ZyXEL Communications ZyWALL 1050 User manual

www.zyxel.com
QUICK START GUIDE
ZyWALL 1050
Internet Security Applicance
Firmware v2.11
Edition 1, 11/2008
DEFAULT LOGIN DETAILS
IP Address: https://192.168.1.1
Username: admin
Password: 1234
CONTENTS
ENGLISH 3
DEUTSCH 17
ESPAÑOL 31
FRANÇAIS 45
ITALIANO 59
日本語 73
РУССКИЙ 87
简体中文 101
繁體中文 113
Copyright 2008 ZyXEL Communications Corporation
C

2
Front and Rear Panels
SYS
LED
HDD
LED
ACT
LED
DIAL
BACKUP
ON/OFF
USB
POWER
FANS
POWER
LED
RESET
PORTS
CONSOLE
PORT
PORT
P1-P5 EXTENSION
CARD SLOT
HDD
SLOT

ENGLISH
3
Checking the Package Contents
Your package should include one of each of the following:
• ZyWALL 1050
• Power cord
• Rack-mounting kit
• RJ-45 Ethernet cable
• RS-232 console Y-cable
• Printed Quick Start Guide
• Configuration Reference Card
• Compact disk (CD)
ENGLISH

4
Rack-mounted Installation
Mount the ZyWALL in a 19-inch rack or place it on a sturdy, flat surface.
Leave 10 cm of clearance at the sides and 20 cm in the rear.
1. Align one bracket with the holes on one side of the ZyWALL and
secure it with the included bracket screws. Similarly, attach the other
bracket.
2. After attaching both mounting brackets, position the ZyWALL in the
rack by lining up the holes in the brackets with the appropriate holes
on the rack. Secure the ZyWALL to the rack with the rack-mounting
screws.

ENGLISH
5
Connecting the Hardware
Make sure that the power switch on the rear panel is turned off before
you make the hardware connections.
1. It is recommended that you configure the ZyWALL before using it to
protect your network. Use an Ethernet cable to connect a computer to
port 1.
2. Use another Ethernet cable(s) to connect port 2 and/or port 3to an
Ethernet jack with Internet access.
3. Use the included power cord to connect the power socket on the rear
panel to a power outlet.

6
4. Push the power switch to the on position and look at the front panel.
The PWR light turns on. The SYS light blinks during system testing
and initialization and then stays on when the system is ready.

ENGLISH
7
Web Login
1. Launch your web browser and go to http://192.168.1.1 (the ZyWALL
automatically redirects you to https://192.168.1.1).
2. Click Yes to proceed if you get a security alert or certificate screen.

8
3. Enter admin as the user name and 1234 as the password. Click
Login.
4. It is strongly recommended that you change the password. Type and
retype a new password, and click Apply.

ENGLISH
9
Installation Setup Wizard
The Status screen opens. Click the Wizard icon in the upper right
corner.
Use an installation setup wizard to connect to the Internet and register
the ZyWALL and/or activate trial services, like IDP and content filter.
Use the installation wizard only for initial configuration starting
from the default configuration.
Changes you make in the installation wizard may not be applied if
you have already changed the ZyWALL’s configuration.
• INSTALLATION SETUP, ONE ISP sets up a single Internet
connection for ge2.
• INSTALLATION SETUP, TWO ISP sets up Internet connections for
ge2 and ge3.

10
The wizard screens vary depending on the encapsulation type you use.
Refer to information provided by your ISP and the web help screens to
know what to enter in each field. You can leave fields blank if you don’t
have that information.

ENGLISH
11
Default Settings and Port Details
The ZyWALL is configured for the following network topology by default.

12
Port Interface Zone IP Address and
DHCP Settings
Suggested Use
With Default
Settings
1ge1 LAN 192.168.1.1, DHCP
server enabled
Protected LAN
2, 3ge2, ge3 WAN DHCP clients Connections to the
Internet
4ge4 DMZ 192.168.2.1, DHCP
server disabled
Public servers (such as
web, e-mail and FTP)
5ge5 DMZ 192.168.3.1, DHCP
server disabled
Public servers (such as
web, e-mail and FTP)
DIAL
BACKUP
aux None None Auxiliary modem
CONSOLE N/A None None Local management
Label Type Cable to Use
1~5 RJ-45 8-wire Category 5e or above Ethernet cable
USB USB Connect a (USB) 3G wireless card to access the
Internet through a 3G network. At the time of writing,
you can use the Huawei E220/E270.
EXTENSION
CARD SLOT
PCMCIA Insert a wireless LAN card to use the wireless LAN
feature. At the time of writing, you can use ZyXEL’s G-
170S wireless card. You can optionally insert a 3G
wireless card to access the Internet wirelessly via a 3G
network. At the time of writing, you can use a Sierra
Wireless AC850, AC860, AC880 or AC881 3G wireless
card.
DIAL BACKUP,
CONSOLE
RS-232 RS-232

ENGLISH
13
The hard disk slot is reserved for future use.

