86 Duino ENJOY Instruction manual

Quick Start
Manual

CONTENTS
ENJOY Introduction
Software Installation*
Install print S/W
Driver Install
Hardware
Hardware Intro Cable installation
Power and Trans cable install
Calibration Settings
Setup and connection Extruder Calibration
Print bed Calebration
Appendex
Print test
Load 3D object Adjust print object
Slice and G-Code Start print
1
2
3
4
5
6

Front view Rear view
Gearbox
Feeding Tube
Rear Panel
Extruder
Print Bed
LED Panel
X、Y Stepper
Motor
Z screw
Bed adjust knob
Unload button
PART
1
ENJOY Introduction

PART
2
Software Installation
Install print S/W ｜Driver Install

S/W-Print software install (1/6)
Download 86DuinoRepetierHost file from following to your computer:
http://www.86duino.com/86Duino-Enjoy/setup86DuinoRepetierHost_1_5_6.exe
Double click the setup file icon 。
Setup icon Select the language you prefer and click “OK”

S/W-Print software install (2/6)
1.
Click “Next” on Setup Wizard : Read the License Agreement and if in agreement, Select
“I accept the agreement” and then click “Next” .
1
2
3

S/W-Print software install (3/6)
Click “Next” if you like to put it under “Program Files” or
you can choose your preferred location by clicking
“Browse…”
then click “Next”（default setting）
4 5

S/W-Print software install (4/6)
Click “Next” if you like to put the shortcut in “86Duino
Repetier-Host” folder or you can click “Browse…” to choose
a different folder.
If you would like to create a desktop icon, check off, “Create
a desktop icon” and then click “Next”.
7.
6
7
8

S/W-Print software install (5/6)
Click “Install” to start the installation. Software Installation
9

•After installation is complete, you can
choose whether to continue to install the
driver.
•If the previous driver has been installed,
you can skip the "Driver Installation"
teaching content.
•If you do not execute software now and
then, can be performed by clicking
"RepetierHost.exe" file.
Installation completion
12.
Install serial driver
Lanch 86Duino
Repetier-Host
86Duino Repetier-Host Icon
S/W-Print software install (6/6)
1
0
1
1
1
2

PART
2
Software Installation
Install print S/W ｜Driver Install

S/W-Driver install (1/3)
If you choose to print software installation to continue after the completion of driver installation, the following installation
screen will appear, please follow the instructions to complete the installation:
Driver extract confirmation screen Driver extracting screen
1

S/W-Driver install (2/3)
2.
Read the License Agreement and if in agreement, Select “I
accept the agreement” and then click “Next” .
Click “Next” for Setup Wizard :
4.
3.
2
3
4

S/W-Driver install (2/3)
Installation completion screenInstall screen
5.
5

PART
3
Hardware Assembly
Hardware Intro | Cable installation | Power and Trans cable install

Hardware Intro /Description
ENJOY includes the following items at the box:
5.
3.
Filament holder
ENJOY
Printer
Test print
micro USB cable
Power Adapter Printing board（include Clips)
Extruderpositioned tested
Accessories

PART
3
Hardware Assembly
Hardware Intro | Cable Installation | Power and Trans cable install

Cable Installation （1/5）
Mounted filament holder on the rear of the printer:
1. Counterclockwise direction of the mounting holder
Filament holder
mounting holes
2. Place the Filament hanging on the holder (note direction)
Direction
Holder
ENJOY
rear
view

Cable Installation （2/5）
Prior to each use, remove the harden/used end of the filament by cutting off 2 inch from the end to be loaded
into the extruder.
4. feed the filament into the Feeder
3. Cutting
Thread
Feeder

Cable Installation （3/5）
Push up on the spring to the left while feeding the filament up into the tube.
5. Push up on the spring 6. gears will be moved to the right,
to generate the space
Feeder Feeder
