3M MATERIAL SAFETY DATA SHEET 3M(TM) Thinner CGS-80 10/21/2005
_________________________________________________________________________________________________
Page 1of 7
Material Safety Data Sheet
Copyright, 2005, 3M Company. All rights reserved. Copying and/or downloading of this information for the purpose of properly
utilizing 3M products is allowed provided that: (1) the information is copied in full with no changes unless prior written agreement is
obtained from 3M, and (2) neither the copy nor the original is resold or otherwise distributed with the intention of earning a profit
thereon.
SECTION 1: PRODUCT AND COMPANY IDENTIFICATION
PRODUCT NAME: 3M(TM) Thinner CGS-80
MANUFACTURER: 3M
DIVISION:
Commercial Graphics
ADDRESS: 3M Center
St. Paul, MN 55144-1000
EMERGENCY PHONE: [phone] or [phone] (24 hours)
Issue Date: 10/21/2005
Supercedes Date: 02/20/2004
Document Group: 11-0346-4
Product Use:
Specific Use: Solvent for Cleaning and Thinning
SECTION 2: INGREDIENTS
Ingredient C.A.S. No. % by Wt
DIETHYLENE GLYCOL MONOETHYL ETHER ACETATE 112-15-2 100
SECTION 3: HAZARDS IDENTIFICATION
3.1 EMERGENCY OVERVIEW
Specific Physical Form: Liquid
Odor, Color, Grade: Solvent Odor, Clear Color
General Physical Form: Liquid
Immediate health, physical, and environmental hazards: May cause target organ effects.
3.2 POTENTIAL HEALTH EFFECTS
Eye Contact:
Mild Eye Irritation: Signs/symptoms may include redness, pain, and tearing.
Skin Contact:

3M MATERIAL SAFETY DATA SHEET 3M(TM) Thinner CGS-80 10/21/2005
_________________________________________________________________________________________________
Page 2of 7
Mild Skin Irritation: Signs/symptoms may include localized redness, swelling, and itching.
Inhalation:
Upper Respiratory Tract Irritation: Signs/symptoms may include cough, sneezing, nasal discharge, headache, hoarseness, and nose
and throat pain.
May be absorbed following inhalation and cause target organ effects.
Ingestion:
Gastrointestinal Irritation: Signs/symptoms may include abdominal pain, nausea, diarrhea and vomiting.
May be absorbed following ingestion and cause target organ effects.
Target Organ Effects:
Central Nervous System (CNS) Depression: Signs/symptoms may include headache, dizziness, drowsiness, incoordination, nausea,
slowed reaction time, slurred speech, giddiness, and unconsciousness.
Prolonged or repeated exposure may cause:
Kidney Effects: Signs/symptoms may include reduced or absent urine production, increased serum creatinine, lower back
pain, increased protein in urine, and increased blood urea nitrogen (BUN).
SECTION 4: FIRST AID MEASURES
4.1 FIRST AID PROCEDURES
The following first aid recommendations are based on an assumption that appropriate personal and industrial hygiene practices are
followed.
Eye Contact: Flush eyes with large amounts of water. If signs/symptoms persist, get medical attention.
Skin Contact: Wash affected area with soap and water. If signs/symptoms develop, get medical attention.
Inhalation: Remove person to fresh air. If signs/symptoms develop, get medical attention.
If Swallowed: Do not induce vomiting unless instructed to do so by medical personnel. Give victim two glasses of water. Never
give anything by mouth to an unconscious person. Get immediate medical attention.
SECTION 5: FIRE FIGHTING MEASURES
5.1 FLAMMABLE PROPERTIES
Autoignition temperature 680 ºF
Flash Point 211 ºF [Test Method: Closed Cup]
Flammable Limits - LEL 0.9 %
Flammable Limits - UEL 19.4 %
OSHA Flammability Classification: Class IIIB Combustible Liquid

