1010music Bitbox Micro 1.0.7 User manual

Bitbox Micro 1.0.7
User Manual
Jun 27, 2020

Page 2 of 88 Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7
WELCOME 7
Document Overview ................................................................................................... 7
SET UP BITBOX MICRO IN YOUR EURORACK 8
Connect Inputs and Outputs....................................................................................... 8
Control the Volume..................................................................................................... 9
Test Your Setup .......................................................................................................... 9
CONTROLS OVERVIEW 10
PRESETS 11
To Save Changes to a Preset:........................................................................11
To Load a Preset: ...........................................................................................11
To Create and Name a Preset:.......................................................................12
PADS OVERVIEW 13
The Pads Screen...................................................................................................... 13
The Waveform Screen.............................................................................................. 14
Pad Parameters Screen ........................................................................................... 15
Pad Selector Grid ..................................................................................................... 15
WAV File Selection Screen....................................................................................... 15
Multi-WAV Recording Screen ................................................................................... 16
WAV Recording Screen ............................................................................................ 16
The Keys Screens .................................................................................................... 17
WORKING WITH PADS 18
Steps Common to All Pad Modes............................................................................. 18
To Select WAV Files and Assign Pad Modes: ................................................18
To View Wave with Start, End, Loop and Slice Points:...................................20
To Congure Pad Parameters and Choose a Pad Mode: ..............................21
Set Up a Sample Pad............................................................................................... 25
Single Sample Pads ............................................................................................ 25
Multi-Sample Pads .............................................................................................. 28
Set Up a Clip Pad..................................................................................................... 31
Table of Contents

Copyright 1010music LLC 2020 Page 3 of 88
Bitbox Micro User Manual 1.0.7
Tips for Synchronizing Clips: ..........................................................................32
Set Up a Slicer Pad .................................................................................................. 33
To Manually Create or Remove Slices: ..........................................................35
To Use Auto Scan to Create Slices: ...............................................................35
To Use Slices to Synchronize Playback of Clip Pads:....................................36
To Use Slice to Grid:.......................................................................................36
Set Up a Granular Pad ............................................................................................. 37
To Connect an Audio Input for Sampling: .......................................................38
Record a New WAV File ........................................................................................... 38
To record a WAV le: ......................................................................................39
If you are recording WAVs for the current preset: ..........................................41
If you are recording WAVs to build up a library of sounds: .............................42
Record a Multi-sample Pack .................................................................................... 43
Manage WAV Files ................................................................................................... 48
Working with WAV Files on the MicroSD Card .................................................... 48
Work with WAV les on the Bitbox Micro............................................................. 49
To Trim WAV Files: .........................................................................................49
To Delete, Save As or Rename a WAV File:...................................................50
Save and Load Parameters in WAV Files ........................................................... 52
To save the values you have congured for a pad back to the WAV le: .......53
Packing Presets .................................................................................................. 54
To Pack a Preset: ...........................................................................................54
WORK WITH KEYS 55
To Play a Sample With the Traditional Keyboard: ..........................................55
To Play a Sample, Clip or Granular Mode Pad With the Grid Keyboard: .......56
To Play Slicer Mode Pads With Keys: ............................................................56
To Select a Scale on the Grid Keyboard: .......................................................58
APPLY EFFECTS 59
To Route a Pad to an Eect:...........................................................................59
To Modify Eect Parameters: .........................................................................59

Page 4 of 88 Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7
ADJUST THE MIX 61
To Adjust the Sound Level and Pan of a Pad: ................................................61
To Mute and Unmute Pads:............................................................................61
MANAGE PRESETS 62
To Save Changes to a Preset:........................................................................63
To Load a Preset: ...........................................................................................64
To Pack a Preset: ...........................................................................................64
To Clean unused WAV les out of a Preset’s folder: ......................................65
To Delete a Preset:.........................................................................................65
To Rename a Preset:......................................................................................66
To Save Current Changes as a New Preset:..................................................66
Work with Preset Files on the MicroSD Card ........................................................... 67
SETTINGS 68
USE MIDI DEVICES WITH BITBOX MICRO 70
Work with MIDI Inputs .............................................................................................. 70
To Trigger Pad Hits with a MIDI Device:.........................................................71
To Play Notes and Use Common MIDI Modulation Signals with a Specic Pad
or Pads: ..........................................................................................................72
To Play Notes and Use MIDI Modulation Signals with the Currently Selected
Pad: ................................................................................................................72
To Congure MIDI modulation for a parameter using named MIDI sources: .73
To Use MIDI Learn mode to Modulate Parameters: .......................................74
To Remove MIDI Modulation from a Parameter: ............................................74
To Use MIDI Notes to Play Slices:..................................................................75
Sharing of MIDI Input Channels .......................................................................... 77
Use MIDI Program Change to Open a Preset..................................................... 78
To Enable or Disable MIDI Program Changes: ..............................................78
Work with MIDI Outputs............................................................................................ 78
Synchronize Playback with a Clock.......................................................................... 79
Congure Bitbox micro to Follow an External Clock ........................................... 79
To Connect an External CV Clock: .................................................................79
Send the Bitbox micro Clock Signal to External Devices .................................... 80

