Aaeon FWS-2150 User manual

Network Appliance
FWS-2150
FWS-2150
Desktop
Network Appliance Platform
1 2.5”Internal Disk Drive bay
1 Ultra ATA-100, 2 SATA I
5 LAN Ports
2 Type A USB Ports
FWS-2150 Manual 2nd Ed.
April 30, 2014

Network Appliance
FWS-2150
i
Copyright Notice
This document is copyrighted, 2014. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Network Appliance
FWS-2150
ii
Acknowledgments
All other products’name or trademarks are properties of their
respective owners.
Award is a trademark of Award Software International, Inc.
CompactFlash™is a trademark of the Compact Flash
Association.
VIA is a trademark of VIA Technologies, Inc.
Microsoft Windows®is a registered trademark of Microsoft Corp.
All other product names or trademarks are properties of their
respective owners.

Network Appliance
FWS-2150
iii
Caution
There is a danger of explosion if the battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer’s instructions and your local government’s recycling or
disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du
fabricant et les directives gouvernementales de recyclage.

Network Appliance
FWS-2150
iv
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
FWS-2150
Quick Installation Guide
CD-ROM for manual (in PDF format) and drivers
D-sub 9-pin Cable x 1
Rubber Foots
60W Power Adapter
2.5”IDE Hard Disk Driver Cable
8-pin PS2 KB/MS Cable
VGA Cable
If any of these items should be missing or damaged, please contact
your distributor or sales representative immediately.
Note:
Serial ATA Cables are optional accessories. Please purchase those
cables according to the following item numbers.
1702151201 SATA Power Cable
1709070050 SATA Cable

Network Appliance
FWS-2150
v
Contents
Chapter 1 General Information
1.1 Introduction..........................................................1-2
1.2 Features ..............................................................1-3
1.3 Specifications ......................................................1-4
1.4 General System Information ...............................1-7
Chapter 2 Quick Installation Guide
2.1 Safety Precautions..............................................2-2
2.2 Location of Connectors .......................................2-3
2.3 Mechanical Drawing............................................2-5
2.4 List of Jumpers....................................................2-7
2.5 List of Connectors ...............................................2-8
2.6 Setting Jumpers ..................................................2-9
2.7 Clear CMOS (JP1) ..............................................2-10
2.8 SM Bus (JP2) ......................................................2-10
2.9 CF Power Selection (JP3)...................................2-10
2.10 Front Panel Connector (FP1)............................2-10
2.11 RS-232 Serial Port Connector (COM1/2)..........2-10
2.12 USB Connector (USB2) ....................................2-11
2.13 Keyboard and Mouse Connector (CN1)............2-11
2.14 VGA Connector (CN2).......................................2-11
2.15 Installing the Hard Disk Drive............................2-12

Network Appliance
FWS-2150
vi
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization .............................3-2
3.2 Award BIOS Setup..............................................3-3
Chapter 4 Driver Installation
4.1 Installation ...........................................................4-3
Appendix A Programming the Watchdog Timer
A.1 Programming ..................................................A-2
A.2 ITE 8712 Watchdog Timer Initial Program......A-5
Appendix B I/O Information
B.1 I/O Address Map.............................................B-2
B.2 Memory Address Map.....................................B-3
B.3 IRQ Mapping Chart.........................................B-4
B.4 DMA Channel Assignments............................B-4
Appendix C Standard Firewall Platform Setting
C.1 Standard Firewall Platform Setting.................C-2
C.2 Status LED Sample Code...............................C-2
C.3 LAN Bypass Mode Sample Code...................C-5
C.4 Console Redirection .......................................C-6

Network Appliance FWS-2150
Chapter 1 General Information 1- 1
General
Chapter
1
Information

Network Appliance FWS-2150
Chapter 1 General Information 1- 2
1.1 Introduction
FWS-2150 adopts the VIA C7/ Eden Processor, up to 2.0GHz with
400/800MHz Front Side Bus. (or onboard VIA Eden ULV 500MHz,
FSB400MHz). Moreover, the chipset is equipped with VIA CN700
+VT8237R. The system memory features 240-pin DDRII 400/533
DIMM socket total up to 1GB. It deploys five LAN ports that
consist of five PCI 10/100Base-TX Ethernet LAN ports with two
ports bypass function. FWS-2150 condensed appearance
features desktop form factor that fits nicely into a space-limited
environment.
This compact FWS-2150 is equipped with one ATA-100, two
SATA I and CompactFlashTM Type II connector with ATA mode.
In addition, it offers flexible expansion with network products and
features one Mini-PCI Type III expansion socket, two USB2.0
ports and one RS-232 console port on the rear panel. The
console port deploys console re-direction that increases the
network security via remote control. All of these designs provide
for a more user-friendly solution.

