3Disc FireCR Flash User manual

User Manual
Computed Radiography Reader
Doc No. : TM-401-EN
Rev 0.1.1 Aug 2013
Part No. : CR-FPM-44-001-EN
3DISC, FireCR, Quantor and the 3D Cube are trademarks of 3D Imaging & Simulations Corp,
South Korea, and its affiliates. All other trademarks are held by their respective owners and
are used in an editorial fashion with no intention of infringement. The data in this publication
are for illustration purposes only and do not necessarily represent standards or specifications,
which must be met by 3D Imaging & Simulations Corp. All information contained herein is
intended for guidance purposes only, and characteristics of the products and services described
in this publication can be changed at any time without notice. Products and services may not
be available in your local area. Please contact your local sales representative for availability
information. 3D Imaging & Simulations Corp. strives to provide as accurate information as
possible, but shall not be responsible for any typographical error.
© Copyright 2010 3D Imaging & Simulations Corp, all rights reserved, printed, and published
in South Korea by 3D Imaging & Simulations Corp.

User Manual
FireCR Flash TM-401-EN
2
3DISC Americas
22560 Glenn Dr, Suite 116
Sterling, VA 20164 USA
Tel : [phone]
E-mail : [email protected]
Contact
815, Tamnip-Dong, Yuseong-Gu,
Daejeon, Korea
Tel : [phone]
Fax : [phone]
Website : www.3DISCimaging.com
E-mail : [email protected]
3DISC Europe
Gydevang, 39-41, 3450 Alleroed, Denmark
Tel : [phone]
E-mail : [email protected]

User Manual
FireCR Flash TM-401-EN
3
The device complies with Part 15 of the FCC Rules. Operation is subject to the condition
that this device does not cause harmful interference.
NOTE : This equipment has been tested and found to comply with the limits for a Class B Digital
Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction, may cause harmful interference to radio communication. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment dose
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures : - Reorient or relocate the receiving antenna. - Increase the
separation between the equipment and receiver - Connect the equipment into an outlet on a
circuit different from that to which the receiver is connected. - Consult the dealer or an
experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference. and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications (including the antenna) made to this device that are not expressly approved by the
manufacturer may void the user’s authority to operate the equipment.

User Manual
FireCR Flash TM-401-EN
4
Warnings and Used Symbols
To ensure the safety of patients, staff and other persons, any changes to software and hardware
delivered by 3D Imaging & Simulations Corp. may only be made with prior written permission
from 3D Imaging & Simulations Corp.
Please read the respective manuals of the connected software, such as acquisition and
diagnostic software, before starting to use the FireCR Flash system.
The following symbols will be used throughout this manual:
DANGER
The functionality of the system can be destroyed in the case of
incorrect use.
If unauthorized changes have been made to delivered system and
accessories, the warranty by 3D Imaging & Simulations Corp.
becomes void. 3D Imaging & Simulations Corp. will not accept
any responsibility or liability for the proper functioning of the
product in such a case.
DANGER
General mandatory action manual.
The functionality of the system can be destroyed in the case of
incorrect use.
If unauthorized changes have been made to delivered system and
accessories, the warranty by 3D Imaging & Simulations Corp.
becomes void. 3D Imaging & Simulations Corp. will not accept
any responsibility or liability for the improper functioning of the
product in such a case.
WARNING
The functionality of the system can be limited in the case of
incorrect use. Hints that require special attention.
NOTE
Notes represent information that is important to know but which do
not affect the functionality of the system.

User Manual
FireCR Flash TM-401-EN
5
General Safety Guidelines
All the safety and operating instructions should be read carefully before this device is operated.
This device has been designed and tested to meet strict safety requirements applicable to
medical equipment, and has been supplied in a safe condition. To ensure personnel and
patient safety, the device shall be operated and serviced in compliance with all procedures,
warnings and precautions during all phases of operation and service of this device. Failure to
comply to with safety guidelines may result in injury to service personnel, operator, or patient.
3D Imaging & Simulations Corp. assumes no liability for failure to comply.
If this device is not used as specified, the protection provided by the device could be impaired.
This device must be used in a normal condition only.
Installation, service and operation of this device should only be undertaken by qualified trained
personnel. The operator should study instructions and precautions carefully before starting to
use the device listed here and throughout the manual.
There are no user serviceable parts inside this device. The device should only be opened and
serviced by qualified service personnel. Failure to heed this warning may result in injury to
service personnel or damage to equipment, and void any and all warranties. If there is a
service problem, please contact 3D Imaging & Simulations Corp. or authorized dealer.
Do not spill liquids on the device, and never operate the device in a wet environment.
Keep the device from radiators and heat sources.
Use the device only with accessories supplied with this device.
This device is intended to be grounded. Plug power cord into properly grounded electrical
outlets. This cord is equipped with three-prong plugs to help ensure proper grounding.
This device contains static sensitive components. Proper static handling procedures and
equipment must be used when servicing this device.

