Aaeon FSB-H81H User manual

Full-size SBC
F S B - H 8 1 H
FSB-H81H
Intel® CoreTM i7/i5/i3
LGA 1150 Processor
Full-size CPU Card
With DDR3/L, 2 Gigabit Ethernet
USB 3.0/ USB2.0
SATA 6.0Gb/s, SATA 3.0 Gb/s
FSB-H81H Manual Rev.A 1st Ed.
August 15, 2014

Full-size SBC
F S B - H 8 1 H
i
Copyright Notice
This document is copyrighted, 2014. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Full-size SBC
F S B - H 8 1 H
ii
Acknowledgments
All other products’name or trademarks are properties of their
respective owners.
AMI is a trademark of American Megatrends Inc.
Intel®, Core™are trademarks of Intel®Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
All other product names or trademarks are properties of their
respective owners.

Full-size SBC
F S B - H 8 1 H
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
1 Cable Set
o1 Serial Port Cable with one DB-9 connector
o2 Serial Port Cable with two DB-9 connectors
o1 Cable with serial port (DB-9) and LPT(DB-25)
port
o1 USB Cable with two USB 2.0 connectors
o4 SATA Cables
1 DVD-ROM for manual (in PDF format) and
Drivers
1 FSB-H81H
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.

Full-size SBC
F S B - H 8 1 H
iv
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features ....................................................................1-3
1.3 Specifications ............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions....................................................2-2
2.2 Location of Connectors and Jumpers .......................2-3
2.3 Mechanical Drawing..................................................2-4
2.4 List of Jumpers..........................................................2-5
2.5 List of Connectors .....................................................2-5
2.6 Setting Jumpers ........................................................2-7
2.7 COM1 RI/+5/+12V Selection (CN10) ........................2-8
2.8 COM2 RI/+5/+12V Selection (CN11)........................ 2-8
2.9 Auto Power Button (CN24)........................................2-8
2.10 CMOS RTC Setting (CN29) .................................... 2-9
2.11 PCI Clock Feedback Setting (CN34).......................2-9
2.12 Front Panel Connector 1 (CN1) .............................. 2-9
2.13 Front Panel Connector 2 (CN2) ..............................2-10
2.14 COM Port 6 (CN3)...................................................2-10
2.15 COM Port 5 (CN4)...................................................2-11

Full-size SBC
F S B - H 8 1 H
v
2.16 COM Port 4 (CN5)...................................................2-12
2.17 COM Port 3 (CN6)...................................................2-12
2.18 COM Port 2 (RS232/485/422) (CN7)...................... 2-13
2.19 COM Port 1 (RS232/485/422) (CN8)...................... 2-15
2.20 USB 2.0 Port 2/3 (CN9)...........................................2-17
2.21 Digital IO Port (CN12) ............................................. 2-18
2.22 High Definition Audio (CN13)..................................2-18
2.23 PS/2 KB/MS Pin Header (CN14)............................. 2-19
2.24 LPT Port (CN15)...................................................... 2-20
2.25 SATA Port 2 (CN16)................................................ 2-21
2.26 SATA Port 3 (CN17)................................................ 2-22
2.27 USB 3.0 Port 0 (CN18)............................................2-22
2.28 SATA Port 0 (CN19)................................................ 2-23
2.29 SATA Port 1 (CN20)................................................ 2-24
2.30 USB 3.0 Port 1 (CN21)............................................2-24
2.31 10M/100M/1G Ethernet Port 1 (CN23).................... 2-25
2.32 LPC Expansion Connector (CN25) ......................... 2-26
2.33 SPI Programming Header (Debug ONLY) (CN26) . 2-27
2.34 DVI Connector (CN27)............................................2-27
2.35 VGA Connector (CN28) .......................................... 2-29
2.36 FAN2 Connector (CN30).........................................2-30
2.37 FAN1 Connector (CN31)......................................... 2-30
2.38 ATX +12V Power Connector (CN32) ...................... 2-31
2.39 10M/100M/1G Ethernet Port 2 (CN33).................... 2-31
2.40 DDR3/DDR3L DIMM Slot (DIMM1).........................2-32

