page.
Connect Devices to Your Mobile Hotspot’s Wi-Fi
You can connect up to five (5) wireless devices, such as smartphones,
laptops, tablets, digital cameras, printers, gaming consoles, and digital
picture frames, to your mobile hotspot’s Wi-Fi network(s). (See Set
Maximum Number of Connected Devices on page 11 for instructions
on setting connections for the Main Wi-Fi and Guest Wi-Fi networks.)
Connect a wireless device to your Wi-Fi network by typing the Wi-Fi
password.
Connect a Wireless Device Manually
To connect a wireless device to your mobile hotspot’s Wi-Fi network,
see Connect to the Internet on page 4.

6 7
Use Your Mobile Hotspot
This chapter describes the main features of the web interfaces
for managing your mobile hotspot. You must be logged in as
Administrator to change advanced settings and view detailed
information.
• Home page URL — http://attwifimanager
• Default Administrator login — attadmin
Lite AT&T Wi-Fi Manager Home Page
To log in as Administrator:
On the lite AT&T Wi-Fi Manager
home page, enter attadmin
in the Login field.
Tap Login.
Full AT&T Wi-Fi Manager Home Page
To log in as Administrator:
On the full AT&T Wi-Fi Manager home page, enter attadmin in the
Login field.
Click Login.

8 9
Security Credentials
The mobile hotspot uses three passwords:
• Wi-Fi password — Used to authenticate wireless devices to your
mobile hotspot network. It is unique to your mobile hotspot and can
be found printed on a label on the mobile hotspot. If you want to
change the Wi-Fi password, see Change Wi-Fi Network Names and
Passwords on page 15.
• Guest Wi-Fi password — When enabled, temporary users can
use this password to access the Guest Wi-Fi network. If you want
to change the Guest Wi-Fi password, see Change Wi-Fi Network
Names and Passwords on page 15.
• Admin login — Used to log in to the AT&T Wi-Fi Manager home
page as Administrator. You must be logged in as Administrator
to use certain features and to make changes to your mobile
hotspot settings. The default Administrator login is attadmin. The
Administrator login can be changed to 4 - 32 characters.
You can change these passwords on the lite or full AT&T Wi-Fi
Manager home page (http://attwifimanager).
Manage Wi-Fi
View Connected Devices
You can view a list of devices connected to your mobile hotspot on
the lite or full AT&T Wi-Fi Manager home page.
On the lite AT&T Wi-Fi Manager home page:
Log in as Administrator.
Tap Wi-Fi Settings.
A list of devices connected to the Main Wi-Fi and Guest Wi-Fi
networks appears in the Connected Devices section.

10 11
On the full AT&T Wi-Fi Manager home page:
Log in as Administrator.
Tap Connected Devices on the navigation menu on the left side.
A list of devices connected to the Main Wi-Fi and Guest Wi-Fi
networks appears on the screen. You can view the IP and MAC
addresses of the devices.
Set Maximum Number of Connected Devices
You can connect up to five (5) wireless devices to your mobile
hotspot. These connections are shared between the Wi-Fi’s Main and
Guest Wi-Fi networks. You can customize the distribution of devices
from the full AT&T Wi-Fi Manager home page.
On the full AT&T Wi-Fi Manager home page:
Log in as Administrator.
Click Home on the navigation menu on the left side.
In the Main and Guest Wi-Fi Max Devices section, select next
to Main Wi-Fi or Guest Wi-Fi to adjust the number of connections
available.
Click Apply.
Block/Unblock Devices
Whenever you block or unblock devices, the mobile hotspot resets to
activate the new settings. Any devices connected to the hotspot will
be disconnected.

12 13
You can block a device that is currently connected to your mobile
hotspot. It will not be able to connect to your Wi-Fi again unless you
choose to unblock it. Some reasons that you may want to block a
device include:
• Stopping them from overusing your bandwidth (and possibly
resulting in charges for overages on your plan).
• Temporarily blocking a child from surfing the Internet.
You can block/unblock devices from the full AT&T Wi-Fi Manager
home page.
On the full AT&T Wi-Fi Manager home page:
To block a connected device:
Log in as Administrator.
Click Connected Devices. A list of devices connected to the Main
Wi-Fi and Guest Wi-Fi networks appears on the screen.
To block a listed device from connecting to your mobile hotspot,
select the Block Access box for the device.
Click Apply.
To unblock a device:
Click Connected Devices on the navigation menu on the left side.
The Blocked Wi-Fi device(s) section lists all blocked devices.
To unblock a listed device so it can connect to your mobile
hotspot, select the Unblock Access box for the device and
click Apply.