Copyright 1010music LLC 2020 Page 5 of 88
Bitbox Micro User Manual 1.0.7
Reset the Clock ........................................................................................................ 80
CREATE PRESET TEMPLATES FOR RE-USE 81
To Congure a Pad without a WAV le: ..........................................................81
To Add a WAV le to a Template Pad: ............................................................81
REDUCE ALIASING WHEN PLAYING PADS CHROMATICALLY 82
PROCESSOR MANAGEMENT TIPS 83
UPDATE FIRMWARE, AUDIO FILES AND PRESETS 84
Switch to a New MicroSD Card While Operating Bitbox micro ................................ 84
Backup Your Presets and WAV Files........................................................................ 84
To Install New Firmware: ................................................................................84
Reset a Bitbox Micro Preset to Factory Settings...................................................... 85
TECHNICAL SPECS 86
On-Board Memory .................................................................................................... 86
Maximum Sample Length......................................................................................... 86
Samples Supported.................................................................................................. 86
Maximum Number of Voices Supported................................................................... 86
Pin Mapping for Mini TRS Jack to MIDI 5 Pin DIN Connectors................................ 87
STAY UP TO DATE 88
Demonstration Videos and Latest Documentation ................................................... 88
Connect with Other Bitbox Micro Users ................................................................... 88
Contact Us................................................................................................................ 88

Page 6 of 88 Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7
Page 6 of 88 Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7

Copyright 1010music LLC 2020 Page 7 of 88
Bitbox Micro User Manual 1.0.7
Copyright 1010music LLC 2020 Page 7 of 88
Bitbox Micro User Manual 1.0.7
WELCOME
Bitbox micro by 1010music is a compact sampling module for eurorack. With bitbox
micro, you can record and play samples, then trigger them using MIDI and CV. Use
bitbox micro to record individual WAV les, or use Auto-sampling to easily create a
sample bank of your favorite MIDI or CV instrument. You can beat sync your clips to an
external clock or use slices to trigger portions of a WAV le. We will start with a quick
walk through of the basic features to get you started. Then we will go deep and cover all
of the features supported.. Find community, support, wish lists, and rmware updates on
our forum at https://forum.1010music.com.
Document Overview
In this manual, we will rst quickly make sure you have bitbox micro installed in your
eurorack and set up so you can make some sound with it. After that, we will review the
basic controls and screens. Next, we will walk through how to set up pads including a
description of each of the dierent pad modes. We will cover the Keys Input mode, how
to apply FX and how to adjust the mix. After that, we will cover presets and global
settings. That will be followed by discussion of how to use MIDI devices with bitbox
micro, along with some more advanced usage features. Lastly, we will delve into
managing bitbox micro rmware and les, touch on a couple of technical specs and
nally tell you where you can nd more information about bitbox micro and other
1010music products.
This manual was written for version 1.0.7 of the bitbox micro rmware. If you have an
older version, we strongly recommend that you upgrade. See UPDATE FIRMWARE,
AUDIO FILES AND PRESETS below to learn how to upgrade your rmware.

