3Dlabs Oxygen GVX420 User manual

The Oxygen
The OxygenThe Oxygen
The OxygenTM
TMTM
TM
GVX420
GVX420GVX420
GVX420
Graphics Accelerator
Graphics AcceleratorGraphics Accelerator
Graphics Accelerator
User
UserUser
User’
’’’s Guide
s Guides Guide
s Guide
3Dlabs,® Inc.
480 Potrero Avenue
Sunnyvale, CA 94086
408 - 530 - 4700
www.3dlabs.com

3Dlabs Oxygen GVX420 User's Guide
ii
Copyright 2000 by 3Dlabs, Inc.
3Dlabs, GLINT and Permedia are registered trademarks, and Oxygen and PowerThreads are trademarks of
3Dlabs, Inc. or 3Dlabs Inc. Ltd. Pentium is a registered trademark of Intel. OpenGL is a registered trademark
of Silicon Graphics, Inc. Soft Engine is a trademark of Vibrant Graphics, Inc. AutoCAD is a registered
trademark of AutoDesk Inc. Colorific is a registered trademark of E-Color, Inc. Microsoft, Windows NT,
Windows 2000 are registered trademarks of the Microsoft Corporation. Athlon and 3DNow! are registered
trademarks of AMD. All other trademarks and registered trademarks are the property of their respective
holders.
Caution: Changes or modifications to the Oxygen GVX420 graphics accelerator card not expressly approved
by 3Dlabs, Inc. voids the user’s warranty.
FCC Notice: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy. If product is not installed and used in accordance with the instruction manual, it may cause
harmful interference to radio communications; however, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Re-orient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
4. Consult 3Dlabs or an experienced radio/TV technician for assistance.
Compliance with FCC Rules requires that a shielded cable be used to connect to other equipment. This
device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this
device may not cause harmful interference, and 2) this device must accept any interference received, including
interference that may cause undesired operation.
This Class B digital apparatus meets all the requirements of the Canadian Interference- Causing Equipment
Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le material
brouilleur du Canada.
3Dlabs, Inc. makes no representation that the use of its products in the manner described in this publication
will not infringe on existing or future patent rights, nor do descriptions contained in this publication imply
the granting of licenses to make, use, or sell equipment or software in accordance with the description.
Specifications Subject to Change With Notice
P/N 62-000004-001, Rev. A (Final)

3Dlabs Oxygen GVX420 User's Guide iii
C
CC
CONTENTS
ONTENTSONTENTS
ONTENTS
Introduction.........................................................................................................................v
Welcome to 3Dlabs! ........................................................................................................vi
System Requirements ...................................................................................................ix
Software Partners ..............................................................................................................x
Chapter 1 - Installation ........................................................................................................1
Getting Ready...................................................................................................................2
Before You Start ........................................................................................................2
Installing Hardware ..........................................................................................................3
To remove an old card from your system...................................................................3
To install your Oxygen GVX420...............................................................................3
Installing Software ............................................................................................................5
To uninstall an old video driver .................................................................................6
To install the Oxygen Windows NT driver................................................................6
To install the Oxygen Windows 2000 driver .............................................................6
To uninstall the Oxygen GVX420 Windows NT or Windows 2000 drivers..............6
To install SoftEngine.................................................................................................7
To install Colorific ....................................................................................................7
Registering Oxygen GVX420............................................................................................8
Chapter 2 - Software Configuration .....................................................................................9
The Oxygen GVX420 Driver .........................................................................................10
The Task Bar - based Configuration Manager .............................................................10
The Display Control Panel..........................................................................................11
Configuring Multiple Monitors ......................................................................................12
To configure a second monitor in Windows NT .....................................................12
To configure a second monitor in Windows 2000 ...................................................13
Configuring your Oxygen GVX420 Card for Stereo Viewing .........................................14
To set up and configure stereo viewing ....................................................................14
Chapter 3 - Troubleshooting ..............................................................................................17
Troubleshooting .............................................................................................................18
Monitors and Display Resolutions ..................................................................................18
Systems and Networks ....................................................................................................18
Online Information ........................................................................................................19

