3Gen DermLite Lumio User manual

®

Instructions
CAUTION: Prior to using the DermLite, read these
instructions and keep them in a safe place for future
reference.
CAUTION: United States Federal Law restricts this device
to sale by or on the order of a physician.
CAUTION: The DermLite is designed for external exami-
nation only.
Lumio is a skin examination device designed to view the
skin with magnification and clarity.
A ring made up of 40 LEDs (light emitting diodes) and
polarization filters provide glare- free, cross-polarized
light by canceling the reflected light from the skin. A
high quality, 75 mm 2x lens with superb color correction
and reduced image distortion produces an image rich in
surface detail.
Directions for Use
CAUTION: Do not look directly into the bright LED light.
Patients must close their eyes during facial examina-
tions.
Hold the Lumio so that the LEDs are aimed in the direc-
tion of the area to be examined. Place the device approxi-
mately 3-5” (~75-125 mm) from the skin. Push the power
button (A) at the left side of the unit to activate the LEDs.
Look through the lens with your eye placed 4-6” (~100-
150 mm) above the Lumio. Move the device closer or
further away from the skin to obtain the desired image
focus and field of view.
Replacing the Batteries
Lumio is designed to work with either lithium-ion, alka-
line, or NiMH rechargeable AA sized batteries. Dispos-
able lithium-ion batteries are recommended for best
lighting performance and longest battery life.
The lithium-ion AA batteries provide approximately 2
hours of continuous operation, or enough power for
performing approximately 240 exams at 30 seconds per
examination. Once the batteries are depleted, an orange
low battery orange indicator light (B) will illuminate. To
replace the batteries, open the battery door (C) by sliding
it towards the end of the handle. Remove all four batter-
ies and insert four new AA batteries with their positive (+)
and negative (-) ends positioned as shown on the inside of
the battery compartment.
Lithium-ion AA batteries are available at most camera
stores or directly from 3Gen.
Troubleshooting
Please check our website (www.dermlite.com) for the
most current troubleshooting information.
If you need to return your Lumio to 3Gen for servicing,
please call 3Gen prior to returning the device.
No Light
Replace the batteries and check again. If the condition
persists, send the unit to 3Gen for evaluation and/or
repair.
Weak Lighting
Replace the batteries.
LED Fails
The LEDs used in the Lumio are designed to last over
100,000 hours. If more than one LED fails, contact 3Gen
for repair.
Mechanical Malfunction
Please contact 3Gen to arrange for service.
Care and Maintenance
The Lumio is designed for trouble-free operation. There
are no adjustments to be made nor is any special servic-
ing required. Never attempt to open the device for any
reason.
Cleaning and Sterilization
The Lumio body may be cleaned or disinfected by wiping
it with Isopropyl alcohol (70% vol.). Do not use alcohol or
disinfectants in the optical areas of the unit. Do not use
abrasive material on any part of the equipment or im-
merse the device in liquid. Do not autoclave.
Cleaning the Lens and the Polarizers
The lens and the polarizing filters should be treated
as high quality photographic equipment and should be
cleaned with standard lens cleaning equipment and pro-
tected from harmful chemicals.
Specifications
Lumio features an innovative imaging system designed
for superb clarity and outstanding vision.
Lumio components include:
• Forty 5 mm white LEDs
• 75mm lens with 2x magnification
• Cross-polarized illumination
• Protective pouch
• Four lithium-ion AA batteries
Warranty
5 years for parts and labor.
Serial number and company information are located on
the inside of the battery door.
English

DermLite and 3Gen are registered trademarks of
3Gen, Inc. | 31521 Rancho Viejo Road | Suite 104
San Juan Capistrano, CA 92675 | U.S.A.
Tel. [phone] | Fax [phone]
E-Mail: [e-mail] | w ww.dermlite.com
©2015 by 3Gen, Inc. | All rights reserved. | REF C DLU-1701
Patents/Trademarks: www.dermlite.com/patents
EN Model Number
DA Modellnummer
DE Modellnummer
ES Número de modelo
FI Mallinumero
FR Numéro de modèle
IT Numero del modello
NL Modelnummer
PT Número do Modelo
SE Modellnummer
EN Manufacturer
DA Fabrikant
DE Hersteller
ES Fabricante
FI Valmistaja
FR Fabricant
IT Produttore
NL Fabrikant
PT Fabricante
SE Tillverkare
EN EC Representative (EU Only)
DA EF-repræsentant (kun for EU)
DE EU-Vertreter (EU-weit)
ES Representante EC (solo UE)
FI EU-edustaja (vain EU:ssa)
FR Représentant CE (seulement pour l’Union
IT Rappresentante CE (solo UE)
NL EC Vertegenwoordiging (Alleen voor EU)
PT Representante CE (apenas na UE)
SE EC-representant (Endast EU)
EN Do not dispose as unsorted municipal waste
DK Må ikke smides ud som usorteret husholdningsaffald
DE Nicht mit dem unsortierten Hausmüll entsorgen
ES No deseche este producto como residuos municipales sin clasificar
FI Ei saa hävittää kaatopaikkajätteen mukana
FR Ne pas jeter en tant que déchet municipal non trié
IT Non smaltire insieme ai rifiuti urbani non differenziati
NL Niet afvoeren als ongesorteerd stedelijk afval
PT Não descartar como resíduos municipais não seleccionados.
SE Får inte slängas i osorterade hushållssopor!
EN Serial Number
DA Serienummer
DE Seriennummer
ES Número de serie
FI Sarjanumero
FR Numéro de série
IT Numero seriale
NL Serienummer
PT Número de Série
SE Serienummer
EN Attention, consult accompanying document
DA Opmærksomhed, konsultér medfølgende dokument
DE Achtung, siehe Bedienungsanleitung
ES Atención, consulte el documento adjunto
FI Huomio: Tutustu mukana tulevaan kirjalliseen aineistoon.
FR Attention, veuillez bien consulter le document d’accompagnement
IT Attenzione, consultare la documentazione allegata
NL Opgelet, raadpleeg bijbehorend document
PT Atenção, consultar o documento anexo
SE OBS! konsultera medföljande dokument
EC REP
EC REP
M. Devices Group, Healthcare Education Centre,
The Church, Portland Street, Southport, PR8 1HU, UK.
Tel: [phone] | Fax: [phone]
®