14 15
Messages
View SMS Messages
You can view SMS messages on the lite or full AT&T Wi-Fi Manager
home page.
On the lite AT&T Wi-Fi Manager home page:
To view or delete messages:
Log in as Administrator.
Tap Messages.
A list of messages appears, previewing the first portion of the text.
Tap any message to read the full text.
If you want to delete the message, go to the bottom of the
message and tap Delete.
On the full AT&T Wi-Fi Manager home page:
To view or delete messages:
Log in as Administrator.
Click Messages on the navigation menu on the left side. A list of
messages appears.
Click any message in the list to read it.
If you want to delete the message, select the checkboxes in front
of the messages and click Delete.
Security
Change Wi-Fi Network Names and Passwords
You can customize the network names and passwords for the Main
and Guest Wi-Fi networks on the AT&T Wi-Fi Manager home page.
Change Main Wi-Fi Name and Password
You can change the Main Wi-Fi name or password from the lite or full
AT&T Wi-Fi Manager home page.
On the lite AT&T Wi-Fi Manager
home page:
Log in as Administrator.
Tap Wi-Fi Settings Wi-Fi Settings.
Change the Main Wi-Fi network name
and/or password.

16 17
On the full AT&T Wi-Fi Manager home page:
Log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Wi-Fi Basic.
Change the Main Wi-Fi network name and/or password.
Click Apply.
Note: If you change the Wi-Fi network name or password, all
connected devices will be disconnected and have to reconnect using
the new Wi-Fi credentials.
Change Guest Wi-Fi Name and Password
If you are using the Guest Wi-Fi profile, you can change the Guest
Wi-Fi name or password from the AT&T Wi-Fi Manager home page.
Note: By default, the Guest Wi-Fi name is the same as the Main Wi-Fi
name, with “-GUEST” appended.
On the full AT&T Wi-Fi Manager home page:
Log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Wi-Fi Basic.
Change the Guest Wi-Fi network name and/or password.
Click Apply.

18 19
Change AT&T Wi-Fi Manager Home Page Access Settings
You can customize the Administrator login used to access the lite or
full AT&T Wi-Fi Manager home page.
On the lite AT&T Wi-Fi Manager home page:
Log in as Administrator.
Tap Other Settings Login.
If desired, change the Administrator login (maximum 32
characters).
Tap Apply.
On the full AT&T Wi-Fi Manager home page:
Log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Advanced Administrator.
If desired, change the Administrator login (maximum 32
characters).
Click Apply.
Note: If you forget the Administrator login, you must perform a
hardware reset to restore the default. See Reset the Mobile Hotspot
on page 27.

20 21
Change Wi-Fi Security Types
You can set the mobile hotspot’s Wi-Fi security types in the lite or full
AT&T Wi-Fi Manager home page.
On the lite AT&T Wi-Fi Manager home page:
Log in as Administrator.
Tap Wi-Fi Settings Wi-Fi Settings.
Select the desired security types for the Main Wi-Fi network.
The Security Type options are:
• WPA2(AES)-PSK – Recommended. Other users can access your
mobile hotspot only if they enter the correct password (default).
Tap Apply.
Reconnect your Wi-Fi devices, if necessary, using the new Wi-Fi
credentials. See Connect to the Internet on page 4.
On the full AT&T Wi-Fi Manager home page:
Log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Wi-Fi Basic.
Select the desired security types for the Main Wi-Fi and Guest
Wi-Fi networks.
Click Apply.
Reconnect your Wi-Fi devices, if necessary, using the new Wi-Fi
credentials.

22 23
Configure Data Network Options
From the lite or full AT&T Wi-Fi Manager
home page, you can turn on mobile data
and choose whether to allow the mobile
hotspot to be used when roaming
internationally.
On the lite AT&T Wi-Fi Manager
home page:
Log in as Administrator.
Tap Connection Settings.
Choose the appropriate option:
• To enable/disable mobile data,
tap the On/Off button next to
Domestic Data.
• To enable/disable international
roaming, tap the On/Off button
next to International Data Roaming.
On the full AT&T Wi-Fi Manager home page:
Log in as Administrator.
Click Home on the navigation menu on the left side.
Choose the appropriate option:
• To enable/disable mobile data, select On or Off in the Domestic
Data section and click Apply.
• To enable/disable international roaming, select On or Off in the
International Data Roaming section and click Apply.

24 25
View Details
You can view details about your mobile hotspot, such as the wireless
number, data usage (not accurate for billing purposes) hardware
version, and IMEI, from the lite or full AT&T Wi-Fi Manager home page.
On the lite AT&T Wi-Fi Manager home page:
Log in as Administrator.
Tap Other Settings.
Tap About Your Mobile Hotspot.
Swipe the screen to scroll through the information.
On the full AT&T Wi-Fi Manager home page:
Log in as Administrator.
Click About on the navigation menu on the left side.
Tap to view
data usage
Tap to view
data usage

26 27
Replace the micro-SIM Card
Your mobile hotspot comes with the micro-SIM card inserted.
If you need to replace the micro-SIM card:
Insert your fingernail into the
slot of the micro-SIM card cover
and lift it up gently.
Remove the existing
micro-SIM card
(if present).
Insert the new micro-SIM
card with the gold-colored
contacts facing down.
Close the micro-SIM
card cover.
Reset the Mobile Hotspot
You can reset the mobile hotspot to its factory settings on the
mobile hotspot itself or on the full AT&T Wi-Fi Manager home page.
(This is useful if you have lost your Administrator login for the
AT&T Wi-Fi Manager home page.)
Notes:
• If you reset the modem to factory settings, all of your
customizations will be lost.
• When you reset the mobile hotspot, any currently connected
devices will lose access and will have to be reconnected after the
mobile hotspot restarts.
On the mobile hotspot:
Press and hold the Reset Key until the LED 1 indicator turns red
(about 7 seconds).
After the device has reset, reconnect Wi-Fi devices.
On the full AT&T Wi-Fi Manager home page:
Log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Advanced Device Reset.
Click Reset.