Full-size SBC
F S B - H 8 1 H
vi
2.41 DDR3/DDR3L DIMM Slot (DIMM2).........................2-32
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization. .................................. 3-2
3.2 AMI BIOS Setup........................................................3-3
Chapter 4 Driver Installation
4.1 Installation ................................................................. 4-3
Appendix A Programming The Watchdog Timer
A.1 Programming .........................................................A-2
A.2 F81866 Watchdog Timer Initial Program...............A-5
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 Memory Address Map............................................B-4
B.3 IRQ Mapping Chart................................................B-5
B.4 DMA Channel Assignments...................................B-7
Appendix C Mating Connector
C.1 List of Mating Connectors and Cables.................. C-2
Appendix D DIO
D.1 DIO........................................................................ D-2

Full-size SBC
F S B - H 8 1 H
Chapter 1 General Information 1-1
General
Information
Chapter
1

Full-size SBC
F S B - H 8 1 H
Chapter 1 General Information 1-2
1.1 Introduction
AAEON, a leading Industrial PC manufacturer, announces the
debut of a high performance full-size Single Board Computer, the
FSB-H81H. AAEON has developed this full-size SBC based on the
latest Intel®H81 chipset and the Intel®4th generation Core™i7/i5/i3
LGA 1150 processor, to fulfill the increasing demands of multi-core
processing.
In a PICMG 1.3 SHB Express form factor the FSB-H81H system
host board takes full advantage of the Intel®H81 chipset for
enhanced system performance and generous expansion
capabilities. Two DIMM slots of dual-channel DDR3/DDR3L
1333/1600 sockets provide ample memory bus bandwidth for
demanding applications. Moreover, this model equips six COM
(four RS-232, and two RS-232/422/485), two USB3.0, and six
USB2.0. In addition to the features above, the FSB-H81H deploys
two SATA 6.0Gb/s and two SATA 3.0Gb/s. The FSB-H81H has
been designed for users that require high performance and
reliability for critical applications.

Full-size SBC
F S B - H 8 1 H
Chapter 1 General Information 1-3
1.2 Features
Intel®4th Generation CoreTM i7/i5/i3 LGA 1150 Processor
Intel®H81 Chipset
Dual-Channel DDR3/DDR3L 1333/1600 DIMM Socket x
2 (Up to 16 GB)
Intel®H81 Integrated Intel®HD Graphics
Gigabit Ethernet x 2
SATA 6.0 Gb/s x 2, SATA 3.0 Gb/s x 2
COM x 6 (RS-232 x 4, RS-232/422/485 x 2)
USB3.0 x 2 (On bracket), USB2.0 x 6
PICMG 1.3
ATX 2.1 Power Requirement
Note: When FSB-H81H is accompanied external Gigabit Ethernet card through
PCIe slots on backplane, the Ethernet works smoothly. However, when both Gigabit
Ethernet ports are used simultaneously, the Ethernet performance may be
decreasing.

Full-size SBC
F S B - H 8 1 H
Chapter 1 General Information 1-4
1.3 Specification
System
Form Factor
PICMG 1.3 Full size SBC
Processor
Intel®4th Generation CoreTM i7/i5/i3 LGA
1150 Processor
System Memory
240-pin Dual-Channel DDR3/DDR3L
1333/1600 DIMM socket x 2, up to 16GB
Chipset
Intel®H81
Ethernet
Realtek 8111E 10/100/1000Base-TX x 2,
RJ-45 x 2 on bracket
BIOS
AMI Plug & Play SPI BIOS-128MB ROM
Wake on LAN
Yes
H/W Status Monitoring
System temperature, voltage and cooling
fan status monitoring
Expansion Interface
Follow PICMG 1.3 Regulation
Battery
Lithium battery
Power Requirement
ATX 2.1
Board Size
13.3”x 5”(339mm x 126mm)
Gross Weight
1.2 lb (0.5 Kg)
Operating
Temperature
32oF ~ 140oF (0oC ~ 60oC)
Storage Temperature
-4oF ~ 158oF (-20oC ~ 70oC)
Operating Humidity
5%~90% resistive humidity,
non-condensing

