ZyXEL Communications Home Station VDSL2 User manual

1
Home Station
VDSL2
Libertad
en una caja.
User’s guide

2

3
For further information please refer to the user’s manual on the advanced settings CD, section 2, or
the glossary section in this guide.
Package contents
(5) Advanced settings CD
VDSL2
(6) Warranty card
This guide details about the start up process for your Internet connection. You will be
able to enjoy your connection in an easy, simple and quick way. Please follow the guide
instructions step by step.
(2) Power adapter (3) Telephone line cable
(4) Ethernet cable
(1) Home Station VDSL2
Wifi
Power
3G
DSL
Internet
234

4
For further information please refer to sections 3.2 and 3.3 of the user’s manual on the advanced
settings CD
Start using your VDSL...
1. Telephone line connection
Connect the grey telephony line cable (3)
to the telephone line socket and to the
connector of the Home Station VDSL2
labeled as DSL.
DSL Reset Eth1 Eth2 Eth3 Eth4 USB Wifi On/Off
12V 1A
Power
DSL 3
2. Power adapter connection
Plug the power adapter (2) into the mains
supply and into the 12V 1A connector of
the Home Station VDSL2.
ON
OFF
DSL Reset Eth1 Eth2 Eth3 Eth4 USB Wifi On/Off
12V 1A
Power
2

5
For further information please refer to sections 3.4 of the user’s manual on the advanced
settings CD
3. Switching on the router
Turn the router on by putting the switch into the ON position. Wait for a few minutes until
the LEDs shine as shown below.
Indicator Current status Description
Power ON (green) Status of the power supply.
Ethernet 1-4 OFF Status of Ethernet connection.
Wifi ON (green) Status of wireless network.
Internet ON (green) Status of internet connection.
DSL ON (orange) Connectivity established with the exchange.
3G OFF For future use.
The routers provided by Movistar are optimised so that they can establish the connec-
tion with Internet without any need for installations or configurations.
Power Wi 3G DSL Internet
Ethernet
12 3 4
Power Wi 3G DSL Internet
Ethernet
12 3 4
Movistar can make a remote update of your equipment to offer you a better service.
During this update process the power and 3G indicators will flash in green while Wifi and
DSL indicators flash in orange and Internet indicator flashes in red.
Warning: Don’t turn off your Home Station VDSL2 while it is upgrading
because it could damage your equipment.
After about 6-8 minutes the power indi-
cator (the first one from the left) will light
up in fixed green indicating the end of the
process.
ON
OFF

6
You may either connect your computer to the router using an Ethernet cable if they are
sufficiently close to each other or by means of a wireless network. Furthermore, you can
simultaneously have certain items of equipment connected to the router using the Ether-
net cable and others as portable through the wireless network.
You can use the wireless network as long
as your computer is equipped with a wire-
less adapter installed or this is integrated
into your equipment.
Your router has enabled the wireless
network by default. If it would not be
enabled, the first step would be to enable
the wireless network for your router. This
is done by pressing the button Wifi loca-
ted at the back of the router within four
seconds (pressing it during eight seconds
would activate the WPS process). The Wifi
indicator will light up in green and will blink
when navigating.
The configuration parameters by default
for your wireless network are shown on
the label at the bottom of your router.
The next step is to configure the compu-
ters on your wireless network in accordan-
ce with your router’s wireless parameters.
A. Connection using wireless network
DSL Reset Eth1 Eth2 Eth3 Eth4 USB Wifi On/Off
12V 1A
Power
Wifi
DSL Reset Eth1 Eth2 Eth3 Eth4 USB Wifi On/Off
12V 1A
Power
4. Connecting the computer to the router. Two options are available
Start using your VDSL...
For further information please refer to sections 3.5 of the User’s manual on the advanced settings
CD

