Zundapp Z801 User manual

Operating manual
Zündapp Z801
Mountain bike -
with electric motor / 250 W rated power
Translation of the original operating manual

Operating Manual –Mountain bike with electric motor / 250 W rated power
05.08.2021 REV 1.1
2
Contents
1. Unpacking and assembly................................................................................................................. 7
2. Notes on the manual and the manufacturer .................................................................................. 8
Keep the manual available for reference at all times. ............................................................ 8
Orthographic features in the text ........................................................................................... 8
Orthographic features in illustrations..................................................................................... 8
Further applicable documents ................................................................................................ 8
Copyright................................................................................................................................. 8
Manufacturer’s contact data................................................................................................... 8
3. Statutory warranty and warranty claims ........................................................................................ 9
Explanation of the statutory warranty.................................................................................... 9
Explanation of guarantee ........................................................................................................ 9
Manufacturer's guarantee ...................................................................................................... 9
Information about the guarantor.......................................................................................... 10
Consequences of warranty claims......................................................................................... 10
Service and preventive maintenance.................................................................................... 10
4. Theft prevention............................................................................................................................ 11
5. Performance tuning forbidden...................................................................................................... 11
6. Recommendation for insurance cover.......................................................................................... 11
7. Safety............................................................................................................................................. 12
Intended use.......................................................................................................................... 12
Unauthorised modifications forbidden................................................................................. 12
Attachment of luggage racks and/or trailers ........................................................................ 13
Minimum age ........................................................................................................................ 13
Personal qualifications .......................................................................................................... 13
Personal protective equipment............................................................................................. 13
Orthographic features of warnings ....................................................................................... 14
Orthographic features of warnings of material damage....................................................... 14
Orthographic features of tips................................................................................................ 14
Basic safety instructions........................................................................................................ 15
Permissible total payload...................................................................................................... 15
Stability (kick stand) .............................................................................................................. 15
Wear a helmet....................................................................................................................... 15
Avoid serious injuries or death due to mechanical defects and improper use of the bike .. 15
Avoid electric shocks or explosions due to improper handling of the battery and charger. 16

Operating Manual –Mountain bike with electric motor up to 250 W
25.08.2021 REV 1.1
3
Avoid fire or explosion hazards............................................................................................. 16
Avoid serious injuries due to contact of body parts with the components of the bike........ 17
Avoid serious injuries caused by damaged components ...................................................... 17
Avoid serious injuries or death in wet weather.................................................................... 17
Avoid serious injuries or death in twilight or at night........................................................... 18
Avoid serious injuries or death caused by damaged, bent or loose reflectors and lights .... 18
Avoid serious injuries caused by riding off-road or over kerbs............................................. 18
Avoid serious injuries or death due to replacing components or adding accessories.......... 19
Avoid serious injury due to inadequate maintenance, cleaning and care............................ 19
Avoid burns............................................................................................................................ 19
Avoid injuries to your legs..................................................................................................... 20
Avoid vibrations..................................................................................................................... 20
Vibration................................................................................................................................ 20
Noise...................................................................................................................................... 20
Avoid illnesses ....................................................................................................................... 20
Avoid dehydration from cycling ............................................................................................ 20
Avoid frostbite....................................................................................................................... 21
Avoid falls due to sudden engagement of the electric motor assistance............................. 21
Avoid pollution ...................................................................................................................... 21
Avoid explosions.................................................................................................................... 21
Avoid material damage ......................................................................................................... 21
8. Safety instructions and general information on the battery ........................................................ 22
9. Description .................................................................................................................................... 23
Assembly ............................................................................................................................... 23
Position of the type plate...................................................................................................... 24
Technical description............................................................................................................. 24
Important note on electrical attachments............................................................................ 24
Scope of supply ..................................................................................................................... 25
Pedal assistance..................................................................................................................... 25
Electric motor........................................................................................................................ 25
Battery................................................................................................................................... 25
Controller............................................................................................................................... 25
Suspension............................................................................................................................. 25
Brakes.................................................................................................................................... 25
Disc brakes............................................................................................................................. 26