3Dlabs Oxygen GVX420 User's Guide
iv
Appendix A - Specifications................................................................................................20
Oxygen GVX420 Specifications......................................................................................21
Monitor Resolutions.......................................................................................................21
Appendix B - Software License ...........................................................................................22
SOFTWARE LICENSE AGREEMENT........................................................................23
Software License and Restrictions................................................................................23
Limited Warranty ...........................................................................................................24
Limited Liability .........................................................................................................24
Restricted Rights Notice..............................................................................................24
Termination................................................................................................................24
General .......................................................................................................................25
Appendix C - Regulatory Statements ..................................................................................26
Declaration of Conformity..............................................................................................27
Appendix D - Glossary .......................................................................................................28
Terms and Definitions....................................................................................................29
Index..................................................................................................................................33

I
II
INTRODUCTION
NTRODUCTIONNTRODUCTION
NTRODUCTION

Introduction
3Dlabs Oxygen GVX420 User's Guide
vi
Welcome to 3Dlabs!
Welcome to 3Dlabs!Welcome to 3Dlabs!
Welcome to 3Dlabs!
Thank you for selecting the 3Dlabs®Oxygen™GVX420 graphics accelerator card!
Oxygen GVX420 delivers high-end geometry and rasterization graphics acceleration on a single
AGP/AGP Pro card for the most demanding workstation professional. By integrating two 3Dlabs GLINT
R4 rasterizers, the new generation GLINT Gamma G2 geometry processor and 128MB of memory on a
single card, Oxygen GVX420 boosts the interactivity of huge models with a 256-bit memory bus.
Oxygen GVX420

Introduction
3Dlabs Oxygen GVX420 User's Guide vii
Overview
OverviewOverview
Overview
Your Oxygen GVX420 card has the following features:
•Seamless Dual-head support
Oxygen GVX420 supports dual high-resolution displays under Windows NT 4.0 and Windows
2000 from a single card, seamlessly supporting a total multi-monitor true-color desktop size of up to
4096 x 1536. The two VGA connectors and two DVI connector allow you to connect either two
VGA monitors, two DFP monitors, or one VGA monitor and one DFP monitor.
•Dual GLINT R4 rasterization processors
The dual GLINT R4 processors doubles rasterization performance for sustained productivity with
more textures and higher resolution screens.
•GLINT Gamma G2 geometry processing
On-board hardware geometry acceleration boosts the interactivity of large models by up to three
times and offloads the CPU for increased application performance. The 5Gflop new generation
GLINT Gamma G2 processes 100% of the OpenGL geometry pipeline in silicon, including 16
simultaneous light sources.
•Virtual Textures
Oxygen GVX420 implements 3Dlabs unique full demand-paged virtual texture sub-system in
hardware, using on-board graphics memory to cache up to 256MB of textures stored in main system
memory. Oxygen GVX420 allows you to manipulate up to 256MB of textures, seamlessly from your
favorite applications.
•PowerThreads SSE OpenGL Drivers
3Dlabs’ new-generation PowerThreads SSE and 3DNow! OpenGL drivers are fully optimized for
Pentium III and Athlon processors to dynamically load balance the geometry and lighting load
between the GLINT Gamma hardware geometry processor and host CPU. PowerThreads SSE and
3DNow! give you the power of geometry hardware plus the additional power of Pentium III’s SSE-
instructions or Athlon's 3DNow! instructions for full performance scalability with faster host CPU’s.
•Dynamic load balancing
When the GLINT Gamma processor is busy, geometry and transform calculations are automatically
shared between the CPU and the GLINT Gamma.
•High-resolution Digital Flat Panel Output
The Oxygen GVX420 is pre-configured with a factory-installed daughter card that provides support
for digital flat panel displays through two Digital Video Interface (DVI) connectors. The daughter
card provides improved on-screen image quality at resolutions up to 1280 x 1024 on two monitors.
•Quad-buffered stereo
Left and right buffers are flipped simultaneously to preserve synchronization in your stereo 3D
images at resolutions up to 1280 x 1024.
•128 MB memory
128 MB of SGRAM memory supports high-precision, high-performance acceleration.
•High-precision, high resolution display
Your Oxygen card has dual 300 MHz RAMDACs enabling flicker-free resolutions up to 2048 x
1536 on a single monitor or 4096 x 1536 with two monitors connected.

