7th Sense Medialon MAS Pro Dante DH Installation manual

Copyright © 7thSense Design Ltd : M732-2 June 2022
Specification
Environmental Characteristics Operating Non-operating
Temperature +15 to +30 °C -10 to +50 °C
Humidity (non-condensing) 10 to 90% 5 to 95%
Altitude <2000 m <10000 m
Regulatory Compliance Statements
FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with this user guide, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his
own expense.
European Union
This is a Class A product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
Medialon MAS Pro Dante DH
Hardware User Guide
Customer Support Portal: https://portal.7thsense.one
Support
If your MAS Pro Dante DH was purchased through one of our regional distributors, please
contact your supplier directly for support.
Visit our customer support portal where you can find a wide range of support documentation
and video tutorials, together with contact information.
Warranty
Standard warranty is 24 months, return-to-supplier. Please contact your supplier if you require
an extended warranty. Please ask for instructions and request authorisation before returning a
server to your supplier.
Operating Instructions
Operating instructions for your server can be found in the Online User Guides section of the
customer support portal.
Handling and Installation
Unpacking
Unpack your MAS Pro Dante DH carefully onto a clean and level surface and examine it for any
signs of transit damage. Contact your supplier immediately if anything appears to be damaged,
or any parts missing. Please retain all packaging in case of future need to return a server.
Lifting
MAS Pro Dante DH weight is stated below and on the server’s product label. Especially when
manoeuvring them into a rack or at height, observe your internal manual handling
recommendations to avoid injury.
Rack mounting
The MAS Pro Dante DH is a 2U device, supplied with rack mount slide rails and fixings.
Installation instructions are included with the slide rails. Ensure that rack-mounted servers are
properly secured to the rack cabinet using M6 rack mount bolts.
Rack stability warnings:
•Ensure the rack is stable (e.g. bolted to the floor) before sliding out the server.
•Do not place objects on equipment projecting from a rack (e.g. do not use as a shelf).
•Only slide out one piece of equipment from the rack at a time.
Product Electrical Rating Weight (kg) Dimensions (H ×W ×D)
MAS Pro Dante DH 100-240V, 7-3.5A, 60-50Hz 18 2U ×483 mm ×545 mm
7thSense Design Ltd : 2 The Courtyard, Shoreham Road, Upper Beeding, BN44 3TN, UK
www.7thsense.one

Connecting External Equipment
To ensure best performance from the server and compliance with relevant EMC regulations, this
equipment should only be used with high-quality shielded data and signal cables.
Only equipment and accessories approved to IEC 60950-1 and SELV circuits may be
connected to the server. All equipment and accessories shall comply to the relevant standard
for the server’s port to which it is connected.
Environment
General
This equipment is intended for use in a commercial (not domestic) environment and should be
operated in a clean, dust free area (e.g. a server room).
The equipment is intended for operation in benign environments; that is, not subject to
corrosive or explosive atmospheres, moisture or flammable gases. The server is non-protected
against ingress of liquid (IPx0). The server is not designed to be subject to excessive
mechanical shock or vibration.
This equipment is not suitable for use in locations where children are likely to be present.
Only used at altitude
not exceeding 2000
m
Only used in not
-tropical
climate regions
Thermal
Do not block any of the unit’s air vents and ensure the ambient temperature around the unit is
compatible with the environmental characteristics stated below.
Particularly when mounted in a rack cabinet with front or rear doors the ambient temperature
around the unit may be higher than the ambient room temperature.
Electrical
Before connecting power to the MAS Pro Dante DH, ensure the electricity supply is compatible
with the electrical ratings shown here and on the server product label. The unit shall not be
connected to an IT (unearthed neutral) power distribution system and the mains socket-outlet
used shall connect to the building installation ground.
The server is connected to and disconnected from the mains supply with the IEC 60320 power
connector on the rear of the unit.
Maintenance
Air Filter
A user-serviceable air filter is located on the unit’s front panel. It is important to remove and
clean or replace the filter periodically to avoid overheating.
MAS Pro Dante DH is supplied with one spare filter pad, others can be provided by your supplier.
The unit should not be run without filters, since accumulations of dust inside the server can
affect performance.
Cleaning
External casing and the front panel should be carefully wiped with a soft cloth and antistatic
solution.
Server internal maintenance
Internal maintenance must only be undertaken by suitable qualified service personnel.
Warning: Do not operate the server with any covers removed as the air flow through
the unit may be compromised leading to overheating.
Warning: Motherboard CMOS battery replacement: Danger of explosion if incorrect battery
used or battery incorrectly installed. Contact your supplier for further instructions.
Any alterations to the product’s specification, including additional/alternative
components, BIOS changes, overclocking, etc., may invalidate the warranty or impact
the server’s performance. Additionally, such changes or modifications could cause equipment
no longer to comply with the relevant EMC regulations, and void the user’s authority to operate
the equipment. If in doubt, please contact your supplier.
Electrostatic discharge (ESD)
When handling electronic assemblies, take precautions to avoid electrostatic discharge (ESD)
causing damage. Precautions should include the wearing of an ESD protective wrist strap and
using antistatic bags for electronic assemblies when not installed in a server.
End of Service Life
Dispose of the equipment and any components in accordance with all local and
national safety and environmental requirements.
