ZyXEL Communications O2 HomeBox User manual

Quick start guide
œ HomeBox 6641
Konfi gurations-CD
Es wird keine Software installiert
Handbücher inklusive
Systemvorraussetzungen
Windows 7 / Vista / XP
für die Geräte
œ HomeBox 3232
œ Box 4421
œ Box 6431
Version
1.00 - 101457
Telefónica Germany
GmbH & Co. OHG
80992 München
www.o2online.de
Hotline: 55222*
aus dem œ Netz oder
0180 40 55 222*
aus dem dt. Festnetz
* 20 Ct./Anruf
Wichtig. Legen
Sie bitte zuerst
diese CD ein.
Konfi gurations-CD
Es wird keine Software installiert
Handbücher inklusive
Systemvoraussetzungen
Windows 8 / 7 / Vista /
XP SP3
für die Geräte
œ HomeBox 6641
œ Box 4421
œ Box 6431
Version
2.10 - 101505
Telefónica Germany
GmbH & Co. OHG
80992 München
www.o2online.de
Hotline: 55222*
aus dem œ Mobil -
funknetz oder
0180 40 55 222*
aus dem dt. Festnetz
* 20 Ct./Anruf
Wichtig. Legen
Sie bitte zuerst
diese CD ein.
101508 01/15
Your œ HomeBox in detail
WLAN/WPS
and DECT
push-buttons
DSL Power
So ISDN LAN 1–4
Internet
On/Off
switch
USB (e.g. Printer
or HDD) Reset
LAN 1–4 Phone InfoWLAN DSLPower
LED view
Side view USB connection
Rear side
DECT
Telefónica Germany GmbH & Co. OHG, Postbox 60 09 40, 22209 Hamburg
e.g. USB mass storage
LED Signal Status
Power Flashing System is starting up
Lights up constantly The system has started and is operating
Off Power supply disconnected or general equipment
fault
Lights up constantly The unit’s software is updating; unit is restarting
or resetting
LAN 1–4 Flashing Transferring data
Lights up constantly Active connection
Off No active connection
WLAN Flashing quickly Transferring data
Lights up constantly WLAN active
Flashing WPS activated
Off WLAN not active
DECT Lights up constantly DECT function on
Flashing DECT scanning for new unit
Off DECT function off
DSL Flashing slowly Pilot signal transmitting
Flashing quickly The œ HomeBox 6641 is being synchronised.
Lights up constantly DSL connection successfully established
Off Internal DSL fault
Internet Flashing Transferring data
Lights up constantly Internet connection established
Flashing quickly Faulty access details
(e.g. incorrect password)
Phone Flashing Active call
Lights up constantly Active line
Off Line not active
Info Flashing quickly Authentication in progress
Lights up constantly
PIN OK; œ phone connection established; when
the unit has completed registration with œ, the
Info LED will disappear
Lights up constantly
1. œHomeBox 6641 is waiting for a PIN
to be entered
2. Incorect PIN, waiting to re-enter PIN
3. Maximum authentication attempts
(5 times) reached
Flashing quickly PIN OK; waiting for authentication
Comprehensive information
You will fi nd detailed information about setting up and confi guring your œ HomeBox 6641 in the comprehensive manual on
the œ CD supplied as well as under http://o2.de/hilfe/o2homebox2.
How to contact us – 7 days a week, 24 hours a day:
On the Internet:
www.dsl.o2.de
Contact options:
www.o2.de/kontakt
By Phone:
[phone]*
[phone]*
By Fax:
[phone] (€ 0.14/min.)**
* Tariff for calls made to German landlines and mobile networks applies
** From a German landline; maximum charge of € 0.42/min. for calls from mobile networks
What’s in the box?
œ HomeBox 6641
LAN cable (yellow)
DSL connecting cable (grey)
œ configuration CD
• Comprehensive manual and
cabling instructions
• Installation wizard for DSL
and WLAN (Windows 8 / 7 /
Vista)
Power adapter
We appreciate you choosing of œ
and hope that you will now enjoy
the many benefi ts of your new DSL
connection.
Do you need help with the
installation?
Scan the QR code or visit
our website under
http://o2.de/hilfe/o2homebox2
to take a look at the installation
video for the œ HomeBox 6641.
Note: After setting up the router, also install the DSL Soforthilfe
from the folder area on the œ CD or from our website. This free
œ software helps you with access to the Internet and optimises
your WLAN connection
