ZyXEL Communications PPC 10 User manual

PPC-10
Phoneline PCI Card
User's Guide
Version 2.0

ii
PPC-10 Phoneline PCI Card
Copyright
Copyright © 2000 by ZyXEL Communications
Corporation.
The contents of this publication may not be
reproduced in any part or as a whole, transcribed,
stored in a retrieval system, translated into any
language,ortransmittedinanyformorbyanymeans,
electronic, mechanical, magnetic, optical, chemical,
photocopying, manual, or otherwise, without the prior
written permission of ZyXEL Communications
Corporation.
Published by ZyXEL Communications Corporation.
All rights reserved.
Disclaimer
ZyXELdoesnotassumeanyliabilityarisingoutofthe
application or use of any products, or software
described herein. Neither does it convey any license
under its patent rights nor the patent rights of others.
ZyXEL further reserves the right to make changes in
any products described herein without notice. This
publication is subject to change without notice.
Trademarks
Trademarks mentioned in this publication are used
for identification purposes only and may be
properties of their respective owners.

iii
FCC Statement
This device compiles with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
Warning! This equipment has been tested and
found to comply with the limits for a Class B digital
device, pursuant to Part 15 of theFCC Rules. These
limits are designed to provide reasonable protection
against harmful interference when the equipment is
operated in a commercial environment. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. Operation of
this equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the interference at his own
expense.
CE-Mark Warning
In a domestic environment this product may cause
radio interference in which case the user may be
required to take adequate measures.

iv
Information for Canadian Users
The Industry Canada label identifies certified
equipment. This certification means that the
equipment meets certain telecommunications
network protective, operation, and safety
requirements. The Industry Canada does not
guarantee that the equipment will operate to a user's
satisfaction.
Before installing thisequipment, usersshould ensure
that it is permissible to be connected to the facilities
of the local telecommunications company. The
equipment must also be installed using an
acceptablemethodofconnection.Insomecases,the
company's inside wiring associated with a single line
individual service may be extended by means of a
certified connector assembly. The customer should
be aware that the compliance with the above
conditions may not prevent degradation of service in
some situations.
Repairs to certified equipment should be made by an
authorizedCanadianmaintenancefacilitydesignated
by the supplier. Any repairs or alterations made by
the user to this equipment, or equipment
malfunctions, may give the telecommunications
company cause to request the user to disconnect the
equipment.
Fortheirownprotection,usersshouldensurethatthe
electrical ground connections of the power utility,
telephone lines, and internal metallic water pipe
system, if present, are connected together. This
precaution may beparticularly important in rural
areas.
Caution
Users should not attempt to make such connections
themselves, but should contact the appropriate

v
electrical inspection authority, or electrician, as
appropriate.
Note
This digital apparatus does not exceed the class A
limits for radio noise emissions from digital apparatus
set out in the radio interference regulations of
Industry Canada.

vi
ZyXEL Limited Warranty
ZyXEL warrants to the original end user (purchaser)
that this product is free from any defects in materials
or workmanship for a period of up to two years from
thedateofpurchase.Duringthewarrantyperiod,and
upon proof of purchase, should the product have
indications of failure due to faulty workmanship
and/or materials, ZyXEL will, at its discretion, repair
or replace the defective products or components
without charge for either parts or labor, and to
whatever extent it shall deem necessary to restore
the product or components to proper operating
condition. Any replacement will consist of a new or
re-manufactured functionally equivalent product of
equal value, and will be solely at the discretion of
ZyXEL. This warranty shall not apply if the product is
modified, misused, tampered with, damaged by an
act of God, or subjected to abnormal working
conditions.
Note
Repair or replacement, as provided under this
warranty, is the exclusive remedy of the purchaser.
This warranty is in lieu of all other warranties,
express or implied, including any implied warranty of
merchantability or fitness for a particular use or
purpose. ZyXEL shall in no event be held liable for
indirect or consequential damages of any kind of
character to the purchaser.
To obtain the services of this warranty, contact
ZyXEL's Service Center; refer to the separate
Warranty Card for your Return Material Authorization
number (RMA). Products must be returned Postage
Prepaid. It is recommended that the unit be insured
when shipped. Any returned products without proof
of purchase or those with an out-dated warranty will

vii
be repaired or replaced (at the discretion of ZyXEL)
and the customer will be billed for parts and labor. All
repaired or replaced products will be shipped by
ZyXEL to the corresponding return address, Postage
Paid (USA and territories only). If the customer
desires some other return destination beyond the
U.S. borders, the customer shall bear the cost of the
return shipment. This warranty gives you specific
legal rights, and you may also have other rights that
vary from state to state.
Registration
Please register your Phoneline PCI Card (fast, easy
onlineregistration atwww.zyxel.com)forfreeproduct
updates and information.

