Aaeon EPIC-9457 User manual

EPIC Board EPIC-9457 Rev.B
EPIC-9457 Rev.B
Intel® Atom™ N270 Processor
Onboard DDR II Memory
Up to 24-bit Dual-channel LVDS LCD
6 USB 2.0 / 4 COMs / 2 SATA
CompactFlash™/ 8-bit Digital I/O
EPIC-9457 Manual Rev.B 3rd Ed.
April 2010

EPIC Board EPIC-9457 Rev.B
i
Copyright Notice
This document is copyrighted, 2010. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

EPIC Board EPIC-9457 Rev.B
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
zAward is a trademark of Award Software International, Inc.
zCompactFlash™ is a trademark of the Compact Flash
Association.
zIntel®, Atom™ are trademarks of Intel®Corporation.
zMicrosoft Windows®is a registered trademark of Microsoft Corp.
zITE is a trademark of Integrated Technology Express, Inc.
zIBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
All other product names or trademarks are properties of their
respective owners.

EPIC Board EPIC-9457 Rev.B
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
•9657666600 Jumper Cap
•Quick Installation Guide
•Utility CD
•EPIC-9457 Rev.B w/Heatsink
If any of these items should be missing or damaged, please contact
your distributor or sales representative immediately.

EPIC Board EPIC-9457 Rev.B
iv
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 Specifications............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions....................................................2-2
2.2 Location of Connectors and Jumpers .......................2-3
2.3 Mechanical Drawing..................................................2-5
2.4 List of Jumpers..........................................................2-7
2.5 List of Connectors .....................................................2-8
2.6 Setting Jumpers ........................................................2-10
2.7 PCI-104 VIO Voltage Selection (JP1).......................2-11
2.8 External AT/ATX Selection (JP2)..............................2-11
2.9 External LVDS Operating Voltage Selection and External
Power Selection (JP3).....................................................2-11
2.10 Touch Screen 4,5,8 Wire Selection (JP4)...............2-11
2.11 COM2 Ring/ +5V/ +12V Selection (JP5).................2-12
2.12 Clear CMOS (JP6) ..................................................2-12
2.13 Internal LVDS Operating Voltage Selection and Inverter
Power Selection (JP7).....................................................2-12
2.14 Internal AT/ATX Selection (S1)...............................2-12

EPIC Board EPIC-9457 Rev.B
v
2.15 Front Panel Connector (CN1) .................................2-13
2.16 External LVDS Inverter Power Connector (CN2)....2-13
2.17 External LVDS Connector (CN3) ............................2-13
2.18 Standby Power Input (CN4)....................................2-14
2.19 Wide Voltage Power Connector (CN5) ...................2-14
2.20 Touch Screen Connector (CN6)..............................2-14
2.21 Audio Connector (CN7)...........................................2-15
2.22 Internal LVDS Connector (CN9)..............................2-15
2.23 TV-out Connector (CN11) .......................................2-16
2.24 USB Connector (CN12)...........................................2-16
2.25 Internal LVDS Inverter Power Connector (CN13)...2-16
2.26 LPT Port Connector (CN14)....................................2-16
2.27 System Fan Connector (CN15)...............................2-17
2.28 Digital I/O Connector (CN16)..................................2-17
2.29 Power Output Connector (CN17)............................2-18
2.30 PS2 Keyboard/Mouse Connector (CN19)...............2-18
2.31 RS-232 Serial Port Connector (CN21, CN22).........2-19
2.32 Standby Power Output Connector (CN23)..............2-19
2.33 COM1/2 Connectors (CN26)...................................2-19
2.34 Primary EIDE Connector (IDE1) .............................2-20
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 Award BIOS Setup....................................................3-3

EPIC Board EPIC-9457 Rev.B
vi
Chapter 4 Driver Installation
4.1 Installation.................................................................4-3
Appendix A Programming The Watchdog Timer
A.1 Programming .........................................................A-2
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 1st MB Memory Address Map ................................B-3
B.3 IRQ Mapping Chart................................................B-4
B.4 DMA Channel Assignments...................................B-4
Appendix C Mating Connector
C.1 List of Mating Connectors and Cables.................. C-2

EPIC Board EPIC-9457 Rev.B
Chapter 1 General Information 1- 1
General
Chapter
1
Information

EPIC Board EPIC-9457 Rev.B
Chapter 1 General Information 1- 2
1.1 Introduction
AAEON announces a brand new EPIC Board EPIC-9457 Rev.B,
designed to fit in diverse applications that demand for fitting in
different space limitations and high performance.
EPIC-9457 Rev.B accommodates onboard Intel®Atom™ N270
Processor 1.6GHz and the Front Side Bus is 400/533MHz. This
model features DDRII 533 and system memory is up to 1GB.
Moreover, EPIC-9457 Rev.B adopts Intel®945GME + ICH7M.
In addition, EPIC-9457 Rev.B deploys Intel®ITE8781 chip and
features two RJ-45 ports onboard to display the transcendent
performance of network connections. This new EPIC Express
Board integrated Intel®945GME + CH7308 + CH7307C display
chipset to support CRT/LCD simultaneous/ dual view displays.
In addition to the PCI/104-Express and Mini-Card expansions,
EPIC-9457 Rev.B also features two SATA, one Type II
CompactFlash™ for the storage and six USB 2.0 ports, four COM
ports, 8-bit Digital I/O for flexible I/O expansion. EPIC-9457 Rev.B
is an excellent choice for your vital applications.

