Caution!
WARNING: Please use this product as instructed. Misuse may cause
injury or death.
DO NOT use while driving
DO NOT expose to water or wet
surfaces. Electric shock may occur.
DO NOT expose the projected LED
image to your eyes or the eyes of
others
DO NOT block or restrict airow
from ventilation holes as this may
cause the projector to overheat
Keep the projector, battery, or
charger away from any heat sources
Caution for Battery Use
• Do not pierce or puncture the battery
with sharp objects
• Do not heat the product or expose it to
high temperature.
• Do not wet it or place it in any liquid
Caution for Headphone Use
• Prolonged use at high volume may
impair your hearing.
• High volume during walking or driving
may cause distractions and result in
injury or death

Table of Contents
Chapter 1: P5 at a Glance
P5 Introduction
Remote & Keypad
Accessories
Chapter 2: Getting Started
Powering On / OFF
Swappable Battery
Focus Adjustment / Throw
Distance
External Input/Outputs
Connecting to a Computer VGA
Connecting to a Computer HDMI
Connecting to Composite Video
Connecting to HDMI Video
Connecting to Speaker or
Headphones
Connecting a Micro SD Card
Connecting a USB Stick
Chapter 3: Menu Screens
Main menu
Video Player Menu
Photo Viewer Menu
Music Player Menu
Ebook Viewer Menu
Chapter 4: Setup Menu
Settings
Brightness Feature
Keystone
Chapter 5: Technical Details
Troubleshooting
Specications
Notes
1
2
3
4
5
7
8
9
11
13
15
17
18
20
22
23
27
31
34
35
39
41
43
45
46

P5 at a Glance
1
Chapter 1
Power Switch
Micro SD Card
HDMI
USB Port
Main Unit Front/Back
VGA Port
Power Button
Focus Adjustment
AV Port
Headphone Out
Power On/Off

Remote & Keypad
2
NOTICE: Pressing power on the remote will only put the projector in STANDBY mode.
Toggle the “ON/OFF” switch on the side of the projector to fully turn the projector off.
Power On/Off Select Source
Input Exit/Back
Direction Pad
Both the keypad and remote can be used to navigate through the menus. The Main Menu
Navigation on the remote functions exactly the same as the directional pad on the P5 unit.
On / Off
LED Lights
OK
Main Menu
Navigation
Keystone
Media Player
Menu Navigation
Keystone
Volume Up
Volume Down
Remote

Accessories
3
*Under various circumstances, the actual accessories may be different from
those shown in the pictures above.
Tripod Remote
Power Adapter
VGA Cable
A/V Cable

Getting Started
1. Connect the power cord to the P5.
2. Connect the other end of the power cord into the wall power source.
3. Toggle the On / Off switch on the side of the projector to the “ON” position --the
projector should automatically turn on.
4. If the projector does not automatically turn on with the “Power Switch” toggled to the
“ON” position, press the “ON/OFF POWER” button on the keypad and hold for
2-3 seconds to start the projector
4
Powering ON the projector
Chapter 2
Powering OFF the projector
Standby Mode
1. To transition to “STANDBY” mode, press the power button twice on the keypad or
the remote control.
2. The optical engine should power off and the fan should stop spinning. The projector
is now in “STANDBY” mode and can be turned on using the remote control.
*Note: Standby mode will still consume a small amount of power.
1. To turn off the projector, toggle the “Power Switch” to the “OFF” position. This will
fully turn off the projector.