Introduction
3Dlabs Oxygen GVX420 User's Guide
viii
•16, 24, and 32-bit linear Z-buffer
The Z-buffer provides the highest level of depth-precision, even at the highest resolutions.
•Full AGP support
Full AGP support ensures high-performance 3D acceleration through the advanced features of the
AGP/AGP Pro bus.
•SoftEngine AutoCAD support
SoftEngine enhances AutoCAD R12, R13, R14, and LT performance by up to four times on
Windows NT systems.
•Colorific screen-to-print color matching
Colorific simplifies color matching without sacrificing accuracy.
•Control Panel Application Configuration
3Dlabs’ advanced control panel and task-bar applet let you optimize your system configuration for
your favorite professional applications in just three mouse clicks.

Introduction
3Dlabs Oxygen GVX420 User's Guide ix
System Requirements
System RequirementsSystem Requirements
System Requirements
Your system needs a minimum of the following features in order to support Oxygen GVX420:
•Intel Pentium II or AMD Athlon K6 or compatible, 166 MHz system
•Windows®NT 4.0 Service Pack 5.0 or later or Windows 2000 operating system.
•Minimum 64 MB RAM (Random Access Memory)
•16 MB available hard drive space
•AGP/AGP Pro and adjacent PCI expansion slots
•VGA multisync monitor or DVI digital flat panel

Introduction
3Dlabs Oxygen GVX420 User's Guide
x
Software Partners
Software PartnersSoftware Partners
Software Partners
Your Oxygen GVX420 card and drivers are designed to optimize the performance of a variety of software
applications, several of which are listed below. Many of these applications are also tuned to the Oxygen
GVX420 to further improve the performance that you will see when using the card, drivers, and application
together. For the most current information about applications support, testing, and certification status, please
visit www.3dlabs.com.
Software Application
Software ApplicationSoftware Application
Software Application Web Site Address
Web Site AddressWeb Site Address
Web Site Address
AutoCAD http://www.autodesk.com
Colorific http://www.colorific.com
3D Studio MAX http://www.ktx.com
Lightscape http://www.lightscape.com
LightWave 3D http://www.newtek.com
Maya http://www.aw.sgi.com
MicroStation http://www.bentley.com
Pro/ENGINEER http://www.ptc.com
SDRC I-DEAS http://www.sdrc.com
Softimage | 3D http://www.softimage.com
SolidWorks http://www.solidworks.com
Unigraphics http://www.ug.eds.com/

C
CC
CHAPTER
HAPTERHAPTER
HAPTER 1 - I
1 - I1 - I
1 - INSTALLATION
NSTALLATIONNSTALLATION
NSTALLATION

Installation
3Dlabs Oxygen GVX420 User's Guide
2
Getting Ready
Getting ReadyGetting Ready
Getting Ready
To successfully use your new Oxygen GVX420 card, you must install the card and the accompanying driver
software. Whether you install your new card or the driver first depends on whether a video card is already
present in your system.
If there is a video card in your system: Uninstall the drivers for the existing card, then install the Oxygen
driver. Once the new driver is loaded, remove the old card and install your Oxygen GVX420 card. The
instructions for uninstalling an old driver and installing the new driver begin on page 3.
If there is not a video card in your system: Install your new card as described in the Installing Hardware
section, below, then install the driver.
Once the basic installation is complete, you can choose to install the SoftEngine and Colorific enhancements
as described on page 7.
Note: Be sure to register your new card using one of the options described on page 8.
Before You Start
Take every possible precaution against static electricity as you prepare to install the card: static can
damage components. We have included an anti-static wrist strap for you to wear while installing the
hardware: you should also try to work in a static free area (such as on a tile floor rather than carpet).
You might even consider wearing special ESD, or at least rubber-soled, shoes.
Save any work in progress and exit any open applications. Always back up your system before you
install new hardware or software.
Have your anti-static strap and a Philips-head screwdriver ready.

Installation
3Dlabs Oxygen GVX420 User's Guide 3
Installing
InstallingInstalling
Installing Hardware
HardwareHardware
Hardware
Your Oxygen GVX420 card is designed to work in an AGP or AGP Pro slot, and the adjacent PCI slot, in
your system. Check the documentation for your system to locate the AGP or AGP Pro expansion slot.
To remove an old card from your system
1. Make sure you have uninstalled any old drivers and installed the Oxygen driver in their place.
2. Turn off and unplug the power source for your system and each of its peripherals.
3. Unplug the monitor cable from the old card.
4. Remove the cover from your system.
5. Attach the anti-static strap to your wrist, and attach the other end to a bare, conductive (as opposed
to painted or sticker-covered) area of your system’s chassis.
6. Remove any screws securing the card to the chassis.
7. Lift the card out of the slot.
To install your Oxygen GVX420
1. Turn off and unplug the power source for your system and each of its peripherals, if you have not
already done so.
2. Remove the cover from your system so you can access an appropriate expansion slot. See your system
documentation for the AGP or AGP Pro slot location.