viii
Customer Support
If you have questions about your ZyXEL product or
desire assistance, contact ZyXEL Communications
Corporation offices worldwide, in one of the following
ways:
E-MAIL –Support/ Sales
Web Site/ FTP Site Telephone/Fax Regular Mail
World
wide [email protected] [email protected]
[email protected]
www.zyxel.com
www.europe.zyxel.com
ftp.europe.zyxel.com
[phone]
[phone]
ZyXEL
Communications
Corp., 6 Innovation
Road II,
Science-Based
Industrial Park,
HsinChu, Taiwan 300,
R.O.C.
North
America [email protected] [email protected]
www.zyxel.com
ftp.zyxel.com
[phone]
800-255-4101
[phone]
ZyXEL
Communications Inc.,
1650 Miraloma
Avenue, Placentia, CA
92870, U.S.A.
Scandin
avia
[email protected]
[email protected]
www.zyxel.dk
ftp.zyxel.dk
[phone]
[phone] ZyXEL
Communications A/S,
Columbusvej 5, 2860
Soeborg, Denmark.
Austria [email protected]
[email protected]
www.zyxel.at
ftp.zyxel.at
[phone]
[phone] ZyXEL
Communications
Services GmbH.
Thaliastrasse
125a/2/2/4 A-1160
Vienna, Austria
Germany [email protected]e
[email protected]
www.zyxel.de
[phone]
[phone]
ZyXEL Deutschland
GmbH. Adenauerstr.
20/A4 D-52146
Wuerselen, Germany

ix
Table of Contents
PPC-10 PHONELINE PCICARD........................II
DISCLAIMER ............................................................II
TRADEMARKS .........................................................II
FCC STATEMENT.................................................III
INFORMATION FOR CANADIAN USERS....IV
ZYXEL LIMITED WARRANTY........................VI
CUSTOMER SUPPORT....................................VIII
1INTRODUCTION..............................................1
1.1 FEATURES........................................................1
1.2 SYSTEM REQUIREMENTS...............................1
1.3 UNPACKING....................................................2
1.4 INSTALLINGTHE PHONELINE CARD............2
1.5 CONNECTINGTHE PHONELINE NETWORK..3
1.6 DRIVERS AND UTILITIES DISKETTE.............3
1.7 SOFTWARE INSTALLATION...........................4
1.8 LED DEFINITIONS.........................................4
1.9 PRODUCT SPECIFICATIONS...........................5
2PHONELINE PCI 轉接卡................................6
2.1 使用說明書....................................................6

x
2.2 軟體安裝方式 ...............................................7

1
1Introduction
Congratulations on the purchase of your new 1 Mbps
phoneline PCI adapter card. This document shows
you how to install of the adapter in your computer.
The phoneline PCI card is a cost-effective,
high-performance network interface card. It provides
connectivity to 1Mbps phoneline networking.
The 1 Mbps phoneline networking is a new
technology that provides network connectivity over
existing telephone wires without any impact on the
voice service.
1.1 Features
ŸCompliantwith1MbpsHomePNAspecification1.0
ŸCompliant with PCI Local Bus revision 2.0/2.1
specifications
ŸTwo RJ-11 phone jacks
ŸMaximum distance of 500 feet for phoneline
networking
ŸTwo LED indicators
ŸPlug-and-play Installation, “jumperless” board with
software configuration program
ŸWindows 95, Windows 98 and Windows NT
support.
ŸFCC certification
1.2 System Requirements
To use the adapter card, you need the following:
qA PCI-based computer
qA PCI master mode expansion slot that is

2
compliant With PCI local bus specifications,
revisions 2.0 and 2.1
qA 3.5-inch, 1.44MB diskette drive
qTwisted-pair telephone lines for 1 Mbps
phoneline networking installation
This section describes how to install the adapter card
in your computer.
1.3 Unpacking
Caution:
To prevent static charge from damaging the
adapter, reduce the charge by touching a
ground, e.g., the computer chassis, before
handling the adapter card.
Open theshippingcarton andcarefullyremove allthe
items. In addition to this User’s Guide, please check
the following:
qOne phoneline networking PCI card
qOne 3.5” driver diskette
Note:
If any of the listed items is missing, please
contact your distributor or reseller.
1.4 Installing the Phoneline Card
1. Turn off the computer and disconnect the power
cord.
2. Remove the computer’s cover according to its
manufacturer’s instructions.
3. Insert the contact edge of the adapter card into

