ZyXEL Communications P-660R-Tx v3s Series User manual

Benefits
High-speed Internet access
The ZyXEL P-660R-Tx v3s Series is an ADSL/ADSL2/ADSL2+ router that supports downstream
transmission of up to 12 Mbps (ADSL2) or 24 Mbps (ADSL2+), 430 times faster than 56K modem.
For ISP/Telco needs, the P-660R-Tx v3s Series supports rate- and line-status monitoring and
management. Users can enjoy not only high-speed ADSL services but also broadband
multimedia applications such as interactive gaming,video streaming and real-time audio much
easier than ever.
SOHO firewall security
Along with the built-in NAT firewall feature,the ZyXEL P-660R-Tx v3s Series provides advanced
packet filtering; and it automatically detects and blocks Denial of Service (DoS) attacks as well.
Automatic remote configuration
The P-660R-Tx v3s series complys with the TR-069/TR-064 standard and most configuration,
diagnosis, and firmware upgrades can be performed via remote ACS without users involved.
In other words,users get better service with less effort for manual configuration.
Ł
ADSL2+ Internet access
Ł
SOHO firewall security with
DoS Prevention
Ł
Web-based user interface
Ł
Powerful remote
management support
(TR-069)
Compact, Flexible and Easy to Install
P-660R-Tx v3s
Series
ADSL2+ Access Router
P-660R-Tx v3s
Series
ADSL2+ Access Router

65-100-660105B 11/10
For more product information, visit us on the web at www.ZyXEL.com
Copyright © 2010 ZyXEL Communications Corp. All rights reserved. ZyXEL, ZyXEL logo are registered trademarks of
ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their
respective owners. All specifications are subject to change without notice.
DSLPOWER
ON/OFF
RESET ETHERNET
P-660R-Tx v3s Series
ADSL2+ Access Router
ZyAIR
Wireless
CardBus Card
Wireless
USB Adapter
ZyAIR
Wireless AP
Wireless AP
ADSL Line
Network Cable
Internet
Prestige600series
PWR/SYS10/100MDSLPPPUSB
GS-105A
LINK/ACT
PWR
12345
ZyAIR
P-660R-Tx v3s Series
ADSL2+ Access Router
P-660R-Tx v3s Series
ADSL2+ Access Router
System Specifications
ADSL Compliance
• Support Multi-Mode Standard (ANSI T1.413,
Issue 2; G.dmt (G.992.1); G.lite (G992.2))
• EOC Specified in ITU-T G.992.1
• ADSL2 G.dmt.bis (G.992.3)
• ADSL2 G.lite.bis (G.992.4)
• ADSL2+ (G.992.5)
• Reach Extended ADSL (RE ADSL)
ATM Protocol
• ADSL Physical Connection ATM AAL5 (ATM
Adaptation Layer Type 5)
• Support Multi-protocol over AAL5
(RFC1483/2684)
• Support VC-based and LLC-based Multiplexing
• Support up to 8 PVCs
• Support PPP over ATM AAL5 (RFC2364)
• PPP over Ethernet Support for DSL connection
(RFC 2516)
• I.610 F4/F5 OAM Loop-back
Network Protocols
• IP Routing
• 802.1d Transparent Bridging
• IGMP v1&v2
• RIP-1/RIP-2
• ICMP
• TCP/UDP
IP Management
• DHCP Client/Server/Relay
• DNS Proxy
• Dynamic DNS (www.dyndns.org)
• UPnP support
• SUA/Multi-NAT Internet Sharing
Network Management
• FTP for Firmware and Configuration
Upgrade/Backup
• Remote Management Control:
Telnet, FTP, and Web
• SNMP support
• Built-in Diagnostic tools
• TR-069 compliance
• TR-064 compliance
Hardware Specifications
• ADSL port: RJ11 port for Annex A or RJ45 port
for Annex B
• LAN port: RJ45 port
• Power: 9 V DC & 0.6 A Switching
Physical Specifications
• Item weight:165 g
• Item dimensions: 110 (W) x 107 (D) x 36 (H) mm
Environmental Specifications
Operating Environment
• Temperature: 0°C ~ 40°C
• Humidity: 20% ~ 85% RH (non-condensing)
Storage Environment
• Temperature: -20°C ~ 60°C
• Humidity: 20% ~ 90% RH (non-condensing)
Certification
• CE
• FCC
Product Description
• P-660R-T1 v3s
ADSL2+ Router over POTS
• P-660R-T3 v3s
ADSL2+ Router over ISDN
Rear Panel
Specifications
Application Diagram