SET UP BITBOX MICRO IN YOUR EURORACK
Let’s get the module in your rack so you can try things out as we cover them here:
1. Insert the microSD card into the MICRO SD
slot, notched edge to the right.
2. Turn o your Eurorack and use the ribbon
cable to connect the module to power:
- The narrow connector attaches to the
module, with the red side of the cable on the
side of the header with a white bar.
- The wide connector attaches to the Eurorack
+12V power supply, with the red side of the
cable aligned with pin 1 or the -12V pins on the
power supply bus.
3. Mount the module into the rack and then power
it up.
After boot up, the bitbox micro displays the Pads screen with a grid of WAV les loaded
from one of the presets provided on the microSD card.
Connect Inputs and Outputs
Connect some basic signals to bitbox micro to get
started. This module has 8 input and 8 output jacks that
support the following connections:
■ Inputs 1 – 2: Gate, CV, Clock, Audio
■ Inputs 3 – 8: Gate, CV, Clock
■ Outputs 1 – 6: Assignable audio
■ Outputs 7 – 8: Master audio left and right
Connect Outputs 7 and 8 to speakers or headphones
through a mixer. To record audio, connect an audio signal
to Inputs 1 and 2.
A gate signal on an input can trigger the corresponding
pad. Connect a standard eurorack gate signal to input 3
to try this out.
Copyright 1010music LLC 2020
Page 8 of 88
Bitbox Micro User Manual 1.0.7

Page 9 of 88
Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7
Connect a MIDI controller to the MIDI In jack to trigger
pads and modulate parameters. Use the included Mini-
TRS to MIDI 5-PIN DIN adapter if needed. This TRS jack
supports both Mini-TRS type A and Mini-TRS Type B
connections.
Control the Volume
By default, the bitbox micro is congured to play at 80%
volume. Here’s how to adjust that if needed:
1. Touch Tools one time to display the Settings
screen.
2. Turn the top knob until the MasterVol
parameter is highlighted pink.
3. Turn the bottom knob to the desired value.
Test Your Setup
Now let’s see what the module sounds like.
1. Push the Home button until you see the Pads
screen.
2. Touch a pad to trigger playback. You should
hear the sample playing out through the
connected audio output. The pad you touched
will turn pink to show that it is selected. A blue
playback progress bar will grow across the
bottom of the pad as the WAV le play
progresses.
If you don’t hear anything, try touching a dierent pad. If you still don’t hear anything,
push Tools then Home to make sure you really are on the Pads screen. (It will say Pads
at the very top middle of the screen.) Then try touching a pad. Next, check your output
connections and your volume (See above.)
Pads Screen
Settings Screen

CONTROLS OVERVIEW
You control bitbox micro using the four white buttons across the top, the two knobs on
the right, and the touchscreen.
The four white buttons across the top control which screen is displayed. Push the Home
and Tools buttons repeatedly to cycle through the Pads, Mixer and FX screens. Push
the arrow buttons to view more or less detail about the selected element.
Turn the knobs to select elements and assign values.
On the touch screen, you can use tap, pinch and stretch gestures to select items, trigger
pads, push buttons, zoom in or zoom out.
If you get lost in the User Interface, push the HOME button up to three times until you
get to the screen with the word “Pads” in the black bar across the top. Now you are
back to the starting screen.
Pads
Mixer
FX
Settings
Input
Output
More DetailLess Detail
Top Knob:
Select an
Element
Bottom Knob:
Assign a
Value
Page 10 of 88 Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7

PRESETS
By now you are probably ready to start playing some music. We are going to cover that
next. First, let’s make sure you know how to save or undo your changes. Bitbox micro
stores your conguration work as Presets. A number of demonstration presets are
loaded on the micro SD card. Each preset holds a set of 8 pad congurations, along
with Mixer, FX, and Input settings. Note that Mute settings are not saved, and the global
Settings (the rst page when you push TOOLS) are saved on the SD Card apart from
the Presets.
Bitbox micro does not save changes automatically. You
have to save your preset to preserve your changes. If
you turn o the module, or change presets, any changes
you have made to the current preset will be lost.
To Save Changes to a Preset:
1. Touch the name of the preset at the top of the
Pads screen (SL Urban Rem Hip Hop in the
screen shot on the right) to display the Preset
Management screen. This screen shows a list
of the presets stored on the microSD card with
a menu across the top. The currently selected
preset is highlighted in blue.
2. Touch Save or touch File then Save As to save
changes. Save is disabled if there are no
unsaved changes. Save As will create a new
preset with the new name, and the old preset
will keep its original settings.
To Load a Preset:
1. Touch the name of the preset at the top of the
Pads screen to access the Preset
Management screen.
2. Turn a knob to select a preset, then touch Load
to make this the active preset.
Note:
► Bitbox micro does not automatically save your changes. Any unsaved changes
will be lost when you load a preset or power down the module.
Page 11 of 88
Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7
Pads Screen
Preset Management
Screen
Preset Management File
Menu

