Aaeon BOXER-6404 User manual

Embedded Box PC BOXER- 6 404
BOXER-6404 Manual 1st Ed.
September 8, 2015
BOXER-6404
Intel®Celeron®/ Atom™ Processor
LAN, HDMI, USB, COM
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
Copyright Notice
This document is copyrighted, 2015. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
i
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
Acknowledgments
•AMI is a trademark of American Megatrends Inc.
•CFast™is a trademark of the Compact Flash Association.
•Intel®, Atom™are trademarks of Intel®Corporation.
•Microsoft Windows®is a registered trademark of Microsoft
Corp.
•PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
All other product names or trademarks are properties of their
respective owners.
ii
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
Packing List
Before you begin operating your PC, please make sure that the
following materials have been shipped:
1 BOXER-6404 Embedded Box PC
1 Power Adapter
1 DVD-ROM for manual (in PDF format) and
Drivers
If any of these items should be missing or damaged, please contact
your distributor or sales representative immediately.
iii
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
Safety & Warranty
Please read the following safety instructions carefully. It is advised
that you keep this manual for future references
1. Disconnect this device from any AC supply before cleaning.
2. While cleaning, use a damp cloth instead of liquid or spray
detergents.
3. For any pluggable equipment, the power outlet must be installed
near the device and easily accessible.
4. Keep this device away from humidity.
5. Place this device on a solid surface during installation. Dropping
it or letting it fall could cause damage.
6. The openings on the device’s enclosure are for dissipating heat.
DO NOT COVER THE OPENINGS.
7. Watch out for high temperatures that may occur during system
operation.
8. Make sure the voltage of the power source is correct before
connecting the device to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the device should be noted.
11. If the device is not to be used for a long time, disconnect it from
the power supply to avoid damage by transient over-voltage.
12. Never pour any liquid into the openings. This could cause fire or
electric shock.
iv
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
13. As most electronic components are sensitive to static electrical
charge, be sure to ground yourself to prevent static charge when
installing the internal components. Use a grounding wrist strap
and contain all electronic components in any static-shielded
devices.
14. If any of the following situations arises, please the contact
our service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner
as described in this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the
device
15. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -30° C (-22°F) OR ABOVE 80° C (176° F) TO
PREVENT DAMAGE.
v
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received including
interference that may cause undesired
operation.
Caution:
There is a danger of explosion if the battery is incorrectly
replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions and your local
government’s recycling or disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du
fabricant et les directives gouvernementales de recyclage.
vi
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Boxer/ Industrial System
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯
醚
(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
外壳
×
○
○
○
○
○
中央处理器
与内存
×
○
○
○
○
○
硬盘
×
○
○
○
○
○
电源
×
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006
标准规定的限量要求以下。
X
：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006
标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、电源为选购品。
vii
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
China RoHS Requirements
Poisonous or Hazardous Substances or Elements in Products
AAEON Embedded Box PC/ Industrial System
Component
Poisonous or Hazardous Substances or Elements
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
PCB & Other
Components X O O O O O
Wires &
Connectors
for External
Connections
X O O O O O
Chassis X O O O O O
CPU & RAM X O O O O O
Hard Disk X O O O O O
PSU X O O O O O
O
：
The quantity of poisonous or hazardous substances or elements found in each of the
component's parts is below the SJ/T 11363-2006-stipulated requirement.
X: The quantity of poisonous or hazardous substances or elements found in at least one
of the component's parts is beyond the SJ/T 11363-2006-stipulated requirement.
Note: The Environment Friendly Use Period as labeled on this product is
applicable under normal usage only
viii
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
Contents
Chapter 1 General Information
1.1 Introduction................................................................ 1-2
1.2 Features .................................................................... 1-3
1.3 Specifications............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Product Overview......................................................2-2
2.2 Setting Jumpers ........................................................ 2-3
2.3 List of Jumpers.......................................................... 2-4
2.3.1 Clear CMOS (JP12 pin 1,3,5)........................2-5
2.3.2 Auto Power Button Enable/ Disable Selection
(JP12 pin 2,4,6).....................................................2-5
2.3.3 Push Power Button with Orange LED (SW1) 2-5
2.4 List of Connectors .....................................................2-7
2.4.1 COM Port RS-232 (CN1)............................... 2-9
2.4.2 +12 V Input (CN2)..........................................2-9
2.4.3 LAN (RJ-45) Port 1,2,3,4 (JP3,4,5,6) ............ 2-10
2.4.4 +5 V Output for SATA HDD (CN7) ................2-10
2.4.5 SATA Port (CN8)...........................................2-11
2.4.6 DDR3L SO-DIMM Slot (CN9)........................ 2-11
2.4.7 C-FAST Card Connector (CN11) ..................2-11
2.4.8 MiniCard Slot (CN13) (USB Port2 Only) .......2-13
2.4.9 Battery (CN14)............................................... 2-15
2.4.10 USB 3.0 Port 0 (CN17)................................2-15
2.4.11 USB 2.0 Port 1,3 (CN18,19)........................ 2-16
ix
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
2.4.12 HDMI Port 1,2 (CN20,21) ............................2-17
2.4.13 LPC Port (CN22) .........................................2-18
2.4.14 SPI Programming Header (CN23) .............. 2-19
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization. .................................. 3-2
3.2 AMI BIOS Setup........................................................3-3
Chapter 4 Driver Installation
4.1 Installation ................................................................. 4-3
Appendix A Programming The Watchdog Timer
A.1 Watchdog Timer Registers ....................................A-2
A.2 Watchdog Sample Program...................................A-3
Appendix B I/O Information
B.1 I/O Address Map ..................................................B-2
B.2 Memory Address Map ..........................................B-4
B.3 IRQ Mapping Chart ..............................................B-5
Appendix C Electrical Specifications for I/O Ports
C.1 Electrical Specifications for I/O Ports ................... C-2
x
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER- 6 404
General
Information
Chapter
1
Chapter 1 General Information 1-1
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
1.1 Introduction
AAEON introduces the slim BOXER-64 series embedded box PCs,
with the Intel®Celeron®/ Atom™processors: this box PC expands
its graphics performance greatly with the newest generation of
Celeron®/ Atom™processors.