7
If you are equipped with an
external wireless device (PCM-
CIA or USB adapter), install it
with the aid of the CD that is
provided with it. If you have a
wireless device that is already
integrated into your equipment, make
sure that it is enabled with the aid of your
operating system.
Press the WPS button on the wireless
client device (check the device’s docu-
mentation to see the details about this).
You have two minutes for setting up the
connection using WPS and, after this time,
the router doesn’t allow connection using
WPS any more.
Connection using WPS
The router can use WPS for setting up a
secure wireless network. Your wireless
client device must support WPS for using
it. Otherwise, use the method explained
in “Connection using Windows wireless
client”.
Press the Wifi button located at the back
of the router during eight seconds and
release it (pressing it during four seconds
would enable or disable the wireless
network).
For further information please refer to sections 3.5 of the user’s manual on the advanced settings
CD.
Power Wi 3G
DSL Internet
Ethernet
12 3 4
Connection using Windows wireless
client
When configuring your wireless device in
Windows XP SP2, Vista or Windows 7 you
can use the wireless client management
application. For Windows XP SP2 or Vista,
press with the right mouse button on the
wireless network connection icon on the
system tray (next to the clock) and select
“View available wireless networks”. For
Windows 7, press with the left mouse
button on the same icon. For other ope-
rating systems refer to the wireless client
assistance manual.


8
For further information please refer to sections 3.5 of the user’s manual on the advanced settings
CD.
Search the available wireless networks.
You can update this list with the button
“Refresh network list” or by clicking the
button
Select the network whose identifier (SSID)
is the one that appears on the router label
and press on Connect.
Connect to the wireless network (to do
this, use the Connect or OK button).
Enter the security key that appears on the
router label.
IMPORTANT. The wireless security key
for the router is of the WPA/PSK type and
its format is alphanumerical. Make sure
you enter that security key exactly as it
appears on the label.
Check to make sure that the wireless net-
work connection icon for the system tray
indicates that the connection has been
correctly established.

9
For further information please refer to section 3.3 of the user’s manual on the advanced settings CD.
Connect the yellow Ethernet cable (4) to
the Ethernet card on the PC and to one of
the router’s connectors labeled as Eth1 to
Eth4.
Switch the PC on. The ETHERNET
indicator will light up in green after a few
seconds. This led will blink when transfe-
rring data.
Power Wi 3G
DSL Internet
Ethernet
12 3 4
B. Connection using Ethernet cable
DSL Reset Eth1 Eth2 Eth3 Eth4 USB Wifi On/Off
12V 1A
Power
DSL Reset Eth1 Eth2 Eth3 Eth4 USB Wifi On/Off
12V 1A
Power
4
4

10
Congratulations, now you can access Internet
using your VDSL !
Open your browser, go to the web address www.movistar.es and start
surfing the net.
Should you not be able to access, please see refer to the Solutions to fre-
quent problems in this guide.
Activate your free e-mail accounts and your website with the Internet
access service contracted.
Once you have accessed www.movistar.es, you can activate your mail account. After ty-
ping in the initial identificador (user) and contraseña (password) provided in the letter with
the service data or the one obtained calling 900 50 20 10 from the telephone line where
you have installed the VDSL service, you will access a website where you can publish your
personal web pages.
Protect your PC
Once you are connected to the VDSL service we strongly recommend you to protect your
PC against Internet viruses or attacks. If you wish to do so, you can contract these servi-
ces (Antivirus PC, Anti-Intrusos PC, Pack Seguridad PC, etc.) at www.movistar.es, calling
1004 or through your usual channel.

11
Advanced settings CD
On the CD you will be able to find further
help in response to any needs that might
arise regarding your VDSL Internet con-
nection.
Agente:
An Advanced Configuration Tool which
will allow you to carry out some advanced
configuration tasks, such as opening ports,
modifying the access password, etc.
Ver Documentación:
It includes more detailed information
about the additional tools and certain
aspects of your Internet connection. This
documentation is in Spanish language.
The CD is not required to set up your VDSL connection.

12
Solutions to frequent problems
Problem Reason Solution
The Ethernet led does not
light up.
The Ethernet cable is not
correctly connected. (This is only
a problem if you have decided
to connect by cable and not by
wireless network).
Verify that the Ethernet cable is correctly connected to the
Ethernet connector and to the Ethernet card of your desktop PC
or laptop computer (See Step 4 in the section “Start using your
VDSL... ” in this guide).
The DSL led does not
light up.
The phone line cable is not
correctly connected.
Verify that the phone line cable is correctly connected to the DSL
connector and to the phone socket (See Step 1 in the section
“Start using your DSL... ” in this guide).
I cannot access Internet.
There is a firewall installed in
your computer which prevents
the connection to Internet.
Verify that no firewall that may hinder the connection to the
Internet is installed. See appendix I of the user’s guide contained
in the advanced settings CD.
The TCP/IP protocol is not co-
rrectly installed for the network
adapter used.
You must make sure that the TCP/IP protocol is correctly
installed for the network adapter that the VDSL router is to be
connected to. Refer to the Guide on the Ethernet card and TCP/
IP protocol contained in the advanced settings CD.
Sometimes the computer does
not receive the IP address, the
gateway or the DNS server data
correctly through DHCP, owing
to the fact the computer and the
router are not simultaneously
turned on.
We recommend that you reset both devices, first of all the router
and then the computer.
I do not have an icon for
the wireless client.
Your wireless client is not
correctly installed, set up or
configured.
Make sure that your wireless client is correctly installed and
enabled. More information is contained in the manual for the
device itself.
The client management
application does not
show the network for
my VDSL router (the
one that appears on the
label) as being one of
the available networks.
The wireless network is disa-
bled on the router.
Make sure that the wireless network for your VDSL router is
enabled: the Wifi indicator is lit up in green.