Operating Manual –Mountain bike with electric motor / 250 W rated power
05.08.2021 REV 1.1
4
Brake force fine adjustment.................................................................................................. 27
Gear shift............................................................................................................................... 27
Pedals .................................................................................................................................... 28
10. Unpacking and checking delivery.............................................................................................. 28
11. Assembling components of the bike......................................................................................... 29
Check the quick release on the front wheel.......................................................................... 29
Installing and turning the handlebars ................................................................................... 30
Adjusting the saddle.............................................................................................................. 31
Saddle height......................................................................................................................... 31
Saddle position...................................................................................................................... 33
Fitting the pedals................................................................................................................... 34
12. Before riding the bike for the first time .................................................................................... 35
Checking the screw connections........................................................................................... 35
Checking the chain tension ................................................................................................... 36
Highest chain tension............................................................................................................ 36
Lowest chain tension............................................................................................................. 36
Check the size of the bike...................................................................................................... 37
Charging the battery.............................................................................................................. 38
Charging with battery on bike............................................................................................... 38
Charging with battery removed from bike............................................................................ 38
Adjusting the spring rate at the suspension forks................................................................. 39
Checking the tyre pressure.................................................................................................... 40
13. Using the bike............................................................................................................................ 41
Installing and removing the battery...................................................................................... 41
Removing the battery............................................................................................................ 41
Installing the battery ............................................................................................................. 41
Actuating the brakes ............................................................................................................. 42
Operating the gears............................................................................................................... 43
Actuating the rear derailleur................................................................................................. 43
Actuating the front derailleur ............................................................................................... 44
14. Controlling the pedal assistance ............................................................................................... 45
Control unit –overview and functions.................................................................................. 45
Display functions and key functions...................................................................................... 46
Switching on and off.............................................................................................................. 47
Speed display......................................................................................................................... 47

Operating Manual –Mountain bike with electric motor up to 250 W
25.08.2021 REV 1.1
5
Distance display..................................................................................................................... 47
Resetting the trip meter........................................................................................................ 47
Switching the display background lighting on and off .......................................................... 48
Selecting the assistance level................................................................................................ 48
Pushing and starting aid........................................................................................................ 49
Battery and charge capacity indicator................................................................................... 50
Error code information.......................................................................................................... 51
15. Basic settings............................................................................................................................. 52
Setting of the tyre diameter.................................................................................................. 52
Background lighting –setting the intensity........................................................................... 52
16. Li ion battery: Questions / answers / tips ................................................................................. 52
What is the optimum temperature for my battery?............................................................. 52
How does the battery power change if it gets too hot or too cold?..................................... 52
At what temperatures may a battery be operated?............................................................. 52
At what temperatures may a battery be charged?............................................................... 53
How should my battery be stored?....................................................................................... 53
Should I leave the battery on the bike during prolonged storage? ...................................... 53
What does self-discharge mean? .......................................................................................... 53
What does deep discharge mean?........................................................................................ 53
What is the service life of my battery? ................................................................................. 53
Can I generally allow my battery to charge over night? ....................................................... 53
17. Riding your bike......................................................................................................................... 53
Tips for safe riding................................................................................................................. 54
Riding with pedal assistance ................................................................................................. 55
Riding without pedal assistance............................................................................................ 56
Foot position on the pedals................................................................................................... 56
18. Troubleshooting ........................................................................................................................ 57
19. Frequently asked questions (FAQ) ............................................................................................ 59
How far can I travel with a fully charged battery?................................................................ 59
General questions ................................................................................................................. 60
Questions about guarantee and warranty ............................................................................ 61
Technical questions............................................................................................................... 61
20. Transporting your bike .............................................................................................................. 63
21. Care and maintenance of your bike.......................................................................................... 63
Care of the battery ................................................................................................................ 63

Operating Manual –Mountain bike with electric motor / 250 W rated power
05.08.2021 REV 1.1
6
Care of the electric motor and controller ............................................................................. 64
Setting and adjusting the rear derailleur .............................................................................. 64
Adjusting the stops................................................................................................................ 65
Setting and adjusting the front derailleur............................................................................. 66
Maintenance intervals........................................................................................................... 67
Service booklet...................................................................................................................... 69
22. Disposal of the bike ................................................................................................................... 72
23. Bike passport............................................................................................................................. 73
24. Service and contact ................................................................................................................... 74
25. EC Declaration of Conformity.................................................................................................... 75
26. Important information for sending back your E-bike................................................................ 76
27. Important information for sending back a battery ................................................................... 77
28. Transport document for hazardous goods (battery)................................................................. 78