User Manual
FireCR Flash TM-401-EN
6
Do not look inside of the device.
If any of the following conditions occur, unplug the device from the electrical outlet and contact
authorized service personnel.
zThe power cord or power adapter is damaged.
zAn object has fallen into the device.
zThe device has been exposed to water.
zThe device has been dropped or damaged.
zThe device does not operate correctly when the operating instructions are followed.
Intended Use
This device is a Computed Radiography System and intended for use in producing digital X-Ray
images for general radiography purposes. It comprises of reader, cassette with reusable
imaging plate and workstation software. It scans X-Ray exposed image plate and produces X-
Ray image in digital form. Then, digital image is transferred to workstation for further
processing and routing. This device is intended to be operated in a radiological environment
by qualified staff.
FireCR Flash is not approved for the acquisition of mammographic image data.

User Manual
FireCR Flash TM-401-EN
7
Index of contents
Chapter 1. Introduction.....................................................................9
Chapter 2. Unpacking......................................................................11
2.1. Inspection for Damage ....................................................................11
2.2. Identify the Components..................................................................11
Chapter 3. Setting Up.....................................................................15
3.1. Tabletop Mount............................................................................... 15
3.2. Wall Mount (Option)........................................................................ 16
3.3. Identify Important Features............................................................. 18
3.3.1. Reader Connecting Part........................................................... 18
3.3.2. Reader Status Indication LED................................................... 19
3.3.3. Reader Reset Button................................................................ 19
3.4. Computer Requirements ................................................................ 19
3.4.1. Recommended Requirement.................................................... 19
3.4.2. Minimum Requirement ............................................................. 20
3.5. Installation of Acquisition and Diagnostic Software......................... 20
3.6. Connect the Cable and Power Cord............................................... 20
3.6.1. Connect Interface Cable........................................................... 20
3.6.2. Connect the Power Cord .......................................................... 21
3.6.3. Installation Report..................................................................... 21
Chapter 4. Operating......................................................................22
4.1. System Specifications .................................................................... 22
4.2. Operation Conditions...................................................................... 23
4.3. Operating Instructions .................................................................... 24
4.3.1. Turn on the Reader................................................................... 24
4.3.2. Turn on the Computer............................................................... 24
4.3.3. Cassette Insert and Eject ......................................................... 24
4.3.4. Getting a Scanned Image......................................................... 24
4.3.5. Circuit Functions....................................................................... 25

User Manual
FireCR Flash TM-401-EN
8
Chapter 5. Symbols........................................................................26
5.1. Manufacturer’s Declaration – Electromagnetic Emission................ 27
5.2. Manufacturer’s Declaration - Electromagnetic Immunity ................ 28
5.3. Guidance and Manufacturer’s Declaration – Electromagnetic
Immunity..................................................................................................... 31
5.4. Laser Safety Statement.................................................................. 32
Chapter 6. Warranty and Repair Service........................................33
6.1. Standard Warranty.......................................................................... 33
6.2. Repair Service................................................................................ 33
6.3. Out of Warranty Repair Service...................................................... 33
6.4. Shipping ......................................................................................... 34
Chapter 7. Technical Assistance..................................................... 35

User Manual
FireCR Flash TM-401-EN
9
Chapter 1. Introduction
Thank you very much for deciding on FireCR Flash – Computed Radiography Reader.
The FireCR Flash System is ideal for a wide range of Computed Radiography examinations in
specialty practices such as chiropractors, podiatrists and orthopedists.
The FireCR Flash can be configured for nearly every clinical application, and is designed for full
DICOM connectivity, and allows user to setup the system to capture high quality X-ray images
of any body parts with minimal steps including reading, processing, displaying and sending of
the high quality image. All imaging parameters are optimized, resulting in digital images that
can be enhanced, enlarged, duplicated, and sent to any location as a DICOM 3.0 file format in
seconds with no loss of resolution.
Combine the system with reusable phosphor screen equipped FireCR Flash cassettes and
portable X-ray equipment, it can be used for X-ray exams everywhere it is needed, e.g. nursing
facilities, forensic institutions, employee screenings etc.
The FireCR Flash System is ideal for Computed Radiography examinations in busy clinics and
specialty practices. Affordable, rugged, compact, lightweight, fast and effective FireCR Flash
System enables all imaging functions to be performed with the advanced image management
software, a solution that can be adapted most clinical applications.
The FireCR Flash Computed Radiography solution with enhanced workflow and improved
productivity are the best solution for medium sized healthcare facilities and clinics. The FireCR
Flash System complements centralized CR and DR environments such as clinics, ER and OR
departments.

