Aaeon AEC-6850 User manual

Embedded Controller AEC-6850
AEC-6850
Fanless Embedded Control PC
Intel
®Celeron®M 600MHz
1.3GHz Processor
With Ethernet, 2 COMs, Audio
TV-out, CompactFlash™
AEC-6850 Manual 2nd Ed.
August 2007

Embedded Controller AEC-6850
i
Copyright Notice
This document is copyrighted, 2007. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Embedded Controller AEC-6850
ii
Acknowledgments
• Award is a trademark of Award Software International, Inc.
• CompactFlash™is a trademark of the Compact Flash
Association.
• Intel® and Celeron®M are trademarks of Intel®Corporation.
• Microsoft Windows®is a registered trademark of Microsoft
Corp.
• PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
All other product names or trademarks are properties of their
respective owners.

Embedded Controller AEC-6850
iii
Packing List
Before you begin operating your PC, please make sure that the
following materials have been shipped:
 1 AEC-6850 Embedded Control PC
 1 Keyboard & mouse cable
 1 AC Power Adapter (AC version only, A1/A2
Version)
 1 Phoenix Power Connector (DC version only,
A3/A4 Version)
 2 Wallmount Brackets
 1 Audio Cable
 1 Screw Package
 1 CD-ROM for manual (in PDF format) and
drivers
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.

Embedded Controller AEC-6850
iv
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from anyAC outlet before cleaning. Do
not use liquid or spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a firm surface during installation. Dropping
it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified
service personnel should open the equipment.
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.

Embedded Controller AEC-6850
v
d. The equipment does not work well, or you cannot get it
to work according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
WHERE THE STORAGE TEMPERATURE IS BELOW -20°C
(-4°F) OR ABOVE 60°C (140°F). IT MAY DAMAGE THE
EQUIPMENT.
FCC Safety
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received including
interference that may cause undesired
operation.
Caution:
There is a danger of explosion if the battery is incorrectly
replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions and your local
government’s recycling or disposal directives.

Embedded Controller AEC-6850
vi
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Boxer/ Industrial System
有毒有害物质或元素
部件名称 铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯
醚(PBDE)
印刷电路板
及其电子组件 ×○○○○○
外部信号
连接器及线材 ×○○○○○
外壳 ×○○○○○
中央处理器
与内存 ×○○○○○
硬盘 ×○○○○○
电源 ×○○○○○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、电源为选购品。

Embedded Controller AEC-6850
vii
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-4
1.3 Specifications............................................................1-5
Chapter 2 Hardware Installation
2.1 Dimension .................................................................2-2
2.2 SDRAM Installation...................................................2-3
2.3 Internal CF Card Installation (IDE interface CF slot for
boot up) ...........................................................................2-4
2.4 COM2 RS-232/422/485 Setting ................................2-6
2.5 COM2 RS-232/422/485 Serial Port Connector.........2-6
2.6 COM 1 RS-232 Serial Port Connector......................2-6
2.7 CD-ROM and 2.5” HDD Kit Installation.....................2-7
2.8 Dual 2.5” HDD Kit Installation ...................................2-11
2.9 3.5” HDD Kit Installation............................................2-15
2.10 Wallmount Bracket Installation................................2-19
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 Award BIOS Setup....................................................3-3
Chapter 4 Driver Installation
4.1 Installation.................................................................4-3

Embedded Controller AEC-6850
viii
Appendix A Programming The Watchdog Timer
A.1 Programming ........................................................A-2
A.2 ITE8712 Watchdog Timer Initial Program ............A-6
Appendix B I/O Information
B.1 I/O Address Map ..................................................B-2
B.2 1st MB Memory Address Map ...............................B-2
B.3 IRQ Mapping Chart ..............................................B-3
B.2 DMA Channel Assignments .................................B-3

Embedded Controller AEC-6850
Chapter 1 General Information 1- 1
General
Chapter
1
Information

Embedded Controller AEC-6850
Chapter 1 General Information 1-2
1.1 Introduction
Due to the growing popularity from the IPC market, the newest
Boxer series AEC-6850 has been introduced by AAEON.
Compared with the AEC-6830, it is an advanced version because it
utilizes an Intel®Celeron®processor without a fan.
New Innovation for Entertainment Multimedia Domain
In this era of information explosion, the advertising of consumer
products will not be confined to the family television, but will also
spread to high-traffic public areas, like department stores, the bus,
transportation station, the supermarket etc. The advertising
marketing industry will resort to every conceivable means to
transmit product information to consumers. System integrators
will need a multifunction device to satisfy commercial needs for
such public advertising.
Being a control center, the AEC-6850 is suitable for public
multimedia entertainment services. Equipped with a high efficiency
heat conduction mechanism, which is patented in Germany, the
AEC-6850 supports up to Celeron® M 1.3GHz processor.
The AEC-6850 is compact in size but has attractive and flexible
extension capabilities such as a 4-in-one card reader, 3 USB2.0
ports, VGA, TV-out, DVI, Audio, 2 COM ports and an optional IEEE
1394(FireWire) port.

