Advanced Security ADSL 2+ Gateway
Benefits
Higher-speed Internet Access
The P-661H series is compatible with high-speed ADSL, ADSL2 and ADSL2+
interfaces over existing copper lines. With speeds of up to 12Mbps (ADSL2)
or 24Mbps (ADSL2+), the P-661H series offers higher data transfer rates and
better bandwidth than traditional ADSL gateways. It also supports RE ADSL
(Reach Extended ADSL) for higher speed and longer distance. With
excellent performance and upward compatibility, the P-661H Series is great
as the bridge between today's communications needs and tomorrow's
converged services.
Robust Firewall Security and IPSec VPN
The ICSA-certified ZyNOS operating system ensures state-of-art firewall
performance and robust security from the P-661H series. Based on Stateful
Packet Inspection, DoS (Denial of Service) and DDoS features, it provides the
first line defense against hackers, network intruders, and other harmful
threats. Furthermore, its VPN feature supports data encryption over the
Internet to ensure secure data transmission between two sites, and can be
used to replace a private leased line, allowing global interconnectivity with
minimal expense.
Media Bandwidth Management
The P-661H series enables network administrators to allocate network
resources and to guarantee Quality of Service (QoS). The MBM (Media
Bandwidth Management) function prioritizes media services, and increases
productivity and efficiency in daily operations by tailoring a system to
specific demands such as VoIP, video streaming, video-conferencing or MP3
applications.
Trend Micro Security Service (TMSS)
The embedded TMSS (Trend Micro Home Network Security Service) feature
not only helps to identify the vulnerabilities and security holes on PCs, but
also protects both the network and the PCs within from virus and hacker
attacks. TMSS includes redirected page setting, virus protection and
parental control that are easy to configure via the TMSS Dashboard.
ADSL 2+ Security Gateway
p-661h series

65-100-661001 03/05
Copyright © 2005 ZyXEL Communications Corp. All rights reserved. ZyXEL,ZyXEL logo and ZyNOS are registered trademarks of ZyXEL Communications Corp. All other brands,
product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.
Specifications
System Specifications
ADSL Compliant
RADSL (ANSI T1.413 Issue 2)
G.dmt ADSL over POTS (G.992.1 Annex A)
G.dmt ADSL over ISDN (G.992.1 Annex B and
U-R2)
G.lite (G.992.2)
ADSL2 G.dmt.bis (G.992.3)
ADSL2 G.lite.bis (G.992.4)
ADSL2+ (G.992.5)
Reach Extended ADSL (RE ADSL)
ATM Support
8 PVCs Support
RFC 1483/2684 Multiple Protocol over AAL5
RFC 2364 PPP over AAL5
RFC 2516 PPP over Ethernet
VC and LLC Multiplexing
Traffic Shaping UBR, CBR, VBR
ATM Forum UNI 3.1/ 4.0 PVC
I.610 OAM F4/F5 loop-back, AIS, and
RDI OAM cells
TR-37,TR-62 DSL Auto Configuration
Firewall Security
Stateful Packet Inspection
Prevent DoS,DDoS Attack
Policy-based Access Control
Content Filtering
IP & Generic Packet Filtering
Real-time Attack Alert and Logs
Virtual Private Network
2 IPSec VPN Tunnels
IKE and Manual Key Management
AH and ESP Protocol
DES, 3DES, and AES Encryption
SHA-1 and MD5 Authentication
Tunnel and Transport ModeEncapsulation
Routing Support
IEEE 802.1d Transparent Bridging
IP Routing: TCP, UDP, ICMP, ARP
RIP1v1 and RIPv2
IP Multicast IGMP v1/v2
IP Policy Route
IP Management
SUA/Multi-NAT Internet Sharing
Multimedia Support
VPN (IPSec, PPTP, L2TP) Pass-through
DHCP Server/Relay/Client
DNS Proxy
Dynamic DNS
UPnP Support
Network Management
Web based Configuration
Command-line Interpreter (CLI)
Telnet Remote Management
SNMP Support
FTP/TFTP firmware upgrade and
configuration backup/restore
Built-in Diagnostic Tool
Application
Trend Micro Security Service (TMSS) Support
MBM (Media Bandwidth Management) QoS
Zero Configuration
Traffic Redirect
Call Scheduling
Budget Management
Hardware specifications
ADSL: One RJ-11 or RJ-45 Port
LAN: 4-Port Switch,10/100M Auto MDI/MDIX
Reset Button
Status LEDs Indicator
Power 12V DC
Physical specifications
Dimensions :180(L)x 128(W)x 36(H)mm
Weight: 325g
Environmental specifications
Temperature: 0˚C ~ 40˚C
Humidity: 20 ~ 85 % (non-condensing)
Product Description
P-661H-61
ADSL2+ Security Gateway over POTS
P-661H-63
ADSL2+ Security Gateway over ISDN
P-661H-67
ADSL2+ Security Gateway over U-R2
What’s TMSS?
Trend Micro Home Network Security
Services are the easiest, most convenient
way to protect your PCs and entire home
network from viruses, hackers, spyware,
and other Internet security threats. Trend
Micro-powered security features built into
your router combined with integrated
security services on your PCs create a
comprehensive and easy to use home
network security solution. For detail
information, please check the Web site at
http://www.trendmicro.com/support/tmss/
High-speed Access with Advanced Security for SOHO/Small Office
ADSL 2+ Security Gateway
p-661h
series
VPN Tunnel
TMSS Security Service
P-661H
ADSL 2+ Security Gateway
P-661H
ADSL 2+ Security Gateway
Workgroup
Trend Micro
Security Service
Dashboard Login
Mobile user
(Laptop w/ VPN
client software)
