Aaeon AHP-2176 User manual

Touch Panel PC
AHP - 2176
AHP-2176
Onboard Intel®Celeron®827E
1.4GHz Processor
Touch Panel PC
With 17”TFT LCD
AHP-2176 Manual 3rd Ed.
April 30, 2014

Touch Panel PC
AHP - 2 176
i
Copyright Notice
This document is copyrighted, 2014. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Touch Panel PC
AHP - 2 176
ii
Acknowledgments
All other products’name or trademarks are properties of their
respective owners.
AMI is a trademark of American Megatrends Inc.
Intel®, and Atom™are trademarks of Intel®Corporation.
Microsoft Windows®is a registered trademark of Microsoft
Corp.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
All other product names or trademarks are properties of their
respective owners.

Touch Panel PC
AHP - 2 176
iii
Packing List
Before you begin operating your PC, please make sure that the
following materials are enclosed:
AHP-2176 Touch Panel PC
Mounting brackets and screws
DVD-ROM for manual (in PDF format) and drivers
If any of these items should be missing or damaged, please contact
your distributor or sales representative immediately.

Touch Panel PC
AHP - 2 176
iv
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Do
not use liquid or spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a firm surface during installation. Dropping
it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified
service personnel should open the equipment.
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.

Touch Panel PC
AHP - 2 176
v
d. The equipment does not work well, or you cannot get it
to work according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
WHERE THE STORAGE TEMPERATURE IS BELOW -20°C
(-4°F) ORABOVE 60°C (140°F). IT MAY DAMAGE THE
EQUIPMENT.
16. RESTRICTED ACCESS LOCATION: location for equipment
where both of the following apply:
a. access can only be gained by SERVICE PERSONS or by
USERS who have been instructed about the reasons for
the restrictions applied to the location and about any
precautions that shall be taken; and
b. access is through the use of a TOOL or lock and key, or
other means of security, and is controlled by the authority
responsible for the location
17. Caution: There is a danger of explosion if the battery is incorrectly
replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions and your local
government’s recycling or disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon
incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent
recommandé par le constructeur. Recycler les batteries usées en accord
avec les instructions du fabricant et les directives gouvernementales de
recyclage.

Touch Panel PC
AHP - 2 176
vi
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received including
interference that may cause undesired
operation.

Touch Panel PC
AHP - 2 176
vii
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Panel PC/ Workstation
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
外壳
×
○
○
○
○
○
中央处理器
与内存
×
○
○
○
○
○
硬盘
×
○
○
○
○
○
液晶模块
×
○
○
○
○
○
光驱
×
○
○
○
○
○
触控模块
×
○
○
○
○
○
电源
×
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、触控模块为选购品。

Touch Panel PC
AHP - 2 176
viii
Contents
Chapter 1 General Information
1.1 Introduction................................................................ 1-2
1.2 Specification..............................................................1-3
1.3 Dimension .................................................................1-6
Chapter 2 Hardware Installation
2.1 Panelmount Installation.............................................2-2
2.2 Hard Disk Drive Installation....................................... 2-4
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization ................................... 3-2
3.2 AMI BIOS Setup........................................................ 3-3
Chapter 4 Driver Installation
4.1 Introduction................................................................ 4-3
Appendix A Programming the Watchdog Timer
A.1 Watchdog Timer Initial Program ............................A-2
Appendix B I/O Information
B.1 I/O Address Map ..................................................B-2
B.2 Memory Address Map ..........................................B-4
B.3 IRQ Mapping Chart ..............................................B-5
B.4 DMA Channel Assignments .................................B-7

Touch Panel PC
A H P - 2 176
Chapter 1 General Information 1- 1
General
Information
Chapter
1

Touch Panel PC
AHP- 2 176
Chapter 1 General Information 1- 2
1.1 Introduction
The AHP-2176 operator panel is an onboard Intel®Celeron®827E
1.4GHz processor computer that is designed to serve as a human
machine interface (HMI). It is a PC-based system with 17" color
TFT LCD display, onboard Ethernet controller, multi-COM port
interfaces and an audio controller. With a built-in CFast™socket,
the AHP-2176 is as compact and user friendly as a multi-function
computer. In addition, its "fit anywhere" design makes it very flexible
and able to be used in many different kinds of installations. It can be
Panel / VESA / Wallmounted.
For system integrators, this simple, complete, compact and highly
integrated system let you easily build an operator panel into your
applications. Common industrial applications include factory
automation systems, precision machinery, and production process
control. It is also suitable for many non-industrial applications,
including vending machine, and car park automation. Our operator
panel is a reliable, cost-effective solution to your application's
processing requirements.