13
Solutions to frequent problems
Problem Reason Solution
I cannot connect to the
VDSL router wireless
network.
Your network identifier (SSID)
is not being correctly indicated
when you connect to it.
Check to make sure that you are using the same network
identifier (SSID) throughout the network. Remember that it is
case sensitive, i.e. a distinction is made between capital and small
letters.
You have not correctly configured
the encryption used on your
wireless network when connec-
ting to it.
Check to make sure that you are using the same type of encryp-
tion and the same key for all the network elements. Remember
that, if you are using WEP encryption, you will have to select
and configure the key number 1 in the configuration for wireless
clients.
The TCP/IP properties of your
wireless client are not configured
to receive IP via DHCP.
Make sure that the TCP/IP properties of the network adapter for
your wireless client are configured to receive the IP dynamically
(via DHCP). Refer to the assistance given in your operating
system.
The connection with the
wireless network is cut
off frequently. The qua-
lity of the connection is
not good.
Interference is being caused
by other existing wireless
networks.
If there is any interference affecting that channel, select a diffe-
rent one. If there are other wireless networks operating in the
same zone, it is recommended that the networks be configured
with a separation of 5 channels. For example, if there is a wire-
less network operating on channel 6 and we wish to install an
additional wireless network, we must select channel 1, or 11. If
this is not possible, select the one that causes the least impact
(the least inundated channel, that is to say, the one with the
lowest number of wireless networks.
The wireless network signal
is weak because the router is
located in a place that is not
very accessible or at a great
distance.
Put the VDSL router in an unobstructed place. If there are net-
work coverage problems, it is recommended that the antenna
be moved to a different position. Remember that it is advisable
to make sure that there are not many obstructions between the
VDSL router and the wireless clients.
See the User’s guide in the advanced settings CD for further details.
If you cannot solve the problem, please refer to the following section, which contains infor-
mation about the customer care service.

14
Customer care
Movistar technical customer care centres
Home users: 1004
Enterprises and Professionals: 900 10 10 10
The customer care service is available via telephone as well as via Internet. For further
information, please refer to chapter 6 in the user’s manual.
All the information about VDSL can be found in the “Internet” section at movistar.es:
www.movistar.es/adsl
Customer care to execute the equipment warranty:
Home users: 1004
Enterprises and Professionals: 900 10 10 10

15
Additional information
Telefónica de España, S.A.U.
informs
Environmental recycling
We thank you the trust to have acquired a
Movistar product and we inform you that
for any clarification, query or complaint,
you can call for free:
•Personalcareline(1004)
•Carecenterforprofessionaland
business(900101010)
•Businesscarecenter(900120900)
Where you will be attended by our consul-
tants or, if you prefere, visit Movistar web
page:
www.movistar.es
For information about the after sales ser-
vice, please see the equipment warranty
card.
Finally, for written complaints regarding
this sale, please contact with Telefónica de
España S.A.U, Gran Vía 28, 28013 Ma-
drid.
Do not dispose of this Home Station
VDSL2 with your normal household waste.
Ask your local authorities about the op-
portunities that are available for disposing
of it correctly so that no damage is caused
to the environment. Always comply with
the applicable legal standards currently in
force.
All offenders will be penalised or otherwise
punished by Law.
Cardboard boxes, the plastic part of the
packaging and the parts that constitute
the device can be recycled in compliance
with the standards currently in force in
Spain where recycling is concerned.
The cross symbol on the
container that is printed on
the device, means that when
the equipment has reached
the end of its useful service
life it must be taken to a
special collection centre and
that it must be processed
separately from household
waste.
Telefónica de España SAU, Gran Vía 28, Registro Mercantil: Hoja M-213180, Folio 6, Tomo 13170, Inscripción 1ª, C.I.F.: A-82018474
Empresa adherida al Sistema Arbitral de Consumo