Full-size SBC
F S B - H 8 1 H
Chapter 1 General Information 1-5
MTBF (Hours)
60,000
Display
Chipset
Intel®H81
Graphic Engine
Integrated Intel®HD Graphics
Resolution
Up to 2048x1536 @ 75Hz for CRT
Output Interface
VGA x 1 or DVI x 1 on bracket
I/O: Fintek 81866D
Storage
SATA 6.0 Gb/s x 2, SATA 3.0 Gb/s x 2
Serial Port
COM x 6
COM1~2: RS-232/422/485 on bracket
COM3~6: RS-232, with box header
PS/2 Port
4x2 pin header x 1
USB
USB3.0 x 2 (Type A on bracket)
USB2.0 x 6 ( two on pin header, four are
on backplane)
Parallel Port
LPT port x 1
Audio
HDAC daughter board (optional) Mic-in/
Line-in/ Line-out/ CD-in
Digital I/O
8-bit programmable (4-in/ 4-out)

Full-size SBC
F S B - H 8 1 H
Chapter 2 Quick Installation Guide 2 - 1
Quick
Installation
Guide
Chapter
2

Full-size SBC
F S B - H 8 1 H
Chapter 2 Quick Installation Guide 2 - 2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

Full-size SBC
F S B - H 8 1 H
Chapter 2 Quick Installation Guide 2 - 3
2.2 Location of Connectors and Jumpers

Full-size SBC
F S B - H 8 1 H
Chapter 2 Quick Installation Guide 2 - 4
2.3 Mechanical Drawing

Full-size SBC
F S B - H 8 1 H
Chapter 2 Quick Installation Guide 2 - 5
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Jumpers
Label
Function
CN10
COM1 RI/+5/+12V Selection
CN11
COM2 RI/+5/+12V Selection
CN24
Auto Power Button
CN29
CMOS RTC Setting
CN34
PCI Clock Feedback Setting
2.5 List of Connectors
The board has a number of connectors that allow you to configure
your system to suit your application. The table below shows the
function of each board's connectors:
Label
Function
CN1
Front Panel Connector 1
CN2
Front Panel Connector 2
CN3
COM Port 6
CN4
COM Port 5
CN5
COM Port 4
CN6
COM Port 3

Full-size SBC
F S B - H 8 1 H
Chapter 2 Quick Installation Guide 2 - 6
CN7
COM Port 2 (RS232/422/485)
CN8
COM Port 1 (RS232/422/485)
CN9
USB 2.0 Port 2/3
CN12
Digital IO Port
CN13
High Definition Audio
CN14
PS/2 Keyboard/Mouse
CN15
Parallel Port Pin Header
CN16
SATA Port 2
CN17
SATA Port 3
CN18
USB 3.0 Port 0
CN19
SATA Port 0
CN20
SATA Port 1
CN21
USB 3.0 Port 1
CN23
10M/100M/1G Ethernet Port 1
CN25
LPC Expansion Connector
CN26
SPI Programming Header
CN27
DVI Connector
CN28
VGA Connector
CN30
FAN2 Connector
CN31
FAN1 Connector
CN32
ATX +12V Power Connector
CN33
10M/100M/1G Ethernet Port 2
DIMM1
DDR3/DDR3L DIMM Slot
DIMM2
DDR3/DDR3L DIMM Slot

Full-size SBC
F S B - H 8 1 H
Chapter 2 Quick Installation Guide 2 - 7
2.6 Setting Jumpers
You configure your card to match the needs of your application by
setting jumpers. A jumper is the simplest kind of electric switch. It
consists of two metal pins and a small metal clip (often protected by
a plastic cover) that slides over the pins to connect them. To “close”
a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will
have three pins, labeled 1, 2 and 3. In this case you would connect
either pins 1 and 2 or 2 and 3.
123
Open Closed Closed 2-3
A pair of needle-nose pliers may be helpful when working with
jumpers.
If you have any doubts about the best hardware configuration for
your application, contact your local distributor or sales
representative before you make any change.
Generally, you simply need a standard cable to make most
connections.

Full-size SBC
F S B - H 8 1 H
Chapter 2 Quick Installation Guide 2 - 8
2.7 COM1 RI/+5/+12V Selection (CN10)
+12V
Ring
+5V
CN10
Function
1-2
+12V
3-4
Ring (Default)
5-6
+5V
2.8 COM2 RI/+5/+12V Selection (CN11)
+12V
Ring
+5V
CN11
Function
1-2
+12V
3-4
Ring (Default)
5-6
+5V
2.9 Auto Power Button (CN24)
Power ON by Button
Auto Power ON
