Aaeon IMBA-Q17A User manual

Industrial Motherboard
IMBA-Q170A

ii
E15232
Revised Edition V2
February 2019
Copyright Notice
This document is copyrighted, 2019. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products described
in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted
in any form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use,
or for any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to
change without notice. While reasonable efforts have been made in the preparation
of this document to assure its accuracy, the original manufacturer assumes no
liabilities resulting from errors or omissions in this document, or from the use of the
information contained herein.
The original manufacturer reserves the right to make changes in the product
design without notice to its users.
Acknowledgments
All other products’ name or trademarks are properties of their respective owners.
• AMI is a trademark of American Megatrends Inc.
• Intel®, Core™ are trademarks of Intel®Corporation.
• Microsoft Windows®is a registered trademark of Microsoft Corp.
• IBM, PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
The original manufacturer reserves the right to make changes in the product
design without notice to its users.
All other product names or trademarks are properties of their respective owners.

iii
Contents
Chapter 1: Product overview
1.1 Package contents......................................................................... 1-1
1.2 Features ........................................................................................ 1-1
1.3 Specications............................................................................... 1-2
Chapter 2: Motherboard information
2.1 Before you proceed ..................................................................... 2-1
2.2 Motherboard layout...................................................................... 2-2
2.3 Screw size..................................................................................... 2-4
2.3.1 Component side.............................................................. 2-4
2.3.2 Solder side ...................................................................... 2-5
2.4 Central Processing Unit (CPU) ................................................... 2-6
2.4.1 Installing the CPU ........................................................... 2-7
2.4.2 CPU heatsink and fan assembly installation................... 2-9
2.5 System memory ......................................................................... 2-10
2.6 Jumpers ...................................................................................... 2-12
2.7 Connectors ................................................................................. 2-15
2.7.1 Rear panel connectors.................................................. 2-15
2.7.2 Internal connectors ....................................................... 2-17
Chapter 3: BIOS setup
3.1 BIOS setup.................................................................................... 3-1
3.2 Main menu .................................................................................... 3-2
3.2.1 System Date [Day MM/DD/YYYY] .................................. 3-2
3.2.2 System Time [HH:MM:SS] .............................................. 3-2
3.3 Advanced menu ........................................................................... 3-2
3.3.1 CPUConguration .......................................................... 3-3
3.3.2 Trusted Computing ......................................................... 3-3
3.3.3 SATAConguration ........................................................ 3-4
3.3.4 PCH-FWConguration ................................................... 3-5
3.3.5 SIOConguration ........................................................... 3-5
3.3.6 NCT6791D HW Monitor .................................................. 3-6
3.3.7 USBConguration .......................................................... 3-8
3.3.8 DigitalIOPortConguration ........................................... 3-8
3.3.9 Power Management........................................................ 3-9
3.4 Chipset menu ............................................................................. 3-10

iv
3.4.1 SystemAgent(SA)Conguration ................................. 3-10
3.4.2 PCH-IOConguration ................................................... 3-10
3.5 Security menu ............................................................................ 3-10
3.5.1 Administrator Password ................................................ 3-11
3.5.2 User Password.............................................................. 3-11
3.6 Boot menu .................................................................................. 3-12
3.6.1 BootConguration ........................................................ 3-12
3.6.2 Boot Option Priorities .................................................... 3-12
3.7 Save & Exit menu....................................................................... 3-12
Appendix
Notices.......................................................................................................A-1

1-1
Chapter 1: General information
1.1 Package contents
Check your industrial motherboard package for the following items.
1 x Industrial Motherboard
1 x SATA 6.0Gb/s cable
1 x COM cable
1 x I/O Shield
1 x Support CD
If any of the above items is damaged or missing, contact your distributor or sales
representative immediately.
1.2 Features
• Intel®7th/ 6th Generation Core™ i7/ i5/ i3, Pentium®and Celeron®14nm LGA1151
socket processor
• 4 x DIMMs, max. 64GB, DDR4 2400*/ 2133/ 1867 MHz, non-ECC, un-buffered
memory
• 4 x SATA III 6.0 Gb/s (one colay with M.2 M-key, BOM option), 10 x USB 3.0, 3 x
USB 2.0
• Realtek®ALC8876-ChannelHighDenitionAudioCODEC
• Multi Display: VGA+HDMI, HDMI+HDMI, VGA+HDMI+HDMI
• Dual Ethernet LAN: 1 x Intel®PHY i219LM Giga LAN (supports Intel®AMT 11.0), 1
x Intel®i211AT Giga LAN
• 1 x PCIe 3.0/2.0 [x16] slot, 2 x PCIe 3.0 [x4] slots (only one slot supported in the 4
SATA III SKU), 3 x PCI slots
• 1 x M.2 E key (22 x 30mm) slot for PCIe/USB/I2C-ME/SDIO/UART/PCM,
1 x M.2 M key (22 x 80mm) slot for Storage (PCIe[x4] module only supported in
4*SATA III SKU)
Chapter 1
Product overview