28 29
Advanced Settings
This chapter provides information on how to configure advanced
settings for various aspects of the device, such as Wi-Fi settings, WAN
settings, and router settings.
Manage Wi-Fi
Set Wi-Fi Network Options
To configure the Wi-Fi network options:
On the full AT&T Wi-Fi Manager home page, log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Wi-Fi Advanced Settings.
For the Main Wi-Fi and Guest Wi-Fi networks, select the desired
options.
• Network Mode – The WLAN protocol being used. The
recommended value depends on the band range selected:
– 802.11 b/g/n
– 802.11 n only
• Country/Region Code – Select region code.
• Frequency (Channel) – The Wi-Fi channel used. The
recommended value is Automatic, which chooses the
channel that will provide the least interference.
Click Apply.
Change Advanced Settings
View WAN Information
To view detailed network information, such as the active network,
connection status, and signal strength:
On the full AT&T Wi-Fi Manager home page, log in as Administrator.
Click About.
Enable Port Mapping
If your computer hosts a server, you can enable port mapping so that
other users can access the server.
To enable port mapping:
On the full AT&T Wi-Fi Manager home page, log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Firewall Port Mapping.
Select Enable beside Port Mapping Settings. The Port Mapping
list will appear. Incoming traffic is forwarded to specific ports and
devices on your network (using their local IP addresses).
Identify the ports to forward. Enter the port forwarding information
(the IP address, the Port range, the Protocol, and the comment).
Click Apply.
Caution: Port mapping creates a security risk. When not required,
port mapping should be disabled.

30 31
Enable MAC/IP/Port Filtering
You can enable or disable the MAC/IP/port filtering feature as
needed to block certain Internet traffic. If this setting is enabled,
you can then choose whether traffic is Accepted or Dropped by
default by selecting the appropriate option from the Default Policy
drop-down menu.
To enable port filtering:
On the full AT&T Wi-Fi Manager home page, log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Firewall MAC/IP/Port Filter.
Select the Default Policy:
• Accepted – Internet traffic is allowed by default. Only traffic from
the selected applications will be blocked from accessing the
Internet. Traffic is identified by port numbers. Some applications
are predefined. You can define additional applications by clicking
the Add Custom Application button, but you need to know
details of the traffic used and generated by the applications you
wish to define. In particular, you need to know the port numbers
and the protocol (TCP, UDP) used by outgoing traffic.
• Dropped – Internet traffic is blocked by default. Only traffic from
the selected predefined or custom applications are allowed to
access the Internet.
Click Apply.
Enable VPN Passthrough
If you want to connect to a corporate network using VPN, you first
need to enable VPN connections (passthrough).
To enable VPN passthrough:
On the full AT&T Wi-Fi Manager home page, log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Advanced Router.
In the VPN Passthrough section, select Enable beside VPN
Passthrough.
Click Apply.
Configure APN Details
The APN is checked to determine the type of network connection to
establish. Your mobile hotspot comes preconfigured with the APN
(Access Point Name) for AT&T.
To add an APN for another network:
On the full AT&T Wi-Fi Manager home page, log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Network APN.
Click Add.
In the blank line, enter the profile name, APN (obtained from your
carrier).
Select the network Authentication mode. The options are
None (default), CHAP, and PAP.

32 33
Enter the username and password, if these are required for the
wireless network.
Click Save.
To select the APN entry to use:
From the drop-down menu beside Profile Selection, select the
desired APN to use.
To remove an APN entry:
Select the APN you want to remove, and click Delete.
Enable DMZ
In a DMZ (demilitarized zone) network configuration, a computer runs
outside the firewall in the DMZ. This computer intercepts incoming
Internet traffic, providing an extra layer of protection for the rest of
the network.
To enable DMZ and designate a computer to screen incoming
traffic:
On the full AT&T Wi-Fi Manager home page, log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Firewall DMZ.
Select Enable beside DMZ.
In the DMZ IP Address field, enter the IP address of the computer
you want to have in the DMZ.
Click Apply.
Set Router Options
To set the mobile hotspot’s LAN options:
On the full AT&T Wi-Fi Manager home page, log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Advanced Router.
Enter the desired information in each section.
If the DHCP Server is enabled, it automatically assigns an IP address
to each device on the network and manages their configuration
information.
Click Apply.
Set Power Save Options
The user may define a time period for the mobile hotspot to stay
on when the vehicle is turned off or idle. Starting the vehicle will
always power on the hotspot. The mobile hotspot will power off
automatically if the voltage of the OBD II connector drops to 9V.
On the AT&T Wi-Fi Manager home page, log in as Administrator.
Click Settings on the navigation menu on the left side.
Click Advanced Power Save.
Select the time period from the drop-down menu.
