7th Sense medialon Showmaster Go Assembly instructions

Mounting the Medialon
Showmaster Go
User Reference Manual

Trademark Information
Medialon is a trademark of Medialon Ltd. Product or company names that mentioned in Medialon
Ltd publications are tradenames or trademarks of their respective owners, and such trademarks
may also be registered in their respective countries.
Copyright Information
All Rights Reserved. This document is copyrighted © by Medialon Ltd and shall not be reproduced
or copied without express written authorization from Medialon Ltd.
The information in this document is subject to change without notice. Medialon Ltd assumes no
responsibility for errors, and/or omissions contained in this information.
Document Revision
Date Document
edition
Software version Revision details Author/Editor
4/12/2019 1 N/A New release Andie Davidson
M555-1

Medialon Control System p 1 of 9
User Reference Manual
M555-1 | 2019-12-4
Contents
1 Environmental Considerations.................................................................................................. 1
2 VESA Mount ............................................................................................................................. 2
3 Anti-shock Frame...................................................................................................................... 3
4 Rack-Mount Tray ...................................................................................................................... 4

Medialon Control System p 1 of 9
User Reference Manual
M555-1 | 2019-12-4
1Environmental Considerations
The Showmaster Go can be mounted singly or in multiples up to three per rack unit. The
available mounting options are VESA, an anti-shock mounting frame, and a rack mounting tray.
All are available options from 7thSense Design.
When mounting the Showmaster Go, do not block any server air vents, and ensure the ambient
temperature around the server is compatible with the environmental characteristics stated
below.
Environmental Characteristics Operating Non-operating
Temperature +15 to +30 °C -10 to +50 °C
Humidity (non-condensing) 10 to 90% 5 to 95%
Altitude <2000 m <10000 m
Particularly when mounted in a rack cabinet with front or rear doors the ambient temperature
around the server may be higher than the ambient room temperature.
Showmaster Go can be mounted vertically using the optional VESA mounting plate or anti-
shock frame, but care must be taken that hot air from the rear panel is not drawn back in at the
front. Do not mount with the front panel uppermost.

Medialon Control System p 2 of 9
User Reference Manual
M555-1 | 2019-12-4
2VESA Mount
A VESA mounting plate is available for the Showmaster Go for stable and static non-horizontal
mounting, on which the unit can be hung.

Medialon Control System p 3 of 9
User Reference Manual
M555-1 | 2019-12-4
3Anti-shock Frame
The Showmaster Go is designed for moving environments, and is resilient to vibration and
shock to BS EN 60068-2-6, further protection especially in mounting security is available by
using the anti-shock frame.
Remove the two black dome-head screws from the front panel (circled):
These are the fixing points for the front of the anti-shock frame. Slide the unit’s VESA mount
slots onto the base pins, push forward and secure using the two black finger screws. These are
spring-mounted, so push them in to locate the threads.
The whole unit is secured using the four rubberised pillars.

Medialon Control System p 4 of 9
User Reference Manual
M555-1 | 2019-12-4
4Rack-Mount Tray
Up to three units can be mounted as a 1U rack unit, using the optional rack mount tray. Where
fewer than three units are mounted this way, use the supplied blanking plates.
Remove the two black dome-head screws from the Showmaster Go front panel:
Present the unit where required into the tray and secure using two black finger screws. These
are spring-mounted, so push them in to locate the threads.

Medialon Control System p 5 of 9
User Reference Manual
M555-1 | 2019-12-4
When adding blanking plates, present these to the outer side first to avoid scraping down a
server side. The screw holes in the plates are asymmetric, so check that the holes align with the
finger screws.
Use the cable tie eyelets on the rear base of the tray to secure loose cables as needed.
The tray itself is supported in the server rack by the two side plates. These are slotted to
receive the pins on the sides of the tray.
Secure the side plates as shown below (here a Showmaster Go is co-hosted in the rack with a
7thSense Pico media server), using 2 × M6 countersunk screws for each:
Leave these slightly loose and present the tray to the rack, engaging the pins in the side plate
slots and easing back into place.
Tighten the screws through the holes and then secure the tray using 1 × M6 standard rack
mounting screws on each side.