16
2200 Este equipo está preparado para su conexión a la red analógica de Telefónica de España, S.A.U.,
con acceso al servicio de banda ancha y su uso está autorizado exclusivamente en España.
DECLARATION OF CONFORMITY
Company Name: ZyXEL Communications, S.A.
Address: C/ Arte, 21, 5th floor
28033 Madrid
Phone: [phone] Fax: [phone]
Identification Number (CIF): A-62475710
Declares under its own responsability that the
Device Type: Router
Manufactured by: ZyXEL Communications Corp.
In: Taiwán
Brand: Telefónica
Model: Home Station VDSL2 P870HNU-51B
Complying with the standards listed below:
ITU.T G.993.1 VDSL1
ITU.T G.993.2 VDSL2
VDSL band plan, Annex A, Annex B, 997, 998
IEEE 802.11b/g
IEEE 802.3 10BaseT Ethernet
IEEE 802.3u 100BaseTx Ethernet
In accordance with the next international directives refered to telecommunication
devices:
EN 55022:1998+A1: 2000+A2: 2003
EN 55024:1998+A1: 2001+A2: 2003
EN 61000-3-2: 2000
EN 61000-3-3: 1995+A1: 2001
Safety EN 60950-1: 2001
According with the 89/336/EEC, 92/31/EEC, 93/68/EEC, 99/5/EEC and LVD 73/23/EEC specs.
And fully complying with the 1995/5/EC directive Annex III and the ErP 2009/125/EC directive.
Date, September 10th 2011
Firma: José Seger Segura
Country Manager

17
Glossary
Antivirus:
An application that detects and removes
any computer virus and other malicious
programs.
DHCP(DynamicHostConguration
Protocol):
A protocol that allows the hosts of a
network to obtain the IP configuration
settings automatically.
DNS(DomainNameSystem):
Domain Name Server. The server transla-
tes a domain name (the name of a machi-
ne) into its corresponding IP address.
Encryption or cryptography:
The science that enables one to encode
and decipher information using techniques
that make it possible to exchange messa-
ges in a safe and secure way, because they
can only be read by the persons to whom
they are addressed.
Ethernet cable:
A cable that is used to transmit data at
high speed in Local Area Networks (LAN).
Firewall:
A hardware or software element that is
used in a computer network to control
and manage the network traffic, either
allowing it or rejecting it, according to the
network policies defined by the organi-
sation that manages the network. It may
block the establishment of the connection
to the Internet.
PCMCIA:
It is a hardware element that is normally
used in laptop computers to expand their
capacities. The most common case is that
of wireless network adapters, which are of
this type.
Ports:
Physical or logical connections for sending
or receiving data. It allows a program to
communicate via the network.
Socket:
A plug that is usually installed on the wall
that enables the telephone cable to be
connected.
SSID(ServiceSetIdentier):
A code included in all the packages of
a wireless network so that they can be
identified as being part of that network.
An SSID thus enables one to make a
distinction between the different wireless
networks that exist.
TCP/IP(TransmissionControlProtol/
InternetProtocol):
It is a set of network protocols upon which
the Internet is based and which allow data
to be transmitted between computer
networks.
URL(UniformResourceLocator):
It is a Uniform Resource Identifier (URI)
that specifies where an identified resource

18
Glossary
is available and the mechanism for retrie-
ving it. The best-known example of the use
of URLs is for the addresses of web pages
on Internet, such as:
http://www.movistar.es
Web browser or web explorer:
It is an application that enables the user
to access and view hypertext document,
commonly in HTML format, that is availa-
ble on the Internet.
Web space:
It is a service that enables the user to offer
his or her own web sites or documents so
that they will be accessible on the Internet.
Web key:
A key that is used to authenticate a user
who connects to a wireless network that
uses this type of encryption (WEP). It
permits encrypting of sent data.
Wireless client:
A hardware or software element that is
used to connect to a network of compu-
ters without any kind of cable being used
for the purpose.
VDSL(VeryhighbitrateDigitalSubscri-
berLine):
It is a digital line for accessing Internet at
very high speed.

19

20
Equipment supplied by: C.I.F.: A-28669844
REI-RAEE Code: 000577
Version: 1.0
For getting further information:
1004
[phone]
Your Movistar shop
www.movistar.es