So far, there is no other boxer PC can be so small and slim like the
BOXER-64 series, not even PICO-ITX system. With this tiny form
factor, customers can fit it almost anywhere, and it provides quite a
lot of I/O ports for basic applications. BOXER-6404 adopts a
reliable fanless design for most rugged environment. It also
provides wireless communication features for users wishing to build
up a network connection at any locations.
The BOXER-6404 is a standalone high performance PC designed
for extended operation and with high reliability. It can replace
traditional methods and become the mainstream boxer PC for
diversified markets.
Chapter 1 General Information 1-2
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER- 6 404
1.2 Features
•Slim Design
•4 LAN, 2 HDMI
•Supports Wide Operating Temperature
Chapter 1 General Information 1-3
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
1.3 Specifications
CPU Intel®Atom™ N2807/ Celeron® J1900
Chipset -
System Memory 204-pin DDR3L 1333 MHz SODIMM x
1, up to 8 GB, (J1900)
204-pin DDR3L 1333 MHz SODIMM x
1, up to 4 GB, (N2807)
Display
Interface
HDMI HDMI x 2
Storage
Device
CF-SATA CFast™ x 1
Network LAN Gigabit Ethernet
Wireless Optional
Front I/O USB Host USB 2.0 x 2, USB 3.0 x 1
LAN －
Serial Port －
DIO －
Audio －
KB/MS －
Others Power On/Off button x 1, HDMI x 2
Rear I/O USB Host －
LAN RJ-45 x 4
Serial Port RS-232 x 1
DIO －
Chapter 1 General Information 1-4
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER- 6 404
Audio －
KB/MS －
Others －
Expansion PCIe －
PCI －
MiniCard Half MiniCard x 1 (USB Only)
Mini PCI －
Others －
Indicator Front －
Rear －
Power Requirement 12 V DC-in with lockable connector
ATX mode (optional AT by jumper/
BIOS setting)
System Cooling Passive cooling
Mounting Wall-mount
Operating Temperature -20~ 50°C with 0.5 m/s Air Flow
(J1900)
-20 ~ 60°C with 0.5 m/s Air Flow
(N2807)
Storage Temperature -30 ~ 80°C (-22 ~ 176°F)
Anti-Vibration 5 Grms/ 5~500 Hz/ operation (CFast)
Anti-Shock 50 G peak acceleration (11 msec.
duration) – (CFast)
Certification EMC CE/FCC Class A
Safety －
Chapter 1 General Information 1-5
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC BOXER-6404
Dimension (W x H x D) 166 x 106.6 x 30 mm (6.5 x 4.2 x 1.2”)
OS Support Windows® Embedded Standard 8
32/64-bit,
Windows® Embedded Standard 7
32/64-bit,
Windows® 8.1 32/64-bit
Windows® 7 32/64-bit
Linux by Fedora kernel 2.6.3 up
Chapter 1 General Information 1-6
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC
B O X E R - 6404
Chapter 2 Hardware Installation 2-1
Quick
Installation
Guide
Chapter
2
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC
B O X E R - 6404
Chapter 2 Hardware Installation 2 - 2
2.1 Product Overview
Units in mm
DISTRIBUTED BY TEXIM EUROPE

Embedded Box PC
B O X E R - 6404
Chapter 2 Hardware Installation
2 - 3
2.2 Setting Jumpers
You configure your card to match the needs of your application by
setting jumpers. A jumper is the simplest kind of electric switch. It
consists of two metal pins and a small metal clip (often protected by
a plastic cover) that slides over the pins to connect them. To “close”
a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will
have three pins, labeled 1, 2 and 3. In this case you would connect
either pins 1 and 2 or 2 and 3.
123
Open Closed Closed 2-3
A pair of needle-nose pliers may be helpful when working with
jumpers.
If you have any doubts about the best hardware configuration for
your application, contact your local distributor or sales
representative before you make any change.
In general, you simply need a standard cable to make most
connections.
DISTRIBUTED BY TEXIM EUROPE
