Zycoo SC10 User manual

Contents
Overview ............................................................................................................ 1
Product Overview............................................................................................ 1
Product Specifications .................................................................................... 1
Basic Settings ..................................................................................................... 3
Web Interface Login........................................................................................ 3
Device Info ...................................................................................................... 4
SIP Account..................................................................................................... 6
P2P Account .................................................................................................... 8
Audio Codecs................................................................................................... 9
Advance SIP Settings ....................................................................................... 9
Advanced Settings ............................................................................................ 10
Volume.......................................................................................................... 10
I/O Settings .................................................................................................... 11
API Settings....................................................................................................13
Multicast ....................................................................................................... 14
Prompt Language ...........................................................................................15
Audio Files .....................................................................................................15
System Settings ................................................................................................ 16
Network ........................................................................................................ 16
Time...............................................................................................................17
Account ..........................................................................................................17
Upgrade ........................................................................................................ 18
Reboot & Reset .............................................................................................. 19
Maintenance Settings....................................................................................... 19

Diagnostic ..................................................................................................... 19
Ethernet Capture........................................................................................... 20
Import/Export .............................................................................................. 20
Auto Provisioning ..........................................................................................21
Test ............................................................................................................... 22

Overview
Product Overview
ZYCOO network speakers are SIP enabled high-performance speaker products that can be
used for SIP paging, notification/tone broadcast and streaming media music playback.
The SC10, SC15 network ceiling speaker and SW15 network cabinet speaker are equipped with
dual speaker drive units, the high-efficient, full-range speaker drive units can provide a
uniquely advanced listening experience, which makes the SC10, SC15 and SW15 suitable for
high-quality music, notification/tone broadcasting in the indoor environment.
The SH30 network horn speaker is equipped with a midrange drive unit powered by a 30W
class D amplifier, which makes it suitable for paging and notification/tone broadcasting to
noisy large spaces and outdoor environments. On the other hand, the SL30 Network Column
Speaker is PoE+ supported, while the SL50 Network Column Speaker is 4G wireless
compatible. SL30 and SL50 could cover a wide frequency band to provide high sensitivity,
beautiful sound, and a unique listening experience for listeners. As well as the IP65-Enclosure
makes the SL30 and SL50 perfect to work in any outdoor environment.
Product Specifications
SC10 Specifications
Speaker Components:
4" woofer unit + 1" tweeter unit
Sensitivity
90dB/1m/1W
Max Sound Pressure
Level
100dB
Amplifier
Built-in Class D Amplifier
Rated Power
8Ω 10W
Frequency Range
70Hz~20KHz
Coverage Pattern
90°H 90°V 30 m²
Acoustics
Mono
SC15 Specifications
Speaker Components:
5.25" woofer unit + 1" tweeter
unit
Sensitivity
85dB/1m/1W
Max Sound Pressure
Level
100dB

Amplifier
Built-in Class D Amplifier
Rated Power
8Ω 15W
Frequency Range
70Hz~20KHz
Coverage Pattern
90°H 90°V 30 m²
Acoustics
Mono
SW15 Specifications
Speaker Components:
5.25" woofer unit + 1.5" tweeter
unit
Sensitivity:
85dB/1m/1W
Max Sound Pressure
Level
100dB
Amplifier
Built-in Class D Amplifier
Rated Power
8Ω 15W
Frequency Range
70Hz~20KHz
Coverage Pattern
90°H 50°V 30 m²
Acoustics
Mono
SH30 Specifications
Speaker Components
2" midrange driver unit
Sensitivity
105dB/1m/1W
Max Sound Pressure
Level
117dB
Amplifier
Built-in Class D Amplifier
Rated Power:
8Ω 30W
Frequency Range:
400Hz~8KHz
Coverage Pattern:
50°H 50°V 70m effective distance
Acoustics:
Mono
IP Rating
IP65

SL30 Specifications
Speaker Components
2 * 3.25'' woofer units + 1 * 1''
tweeter unit
Sensitivity
82dB/1m/1W
Max Sound Pressure
Level
97dB
Amplifier
Built-in Class D Amplifier
Rated Power:
4Ω 30W
Frequency Range:
100Hz~20KHz
Coverage Pattern:
135°, best effective distance 50m
Acoustics:
Mono
SL50 Specifications
Speaker Components
4 * 3.25'' woofer units + 1 * 25ø
tweet unit
Sensitivity
85dB/1m/1W
Max Sound Pressure
Level
105dB
Amplifier
Built-in Class D Amplifier
Rated Power:
8Ω 50W
Frequency Range:
100Hz~20KHz
Coverage Pattern:
135° 50m, max effective distance
70m
Acoustics:
Mono
IP Rating
IP65
Basic Settings
Web Interface Login
By default, the network speaker’s IP assignment has been configured as DHCP. Please ensure
there’s a DHCP server available in the LAN where the network speakers are installed. If
there’s no DHCP server available or DHCP fails, you’ll have to use the failover IP address
192.168.1.101 to access the web management interface. Press and hold the RST button for 5
seconds (10 seconds for reset) and release, the speaker will announce its IP address. Input the
IP address in the browser address bar to open the web management interface of the speaker.
The login screen is shown as below image, here we take one SC15 network ceiling speaker as
an example.

Use the default login credentials to login to the web management interface.
Default username: admin
Default password: admin
For the safety of the network speakers, it is recommended to change the default password on
the first login, please go to Settings -> Change Password page to change the password.
Device Info
After login, you’ll first see the Device Info screen.

SIP Status
• SIP Account: The SIP number configured on this device.
• SIP Server: The SIP server (ZYCOO IP Audio Center or other IP PBX) address.
• Register Status: The SIP number registration status.
Device Information
• Device Model: The speaker model, SC10, SC15, SW15, etc.
• Hardware Version: Speaker hardware version.
• Software Version: Speaker software version, can be upgraded.
• Uptime: Last startup time of the device.
• Speaker Volume: The current volume level of the speaker device.
• Mic Volume: The current volume level of the microphone.
• Device Description: The device description will be used to display the tab name of
the web browser. This is useful when configuring multiple speaker devices using the same
web browser. Click on the button to edit.
After modification, the tab name will change.

Network information
• Mac Address: Shows the speaker Mac address.
• IP Assignment: Shows the network mode of the speaker, either STATIC or
DHCP.
• IP Address: Shows the current IP address of the speaker.
• Subnet Mask: Shows the current subnet mask of the speaker.
• Default Gateway: Shows the current default gateway of the speaker.
• Primary DNS: Shows the current primary DNS of the speaker.
• Alternative DNS: Shows the current alternative DNS of the speaker.
SIP Account
There are three (3) SIP accounts under the SIP Settings, one (1) primary and two (2)
secondary for the use of different SIP accounts to proceed with various tasks. If the current
device needs to cooperate with the ZYCOO IP Audio Center, please turn on the ‘ZYCOO IP
Audio Center’ option.
Please go to SIP Settings -> Primary SIP Account / Secondary SIP Account-1 / Secondary SIP
Account-2
Primary SIP Account:

Secondary SIP 1 Account:
Secondary SIP 2 Account:
