NEED HELP? GIVE US A CALL 877.333.7108
1. Select a space under sink that is at least
6" from bottom of your cabinet to allow
for lter replacements. Use mounting
holes located on back of system manifold
(A) to mark wall screw placements.
Ensure holes are level.
2. Use a 1⁄8" drill bit to drill pilot holes.
Mount unit to wall using two screws (U)
leaving approximately 3⁄8" of each screw
exposed. Mount system manifold on wall
and screw into place.
3. Mark screw placement of remineralizer
holder 2" away from right side of
system. Using third screw (U), mount
remineralizer holder onto wall.
STEP 2 Install System Manifold
STEP 3 Install RO Faucet
Note: Avoid over tightening
screws. Drilling holes into solid
surfaces or surfaces made of
stone should only be performed
by a certied installer.
You will need the faucet (F) and gasket, nut, washer and escutcheon (G) to complete this step.
Note: Sink top hole must be 11⁄4" diameter for the faucet. If drilling a new hole, ensure faucet
body will mount at against the surface and there is sufcient tubing between faucet and
system manifold.
Note: Save leftover tubing
for a future step.
1. Slide metal escutcheon
(G1) onto faucet base (F)
rst and then black gasket
(G2). Feed tubing and
faucet threads through
countertop hole.
2. Thread metal washer
(G3) onto faucet threads
and then faucet nut
(G4). Tighten faucet
nut by hand.
3. Measure white tubing
attached to faucet to
outlet of remineralizer
and cut to desired length.
INSTALLATION GUIDE
4