Operating Manual –Mountain bike with electric motor up to 250 W
25.08.2021 REV 1.1
7
1. Unpacking and assembly
I M P O R T A N T
The first charge is crucial!
Please fully charge the battery before using your bike for the
first time!
Dear Customer, Please note that your bike is delivered to you 98% pre-assembled. As a rule, the fol-
lowing activities remain to be carried by you after unpacking the bike:
-Check the scope of supply (see: 10 Unpacking and checking delivery on p. 28)
-Charge the battery (see: 12 Before riding the bike for the first time / Charging the battery on
p. 38)
-Fit the pedals (see: 11 Assembling components of the bike / Fitting the pedals on p. 34)
-Adjust the handlebars (see: 11 Assembling components of the bike / Installing and turning
the handlebars on p. 30)
-Adjust the saddle (see: 11 Assembling components of the bike / Adjusting the saddle on p.
31)
-Check the proper function of all the brakes (see: 13 Using the bike / Actuating the brakes on
p. 42)
-Check the function of the derailleur (see: 13 Using the bike / Operating the gears on p. 43)
and possibly after adjustment or fine adjustment of the derailleur (see: 13 Using the bike / 21
Care and maintenance of your bike / Setting and adjusting the rear derailleur on p. 64 and 21
Care and maintenance of your bike / Setting and adjusting the front derailleur on p. 66)
-Check all components and bolt connections for proper installation and tightness.
An informative and practical assembly video can be found under the following QR code:

Operating Manual –Mountain bike with electric motor / 250 W rated power
05.08.2021 REV 1.1
8
2. Notes on the manual and the manufacturer
This manual is intended to help you use you to use the electric mountain bike safely. These e-bikes
are referred to in the further course of this manual as “bike” for short. This manual has been pre-
pared in accordance with IEC 82079-1 (Preparation of instructions for use. Structuring, content and
presentation).
Keep the manual available for reference at all times.
This manual forms an integral part of the bike.
-Always keep this manual together with the bike.
-Ensure that the manual is readily available to the user.
-Include this manual if you sell or otherwise pass on the bike.
Orthographic features in the text
Various elements in this manual are highlighted with defined orthographic features. The following
elements can thus be easily distinguished:
Normal text
-Work steps
-Enumeration
Orthographic features in illustrations
If reference is made to elements in a legend or in the running text, these are indicated with a num-
ber.
Further applicable documents
Further details, instructions and information on the components of the bike can also be found in the
documentation from the respective manufacturers. These documents form an integral part of this
manual. Keep these documents together with this manual. Hand over these documents if you sell or
otherwise pass on the bike. Risk of injury due to failure to observe the further applicable documents.
-Read and follow all the further applicable documents before using the bike. Further applicable docu-
ments include, in particular, the following document types:
-Operating instructions
-Assembly instructions
-Declarations of conformity or declarations of incorporation
Copyright
This manual contains information that is subject to copyright. This manual may not be copied,
printed, filmed, processed, reproduced or distributed in any way or form, either in whole or in part,
without the prior written approval of Pentagon Sales GmbH. © Pentagon Sales GmbH 2021 - All
rights reserved.
Manufacturer’s contact data
Pentagon Sales GmbH
Lindenstraße 31 - 33
73479 Ellwangen (Jagst)
Germany
www.pentagonsales.de