Page 12 of 88 Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7
Page 12 of 88 Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7
To Create and Name a Preset:
1. Touch the name of the preset at the top of the
Pads screen (SL Urban Rem Hip Hop in the
screen shot on the right) to display the Preset
Management screen.
2. Touch File then New in the top menu. This will
create the new preset with a default name, and
display the File Naming screen.
3. Turn the knobs to enter a name for the preset.
File naming works like old school arcade
games. Turn the top knob to move the cursor.
Turn the bottom knob to scroll through letters
alphabetically. First capital letters are
displayed, then lower case, then numbers.
4. Touch Enter to save the name and return to the
Presets screen with the new preset selected.
5. Push the PADS button to start working with
your new preset from the Pads screen.
File Naming Screen
Note:
► When bitbox micro rst starts up, it loads the last preset you used on this
microSD card.

Copyright 1010music LLC 2020 Page 13 of 88
Bitbox Micro User Manual 1.0.7
Copyright 1010music LLC 2020 Page 13 of 88
Bitbox Micro User Manual 1.0.7
PADS OVERVIEW
Pads are the onscreen cells that are used to load WAV les into Presets and to trigger
them. In this section, we will give an overview of the primary screens used when
working with Pads and how to navigate between them. In the next section, we will walk
through settings and tasks for all pads, followed by settings and tasks specic to each
pad mode. Finally, we will discuss how to record single WAV les and automate the
recording of a multi-sample bank.
The Pads Screen
When you rst turn on bitbox micro, the Pads screen is
displayed. If you move away from this screen, you can
get back here by pushing the white HOME button at the
top of the module.
The 8 squares in the bottom two rows of the screen are
the pads. Each pad displays an abbreviated name of the
WAV le or folder mapped to the pad. Each pad can be
mapped to one WAV le or a bank of WAV les. Touch a
pad to trigger it. This will also select it, as indicated by the
pink background. You can also use the knobs to select a
pad without triggering it. Depending on how the pad is
Pads Screen
congured, a triggered sample might play all the way through each time you press it, it
might play only while you are touching the pad, or it might play until you touch it again. A
blue progress bar appears at the bottom of the pad while it is playing. You can trigger
multiple pads at once. Push the Stop button in the top right corner of the screen to halt
playback of WAV les. A white bar at the bottom of a pad indicates the pad is ready to
start at the next quantization break.
The black bar along the top of the screen displays the playback clock and the current
screen name. The number pair on the left displays the overall playback time in
measures and beats.
The Keys button in the top left displays an onscreen keyboard where you can play the
notes by pitch shifting the currently selected pad. The text between the Keys and Stop
buttons is the name of the currently selected preset. Touch this to go to the Preset
Management screen where you can save, load and create new presets.

Copyright 1010music LLC 2020
Page 14 of 88
Bitbox Micro User Manual 1.0.7
There is a series of buttons across the top of the
Waveform screen. The left button is the Pad Selector
Grid. We will talk about that soon. To the right of that, is
the Pad Mode Selector. Touch this button to display the
list of Pad Modes, then touch a pad mode to select it.
The text in the top row, A GrainSting in the screen shot of
the Wave Screen, is the name of the WAV le or directory
loaded into this pad. It may be shortened here. The
button on the right is the Play button. Touch this button to
playback the WAV le. A white cursor will appear on the
screen to show the current play position, and the large
WAV display will scroll as the current play position moves
o screen.
The Waveform Screen
To congure a pad, touch the pad to select it, then push
the white right arrow button ► above the screen. This will
display the Waveform screen for this pad. There are two
versions of the WAV le displayed on the screen. The
large blue wave can zoom in or out using pinch and
stretch touch gestures. The shorter white wave shows the
entire WAV le. You can touch a spot in the white wave
Waveform Screen
display to change the current display area of the larger blue wave. This can be useful
when dealing with long WAV les.
As you turn the top knob, the text in the lower right corner shows you which parameter
you are controlling with the bottom knob. Turn the top knob to the left to select Start,
then turn the bottom knob to move the pink bracket that represents the audio playback
range for the WAV. Turn the top knob to the right to select Length, then turn the bottom
knob to adjust the width of the pink bracket and the length of the WAV le section that
will be played. If Looping is enabled, a white bracket will appear that represents the
looped range. Turning the top knob will now allow you to select Loop Start and Loop
End.
Pad Mode Selection
Screen