Installation
3Dlabs Oxygen GVX420 User's Guide
4
3. Locate the AGP or AGP Pro slot and remove its slot cover. The PCI slot adjacent to the AGP or
AGP Pro slot must be empty to make room for the daughter card.
4. Remove the slot cover from the PCI slot adjacent to the AGP or AGP Pro slot.
5. Attach the anti-static strap to your wrist, and attach the other end to a bare, conductive (as opposed
to painted or sticker-covered) area of your system’s chassis.
6. Remove the card from its anti-static packaging. Write down the serial number for registration and
future use.
7. Align the connector on the Oxygen GVX420 card over the AGP or AGP Pro slot and the connector
on the daughter card over the adjacent PCI slot before attempting to seat the cards.
Important! See your system documentation for instructions on securing the card to the chassis.
Loose cards and connections can cause grounding and operating problems.
8. Remove the anti-static strap and replace the cover on your system.
Installing Oxygen
GVX420 with
DVI daugher card

Installation
3Dlabs Oxygen GVX420 User's Guide 5
9. Connect the video cable from your monitor to one of the VGA connectors on the base board or one
of the DVI connectors on the daughter card. Always connect your first or only monitor to a
connector marked "1" and then connect your second monitor (if used) to one of the connectors
marked "2".
10. If you want to attach a second monitor, connect the second monitor to either the VGA or DVI
connector marked "2". The Oxygen GVX420 card supports multi-monitor functionality on one
card. You can connect either two VGA monitors, two DFP monitors, or one VGA monitor and one
DFP monitor.
11. Plug in and start up your system, including peripherals, and log on to your operating system.
Installing Software
Installing SoftwareInstalling Software
Installing Software
The Oxygen Product CD-ROM for the Oxygen GVX420 includes Oxygen PowerThreads video driver software,
which lets you set image quality and performance preferences for your card. It also includes the Soft Engine
AutoCAD accelerator and productivity tool package, and Colorific screen-to-print color matching software.
Installing Soft Engine on your AutoCAD equipped system will improve graphics performance by up to four
times, while Colorific painlessly ensures that what you see is what you print.
This section describes the two software installation processes for supported Windows operating systems.
DVI connectors
for flat panel
displays
Stereo
connector
1
2
1
2
VGA connectors DVI connectors

Installation
3Dlabs Oxygen GVX420 User's Guide
6
To uninstall an old video driver
1. If there is an icon for the video card on the taskbar, desktop, or on the Control Panel, select the icon
and then check for an uninstall option. If an uninstall option exists, select the option and follow the
instructions. (To display the Control Panel, click the Start button, point to Settings, and click
Control Panel.)
2. If an uninstall option does not exist, click the Start button, point to Settings, and click Control
Panel.
3. Double-click the Add/Remove Programs icon.
4. Click the name of the video card driver you want to remove.
5. Click Add/Remove and follow the instructions.
To install the Oxygen Windows NT driver
1. Start up Windows NT. Log onto an account with administrator privileges.
2. Place the Oxygen Product CD-ROM in your CD-ROM drive. When the installation window opens,
choose the Oxygen driver installation.
3. Follow the instructions that appear on your screen. (Be sure to read the software license agreement.)
4. Restart your system at the prompt.
To install the Oxygen Windows 2000 driver
1. After installing the Oxygen GVX420, start up Windows 2000. The Hardware Wizard appears.
2. Click Cancel in all dialog boxes that appear regarding "Found New Hardware."
2. Place the Oxygen Product CD-ROM in your CD-ROM drive.
3. On the CD-ROM, locate the drivers directory and run setup.exe. The 3Dlabs Graphics Driver Setup
program begins and guides you through the driver installation process.
4. Click Yes each time you are asked for confirmation before installing a driver. The Oxygen GVX420
requires three drivers: one for the GLINT Gamma geometry accellerator, and one each for the two
GLINT R4 graphics accelerators.
5. Restart your system at the prompt.
To uninstall the Oxygen GVX420 Windows NT or Windows 2000 drivers
Administrator privleges are required to uninstall these drivers.
1. On the Start menu, point to Settings and then click Control Panel.
2. In the Control Panel, double-click the Add/Remove Programs icon.
3. Click the 3Dlabs Graphics driver to select it.
4. Click Add/Remove.
5. Follow the instructions to complete the removal of each driver.
6. Restart your system at the prompt.