Touch Panel PC
A H P - 2 176
Chapter 1 General Information 1-3
1.2 Specification
System
CPU
Onboard Intel®Celeron®827E 1.4GHz
Processor
System Memory
DDR3 800/1066/1333 MHz (204 pin) x
2, SODIMM, Max. 8GB
Ethernet
10/100/1000Base-T, RJ-45 x 2
LCD / CRT Controller
Integrated in Processor
I/O Port
USB2.0 x 4 (2 on front, 2 on rear)
DB-9 RS-232 x 4 (COM3/4/5/6)
LAN x 2
VGA x 1
Line-out x 1
Power switch x 1
Storage Disk Drive
CFast™ slot x 1 (Internal);
2.5” SATA Hard Disk Drive x 1
Expansion Slot
Mini PCIe Card x 2
OS Support
Windows®CE, Windows®XP,
Windows®XP embedded, Windows®7,
linux kernel 2.6.3 or above
Mechanical
Construction
IP-65 aluminum die cast front bezel
Mounting
Panel/ Wall/ VESA 100/ Desktop

Touch Panel PC
AHP- 2 176
Chapter 1 General Information 1- 4
Dimension
16.5”(W) x 14.1”(H) x 2.8”(D) (420mm x
358mm x 97mm)
Carton Dimension
26”(W) x 8.11”(H) x 19.53”(D) (661mm x
206mm x 496mm)
Net Weight
17.9 lb (8.1 kg)
Gross Weight
23.1 lb (10.5 kg)
Environmental
Operating Temperature
-4oF~140oF (-20oC~60oC)
Storage Temperature
-4oF~158oF (-20oC~70oC)
Operating Humidity
5% to 95%@ 40oC, non-condensing
Vibration
1 g rms/ 5-500Hz/ Operation (HDD)
Shock
20 G peak acceleration (11 msec.
duration)
EMC
CE/FCC Class A
Power Supply
9~30V DC input ;
Over-voltage protection
Low-voltage protection
Reverse protection
Power Supply
DC Input
9~30V DC input ;
Over-voltage protection
Low-voltage protection
Reverse protection

Touch Panel PC
A H P - 2 176
Chapter 1 General Information 1-5
LCD
Display Type
17”TFT LCD
Max. Resolution
1280x1024
Max. Colors
16.7M colors
Luminance (cd/m2)
HTT : 350
Viewing Angle
HTT: 170o(H),160o(V)
Backlight
LED
Backlight MTBF (Hours)
HTT : 50,000
Touch Screen
Type
5-wire analog resistive
Resolution
2048x2048
Light Transmission
> 80%
Lifetime
35 million activations

Touch Panel PC
AHP- 2 176
Chapter 1 General Information 1- 6
1.3 Dimension
419.76
357.79
97.30
AHP- 2176
100.00
100.00
404.03
338.03
VESA 100
300.00
34.75
UNITS:m m

Touch Panel PC
AHP - 2 1 76
Chapter 2 Quick Installation Guide 2-1
Hardware
Installation
Chapter
2

Touch Panel PC
AHP- 2 176
Chapter 2 Quick Installation Guide 2 - 2
2.1 Panelmount Installation
The display panel can be mounted into the wall. You will need the
screws along with the mounting brackets, which be packed in the
accessory box. Follow the steps below:
Before you start to follow the instructions, please place the
display panel into the wall. See the following illustration on the
left.
Step 1: Place the mounting brackets and plug the screw.
Step 2: Aim the mounting set at the hole on the monitor.
Step 3: Move the mounting set to the narrow gauge and fix it with
screws.
Step 4: You’ve completed the preliminary when the mounting set
is tightened. Next, repeat the steps and tighten all mounting set
around the monitor until the monitor is firmly mounting on the
wall.

Touch Panel PC
AHP - 2 1 76
Chapter 2 Quick Installation Guide
2 - 3
1 2 3 4
Complete Illustration

Touch Panel PC
AHP- 2 176
Chapter 2 Quick Installation Guide 2 - 4
2.2 COM Port Connector
Pin
2BSignal
Pin
3BSignal
1
DCD
2
RXD
3
TXD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI
1
2
5
6
7
8
9
4

Touch Panel PC
AHP - 2 1 76
Chapter 2 Quick Installation Guide
2 - 5
2.3 Hard Disk Drive Installation
Step 1: Unfasten the screws of the heatsink
Step 2: Get the Bracket of Hard Disk Drive from the package