User Manual
FireCR Flash TM-401-EN
10
Main Features
State-of-the-Art Scanning Mechanism
FireCR Flash adopts state-of-the-art scanning mechanisms using high beam delivery efficiency
optics module to construct its compact and rigid structure.
High Throughput
Its unique and patented dual direction scanning mechanism enables to improve the efficiency
and high throughput.
Scanning Resolution
User selectable resolution of 100μm and 200μm allows user to make diagnosis on variable
purposes.
Detector
High sensitive photomultiplier tube equipped in FireCR Flash delivers high gain, wide dynamic
range and high speed response for radiographic imaging.
Powerful Acquisition and Diagnostic Software
Acquisition and Diagnostic Software designed for the FireCR Flash, and its accurate and rapid
data processing make the reader more powerful.

User Manual
FireCR Flash TM-401-EN
11
Chapter 2. Unpacking
2.1. Inspection for Damage
FireCR Flash is shipped in a custom designed container to protect the reader from external
shock. Before unpacking the reader, inspect the shipping container for damage. In case the
container is damaged, notify the shipper immediately.
2.2. Identify the Components
Identify each of these components.
Part No. Item
CR-FP-41-001 FireCR Flash CR Reader
CR-FP-02-003 Universal Cassette 35 x 43 containing IP size 35cm x 43cm
CR-FP-02-004 Universal Cassette 25 x 35 containing IP size 24cm x 30cm
CR-FP-32-001 Universal Cassette 24 x 30 containing IP size 24cm x 30cm
CR-FP-32-002 Universal Cassette 18 x 24 containing IP size 18cm x 24cm
CR-FPA-02-001 USB 2.0 Interface Cable
CR-FPA-02-002 RJ45 CAT.5E FTP Cable 2M (Cross type)
CR-FPA-03-00X Power Cord
CR-FPM-44-001 FireCR Flash User Manual
CR-FP-35-001 FireKit (Optional Product Identification Card)
CR-FP-04-021 QuantorMed Plus Acquisition and Diagnostic Software
CR-FP-04-026 QuantorMed Dongle
CR-FPM-04-021 QuantorMed Plus User Manual
WARNING
If the FireCR Flash needs to be returned to manufacturer or one
of its representatives, the scanner must be repacked in the
original container with all accessories.

User Manual
FireCR Flash TM-401-EN
12
FireCR Flash CR Reader
Power Cord
WARNING
Use of Power Cord;
Type SJT or SVT, min. 18AWG, 3-Conductor, VW-1 125V, min 10A
(or 250V, 10A). Max 3.0m long; One end with Hospital Grade
Type, NEMA 5-15P for 125V or NEMA 6-15P for 250V. Other end
with appliance coupler. “CAUTION Grounding reliability can only
be achieved when the equipment is connected to an equipment
receptacle marked “Hospital Only” or “Hospital Grade”.
For connection to supply not in USA, make sure the power cord is
the correct type that is required in your area.
WARNING
Improper disposal of this product may result in environmental
contamination. When disposing of this equipment, contact 3D
Imaging & Simulations Corp.’s representative or related organs
of government. Do not dispose of any part of this equipment
without consulting a 3D Imaging & Simulations Corp.’s
representative first.
3D Imaging & Simulations Corp. does not assume any
responsibility for damage resulting from disposal of this equipment
without consulting 3D imaging & Simulations Corp.
WARNING
Use the device passed IEC60950-1 or IEC60601-1 for the product
connected via USB port.

User Manual
FireCR Flash TM-401-EN
13
Universal Cassette 35 x 43 containing IP size
35cm x 43cm
Universal cassette 25 x 35 containing IP
size 24cm x 30cm
Universal cassette 24 x 30 containing IP size
24cm x 30cm
Universal Cassette 18 x 24 containing IP
size 18cm x 24cm
USB 2.0 Interface cable
RJ45 CAT.5E FTP Cable 2M (Cross type)
FireCR Flash User Manual
QuantorMed Plus User Manual
QuantorMed Plus Acquisition and Diagnostic
Software
QuantorMed Dongle