Installation
3Dlabs Oxygen GVX420 User's Guide 7
To install SoftEngine
Soft Engine works exclusively with AutoDesk’s AutoCAD R12, R13, R14, and LT software. Install Soft
Engine if you use one of these AutoCAD programs. Do not install Soft Engine if you do not use one of
these AutoCAD programs; it will have no beneficial effect.
1. Place the Oxygen Product CD-ROM in your CD-ROM drive. When the installation window opens,
choose Install Soft Engine. A menu appears.
2. Select your AutoCAD product type to start the installation.
3. Follow the instructions that appear on your screen.
To install Colorific
1. Place the Oxygen Product CD-ROM in your CD-ROM drive. When the installation window opens,
choose the Colorific installation.
2. Follow the instructions that appear on your screen.

Installation
3Dlabs Oxygen GVX420 User's Guide
8
Registering Oxygen GVX420
Registering Oxygen GVX420Registering Oxygen GVX420
Registering Oxygen GVX420
When you register your Oxygen GVX420 card you:
•Activate your warranty
•Receive notification of software updates
•Qualify for technical support
You can complete the registration card and return it to us in the mail, or register on-line once your hardware
and software installations are complete. (You must have Internet access to register on-line.)
1. Open your Internet browser.
2. Go to http://www.3dlabs.com/register
3. Fill out the registration form that appears on your screen, and click Submit when you are finished.

C
CC
CHAPTER
HAPTERHAPTER
HAPTER 2 - S
2 - S2 - S
2 - SOFTWARE
OFTWAREOFTWARE
OFTWARE C
CC
CONFIGURATION
ONFIGURATIONONFIGURATION
ONFIGURATION

Software Configuration
3Dlabs Oxygen GVX420 User's Guide
10
The Oxygen GVX420 Driver
The Oxygen GVX420 DriverThe Oxygen GVX420 Driver
The Oxygen GVX420 Driver
The OxygenGVX420 driver software lets you optimize the working relationship between your card, your
system and your applications. The 3Dlabs Display Control Panel allows you to customize and create driver
settings. The Taskbar based Configuration Manager provides quick and convenient access to most of the
Display Control Panel features, and allows you to quickly switch between alternative driver settings.
The Task Bar
The Task BarThe Task Bar
The Task Bar - based Configuration Manager
- based Configuration Manager- based Configuration Manager
- based Configuration Manager
When you install the Oxygen GVX420 card and software, the 3Dlabs logo appears in your system tray, also
called the task bar. Click the logo with your right mouse button to access the Display Configuration Manager
and its shortcuts to these configuration tools:
Remove from System Tray lets you delete this task bar utility from your system. You will still be able to
access the driver configuration options with the Display Control Panel.
About 3DL Display Manager displays version information for this configuration utility.
Go to 3Dlabs Website takes you directly to www.3dlabs.com through your existing Internet
connection.
Pop up the Display Panel reaches the 3Dlabs section on the display control panel.
Display Driver Information provides quick access to information about your Oxygen card
configuration.
Change Display Resolution brings up a pop-up list of supported resolutions. Each resolution has an
associated pop-up list of available refresh rates.
Select Optimized Application quickly accesses a list of supported applications. Click an application in
the list to optimize card settings for your selected option. (The Display Control Panel allows you to
create new application settings.)
Help provides help on the task bar configuration manager, the driver, and its settings.
Table of contents
Other 3Dlabs Video Card manuals

3Dlabs
3Dlabs Oxygen ACX User manual

3Dlabs
3Dlabs Wildcat II 5110 User manual

3Dlabs
3Dlabs Workstation x1000 User manual

3Dlabs
3Dlabs Wildcat 4210 User manual

3Dlabs
3Dlabs Wildcat II 5000 User manual

3Dlabs
3Dlabs Oxygen GVX1 Pro User manual

3Dlabs
3Dlabs Wildcat II 5110 User manual

3Dlabs
3Dlabs Wildcat II 5000 User manual

3Dlabs
3Dlabs The Wildcat 4110 PRO User manual

3Dlabs
3Dlabs Wildcat4 User manual