IMBA-Q170A
1-2
1.3 Specications
(continued on the next page)
SYSTEM
CPU Intel®7th/ 6th Generation Core™ i7/ i5/ i3, Pentium®and Celeron®14nm
LGA1151 socket processor
Chipset Intel®Q170 Express Chipset
Memory 4 x DIMMs, max. 64GB, DDR4 2400*/ 2133/ 1867 MHz, non-ECC,
un-buffered memory
Dual channel memory architecture
I/O Chipset NCT6791D + F81216HD
Ethernet 1 x Intel®PHY i219LM Giga LAN (supports Intel®AMT 11.0)
1 x Intel®i211AT Giga LAN
Audio Realtek®ALC8876-ChannelHighDenitionAudioCODEC
TPM Nuvoton NPCT650ABBYX TPM2.0 onboard (optional)
Expansion slots 1 x PCIe 3.0/2.0 [x16] slot
1 x PCIe 3.0 [x4] slot (open edge) (Removed in the 4 SATA III SKU)
1 x PCIe 3.0 [x4] slot (open edge)
3 x PCI slots
1 x M.2 E-key (22 x 30mm) slot for PCIe/USB/I2C-ME/SDIO/UART/PCM
1 x M.2 M-key (22 x 80mm) slot for Storage (PCIe[x4] module only
supported in 4*SATA III SKU)
BIOS 1 x 128Mbit Flash ROM, AMI BIOS
H/W Status Monitor Monitors CPU/system temperature
Monitors Vcore/5V/3.3V/12V/3VSB/VBAT voltages
Monitors CPU/chassis fan speed
Watchdog Timer 1~255 steps by software program
Smart Fan Control 1 x CPU Fan
2 x Chassis Fan
Wake On LAN / PXE Yes ( WOL, PXE)
Power States S3, S4, S5
Graphics
Graphics Chipset Intel®Graphics Media Accelerator
VGA support via RTD2168
Graphics Multi Display VGA+HDMI, HDMI+HDMI, VGA+HDMI+HDMI
Resolution VGA: Up to 1920 x 1200 @60Hz (via RTD2168)
HDMI: Up to 4096 x 2304 @24Hz
Environment, Power, and ME
Battery Lithium battery
Power requirement 1 x 24-pin ATX connector
1 x 8-pin (2x4) ATX 12V power connector
Operating temperature 32oF~140oF (0oC~60oC)
Storage temperature -40oF~185oF (-40oC~85oC)
Operating humidity 0%~90% relative humidity, non-condensing
Certicate CE & FCC Class A
Form factor ATX form factor: 12 in. x 9.6 in. (305 mm x 244 mm)
Weight 1.76 lb (0.8 Kg)

1-3
Chapter 1: General information
Back I/O
USB 10 x USB 3.0 ports
Display 2 x HDMI ports
1 x VGA port
Serial port 1 x RS-232/422/485 COM port (COM1, supports 5V/12V/RI, optional)
PS/2 port 1 x PS/2 combo port (keyboard & mouse)
LAN 2 x LAN (RJ-45) ports
Audio 3 x Audio jacks: Line-in, Mic-in, Line-out
Internal I/O
Storage 4 x SATA III 6.0Gb/s ports, support RAID 0/1/5/10 (2 x PCIe[x4] SKU only
has 3 ports)
1 x M.2 M-Key slot (22 x 80mm)
USB 2 x USB 2.0 headers support additional 3 USB ports (2x5 PIN, p=2.54mm)
Audio 1 x AMP speaker header (Line-out)
Serial port 5 x RS-232 headers
DIO 1 x 8-bit Digital I/O interface (In/Out programmable)
Fan 1 x CPU Fan connector (4-pin)
2 x Chassis Fan connectors (4-pin)
Power 1 x 24-pin EATX Power header
1 x 8-pin EATX 12V Power connector
Others 1 x Chassis Intrusion
1 x AT/ATX mode selection jumper
1 x Front panel header
1 x Clear CMOS jumper
Others
OS support Windows®10 64-bit
Windows®8.1 64-bit (not supported when using a Kaby Lake processor)
Windows®7 32-bit / 64-bit (not supported when using a Kaby Lake
processor)
Ubuntu16.04.02/Kernel4.8.0
Accessories 1 x SATA 6.0Gb/s cable
1 x COM cable
1 x I/O shield
1 x Support DVD
NOTE: Specicationsaresubjecttochangewithoutnotice.