User Manual
FireCR Flash TM-401-EN
14
FireKit

User Manual
FireCR Flash TM-401-EN
15
Chapter 3. Setting Up
3.1. Tabletop Mount
The reader must be placed on a rigid and flat desk or tabletop with at least 10 cm (4 inch) free
space on both sides, 20 cm (8 inch) on rear side and 50 cm (20 inch) on front side for cassette
insertion. Its space requirements are shown below.
In case that desk or table is not flat, adjust feet under the reader for leveling. The reader
weighs approximately 21.5 kg (47 lbs) and requires two persons to lift. Carefully place the
reader into its final position.
WARNING
Unsuitable Installation Sites
Locations with excessive humidity or dust
Locations subject to high temperature
Locations subject to shaking or vibration
Locations exposed to considerable electrical or magnetic
noise, or other forms of electromagnetic energy
Locations with poor heat radiation
Free space of 20 cm (8
inch) on backside, at
least, to allow the power
switch, power cord and
USB cord to be reached
by hand at all times.
Free space of 50 cm (20
inch) on front side, at
least, for cassette insertion
and ejection.
Front Side Backside

User Manual
FireCR Flash TM-401-EN
16
3.2. Wall Mount (Option)
The FireCR Flash can be mounted on the wall to save space occupancy. When purchasing
the wall mount kit, a detailed installation guide and all parts necessary for assembly are
provided.
DANGER
Never place the reader on the floor.
Sliding the reader may result in internal damage or misalignment
of the optics.
Install in a location that is level and stable. Installation in an
unsuitable location can cause accident, or deterioration in image
quality.
WARNING
Sliding the reader may result in internal damage or misalignment
of the optics.
External vibration or shock during scanning may affect image
quality. The scanner must be placed on rigid, flat and reinforced
desk or tableto
p
.
WARNING
Do not place anything on top of the scanner.
WARNING
This equipment may be interfered or interfere by electromagnetic
or other interference.
Assure a distance of minimum 1.0 m with neighboring equipment.

User Manual
FireCR Flash TM-401-EN
17
NOTE
Refer to Wall Mount Installation Guide provided with Wall Mount
Installation Kit.
DANGER
Only authorized or trained personnel should set wall mount
installation.
Free space of 10 cm
(4 inch) on both
sides, at least.
Front Side
Back Side
Free space of 20 cm (8 inch) on back side, at least, to allow the
power switch, power cord and USB cord to be reached by hand
at all times.
Free space of 50 cm (20 inch) on top side, at least, for cassette
insertion and ejection.

User Manual
FireCR Flash TM-401-EN
18
3.3. Identify Important Features
Look over the reader and features shown in this section. User will need to know where these
features are when user operates the reader in later chapters.
3.3.1. Reader Connecting Part
DANGER
Install the wall mount on a solid wall perpendicular to the floor.
When attaching to other building materials, please contact your
local dealer. If installed on a slanted wall, it may fall and result in
severe injury.
DANGER
3D Imaging & Simulations Corp. is not liable for product damage or
personal injury when the user fails to follow the product installation
instruction.
WARNING
Pulling, pushing, or climbing on the system may cause the system
fall.
USB 2.0 Port
Power Inlet
Power Switch
Ethernet Port

User Manual
FireCR Flash TM-401-EN
19
3.3.2. Reader Status Indication LED
Indication LED shows the status of the reader as described below.
LED Status Remark
Green Blue
On System On
On Ready to Scan Cassette is in initial position, and
ready to scan.
Blinking Scanning
Blinking Erasing
Blinking Blinking Error
3.3.3. Reader Reset Button
In case that the reader is stuck during scanning, push reader reset button by sharp pin to
initialize the reader.
3.4. Computer Requirements
3.4.1. Recommended Requirement
Operating System Microsoft Windows 7, 8
CPU Intel CORE i5
Memory RAM 4 GB or more
WARNING
Do not push scanner reset button during scanning.
Reader Reset Button

User Manual
FireCR Flash TM-401-EN
20
Hard Disk 500 GB Free Hard Disk Space
Network 1 Gbps Ethernet
Video 32-bit Color Display
Video Resolution 1920 x 1080, 1440 x 900
3.4.2. Minimum Requirement
Operating System Microsoft Windows XP
CPU Intel Processor
Memory RAM 2 GB or more
Hard Disk 80 GB Free Hard Disk Space
Network 1 Gbps Ethernet
Video 32-bit Color Display
Video Resolution 1366 x 768, 1280 x 800, 1600 x 900, 1280 x 1024
3.5. Installation of Acquisition and Diagnostic Software
Refer to Acquisition and Diagnostic Software manual.
3.6. Connect the Cable and Power Cord
3.6.1. Connect Interface Cable
The reader interfaces with computer via USB2.0 cable or Ethernet cable. (RJ45 CAT.5E FTP)
1. Use the USB / Ethernet cable in the shipping container.
2. Connect the cable to the reader’s USB2.0 / Ethernet port, located on the rear of the
reader.
3. Connect the other end of the cable to the USB2.0 / Ethernet port on the computer.
DANGER
This equipment is indoor use only and all the communication
wirings are limited to inside of the building.
WARNING
Do not pull out the USB / Ethernet cable during scanning.
