Aaeon RTC-700B User manual

Last Updated: October 12, 2016
RTC-700B
Rugged Tablet Computer
User’s Manual 1st Ed

Preface II
Rugged Tablet Computer RTC-700B
Copyright Notice
This document is copyrighted, 2016. All rights are reserved. The original manufacturer
reserves the right to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any
form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design without notice to its
users.

Preface III
Rugged Tablet Computer RTC-700B
Acknowledgement
All other products’ name or trademarks are properties of their respective owners.
Intel® Atom is registered trademarks of Intel® Corporation
Microsoft® Windows is a registered trademark of Microsoft® Corporation.
All other product names or trademarks are properties of their respective owners.

Preface IV
Rugged Tablet Computer RTC-700B
Packing List
Before setting up your product, please make sure the following items have been
shipped:
Item
Quantity
RTC-700B with Windows 10 1
AC/DC power adapter 1
Product DVD with User’s Manual (in pdf) 1
If any of these items are missing or damaged, please contact your distributor or sales
representative immediately.

Preface V
Rugged Tablet Computer RTC-700B
About this Document
This User’s Manual contains all the essential information, such as detailed descriptions
and explanations on the product’s hardware and software features (if any), its
specifications, dimensions, jumper/connector settings/definitions, and driver
installation instructions (if any), to facilitate users in setting up their product.
Users may refer to the AAEON.com for the latest version of this document.

Preface VI
Rugged Tablet Computer RTC-700B
Safety Precautions
Please read the following safety instructions carefully. It is advised that you keep this
manual for future references
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the device.
3. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
4. Always completely disconnect the power before working on the system’s
hardware.
5. No connections should be made when the system is powered as a sudden rush
of power may damage sensitive electronic components.
6. If the device is not to be used for a long time, disconnect it from the power
supply to avoid damage by transient over-voltage.
7. Always disconnect this device from any AC supply before cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray detergents.
9. Make sure the device is installed near a power outlet and is easily accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent falls
12. Do not cover the openings on the device to ensure optimal heat dissipation.
13. Watch out for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is running
15. Never pour any liquid into the openings. This could cause fire or electric shock.
16. As most electronic components are sensitive to static electrical charge, be sure
to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and contain all electronic components
in any static-shielded containers.

Preface VII
Rugged Tablet Computer RTC-700B
17. If any of the following situations arises, please the contact our service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described in
this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
18.
DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED ENVIRONMENT WITH
TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES
(SEE CHAPTER 1) TO PREVENT DAMAGE.

Preface VIII
Rugged Tablet Computer RTC-700B
FCC Statement
This device complies with Part 15 FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept
any interference received including interference that may
cause undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions and your local government’s
recycling or disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et
les directives gouvernementales de recyclage.

Preface IX
Rugged Tablet Computer RTC-700B
China RoHS Requirements (CN)
产品中有毒有害物质或元素名称及含量
AAEON Panel PC/ Workstation
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
○
○
○
○
○
○
外部信号
连接器及线材
○
○
○
○
○
○
外壳
○
○
○
○
○
○
中央处理器
与内存
○
○
○
○
○
○
硬盘
○
○
○
○
○
○
液晶模块
○
○
○
○
○
○
光驱
○
○
○
○
○
○
触控模块
○
○
○
○
○
○
电源
○
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006
标准规定的限量要求以下。
X
：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006
标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、触控模块为选购品。

Preface X
Rugged Tablet Computer RTC-700B
China RoHS Requirement (EN)
Poisonous or Hazardous Substances or Elements in Products
AAEON Panel PC/ Workstation
Component
Poisonous or Hazardous Substances or Elements
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
PCB & Other
Components
OO O O O ○
Wires &
Connectors
for External
Connections
OO O O O O
Chassis
OO O O O O
CPU & RAM
OO O O O O
Hard Disk
OO O O O O
LCD
OO O O O O
Optical Drive
OO O O O O
To u c h s c r e e n
OO O O O O
PSU
OO O O O O
O
：
The quantity of poisonous or hazardous substances or elements found in each of the
component's parts is below the SJ/T 11363-2006-stipulated requirement.
X: The quantity of poisonous or hazardous substances or elements found in at least one of the
component's parts is beyond the SJ/T 11363-2006-stipulated requirement.
Note: The Environment Friendly Use Period as labeled on this product is applicable under normal
usage only

Preface XI
Rugged Tablet Computer RTC-700B
Table of Contents
Chapter 1 - Product Specifications........................................................................................1
1.1 Specifications........................................................................................................... 2
Chapter 2 – Getting Started...................................................................................................5
2.1 Product Overview .................................................................................................. 6
2.2 Notes Before Use ................................................................................................. 11
2.3 Turning On the Device ........................................................................................ 13
2.4 Touch Controls ...................................................................................................... 14
Chapter 3 – Setting Up.........................................................................................................15
3.1 Settings Screen ..................................................................................................... 16
3.1.1 System................................................................................................... 19
3.1.2 Device ................................................................................................... 22
3.1.3 Network & Internet ............................................................................ 23
3.1.4 Personalization Settings .................................................................... 25
3.1.5 Accounts Settings ............................................................................... 26
3.1.6 Time & Language Settings ............................................................... 27
3.1.7 Ease of Access Settings ..................................................................... 28
3.1.8 Privacy Settings ................................................................................... 29
3.1.9 Update & Security .............................................................................. 30
Chapter 4 – Optional Accessories.......................................................................................31
4.1 1D/2D Code Scanner .......................................................................................... 32
4.2 Magnetic Stripe Reader (MSR) .......................................................................... 33
4.3 Smart Card Reader (SCR) ................................................................................... 33
4.4 Docking Station .................................................................................................... 34
4.4.1 Specifications....................................................................................... 35
Chapter 5 – Drivers Installation ...........................................................................................37
5.1 Product CD/DVD.................................................................................................. 38