Page 15 of 88
Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7
Pad Parameters Screen
Push the right arrow button above the screen again to
display the Pad Parameters screen. This screen displays
one long list of all of the parameters that can be
congured for the current pad. Turn the top knob to select
a parameter, as indicated by the pink highlight. Turn the
bottom knob to select a value for a the highlighted
parameter. If the parameter has three black or blue boxes
on the far right of the screen, this parameter is a
modulation target. Push the right arrow button again to
view the Parameter Modulation screen. We will go into
more detail about modulation later. For now, push the
white left arrow button ◄ to go back to the previous
screen. Push the HOME button to go back to the Pads
screen.
Pad Parameters Screen
Parameter Modulation
Screen
Pad Selector Grid
While on the Wave screen or the Pad Parameters
screen, the grid icon in the top left corner indicates which
pad is currently selected. Touch this icon and a grid will
pop up. Touch a pad in the pop up grid to change which
pad is selected.
Pad Selector Grid
WAV File Selection Screen
The name of the loaded WAV le is displayed at the top
of the Wave Screen and the Pad Parameters screen (A
GrainSting in the screenshots above). Touch this le
name to display the WAV File Selection screen where
you can choose a dierent WAV to load into this pad.
Touch the le or directory you want, and then touch Load.
To either load the le or display the contents of the
directory. Touch the caret ^ button to the left of the File
button to navigate to the parent le folder. Touch the back
arrow <-- to return to the previous screen.
WAV File Selection
Screen

Copyright 1010music LLC 2020
Page 16 of 88
Bitbox Micro User Manual 1.0.7
Multi-WAV Recording Screen
At the top of the WAV Recording Screen, is a small
button labeled 1X. This indicates that you are in single
WAV recording mode. Touch this and select Mx to set up
a multiple WAV recording to automate recording of a
sample bank that can be used to create a set of samples
of various pitches to use in Multi-Sample mode. We will
discuss multi-sample mode and automatic sample bank
recording later.
Multi-Wav Recording
Screen
WAV Recording Screen
If you push the right arrow button above the screen while
on an empty pad, you will see the WAV recording screen.
You can also get to this screen by selecting New Rec
from the Pad Mode menu. Before you record, you will
need to go into the Inputs screen and congure inputs 1
and 2 for audio. Once that is done, a level meter appears
above the list of recording parameters. Scroll through the
parameters and set the options for this recording session.
Then touch Rec at the top of the screen to begin
recording. Push Stop to end recording. The le will be
given a default name and will be stored on the microSD
card. Bitbox micro will then take you to the Pads screen.
Wav Recording Screen

Page 17 of 88
Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7
The Keys Screens
You will nd some new ways to play your samples on the
Keys screen. To start, please load the preset SO Bells &
Chimes that came loaded on the microSD card. Then, on
the Pads screen, select either of the pads named Bell
Rotos, and then push the KEYS button at the top of the
screen. Bitbox micro displays a piano style keyboard on
the screen. Touch some of the keys on the keyboard to
hear the selected pad play pitch shifted by note. You can
adjust which octave is playing by touching the arrow
buttons above the keyboard or by turning a knob. The C
keys are numbered so you can quickly identify which
octave will be playing.
Push the right arrow button above the screen to access
the Keys Grid screen. Use the two buttons in the top right
of the screen to select the Key and Scale that will be
used by the grid keyboard. Now you can play without
worrying about hitting an o-key note.
If you have a slicer pad selected when you are on the
Keys screen, the keys and grid squares will trigger
dierent slices. The rst slice plays with C2.
Keys Screen
Keys Grid Screen