3M MATERIAL SAFETY DATA SHEET 3M(TM) Thinner CGS-80 10/21/2005
_________________________________________________________________________________________________
Page 3of 7
5.2 EXTINGUISHING MEDIA
Ordinary combustible material. Use fire extinguishers with class A extinguishing agents (e.g., water, foam).
5.3 PROTECTION OF FIRE FIGHTERS
Special Fire Fighting Procedures: Wear full protective equipment (Bunker Gear) and a self-contained breathing apparatus
(SCBA).
Unusual Fire and Explosion Hazards: Non-flammable: ordinary combustible material.
Note: See STABILITY AND REACTIVITY (SECTION 10) for hazardous combustion and thermal decomposition
information.
SECTION 6: ACCIDENTAL RELEASE MEASURES
Accidental Release Measures: Observe precautions from other sections. Call 3M- HELPS line (1-800-364-3577) for more
information on handling and managing the spill. Evacuate unprotected and untrained personnel from hazard area. The spill should be
cleaned up by qualified personnel. Ventilate the area with fresh air. For large spill, or spills in confined spaces, provide mechanical
ventilation to disperse or exhaust vapors, in accordance with good industrial hygiene practice. Warning! A motor could be an ignition
source and could cause flammable gases or vapors in the spill area to burn or explode. Contain spill. Working from around the edges
of the spill inward, cover with bentonite, vermiculite, or commercially available inorganic absorbent material. Mix in sufficient
absorbent until it appears dry. Collect as much of the spilled material as possible. Clean up residue with detergent and water. Place
in a closed container approved for transportation by appropriate authorities. Dispose of collected material as soon as possible.
In the event of a release of this material, the user should determine if the release qualifies as reportable according to
local, state, and federal regulations.
SECTION 7: HANDLING AND STORAGE
7.1 HANDLING
Do not eat, drink or smoke when using this product. Wash exposed areas thoroughly with soap and water. Avoid breathing of vapors,
mists or spray. Avoid prolonged or repeated skin contact. Avoid eye contact with vapors, mists, or spray. For industrial or
professional use only. Avoid contact with oxidizing agents.
7.2 STORAGE
Keep container in well-ventilated area. Store away from oxidizing agents.
SECTION 8: EXPOSURE CONTROLS/PERSONAL PROTECTION
8.1 ENGINEERING CONTROLS
Use with appropriate local exhaust ventilation. Provide local exhaust ventilation at transfer points. Provide appropriate local exhaust
ventilation on open containers.
8.2 PERSONAL PROTECTIVE EQUIPMENT (PPE)
8.2.1 Eye/Face Protection
Avoid eye contact.
The following eye protection(s) are recommended: Safety Glasses with side shields, Indirect Vented Goggles. (Goggles
recommended when a splash potential exists.)

3M MATERIAL SAFETY DATA SHEET 3M(TM) Thinner CGS-80 10/21/2005
_________________________________________________________________________________________________
Page 4of 7
8.2.2 Skin Protection
Avoid skin contact.
Select and use gloves and/or protective clothing to prevent skin contact based on the results of an exposure assessment. Consult with
your glove and/or protective clothing manufacturer for selection of appropriate compatible materials.
Gloves made from the following material(s) are recommended: Butyl Rubber.
8.2.3 Respiratory Protection
Avoid breathing of vapors, mists or spray.
Select one of the following NIOSH approved respirators based on airborne concentration of contaminants and in accordance with
OSHA regulations: Half facepiece or fullface air-purifying respirator with organic vapor cartridges. Consult the current 3M
Respiratory Selection Guide for additional information or call 1-800-243-4630 for 3M technical assistance.
8.2.4 Prevention of Swallowing
Do not eat, drink or smoke when using this product. Wash exposed areas thoroughly with soap and water.
8.3 EXPOSURE GUIDELINES
None Established
SECTION 9: PHYSICAL AND CHEMICAL PROPERTIES
Specific Physical Form: Liquid
Odor, Color, Grade: Solvent Odor, Clear Color
General Physical Form: Liquid
Autoignition temperature 680 ºF
Flash Point 211 ºF [Test Method: Closed Cup]
Flammable Limits - LEL 0.9 %
Flammable Limits - UEL 19.4 %
Boiling point 423 ºF
Density 1.01 g/ml
Vapor Density > 1 [Ref Std: AIR=1]
Vapor Pressure 0.05 mmHg [@ 20 ºC]
Specific Gravity 1.01 [Ref Std: WATER=1]
pH Not Applicable
Melting point Not Applicable
Solubility in Water Complete
Volatile Organic Compounds 1,010 g/l
Percent volatile 100 %
VOC Less H2O & Exempt Solvents 1,010 g/l
SECTION 10: STABILITY AND REACTIVITY
Stability: Stable.
Materials and Conditions to Avoid: Strong oxidizing agents