Embedded Controller AEC-6850
Chapter 1 General Information 1- 3
Stable Design for Rugged Environment
The AEC-6850 is designed for rugged environments due to the
following reasons; first, it can withstand tough vibration testing up to
5G rms. With the anti-vibration hard drive device option, the
AEC-6850 can be used in high vibration environments. In addition,
the AEC-6850 offers low power consumption system that while
operating in ambient temperatures ranging from -15° to 60°C. The
MTBF(Mean Time Before Failure) rating states that the AEC-6850
can operate up to 50,000 hours at 35°C ambient temperature,
which indicates its careful and long-life design.
The AEC-6850 is a standalone high performance controller
designed for long-life operation and with high reliability. It can
replace traditional methods and become the mainstream
controller for the multimedia entertainment market.

Embedded Controller AEC-6850
Chapter 1 General Information 1-4
1.2 Features
• Fanless Design with Intel®Celeron®M 600MHz / 1.3GHz
Processor
• 4 in 1 Card Reader
• 2 COM / S-video / 3 USB 2.0 / Ethernet

Embedded Controller AEC-6850
Chapter 1 General Information 1- 5
1.3 Specifications
System
 CPU: Intel®Celeron®M 600MHz/ 1.3GHz
Processor
 Construction: Rugged Aluminum Alloy chassis
 System Memory: DDR SODIMM x 1, Max. 512MB
 VGA: DB-15 VGA connector
 Keyboard/Mouse: PS/2 Keyboard & Mouse
 Ethernet: 10/100Base-TX RJ-45 connector x 1
 SSD: Internal Type II CompactFlash™slot x 1
 Card Reader: CompactFlash™, SD/ MMC/ MS/ XD
 Device Bay
(Optional):
CD-ROM & 2.5”HDD Kit, 2 x 2.5” HDD Kit,
3.5” HDD Kit
 Serial Port: 1 x RS-232, 1 x RS-232/422/485
 Audio: MIC / Line In / Line Out by expansion
cable
 USB: 3 USB 2.0 ports
 DVI: DVI connector x 1
 Watchdog Timer: Generate a time-out System reset, setting
via software
 Power Supply: A1/A2 Version—AC Input:
External Power Adapter; Input Voltage:
100V AC~240V AC@ 50 ~ 60Hz;
A3/A4 Version—DC Input: 9V DC~30V DC

Embedded Controller AEC-6850
Chapter 1 General Information 1-6
 System Control: Power on / off switch x 1; Reset button x 1
 Indicator: Power LED x 1; HDD active LED x 1
 OS Support: Windows®CE. NET, Windows®XP
Embedded, Windows®XP, Windows®
2000
Mechanical and Environmental
 Construction: Rugged Aluminum Alloy chassis
 Color: Dark Blue
 Mounting: Wallmount, Desktop
 Dimension: 8.35” (W) x 2.53” (H) x 6.26” (D) (212mm x
64mm x 159mm)
 Net Weight: 5.57lb (2.53kg)
 Gross Weight: 10.34lb (4.7kg)
 Operation
Temperature:
14°F~140°F (-15°C~60°C) – Celeron®M
600MHz/CFD;
14°F~122°F(-15°C~50°C) –Celeron®M
600MHz/HDD;
14°F ~ 122°F (-15°C ~ 50°C) – Celeron®
M 1.3GHz/CFD;
14°F ~ 113°F (-15°C ~ 45°C) – Celeron®M
1.3GHz/HDD
 Operation
Humidity:
5~95% @ 40°C, non-condensing

Embedded Controller AEC-6850
Chapter 1 General Information 1- 7
 Vibration: 5 g rms / 5~500Hz / random operation
(CFD) 1 g / 5~500Hz / random operation
(HDD)
 Shock: 100g peak acceleration (11 msec.
duration)
15g peak acceleration (11 msec. duration)
(HDD)
 EMC: CE/FCC class B

Embedded Controller AEC-6850
Chapter 1 General Information 1-8
Front Side
Rear Side
TV-Out
S-Video
Ethernet
RJ-45, 10/100
Audio
Mini-Din 9-pin Line
Out/In, MIC In
Line out
USB 2.0 Port x 2
HDD LED
Reset
Power Switch 4-in-1 Card Reader
DVI
KB/Mouse
Mini-DIN 6-pin
VGA
D-sub 15-pin
Serial port
D-sub 9-pin
Serial port
D-sub 9-pin
USB 2.0 Port x 1
Power LED
Power Inlet
Mini-Din 4-pin

Embedded Controller AEC-6850
Chapter 2 Hardware Installation 2-1
Hardware
Installation
Chapter
2

Embedded Controller AEC-6850
Chapter 2 Hardware Installation 2 - 2
2.1 Dimension

Embedded Controller AEC-6850
Chapter 2 Hardware Installation 2 - 3
2.2 SDRAM Installation
Step 1: Take off the lid from the bottom of the chassis by loosening the
screws.
Step 2: Insert the SDRAM Module into the slot.
X
SDRAM Module Slot
Y