Preface XII
Rugged Tablet Computer RTC-700B
Appendix A - Statements .....................................................................................................41
A.1 Statements............................................................................................................. 42
A.2 Canadian Notice................................................................................................... 44
A.3 Safety Caution....................................................................................................... 45
A.4 Battery Disposal.................................................................................................... 47
A.5 Battery Caution..................................................................................................... 49
A.6 Adapter Caution................................................................................................... 50
A.7 FCC Interference Statement............................................................................... 51

Rugged Tablet Computer RTC-700B
Chapter 1
Chapter 1 - Product Specifications

Chapter 1 – Product Specifications 2
Rugged Tablet Computer RTC-700B
1.1 Specifications
System

Processor
Intel® AtomTM x5-Z8350 Quad-Core up to
1.92 GHz

System Memory
DDR3L-RS 1600 2GB

LCD Display
7” (1280 x 800) TFT LCD with 10-point P-cap
Anti-Scratch Screen

Communication
WiFi a/b/g/n
Bluetooth 3.0 (EDR) with integrated class 1 PA
and BLE Support

I/O Port
Mini USB x 1
USB Type A x 1
USB Type C x 1

3.5 mm Stereo Headphone Jack x 1
DC-In Jack x 1
Built-In Speaker & Microphone
10-pin Cradle Pin
SIM Card Slot
Micro SD card slot

Storage
64 GB eMMC Flash

Navigation
GPS/ Glonass/ AGPS (when 3G is enabled)
E-Compass

Camera
2MP Front Camera,8MP Rear Camera

Sensor
Built-in Light Sensor

Chapter 1 – Product Specifications 3
Rugged Tablet Computer RTC-700B
Built-in G-Sensor
Built-in 3-axis Digital Gyroscope
Built-in Vibration Motor

OS
Window 10
Mechanical

Color
Black

Dimension (W x H x D)
136.6 x 219 x 21 mm (5.38 x 8.58 x 0.83”)

Gross Weight
0.57 Kg (1.25 lb)

Carton Dimension
245 x 158 x 82 mm (96.5 x 62.2 x 32.3”)
Environmental

Operating Temperature
-20°C ~ 50°C (-4 ~ 122°F)

Storage Temperature
-55°C ~ 75°C (-67 ~ 167°F)

Operating Humidity
10 ~ 75%

Water/ Dust Protection
Rating
IP65

Vibration
Met MIL-STD-810G-514.6 Procedure I Cat.24,
Fig 514.6E-1 & 514.6E-2 (Unit is non-operating)
ASTM 4169-99 Truck Assurance Level II,
Schedule E (Unit is non-operating)

Drop
26 drops from 150 cm height to 2“ plywood over
concrete with bumpers & unit off
2 units to pass

Chapter 1 – Product Specifications 4
Rugged Tablet Computer RTC-700B
MIL-STD-810G-516.6, Procedure IV

ESD
Air +/- 8KV, Contact +/- 4KV

EMI/ Safety
CE/ FCC Class B/ UL
Power Supply
AC/DC Adapter
AC Power Input: 100 ~ 240 V, 50 ~ 60 Hz, 36 W
output: 12 V, 3 A
Battery
Lithium-Polymer High Capacity Battery
swappable, 6 hrs
1) Master BAT/Hard pack: 7.4V 1530 mAh
2) Slave BAT/Soft pack:7.4V 1530 mAh
LCD

Display Type
7” TFT LCD Module with LED Backlight

Max. Resolution
1280 x 800

Max. Colors
16.7 M

Dot Size (H x W)
0.117x 0.117

Luminance (cd/m2)
400 nit

Viewing Angle
Horizontal: 178°
Vertical: 178°

Rugged Tablet Computer RTC-700B
Chapter 2
Chapter 2 – Getting Started

Chapter 2 – Getting Started 6
Rugged Tablet Computer RTC-700B
2.1 Product Overview
Front View

Chapter 2 – Getting Started 7
Rugged Tablet Computer RTC-700B
Side View (Left)
Part
Function
USB Type A
You may connect a USB type A device (ie USB flash drive)
or extension cable directly to the tablet.
COM/ Ethernet Port
(Optional)
A module with a RS-232 and RJ-45 port.
SIM Card Slot
Usable with standard-size SIM cards only.
Cradle Interface
For interaction with the tablet’s docking station.
3.5 mm Audio Jack
Usable with any audio device with a 3.5 mm jack.
USB
Type A
Cradle Interface
COM/ Ethernet Module
SIM Card Slot
3.5 mm Audio Jack

Chapter 2 – Getting Started 8
Rugged Tablet Computer RTC-700B
Side view (Right)
Part
Function
USB Type C
Usable with a USB Type C cable
DC-in Jack
Connect the DC power cable to this jack.
Mini USB
Usable with a Micro USB cable.
Power Button
Turns the tablet on/off. If the system is unresponsive, press
and hold the button to forced power off.
Micro-SD Card Slot
A micro-SD card (or adapter) can be inserted here.
Front Camera
Ext.GPS ANT
Micro SD Slot
Power Button
USB Type C
Mini USB
DC-in
Speaker