WORKING WITH PADS
Each pad in bitbox micro can be assigned a WAV le or a folder of WAV les. You can
congure playback options, such as trigger mode and looping, individually for each pad.
Once a pad is loaded, you can touch the pad on the main Pads screen to trigger it. You
can also use the Keys screen to play the currently selected pad. When you trigger a pad
from the Keys screen, a pad with a single WAV le is pitch shifted to correspond to the
note played. Multi-sample pads play the WAV le with a root note closest to the played
note, with pitch shifting if needed. We’ll talk more about multi-samples later.
Steps Common to All Pad Modes
The tasks in this section apply to all pads, no matter which pad mode you select. The
rst task to create a new pad is to select the WAV le or les and then set the Pad
Mode.
To Select WAV Files and Assign Pad Modes:
Push HOME until you are on the Pads screen. This screen has two rows of 4 pads
each, for a total of 8 pads. A WAV le or folder of WAV les can be assigned to each of
these pads, and each pad is assigned a Pad Mode.
Bitbox micro supports the following pad modes:
Icon Pad Mode Description Reverse Playback Beat Sync
Set
Loop
Points Play Slices Poly- phony
Sample Use to play single notes or
drum hits. You can control
start and end points for
playback and looping.
Supports reverse
playback, along with
forward and bidirectional
looping.
√ √
8 notes
Sample:
Multi-
Sample
Mode
Spread a folder full of wav
les across the keyboard
to get more realistic
instrument pitch shifting or
to map dierent sounds to
each key on the keyboard.
8 notes
Clip Use for synchronized
loops and quantized
playback, e.g. drum loops
and guitar tracks between
one and eight measures
long.
√
2 notes
Page 18 of 88 Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7

Page 19 of 88
Copyright 1010music LLC 2020
Bitbox Micro User Manual 1.0.7
Icon Pad Mode Description Reverse Playback Beat Sync
Set
Loop
Points Play Slices Poly- phony
Slicer Use with a WAV le with
dierent sections that
you want to trigger
independently.
√
2 notes
Granular Generate new sounds
from your samples. The
sample is played back in
small portions about 10
to 200ms in length,
called grains.
√ √
mono
New Rec Use to start recording a
new WAV le or clear a
WAV from a pad.
New Multi Automate recording of
multiple samples across
a range of notes
triggered via MIDI.
Each pad can have a dierent Pad Mode. You can use the same WAV le in dierent
pads in dierent Pad Modes. To load a WAV le into a pad:
1. Push the HOME button to bring up the Pads screen.
2. Select a pad by touching it or using the control knobs to cycle through the
pads. (The top control knob moves the selection horizontally. The bottom
control knob moves the selection vertically.) The selected pad is highlighted
pink. Touching a pad that is loaded with a WAV le will also trigger playback of
the pad.
3. Push the white right arrow button ► above the screen. If the pad was empty,
the WAV Load and Record screen will be displayed. If the pad already had a
WAV le assigned, the Waveform screen will be displayed.
WAV Load and Record
Screen Waveform Screen WAV File Selection Screen

Note:
► There may be considerable dierences in volume levels of WAV les depending
on how they were originally recorded. Be careful when previewing the WAVs on
the load screen or you could get a rude surprise if you switch between soft and
loud WAV les.
4. If you are on the WAV Load and Record screen, touch Load in the top menu
bar. If you are on the Waveform screen, touch the name of the WAV le at the
top of the screen (A GrainSting in the example). You will now be on the WAV
File Selection screen.
5. From the WAV le selection screen, use the control knobs to scroll through
the list of les. Bitbox micro displays the directories at the top of the list
followed by the individual les in alphabetical order. The selected le or
directory name has a blue highlight. Touch Play to preview the highlighted le.
The Play button will turn blue to show that auto-preview is enabled. Bitbox
micro will play each WAV le once when you pause on it while scrolling. If you
have a CV trigger or a MIDI input trigger playing for this pad, bitbox micro will
play the selected WAV le whenever a trigger is received for this pad. Touch
the Play button again to disable auto-preview mode. Touch Load to assign the
selected WAV le to this pad. When looking at the list of les, list items that
start with a slash \ are directories. Load a directory to see its contents. The le
path is displayed above the list of les (e.g. SoundtrackLoops\SL Bass Mu in
the example above.) Touch the caret ^ to navigate back up the directory tree.
Touch the back arrow to go back to the previous screen.
To View Wave with Start, End, Loop and Slice Points:
Once you have loaded a WAV le, you will be on the
Waveform screen. There are a number of important
features on the Waveform screen. The grid icon in the top
left of the screen, immediately below the clock counter,
provides a graphical representation of which pad in the
grid you are conguring. You can touch it to bring up a
pad selection grid. Touch a square in the grid to change
which pad you are working with. The icon just to the right
of that is a button that allows you to select the Pad Mode.
The text in the top bar displays the rst characters of the
name of the loaded WAV le, and can be touched to
choose a dierent le. Trigger playback by touching the
arrow button on the right.
Waveform Screen
Copyright 1010music LLC 2020
Page 20 of 88
Bitbox Micro User Manual 1.0.7
