3M Adflo 83 37 09 User manual

Instruction 3M™ Ado™ Battery Charging Stand 6 position a
USER INSTRUCTIONS
Please read these instructions in conjunction with other relevant user
instructions for 3M Ado Battery Charger and Battery Packs
SYSTEM DESCRIPTION
3M Ado Battery Charging Stand is designed for charging up to 6
Ado battery packs at the same time. The Charging Stand can be
used for re-charging Ado Li-Ion and NiMH battery packs respectively.
The Battery Charging stand may be either, wall mounted or placed
vertically on a at surface. In either case the area must be well
ventilated.
WARNING
For suitability and proper use follow local regulations, refer to all
information supplied.
For the Battery Charging Stand to function correctly, the power supply
cord must be directly connected to its own AS/NZS 3000 approved
xed power point. Do not connect the power supply cord to a double
adapter, extension cord, power board, or any other kind of secondary
plug or socket.
Particular attention should be given to warning statements
where indicated.
LIMITATIONS OF USE
Only use in accordance with conditions prescribed in the technical
specications.
Do not place the Ado Battery Charging Stand, in enclosed cabinets
without ventilation, in hazardous environments, or near sources of
heat.
To prevent the risk of re or electric shock, the Battery Charging
Stand should be installed in a well-ventilated, dry indoor area, free
from condensation and excessive dust.
-Do not use with a damaged power cord or power supply.
-Inspect stand outlets and power cord before use. If the stand outlets
or power cord are damaged, dispose of the device
-Do not attempt to service the charging stand. There are no user-
servicable parts
Risk of Electric Shock - The charging stand must be connected to a
properly grounded outlet that is properly installed and grounded in
accordance with all local codes and ordinances
EQUIPMENT MARKING
= Read the instructions before use
= Shall be disposed of as electrical and electronic waste
= For indoor use only
PREPARATION FOR USE
Carefully check that the product is complete and undamaged see g
A:1.
ASSEMBLY INSTRUCTIONS
See g B:1-B:6
OPERATING INSTRUCTIONS
See g C:1-C:3
TECHNICAL SPECIFICATIONS
Storage and transportation
Do not store outside the temperature range -30°C to +70°C
-30 °C
+70 °C
or with
humidity above 90%
<90%
.
Weight Ado charger stand: 6 kg
Max load: 8 kg
Operating conditions: 0-40°C
AU 83 37 09
Mains voltage: 230 - 240V, 50Hz
Max wattage: 2300 - 2400W
Current: 10A
MATERIAL:
Enclosure: Powder coated steel

x4
B:1 B:2 B:3
B:4
A:1
x20
x6
x
6
x4

40 cm
24 cm
B:5 B:6
1.
2.
10 cm
25 cm
C:1 C:2
C:3
DV-9663-0077-9 / 047188 / JAN 2015