14
Troubleshooting
None of the LEDs turn on.
• Make sure that you have the power cord connected to the ZyWALL
and plugged in to an appropriate power source. Make sure you
have the ZyWALL turned on. Check all cable connections.
• If the LEDs still do not turn on, you may have a hardware problem.
In this case, you should contact your local vendor.
Cannot access the ZyWALL from the LAN.
• Check the cable connection between the ZyWALL and your
computer or switch. Refer to section for details.
• Ping the ZyWALL from a LAN computer. Make sure your
computer’s Ethernet card is installed and functioning properly. Also
make sure that its IP address is in the same subnet as the
ZyWALL’s.
In the computer, click Start, (All) Programs, Accessories and then
Command Prompt. In the Command Prompt window, type "ping"
followed by the ZyWALL’s LAN IP address (192.168.1.1 is the
default) and then press [ENTER]. The ZyWALL should reply.
• If you’ve forgotten the ZyWALL’s password, use the RESET button.
Press the button in for about 5 seconds (or until the PWR LED
starts to blink), then release it. It returns the ZyWALL to the factory
defaults (password is 1234, LAN IP address 192.168.1.1 etc.; see
your User’s Guide for details).

ENGLISH
15
• If you’ve forgotten the ZyWALL’s IP address, you can use the
commands through the console port to check it. Connect your
computer to the CONSOLE port using a console cable. Your
computer should have a terminal emulation communications
program (such as HyperTerminal) set to VT100 terminal emulation,
no parity, 8 data bits, 1 stop bit, no flow control and 115200 bps port
speed.
Cannot access the Internet.
• Check the ZyWALL’s connection to the Ethernet jack with Internet
access. Make sure the Internet gateway device (such as a DSL
modem) is working properly.
• Check ge2’s status in the Status screen. Use the installation setup
wizard again and make sure that you enter the correct settings.

16

DEUTSCH
17
Prüfen des Packungsinhalts
Prüfen Sie ob alle Teile vorhanden sind:
• ZyWALL 1050
• Netzkabel
• Rackmontage-Zubehör
• RJ-45-Ethernetkabel
• Y-Kabel für RS-232-Konsole
• Kurzanleitung in Druckform
• Konfigurationskarte
• CD
DEUTSCH

18
Rackmontage
Montieren Sie die ZyWALL an einem 19"-Rack oder stellen Sie es auf
eine stabile Unterlage.
Lassen Sie seitlich 10 cm und hinten 20 cm Platz.
1. Richten Sie eine Halterung an den Löchern an der Seite der ZyWALL
aus und schrauben Sie sie mit den mitgelieferten Montageschrauben
fest. Verfahren Sie ebenso mit der zweiten Halterung.
2. Wenn Sie beide Montagehalterungen befestigt haben, richten Sie die
ZyWALL im so im Rack aus, dass die entsprechenden Schraublöcher
übereinander stehen. Befestigen Sie den ZyWALL mit den
Befestigungsschrauben am Rack.

DEUTSCH
19
Anschließen der Hardware
Stellen Sie sicher, dass der Netzschalter an der Rückseite des Geräts
ausgeschaltet ist, bevor Sie die ZyWALL in Betrieb nehmen.
1. Es wird empfohlen, die ZyWALL zu konfigurieren, bevor Sie sie zum
in Ihrem Netzwerk einsetzen. Schließen Sie einen Computer mit
einem Ethernetkabel an Port 1 an.
2. Schließen Sie an Port 2 und/oder Port 3Ihren Router mit
Internetzugriff an.
3. Schliessen Sie den Netzanschluss des Geräts (an der Rückseite) mit
dem mitgelieferten Netzkabel an eine Netzsteckdose an.

20
4. Schalten Sie den Ein/Aus-Schalter in die Position On und sehen Sie
sich das vordere Bedienfeld an. Die PWR-LED beginnt zu leuchten.
Die SYS-LED blinkt während des Systemtests und der Initialisierung,
und sie leuchtet, wenn der Test abgeschlossen und das System
bereit ist.