3M MATERIAL SAFETY DATA SHEET 3M(TM) Thinner CGS-80 10/21/2005
_________________________________________________________________________________________________
Page 5of 7
Hazardous Polymerization: Hazardous polymerization will not occur.
Hazardous Decomposition or By-Products
Substance Condition
Carbon monoxide Not Specified
Carbon dioxide Not Specified
SECTION 11: TOXICOLOGICAL INFORMATION
Please contact the address listed on the first page of the MSDS for Toxicological Information on this material and/or its
components.
SECTION 12: ECOLOGICAL INFORMATION
ECOTOXICOLOGICAL INFORMATION
Not determined.
CHEMICAL FATE INFORMATION
Not determined.
SECTION 13: DISPOSAL CONSIDERATIONS
Waste Disposal Method: Reclaim if feasible. Incinerate in an industrial or commercial facility in the presence of a combustible
material. As a disposal alternative, dispose of waste product in a facility permitted to accept chemical waste.
EPA Hazardous Waste Number (RCRA): Not regulated
Since regulations vary, consult applicable regulations or authorities before disposal.
SECTION 14:TRANSPORT INFORMATION
ID Number(s):
75-3465-0408-9, 75-3469-5888-9, 75-3470-5586-7
Please contact the emergency numbers listed on the first page of the MSDS for Transportation Information for this
material.
SECTION 15: REGULATORY INFORMATION
US FEDERAL REGULATIONS
Contact 3M for more information.

3M MATERIAL SAFETY DATA SHEET 3M(TM) Thinner CGS-80 10/21/2005
_________________________________________________________________________________________________
Page 6of 7
311/312 Hazard Categories:
Fire Hazard - No Pressure Hazard - No Reactivity Hazard - No Immediate Hazard - Yes Delayed Hazard - Yes
Section 313 Toxic Chemicals subject to the reporting requirements of that section and 40 CFR part 372 (EPCRA):
Ingredient C.A.S. No % by Wt
DIETHYLENE GLYCOL MONOETHYL
ETHER ACETATE (GLYCOL ETHERS) 112-15-2 100
STATE REGULATIONS
Contact 3M for more information.
CHEMICAL INVENTORIES
The components of this product are in compliance with the chemical notification requirements of TSCA.
All applicable chemical ingredients in this material are listed on the European Inventory of Existing Chemical Substances (EINECS),
or are exempt polymers whose monomers are listed on EINECS.
Contact 3M for more information.
INTERNATIONAL REGULATIONS
Contact 3M for more information.
This MSDS has been prepared to meet the U.S. OSHA Hazard Communication Standard, 29 CFR 1910.1200.
SECTION 16: OTHER INFORMATION
NFPA Hazard Classification
Health: 1 Flammability: 1 Reactivity: 0 Special Hazards: None
National Fire Protection Association (NFPA) hazard ratings are designed for use by emergency response personnel to address the hazards that are
presented by short-term, acute exposure to a material under conditions of fire, spill, or similar emergencies. Hazard ratings are primarily based on the
inherent physical and toxic properties of the material but also include the toxic properties of combustion or decomposition products that are known to
be generated in significant quantities.
Revision Changes:

3M MATERIAL SAFETY DATA SHEET 3M(TM) Thinner CGS-80 10/21/2005
_________________________________________________________________________________________________
Page 7of 7
Section 16: NFPA hazard classification heading was modified.
Section 3: Other potential health effects heading was modified.
Copyright was modified.
Section 7: Handling information was modified.
Section 7: Storage information was modified.
Section 8: Engineering controls information was modified.
Section 15: 311/312 hazard categories heading was modified.
Section 15: International regulations information was modified.
Section 15: State regulations information was modified.
Section 15: US federal regulations information was modified.
Section 10: Hazardous polymerization heading was modified.
Section 3: Other health effects information was modified.
Section 14: ID Number(s) was modified.
Section 16: NFPA explanation was modified.
Section 15: Inventories information was modified.
Section 15: EPCRA 313 text was modified.
Section 12: Ecotoxicological information heading was modified.
Section 12: Chemical fate information heading was modified.
Section 16: NFPA hazard classification for special hazards was modified.
Section 8: Exposure guidelines information - none - was modified.
Section 12: Ecotoxicological phrase was modified.
Section 12: Chemical Fate phrase was modified.
Section 2: Ingredient phrase was added.
DISCLAIMER: The information in this Material Safety Data Sheet (MSDS) is believed to be correct as of the date issued. 3M
MAKES NO WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR COURSE OF PERFORMANCE OR USAGE OF
TRADE. User is responsible for determining whether the 3M product is fit for a particular purpose and suitable for user's method of
use or application. Given the variety of factors that can affect the use and application of a 3M product, some of which are uniquely
within the user's knowledge and control, it is essential that the user evaluate the 3M product to determine whether it is fit for a
particular purpose and suitable for user's method of use or application.
3M provides information in electronic form as a service to its customers. Due to the remote possibility that electronic transfer may
have resulted in errors, omissions or alterations in this information, 3M makes no representations as to its completeness or accuracy.
In addition, information obtained from a database may not be as current as the information in the MSDS available directly from 3M.
3M MSDSs are available at www.3M.com