Network Appliance FWS-2150
Chapter 1 General Information 1- 3
1.2 Features
 Desktop 5 LAN Ports Network Appliance Platform
 VIA C7/ Eden CPU, Up to 2.0GHz
 240-pin x 1 DDRII 400/533MHz Memory Support, Up
to 1GB
 10/100Base-TX Ethernet x 5 (2 Ports Bypass
Function)
 Ultra ATA-100 Port x 1 & SATA-I x 2
 CompactFlashType-II Connector & Mini PCI Slot
 USB2.0 Port x 2 & RS-232 Console x 1 in the Real
Panel
 60W AC/DC Power Adapter
 Watchdog Function 1~255 Sec.
 2.5" Internal Disk Drive Bay x 1

Network Appliance FWS-2150
Chapter 1 General Information 1- 4
1.3 Specifications
System
Form Factor
Processor
Desktop 5 LAN ports NetworkAppliance
VIA C7/Eden CPU, up to 2.0GHz (FSB
400/800MHz) onboard Eden ULV 500MHz
(FSB 400MHz)
System Memory
Chipset
240-pin DDRII 400/533 DIMM Socket x 1,
total up to 1GB
VIA CN700 + VT8237R+
LAN
BIOS
IDE
SATA Interface
Solid Storage Disk
PCI 10/100 w/ Realtek 8100C x 5 (2 ports
bypass), RJ-45 x 5
Award Plug & Play FWH BIOS – 512KB
ROM
ATA-100 x 1 channel
SATA I x 2
CFD Type II connector(ATA mode)
Expansion Interface
Watchdog Timer
RTC
Mini PCI Type III Socket
1~255 steps, can be set with software on
Super I/O
Internal RTC
Storage Internal：One 2.5" Hard Disk (SATAor IDE)
System Fan
Front I/O Panel
Depends on processor options
Power LED x 1, HDD Active LED x 1,
Status LED x 1, Bypass LED x 1, LAN

Network Appliance FWS-2150
Chapter 1 General Information 1- 5
Active/Link LED x 5, LAN Speed LED x 5
Color Blue
LCM
Power Supply
Dimension
N/A
60W AC/DC power adapter
7”(W) x 9.84” (D) x 1.73” (H) (178mm x
250mm x 44mm)—Chassis
8.46 (L) x 6.77” (W) (215mm x
172mm)—Board
Display
VGA Controller
I/O
Serial Port
Keyboard & Mouse
Universal Serial Bus
Front I/O Panel
Integrated UniChrome Pro graphics, VGA
pin header
Two COM ports: (Internal Pin Header x 1,
External D-sub x 1)
COM 1: RS-232
COM 2: RS-232 (Pin Header)
Reserve pin header
USB2.0 x 2, dual Type-
A
connector on the
rear panel
One Power LED
One Bypass LED
One Status LED
One HDD Active LED
Five LAN LEDs

Network Appliance FWS-2150
Chapter 1 General Information 1- 6
Rear I/O panel
Environmental
USB port x 2, LAN port x 5, DB-9
connector x 1, Software Reset Switch x 1
Operating Temp. 32°F ~ 104°F (0°C ~ 40°C)
Storage Temp. -4°F ~ 140°F (-20°C ~ 60°C)
Operating humidity: 10 ~ 80%
Storage humidity: 10 ~ 80% @ 40°C, non-condensing
Vibration 0.5G / 5 ~ 500Hz / operation (2.5” Hard
Disk Drive)
1.5G / 5 ~ 500Hz / non operation
Shock 10G peak acceleration (11 m sec.
duration), operation
20G peak acceleration (11 m sec.
duration), non operation

Network Appliance FWS-2150
Chapter 1 General Information 1- 7
1.4 General System Information
Front Panel
Rear Panel
5 LAN LEDs
Bypass LED
HDD LED
Status LED
Power LED
5 LAN ports
Two USB ports
Console port
Reset
Power in

Network Appliance FWS-2150
Chapter2QuickInstallationGuide2-1
FWS-2150
Chapter
2
Quick
Installation
Guide
Notice:
The Quick Installation Guide is derive
d
f
rom Chapter 2 of the user manual. Fo
r
other chapters and further installation
instructions, please refer to the use
r
manual CD-ROM that came with th
e
p
roduct.
Part No. 2001215010 Printed in Taiwan Mar. 2008

Network Appliance FWS-2150
Chapter 2 Quick Installation Guide 2-2
2.1 Safety Precautions
The installation is intended for technically qualified personnel who
have experience installing and configuring system boards.
The equipment can be installed in a restricted access location (RAL)
only.
A restricted access location is a site location for equipment where
the following criteria apply:
01. Access can only be gained by service persons or by users who
have been trained on the restrictions and the precautions for this
specific site.
02. Access is by means of at least one of the following, special tool,
lock and key, or other means of security, and is controlled by the
authority responsible for the location.
Safety Precautions:
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

Network Appliance FWS-2150
Chapter 2 Quick Installation Guide 2-3
2.2 Location of Connectors

Network Appliance FWS-2150
Chapter 2 Quick Installation Guide 2-4
Connectors on Rear Panel of FWS-2150

Network Appliance FWS-2150
Chapter 2 Quick Installation Guide 2-5
2.3 Mechanical Drawing

Network Appliance FWS-2150
Chapter 2 Quick Installation Guide 2-6