EPIC Board EPIC-9457 Rev.B
Chapter 1 General Information 1- 3
1.2 Features
zIntel® Atom™ N270 Processor
zIntel® 945GME + ICH7M
zOnboard DDRII 533 Memory, Max. 1GB
zGigabit Ethernet x 2
zDual 24-bit Dual-channel LVDS LCD
zAC97 2.0 Codec 2CH Audio
zUSB2.0 x 6, COM x 4, 8-bit Digital I/O
zSATA x 2, CompactFlash™ x 1
zPCI/104-Express, Mini-Card Expansion Connectors
zWide DC Voltage Input: 8.5V ~ 19V

EPIC Board EPIC-9457 Rev.B
Chapter 1 General Information 1- 4
1.3 Specifications
System
zForm Factor EPIC Express Board
zProcessor Onboard Intel®Atom™ N270
Processor 1.6GHz, FSB:
400/533MHz
zSystem Memory Onboard DDRII 533, Max. 1 GB
zChipset Intel® 945GME + ICH7M
zI/O Chipset ITE8781
zEthernet Intel® 82574L for
10/100/1000Base-TX, RJ-45 x 2
zBIOS Award Plug & Play SPI BIOS –
2MB ROM
zWake On LAN Yes
zWatchdog Timer Generates a time-out system reset
zH/W Status Monitoring Supports power supply voltages,
fan speed, and temperature
monitoring
zExpansion Interface PCI/104-Express Expansion
(PCI-104 + PCIe/104) connectors
zBattery Lithium battery
zPower Requirement +8.5V ~ 19V
(Typical)
zBoard Size 4.5" x 6.5" (115mm x 165mm)

EPIC Board EPIC-9457 Rev.B
Chapter 1 General Information 1- 5
zGross Weight 1.1 lb (0.5KG)
zOperation Temperature 32°F ~ 140°F (0°C ~ 60°C)
zStorage Temperature -40°F ~ 176°F (-40°C ~ 80°C)
zOperation Humidity 0% ~ 90% relative humidity,
non-condensing
Display: Supports CRT/LCD, CRT/TV, LCD/TV simultaneous/
displaysdual view
zChipset Intel® 945GME integrated +
CH7308 + CH7307C
zMemory Shared system memory up to
224MB
zResolutions Up to 2048x1536 colors for CRT,
Up to 1920x1200 @ 24bpp
colors for LCD
zLCD Interface 24-bit dual-channel LVDS
I/O
zStorage SATA x 2,
Type II CompactFlash™ x 1
zSerial Port RS-232 x 3, RS-232/422/485 x 1
zParallel Port SPP/EPP/ECP Mode
zUSB USB2.0 x 6
zPS/2 Port Keyboard+Mouse x 1
zDigital I/O Supports 8-bit (programmable)
zAudio Line-in, Line-out, Mic-in & CD-in

EPIC Board EPIC-9457 Rev.B
Chapter2QuickInstallationGuide2-1
Quick
Installation
Chapter
2
Guide
Notice:
The Quick Installation Guide is derived
from Chapter 2 of user manual. For other
chapters and further installation
instructions, please refer to the user
manual CD-ROM that came with the
product.
Part No. 2007945722 Printed in Taiwan April 2010

EPIC Board EPIC-9457 Rev.B
Chapter 2 Quick Installation Guide 2-2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

EPIC Board EPIC-9457 Rev.B
Chapter2QuickInstallationGuide2-3
2.2 Location of Connectors and Jumpers
Component Side

EPIC Board EPIC-9457 Rev.B
Solder Side
Chapter 2 Quick Installation Guide 2-4

EPIC Board EPIC-9457 Rev.B
Chapter2QuickInstallationGuide2-5
2.3 Mechanical Drawing
Component Side

EPIC Board EPIC-9457 Rev.B
Chapter 2 Quick Installation Guide 2-6
Solder Side

EPIC Board EPIC-9457 Rev.B
Chapter2QuickInstallationGuide2-7
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Jumpers
Label Function
JP1 PCI-104 VIO Voltage Selection
JP2 External AT/ATX Selection
JP3 External LVDS Operating Voltage Selection
and External Power Selection
JP4 Touch Screen 4,5,8 Wire Selection
JP5 COM2 Ring/+5V/+12V Selection
JP6 Clear CMOS
JP7 Internal LVDS Operating Voltage Selection
and Inverter Power Selection
S1 Internal AT/ATX Selection

EPIC Board EPIC-9457 Rev.B
Chapter 2 Quick Installation Guide 2-8
2.5 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application. The table below shows the function of
each board's connectors:
Connectors
Label Function
CN1 Front Panel Connector
CN2 External LVDS Inverter Power Connector
CN3 External LVDS Connector
CN4 Standby Power Input
CN5 Wide Voltage Power Connector
CN6 Touch Screen Connector
CN7 Audio Connector
CN9 Internal LVDS Connector
CN10 PCI-104 Connector
CN11 TV-out Connector
CN12 USB Connectors
CN13 Internal LVDS Inverter Power Connector
CN14 LPT Port Connector
CN15 System Fan Connector
CN16 Digital I/O Connector
CN17 Power Output Connector
CN18 PCIe/104 Connector
CN19 PS2 Keyboard/Mouse Connector
CN21 COM3 Connector