IMBA-Q170A
1-4

2-1
Chapter 2: Motherboard information
Chapter 2
Motherboard information
2.1 Before you proceed
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
CAUTION!
• Unplugthepowercordfromthewallsocketbeforetouchingany
component.
• Beforehandlingcomponents,useagroundedwriststraportouchasafely
groundedobjectorametalobject,suchasthepowersupplycase,toavoid
damaging them due to static electricity.
• HoldcomponentsbytheedgestoavoidtouchingtheICsonthem.
• Wheneveryouuninstallanycomponent,placeitonagroundedantistatic
pad or in the bag that came with the component.
• Beforeyouinstallorremoveanycomponent,ensurethattheATXpower
supply is switched off or the power cord is detached from the power
supply.Failuretodosomaycauseseveredamagetothemotherboard,
peripherals,orcomponents.

IMBA-Q170A
2-2
IMBA-Q170A
PCIEX16_1
M2_TYPE_M1
M2_TYPE_E1
2280
2230
PCIEX4_2
PCIEX4_1
PCI1
PCI2
PCI3
F_PANEL
CLRTC1
AT_ATX
CHASSIS
USB1112 USB1314
EATX_PWR1
CPU_FAN1
CHA_FAN1
CHA_FAN2
BATTERY1
Super
I/O
Super
I/O
ASM
1085
ALC
887
COM1_V1
J3
J1
J2
COM1
VGA
J4
ASM
1442K
ASM
1442K
RTD
2168
LGA1151
Intel®
Q170
Intel®
PHY i219LM
Intel®
i211AT
DDR4 DIMM_A1 (64bit, 288-pin module) DDR4 DIMM_A2 (64bit, 288-pin module) DDR4 DIMM_B1 (64bit, 288-pin module) DDR4 DIMM_B2 (64bit, 288-pin module)
SATA6G_2
SATA6G_4
SPI_1
SATA6G_1
SATA6G_3
BUZZER1
AUDIO1
KBMS_
USB3_910
LAN2_USB3_34
LAN1_USB3_12
244mm(9.6in)
128Mb
BIOS
EATX_PWR2
HDMI12
USB3_5678
305mm(12.0in)
COM3COM4
COM2
COM5COM6
DIO
AMP_CON
5 42 431 6
7
2
15
8
10
11
9
121341471617
2.2 Motherboard layout
Place this side
towards the rear
of the chassis
NOTE: Place nine screws into the holes indicated by circles to secure the
motherboard to the chassis.
CAUTION!Donotovertightenthescrews!Doingsocandamagethe
motherboard.

2-3
Chapter 2: Motherboard information
Connectors/Jumpers/Slots Page
1. COM1operatingmodeselectionjumpers(2-pinJ1/J2/J3/J4) 2-13
2. ATXpowerconnectors(24-pinEATXPWR1,8-pinEATX_PWR2) 2-17
3. COM1Ring/+5V/+12Vselectionjumper(6-pinCOM1_V1) 2-13
4. CPUandchassisfanconnectors(4-pinCPU_FAN1,4-pinCHA_FAN1/2) 2-18
5. Intel® LGA1151CPUsocket 2-6
6. DDR4DIMMslots 2-10
7. Serialportconnectors(10-pinCOM2~6) 2-21
8. BIOSprogrammableconnector(8-pinSPI_1) 2-19
9. M.2M-KeyandM.2E-Keyslots 2-22
10. SerialATA6.0Gb/sconnectors(7-pinSATA6G_1~4) 2-18
11. Systempanelconnector(10-1pinF_PANEL) 2-20
12. AT/ATXmodeselection(3-pinAT_ATX) 2-14
13. Chassisintrusionjumper(4-1pinCHASSIS) 2-14
14. ClearRTCRAM(3-pinCLRTC1) 2-12
15. USB2.0connectors(10-pinUSB1112andUSB1314) 2-19
16. DigitalI/Oconnector(10-pinDIO) 2-21
17. Speakeroutconnector(4-pinAMP_CON) 2-17