3
one of the available PCI bus master expansion
slot. Press the card firmly into the PCI slot and
make sure that the card is fully seated.
4. Tighten the bracket screw that secures the card to
the computer chassis.
5. Reinstall the computer’s cover.
6. Turn on the computer.
7. If your computer is plug-n-play compliant, then at
power up the BIOS will configure any newly
installed adapter card automatically.
Note:
Due to some plug-n-play BIOS’ bug, it happens
occasionally that a newly installed adapter card is
assigned an interrupt number that is already usedby
another device. The conflict in interrupt number will
cause both devices to behave abnormally. If this
should happen, it is necessary to run the CMOS
Setup utility and manually assign a non-conflicting
interrupt number to the adapter card.
1.5 Connecting the Phoneline Network
Connect either one of the RJ-11 ports on the adapter
card to the wall jack using a regular telephone line. If
you have a telephone, connect it to the other RJ-11
port.
1.6 Drivers and Utilities Diskette
The diskette contains drivers for the following
operatingsystems:
ŸWindows 95/98
ŸWindows NT 3.5, 4.0

4
1.7 Software Installation
Microsoft Windows 95:
1.After installing the adapter card and reboot,
Windows 95 will discover the new adapter card.
2.Windows 95 will prompt for driver installation.
3.Insert the driver diskette into the floppy drive and
click <other locations>.
4.Windows 95 will install the driver from the diskette.
5.Reboot the computer.
Microsoft Windows 98:
1.After installing the adapter card and reboot,
Windows 98 will discover the new adapter card.
2.Windows 98 will show two choices. Choose
“Search for the best driver for your device”.
3.Select “Floppy disk drives” when Windows 98
prompts for driver installation.
4.Windows 98 will install the driver from the diskette.
5.Reboot the computer.
1.8 LED Definitions
LED Status Description
Blinking The port is transmitting
or receiving data.
ACT
Off No traffic.
Steadily On The link is up.Link
Off The port is not
connected or the link is
down.
Note: The LEDs may vary on different hardware
versions.

5
1.9 Product Specifications
Standard HomePNA specification 1.0
Interface Two RJ-11 connectors for
phoneline networking
Cable Phoneline networking:
Twisted-pair telephone
wires
Network Data Rate 1 Mbps
LED indications Link, Activity
Base I/O Addresses Assigned by BIOS
Bus Interface 32-bitbus master
Hardware Interrupt PCI INTA
Emission FCC Class B
Operating
Temperature 00~ 550C (320~ 1310F)
Operating Humidity 10% -90%
(non-condensing)

6
2Phoneline PCI 轉接卡
2.1 使用說明書
感謝您購買Phoneline PCI 轉接卡，本轉接卡提供
以電話線及電腦終端機設備連接網路之功用。主
要功能項目包括：
1. 支援 1Mbps HomePNA specification 1.1。
2. 支援 IEEE 802.3 10BASE-T及IEEE 802.3u
100BASE-TX。
3. 支援 32位元PCI 2.0/2.1/2.2 之介面標
準。
4. 支援兩個RJ-11電話接頭及一個10Mbps
RJ-45 乙太網路接頭。
5. 支援全雙工功能。
6. 1/10Mbps 自動偵測速率功能。
7. 以電話線連接能夠連接最高達500呎(150
公尺)。
8. 提供顯示燈號，以方便偵測除錯之用。
9. 支援各種操作作業系統：Microsoft Windows
95/98/2000/NT及其他各種作業系統。
10. 通過 FCC認證。

7
2.2 軟體安裝方式
Windows 2000安裝步驟
請採用下列步驟安裝 Windows 2000 驅動程式：
1. 將電腦電源關上。
2. 將網路卡插入電腦的 PCI 插槽內。
3. 重新開機。
4. 當Windows 2000開始執行時，它會自動
測到 Phoneline PCI轉接卡，並將系統內
之驅動程式自動啟動。
5. W2000 會提示數位簽章警告，請按”是”，
完成更新動作。
6. Windows 會自動安裝驅動程式。
7. 重新啟動 Windows 系統。
Windows 95/98 安裝步驟
1. 將電腦電源關上。
2. 將網路卡插入電腦的 PCI 插槽內。
3. 重新開機。
4. 當Windows 開始執行時，它會自動偵測到
10/100Mbps 網路卡，並要求安裝驅動程式。
5. 插入 “Driver and Utilities”磁片，並按
下”Enter”。
6. Windows 95/98，敲入 a:\並安裝驅動程
式
7. Windows 會自動安裝驅動程式。
8. 重新啟動 Windows 系統。
