3M™Super Close Projection System SCP740
For the ideal projected image to match the latest in WXGA notebooks and popular video formats, the 3M
Super Close Projection System SCP740 is the solution you need. The first high brightness, WXGA projector
to be available with super close projection technology, the SCP740 has the benefits of DLP™, Brilliant Color™
DVI-D connectivity and an integrated wind tunnel for fan noise reduction. Works better than traditional ceiling
mounted projectors because the extreme off-axis short throw reduces light in the presenter’s eyes and the
full connectivity makes it the perfect tabletop media hub tool!
•Two computer/component RGB inputs
• One computer RGB output
• RJ-45 ethernet connection
provides network capabilities and
basic remote administration
• RS232 connection for basic
remote control
• +5V/2A DC power output
• S-video input for connecting a
DVD/analog video device
• DVI-D connection
Features
RJ-45 Ethernet USB
+5V/2A
AC Power
RCA Video
Audio Out
Audio-In
RS-232 IR Receiver Kensington Lock Slot
S-Video
RGB-Out RGB-2/In
Component
RGB-1/In
Component
DVI-D
• RCA Audio/Video for camcorders,
digital cameras, gaming and more
• One USB port for remote mouse
• Audio output connection
for external speakers
3M SCP740 Projector
78-9236-6999-4

Note: These sizes are +10 percent. This is due to variations in the manufacture of the lens. If you are close to
one of the endpoints you should verify with your unit that the image is the proper size at the proper distance.
Image Size
Screen Size Projection Distance
Diagonal [inch (m)] Maximum [inch (m)]
60" (1.5) 35.0" (0.9)
70" (1.7) 40.9" (1.04)
80" (2.0) 46.7" (1.19)
90" (2.3) 52.6" (1.34)
95" (2.4) 55.5" (1.41)
100" (2.5) 58.4" (1.49)
© 3M 2008. All rights reserved. Please recycle.
Printed in USA. v06.08
78-6970-8654-0
3M Projection
Systems
Building A147-5N-01
6801 River Place Blvd.
Austin, TX 78726-9000
USA
3M Canada
PO Box 5757
London,
Ontario, Canada
NGA 4T1
3M Mexico, S.A. de C.V.
Apartado Postal 14-139
Mexico, D.F. 07070
Mexico
Important Notice
All statements, technical information, and recommendations related to 3M’s products are based on
information believed to be reliable, but the accuracy or completeness is not guaranteed. Before using
this product, you must evaluate it and determine if it is suitable for your intended application. You assume
all risks and liability associated with such use. Any statements related to the product which are not
contained in 3M’s current publications, or any contrary statements contained on your purchase order
shall have no force or effect unless expressly agreed upon, in writing, by an authorized officer of 3M.
Warranty; Limited Remedy; Limited Liability
This product will be free from defects in material and manufacture for a period of 3 years from the time of
purchase. 3M MAKES NO OTHER WARRANTIES or CONDITIONS INCLUDING, BUT NOT LIMITED TO, ANY
IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
If this product is defective within the warranty period stated above, your exclusive remedy shall be, at
3M’s option, to replace or repair the 3M product or refund the purchase price of the 3M product. Except
where prohibited by law, 3M will not be liable for any indirect, special, incidental or consequential loss or
damage arising from this 3M product, regardless of the legal theory asserted.
Specifications subject to change without notice.
3M, and the 3M logo are trademarks of 3M Company. Used under license in Canada. All
other trade names referenced are the service marks, trademarks, or registered trademarks of their
respective companies.
Optical
Vikuiti™Super Close Projection
Technology by 3M
DMD Panel
.65 in. DLP
Resolution
WXGA (1280 x 800)
Aspect Ratio
16:10 native, 16:9 and 4:3 supported
Contrast Ratio
1600:1
Digital Zoom
100% to 200%
Brightness
2600 lumens (maximum rating)
Projection Lens
F2.5
Throw Ratio (Distance: Image Width)
0.69
Image Size (range)
50-98 inches (1.27m-2.48m)
Focus
Manual (1.2x)
Lamp
260W (normal mode), 200W (eco mode)
Lamp Life
2000 hours (normal)
Up to 3000 hours (eco)
Security
Integrated Kensington Lock Slot
(security kit, optional upgrade)
Size
Dimensions (W x D x H)
14 x 12.2 x 5 in. (360 x 309 x 126mm)
Weight
10 lbs (4.5kg)
System Specifications
Video Compatibility
NTSC, PAL, SECAM, 480i/p (1080i), 720p
PC Compatibility
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA),
1280 x 1024 (SXGA), 1280 x 960* (iMAC), 1152 x 870*
(MAC), 1024 x 768 (MAC 19")
*resolution digitally compressed
Digital Keystone Correction
Vertical ±16 degrees
Audio Output
Two 2 Watt integrated speakers
Noise Level
Normal 38dB; eco 35dB
Power Consumption
200W (Max, <20K Stand by)
Power Supply
Universal: 100-240VAC, 50/60Hz
Regulatory Approvals
FCC Class B, CCC for China, NOM, EK, cULus, CE Class
B, RoHS, WEEE, Nemko, CE-TUV, PSB, SABS, IRAM
Warranties
For details see www.3m.com/meetings/warranties
Projector
3 year limited, parts and labor on projector (see
website for optional warranty)
Lamp
90 days or 180 hours with remainder of year 1 prorated
Technical Support
• Free unlimited software downloads and updates
available on our website at www.3m.com/meetings
• 24/7 Technical Support by calling 800.328.1371
800.328.1371 | www.3m.com/meetings
Accessories Included
1.8m power cord (US, UK, Europe)
1.8m 15 pin D-sub VGA cable
3.5mm audio cable
USB cable
Remote control with batteries
Multi-Language Operator’s Guide (CD)
Quick Start Guide
Product Safety Guide
WEEE card (EMEA)
Optional Accessories
SCP740 Lamp Replacement Kit 78-6969-9957-8
C1 Universal Ceiling Mount -black 78-6969-9928-9
C1 Universal Extender Pole
& Plate -black 78-6969-9927-1
(Order if required to match SKU 78-6969-9928-9)
P1 Universal ceiling mount -white 78-6969-9874-5
Kensington Lock/Key Security Kit 78-6969-9961-0