Operating Manual –Mountain bike with electric motor up to 250 W
25.08.2021 REV 1.1
9
3. Statutory warranty and warranty claims
Explanation of the statutory warranty
The manufacturer grants a 24-month warranty (“liability for defects”) on new goods (§ 439 and 476
German Civil Code (BGB)).
The warranty covers defects already inherent in the product at the time of purchase. If you discover
a defect, you can demand that the manufacturer repair or otherwise rectify the product.
If the seller is of the opinion that the defect only arose after the purchase, he must prove this during
the first six months. After six months, however, the burden of proof is reversed. Then the buyer has
to prove that the defect already existed at the time of purchase.
Explanation of guarantee
The guarantee is granted on a voluntary basis by the manufacturer (manufacturer's guarantee). The
duration and conditions of the guarantee can be freely determined by the manufacturer.
Manufacturer's guarantee
The manufacturer grants a guarantee of 2 years on frame breakage and 6 months on the entire bike
and its attachments. This guarantee does not cover parts subject to wear, e.g. chains, pedals,
toothed belts, tyres, wheel rims, inner tubes, bearings, gear shift mechanism, brake pads, chain
sprockets, pinions, bottom bracket, gear shift and brake cables as well as paintwork and stickers. The
warranty does not cover damage caused by failure to observe the assembly instructions or by im-
proper use (jumps, stunts, tricks, wheelies, downhill). The bike is intended exclusively for private use.
Damage caused by rental, leasing or participation in competitions is fully excluded from the war-
ranty. Repairs, conversions or other modifications to this bike carried out independently and without
consulting the manufacturer will void the warranty. The warranty will also be voided if the mainte-
nance intervals prescribed in this manual are not observed and a thorough inspection of your bike is
not carried out at least once or twice a year.
The original proof of purchase must be kept together with the service booklet in order to substanti-
ate warranty claims. With the purchase, the guarantee terms are accepted in full and without qualifi-
cation.
The following conditions apply:
-No guarantee in the case of accident damage
-No guarantee in the case of improper use
-No guarantee in the case of use for purposes other than the intended use
-No guarantee in the case of damage resulting from improper assembly
-No guarantee if the inspection and maintenance intervals are not been observed
-No guarantee in the case of loss of parts and attachments

Operating Manual –Mountain bike with electric motor / 250 W rated power
05.08.2021 REV 1.1
10
The wear parts that the manufacturer excludes from the guarantee include the following:
-Brake pads and brake discs, and wheel rims if the system is a rim brake system
-The complete drive train including rear derailleur, front derailleur, crankset and chain
Information about the guarantor
Pentagon Sales GmbH
Lindenstraße 31 –33
73479 Ellwangen (Jagst)
Germany
www.pentagonsales.de
Consequences of warranty claims
If a warranty claim occurs within 14 days, the customer has the right to return the product free of
charge for a full refund of the purchase price. Optionally, the customer is entitled to a remedy of the
defect in the form of a repair or a replacement of the defective component.
After the expiry of these 14 days but still within the first 6 months from the date of purchase, the
customer is entitled to a remedy of the defect in the form of a repair or a replacement of the defec-
tive component.
Service and preventive maintenance
Please note that you are only entitled to the manufacturer's warranty if you
observe the service intervals and have the preventive maintenance carried
out.
The customer is responsible for observing the service intervals and having the preventive mainte-
nance carried out (see 21 Unpacking and assembly on p. 7).
Any service and maintenance work must be carried out by a suitably qualified person. Please have all
service and maintenance work documented with signature in your service booklet that you will find
under 21 Care and maintenance of your bike / Service booklet on p. 69.
On a pedelec, the service must be carried out at least once a year.
-First service: After the first 350 km or after the first three months
-Second service: After the first 800 km or after the first six months
-Thereafter: Once a year for a complete check-up

Operating Manual –Mountain bike with electric motor up to 250 W
25.08.2021 REV 1.1
11
4. Theft prevention
I M P O R T A N T
The frame number is not filed by us together with the
buyer’s purchase order.
Record the frame number in your bike passport or on
your invoice and register your bike with the police free of
charge!
-Use a suitable bike lock to protect your bike from theft.
-If possible, park your bike only in designated areas, preferably in heavily frequented areas.
-Register your bike with the frame number free of charge with the police. For this, fill in your
bike passport that you will find on p. 73 of this operating manual.
-As a precaution, check whether your household insurance covers the theft of pedelecs, and
what the conditions for this are..
5. Performance tuning forbidden
F O R B I D D E N
Modifications and/or performance tuning are strictly
prohibited!
In the event of an accident/damage (without insurance
cover), the rider is liable with his entire private assets!
Performance optimisation (tuning) of EPACs is illegal. According to the German Road Traffic Licensing
Regulations (StVZO), an EPAC whose motor accelerates the bike to more than the permitted 25 km/h
is considered a motor vehicle. This requires an insurance number plate, an operating permit (ABE)
and a corresponding driving licence (driving licence class AM or class B).
The EPACs sold by the manufacturer do not have an operating permit as is the case, for example,
with S-pedelecs. Performance optimisation thus has the following consequences for you:
-Tuning is considered a significant modification of the EPAC.
-The manufacturer's declaration of conformity is voided.
-No warranty or defect liability claims can be made.
-Riding without an operating permit can result in a fine.
6. Recommendation for insurance cover
The manufacturer recommends taking out private liability insurance for riding an EPAC!