IMBA-Q170A
2-4
2.3 Screw size
2.3.1 Component side

2-5
Chapter 2: Motherboard information
2.3.2 Solder side

IMBA-Q170A
2-6
2.4 Central Processing Unit (CPU)
ThismotherboardcomeswithanIntel®7th/6thGenerationCore™i7/i5/i3,
Pentium®andCeleron® 14nmLGA1151socketprocessor.
IMPORTANT:UnplugallpowercablesbeforeinstallingtheCPU.
CAUTION!
• Uponpurchaseofthemotherboard,ensurethatthePnPcapison
thesocketandthesocketcontactsarenotbent.Contactyourretailer
immediatelyifthePnPcapismissing,orifyouseeanydamagetothePnP
cap/socketcontacts/motherboardcomponents.
• Keepthecapafterinstallingthemotherboard.Themanufacturerwill
processReturnMerchandiseAuthorization(RMA)requestsonlyifthe
motherboardcomeswiththecapontheLGA1151socket.
• Theproductwarrantydoesnotcoverdamagetothesocketcontacts
resultingfromincorrectCPUinstallation/removal,ormisplacement/loss/
incorrectremovalofthePnPcap.
IMBA-Q170A
IMBA-Q170A CPU socket LGA1151

2-7
Chapter 2: Motherboard information
2.4.1 Installing the CPU
1
A
B
2 3
CAUTION! EnsurethatyouinstallthecorrectCPUdesignedforLGA1151only.
DONOTinstallaCPUdesignedforLGA1155andLGA1156socketsonthe
LGA1151socket.

IMBA-Q170A
2-8
A
B
C
4
5

2-9
Chapter 2: Motherboard information
2.4.2 CPU heatsink and fan assembly installation
CAUTION!ApplytheThermal
InterfaceMaterialtotheCPU
heatsinkandCPUbeforeyou
install the heatsink and fan if
necessary.
To install the CPU heatsink and fan assembly
B
A
A
B
1
2
3 4

IMBA-Q170A
2-10
2.5 System memory
ThismotherboardcomeswithfourDoubleDataRate4(DDR4)DualInlineMemory
Modules(DIMM)sockets.ThegureillustratesthelocationoftheDDR4DIMM
sockets:
To uninstall the CPU heatsink and fan assembly
A
B
B
A
2
1
IMBA-Q170A
IMBA-Q170A 288-pin DDR4 DIMM sockets
DIMM_A1 DIMM_A2 DIMM_B1 DIMM_B2

2-11
Chapter 2: Motherboard information
Installing a DIMM
To remove a DIMM
A
B
1
2
3

IMBA-Q170A
2-12
2.6 Jumpers
1. Clear RTC RAM (3-pin CLRTC1)
ThisjumperallowsyoutocleartheRealTimeClock(RTC)RAMinCMOS.
YoucancleartheCMOSmemoryofsystemsetupparametersbyerasing
theCMOSRTCRAMdata.TheonboardbuttoncellbatterypowerstheRAM
datainCMOS,whichincludesystemsetupinformationsuchassystem
passwords.
To erase the RTC RAM:
1. TurnOFFthecomputerandunplugthepowercord.
2. Movethejumpercapfrompins1-2(default)topins2-3.Keepthecapon
pins2-3forabout5~10seconds,thenmovethecapbacktopins1-2.
3. PlugthepowercordandturnONthecomputer.
4. Holddownthe<Del>keyduringthebootprocessandenterBIOSsetup
to reenter data.
CAUTION!ExceptwhenclearingtheRTCRAM,neverremovethecapon
CLRTCjumperdefaultposition.Removingthecapwillcausesystemboot
failure!
NOTES:
• Ifthestepsabovedonothelp,removetheonboardbatteryandmovethe
jumperagaintocleartheCMOSRTCRAMdata.AfterclearingtheCMOS,
reinstall the battery.
• YoudonotneedtocleartheRTCwhenthesystemhangsdueto
overclocking.Forsystemfailureduetooverclocking,usetheCPU
ParameterRecall(C.P.R)feature.Shutdownandrebootthesystemsothe
BIOScanautomaticallyresetparametersettingstodefaultvalues.
IMBA-Q170A
IMBA-Q170A Clear RTC RAM
21 2 3
Normal
(Default)
Clear RTC
CLRTC1
