Assembly Instructions
Poly Table with Attached Benches
Thank you for choosing Furniture Co.
We hope that this piece brings you many years of enjoyment!
For help with assembling your furniture,
or if you have missing hardware, please email us at
[email protected] or call us at 866-896-5747

PARTS (included)
Table Top (1)
Bench Top (2)
Legs (2)
Braces (2)
TOOLS NEEDED
Screwgun/powerdrill
7/16” Socket
b
c
a
STEP 1
Lay table top upside down on a clean flat surface and attach leg as shown in photo 1 and 2. Tighten the
bolts using the included Allen wrench.
Photo 1 Photo 2
STEP 2
Attach the braces as shown. (See photo 3.) Slip a washer on each lag (photo 4) and insert the lag into the
countersunk hole in the brace. (See photo 5.) Use the 7/16” socket to tighten the lag. Use the screws to
fasten the brace to the table leg. (See photo 6.) Tighten with the included square drive bit using your
screwgun/power drill.
Photo 3
Photo 4
a
d
C
b
HARDWARE (included)
2½” Bolts (12)
Lags (2)
Washers (2)
Screws (4)
Square Drive Bit (1)
Allen Wrench (1)
d
e
f
Photo 5
Photo 6
a
CD
D
D
b
c
A
C
c
d

STEP 3
Set the table upright. (See photo 7.) Attach bench tops as shown. (See photo 8.) Insert 2½” bolts through
the table legs and tighten using the Allen wrench. (See photo 9.)
Photo 7 Photo 8
Photo 9
BC
A
C
a
a