Operating Manual –Mountain bike with electric motor / 250 W rated power
05.08.2021 REV 1.1
12
7. Safety
Intended use
N O T E
The intended use also implies reading and understanding the operat-
ing manual!
Bicycles are used to transport a single person. Because the necessary safety equipment according to
StVZO is not included in the scope of delivery, your bike is not intended for use on public roads.
Simple forest and dirt roads can be driven with the technical equipment without further ado. Your
bike is not intended for:
-Jumps
-Wheelies
-Stunts
-Downhill
-Riding down steps
-Riding through deep water
-Participation in sporting events
The intended use also implies observing the recommended maintenance intervals and reading and
understanding this manual.
Unauthorised modifications forbidden
F O R B I D D E N
Modifications (like mounting a child seat, carrier or a bicycle trailer)
are permitted only with the consent of the manufacturer! Modifica-
tions not approved by the manufacturer will void the declaration of
conformity.
Unauthorised modifications or changes to the bike can result in serious injuries and voiding of the
guarantee. This applies in particular to manipulating and modifying the electric motor and control
unit.
Never modify the control unit or the electric motor.

Operating Manual –Mountain bike with electric motor up to 250 W
25.08.2021 REV 1.1
13
Attachment of luggage racks and/or trailers
The attachment of other of further luggage racks and/or trailer couplings is only permitted by agree-
ment with the manufacturer.
Unauthorised modifications or attachments of load carriers of any kind without the consent of the
manufacturer will void the declaration of conformity supplied and the entire risk must be borne by
the user.
Minimum age
From a legal point of view, there is no minimum age for the use of an EPAC. We recommend, how-
ever, that it should be used only by persons over the age of 14.
Personal qualifications
This manual is intended for instructed riders. The rider should have the following know-how and ex-
perience:
-The rider has been instructed in the use of the bike by a dealer
-The rider knows that improper use of the bike can result in accidents
-The rider can use the bike in accordance with this manual
Personal protective equipment
Riding a bike can result in serious injuries or even death.
-When riding, always wear an approved helmet and follow the manufacturer's instructions in
the respective manual for adjustment, use and care of the helmet.
-Always wear sturdy shoes with a non-slip sole (e.g. profiled rubber sole).
-The wearing of gloves is recommended.
-Always wear tight-fitting clothing to avoid getting tangled up in the bike or objects on the
side of the road or track.
-Always wear goggles (clear) to protect the eyes from dirt, dust and insects.
-Always wear tinted goggles in sunshine.

Operating Manual –Mountain bike with electric motor / 250 W rated power
05.08.2021 REV 1.1
14
Orthographic features of warnings
The following types of warning can be found in this manual:
W A R N I N G
Texts introduced with the word WARNING warn of a
hazardous situation that could result in serious injury
or even death.
C A U T I O N
Texts introduced with the word CAUTION warn of a
situation that could result in minor to moderate
injuries.
Orthographic features of warnings of material damage
W A R N I N G
These texts warn of a situation that could result in material
damage.
Orthographic features of tips
Tips contain additional information.

Operating Manual –Mountain bike with electric motor up to 250 W
25.08.2021 REV 1.1
15
Basic safety instructions
Permissible total payload
Your bike is for a total payload of 120kg designed. The total pay-
load includes the empty weight of the bike including the battery
(this is 22.7kg), the driver and additional luggage. Do not exceed
the total permissible payload. This can lead to damage to me-
chanical components such as the frame or suspension fork and
represents a considerable security risk!
Stability (kick stand)
The kick stand on your bike is only designed for the empty weight including the battery.
Never sit on your bike with the kick stand down. In the worst case, this could lead to a break in the
side stand and serious injuries from the bike falling over!
Wear a helmet
We recommend that you always wear a suitable bicycle helmet when riding. The right fit and the
right size of helmet is crucial!
Avoid serious injuries or death due to mechanical defects and improper use of the bike
Riding a bike can result in serious injury or death due to a mechanical defect or improper use of the
bike.
-Always carry out a safety check (see section Riding your bike) before riding your bike.
-Familiarise yourself with the brakes, pedals and gears before riding.
-Always ride at a speed appropriate to the riding conditions.

Operating Manual –Mountain bike with electric motor / 250 W rated power
05.08.2021 REV 1.1
16
Avoid electric shocks or explosions due to improper handling of the battery and charger.
F O R B I D D E N
Never open the electric motor,
battery and other components!
Improper handling of the battery and charger can result in an electric shock or explosion. This may
cause serious injury or even death.
-Use only the battery included in the scope of supply.
-Never connect the positive terminal to the negative terminal of the battery.
-Protect the battery from direct sunlight.
-Do not dismantle the battery.
-Use only the charger included in the scope of supply to charge the battery.
-Use the charger only indoors.
-The plug of the charger is the disconnection device from the electrical mains. Ensure that the
plug socket is located near the charger and is easily accessible.
-Connect the charger only to a grounded 230 V mains plug socket.
-Keep the metal contacts clean; clean them with a soft and dry cloth, if necessary.
-Do not charge a battery with visible damage, e.g. a broken battery casing.
-Do not use a battery with visible damage, e.g. a broken battery casing.
-Do not drop the battery.
-Charge the battery in a temperature range between 10° and 30°C.
-Ensure that the charger is used only by persons who do not have limited physical, sensory or
mental abilities.
Avoid fire or explosion hazards
F O R B I D D E N
Cleaning your bike and its components
Never clean your bike with a water hose, high-pressure or
steam cleaner!
Moisture, electrically conductive soiling or mechanical damage can cause a short circuit. This could
lead to a fire or explosion of the battery.
-Clean the electric motor and the controller only from the outside with a damp sponge. Never
use a high-pressure cleaner.
-If these components are accidentally completely immersed in water, disconnect the motor
from the battery immediately and do not use it again until it has been inspected by the man-
ufacturer.

Operating Manual –Mountain bike with electric motor up to 250 W
25.08.2021 REV 1.1
17
Avoid serious injuries due to contact of body parts with the components of the bike
C A U T I O N
Risk of injury from reaching into the
drive chain.
Never reach into the drive chain while riding.
When riding, parts of the body or other objects may come into contact with the sharp teeth of the
sprockets, the moving chain, the rotating pedals and cranks and the rotating wheels of the bike. This
can lead to serious injuries.
-Take care when riding that parts of your body do not come into contact with these compo-
nents of the bike.
Avoid serious injuries caused by damaged components
When riding off-road or over kerbs, the electric motor, cranks or bottom bracket may touch the
ground and be damaged. This can lead to serious injuries.
-Use the bike only on the approved surfaces.
-If you encounter obstacles, dismount and lift the bike over the obstacle.
-In the event of damage, have the bike inspected by a dealer.
Avoid serious injuries or death in wet weather
C A U T I O N
Wet and/or slippery roads and paths influence the road grip and
braking behaviour!
Wet weather affects road grip, braking behaviour and visibility for both cyclists and all other road us-
ers. In wet weather, the stopping power of your brakes (as well as the brakes of all other road users)
is significantly reduced. In addition, the tread pattern does not grip nearly as well as on dry roads.
This makes speed control more difficult and increases the risk of losing control over the bike. This
may cause serious injuries or even death.
-Always ride slowly in wet weather.
-Always brake carefully and with foresight in wet weather.
-Switch off the electric motor or ride carefully with minimum motor assistance.

Operating Manual –Mountain bike with electric motor / 250 W rated power
05.08.2021 REV 1.1
18
Avoid serious injuries or death in twilight or at night
N O T E
We generally recommend riding with your lights on even during
the day.
Riding with lights is crucial
in twilight or at night!
Riding in twilight or at night is more dangerous than during the day. A cyclist is very difficult to recog-
nise for other road users and this can result in serious injuries or even death.
-Avoid riding in twilight or at night, if possible.
-Always ride slowly.
-Always ride with bike lights and reflectors.
-Always avoid dark areas and areas with heavy or fast traffic.
-Always avoid road obstacles.
-Ride on familiar routes, if possible.
Avoid serious injuries or death caused by damaged, bent or loose reflectors and lights
Bike reflectors catch the light from street lamps and car headlights and reflect it so that you can be
recognised as a cyclist. Damaged, bent or loose reflectors can result in you being poorly recognised
by other road users. This may cause serious injuries or even death.
-Check your reflectors and their secure attachment at regular intervals.
-Have damaged, bent or loose reflectors replaced by your dealer.
Avoid serious injuries caused by riding off-road or over kerbs
C A U T I O N
Risk of falling when riding on uneven terrain!
Riding off-road or over kerbs at inappropriate speeds can cause you to fall. This may cause serious
injury or even death.
-Always ride at a speed appropriate to the riding conditions.

Operating Manual –Mountain bike with electric motor up to 250 W
25.08.2021 REV 1.1
19
Avoid serious injuries or death due to replacing components or adding accessories
Numerous components and accessories are available that can improve the comfort, performance
and appearance of your bike. You add components or accessories at your own risk. It is possible that
these components or accessories have not been tested for compatibility, reliability or safety by the
bike manufacturer. Unconfirmed compatibility, reliability or safety and improper installation, use and
maintenance of bike components or accessories can lead to serious injuries or even death.
-Always consult your dealer before installing, using and maintaining the component.
-Always read and follow the instructions for use supplied with the accessories.
Avoid serious injury due to inadequate maintenance, cleaning and care
Improper maintenance, care and cleaning can result in injuries or even death.
-Carry out only the activities listed in the maintenance plan.
-Use only use commercially available lubricants and
cleaning agents.
-Have other maintenance work and repairs carried out
by a qualified dealer.
Avoid burns
C A U T I O N
Risk of burns on hot surfaces!
Bike components (e.g. brakes, wheels, etc.) can get hot while riding. Touching these components can
result in burns.
-Allow hot components to cool down before working on them or wear heat-resistant protec-
tive gloves.

Operating Manual –Mountain bike with electric motor / 250 W rated power
05.08.2021 REV 1.1
20
Avoid injuries to your legs
Injuries to your legs can occur if the pedal spacing (Q-fac-
tor) is too small or too large. There is a risk that riders will
have problems with the crankset installed.
Should riding feel uncomfortable due to the pedal spacing,
seek advice from the manufacturer and have your crankset
changed, if necessary.
Avoid vibrations
Incorrect installation, wear and overloading (e.g. electric motor touching the ground when riding
over bumps or kerbs) or loose parts can cause the electric motor to no longer run smoothly.
-Use the bike only on approved surfaces.
-Check the drive unit for backlash-free and smooth running before every trip.
-If you hear grating or grinding noises or discover obvious signs of
damage, contact a dealer and have the bike repaired. Using the bike on the road or off-road causes
vibrations to be transmitted from the ground to your body.
-Use the bike only on approved surfaces.
Vibration
When used for the intended purpose, the values of 2.5 m/s² for the hand/arm system and 0.5 m/s²
for the whole body are not exceeded.
If you feel unwell due to extreme vibrations caused by changing ground, adapt your speed accord-
ingly and use the function of the suspension forks!
Noise
The A-weighted emission sound pressure level does not exceed 70 dB(A).
Avoid illnesses
Long and frequent sitting on the saddle may lead to prostate disease in men.
-If necessary, fit a saddle suitable for female/male ergonomics.
-Go to medical check-ups, if necessary.
Avoid dehydration from cycling
Cycling is a strenuous physical activity.
-Ensure an adequate supply of fluids at all times.