Swappable Lithium Ion Battery
5
*CAUTION! Lithium Ion Battery Packs store a lot of energy and can be dangerous. Lithium
Ion Battery Packs should always be treated with care and properly disposed. Do not mis-
use, do not put near a heat source, do not open.
The P5 Features a 135 minute, 22 Watt, Swappable Lithium Ion Battery Pack.
This battery pack is designed to be interchangeable with spare battery packs and
can be removed and replaced as needed.
This battery pack can only be charged by connecting to the P5 projector while the
power supply is plugged in. This battery pack does NOT charge while the projec-
tor is in operation. Additional battery packs can be purchased at www.aaxatech.
Shown: P5 Lithium Ion Battery

Battery Installation
1. Locate the battery locking mechanisms underneath the projector
2. Slide the two locking mechanisms outwards
3. Gently slide the Battery Pack out by pushing the battery pack away from the projec-
tor
6
Removing Battery
Installing the Battery
1. Reverse the removal instructions and ensure the battery is properly connected to the
guide clips

Focus Adjusment / Throw Distance
7
DIAGONAL SCREEN SIZE
16:9 Aspect Ratio
Throw Distance
Units: Inches
10
20
30
40
50
60
70
80
Diagonal Size
Units: Inches
8
16
23
31
39
47
55
62
• Spin the focus wheel up or down until the image becomes
clear.
Focus Adjustment
Throw Distance Chart
Throw Ratio 1.47
Projection Angle: 100% Offset
*minimum throw distance: 10 inches

8
External Inputs and Outputs
Headphones/speakers
Composite Cable
HDMI
VGA
USB Stick
MicroSD

Connecting to a Computer via VGA
9
Connect one end of the VGA Cable
to your computer’s VGA Adapter.
Step 1:
Step 2:
Step 3:
In the Main Menu Select the “Inputs” icon and then the “VGA” Icon.
Connect the other end of the
VGA Cord to your P5’s VGA port.
Select “VGA” iconSelect “INPUT” icon

Connecting to a Computer Cont.
Step 4:
Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your com-
puter most computers require “turning on” the video output feature. Each computer is different.
Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are
standard instructions for a Windows 7 computer – not all systems are the same.
Press Windows+P to toggle
through display settings. Select
either “Duplicate” or “Extend” de-
pending on your viewing option.
*NOTE: different operating sys-
tems may differ
Step 5:
1. Right click on computer
desktop and select “Screen
Resolution”
2. Display Properties window
will pop up
3. If a secondary monitor is
grayed out, click on it and se-
lect “Extend these displays”
in the “Multiple Displays” drop
down
4. If the image is blurry or the
text is not legible, adjust
the screen resolution. We
recommend 1280x720.
Step 6:
10

Connecting to a Computer via HDMI
11
Connect one end of the HDMI Cable
to your computer’s HDMI Adapter.
Step 1:
Step 2:
Step 3:
In the Main Menu Select the “Inputs” icon and then the “HDMI” Icon.
Connect the other end of the HDMI
Cord to your P5’s HDMI port.
Select “INPUT” icon Select “HDMI” icon

Connecting to a Computer Cont.
Step 4:
Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your com-
puter most computers require “turning on” the video output feature. Each computer is different.
Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are
standard instructions for a Windows 7 computer – not all systems are the same.
Press Windows+P to toggle
through display settings. Select
either “Duplicate” or “Extend” de-
pending on your viewing option.
*NOTE: different operating sys-
tems may differ
Step 5:
1. Right click on computer
desktop and select “Screen
Resolution”
2. Display Properties window
will pop up
3. If a secondary monitor is
grayed out, click on it and se-
lect “Extend these displays”
in the “Multiple Displays” drop
down
4. If the image is blurry or the
text is not legible, adjust
the screen resolution. We
recommend 1280x720.
Step 6:
12

Connecting to Composite Video
13
Connect the 3.5mm Composite A/V
Cable to the back of the P5.
Connect the composite end of
the AV Cable (Red, White,Yellow)
to your device.
Step 1:
Step 2:

Connecting to Composite Video Cont.
Connectivity with multimedia devices
The P5 can connect to many media devices including: iPod, iPhone, iPad, VHS
players, DVD players, smart phones, cameras, video game consoles and other
peripherals with ease.
*Some smart phones require video out capabilities to be displayed with the P5. Check with
your phone manufacturer. 14
In the Main Menu
Turn on your multimedia device.
Select “INPUT” icon Select “RCA”
Step 3:
Step 4:

Connecting to HDMI Video
15
Connect one end of the HDMI to
your P5’s HDMI Adapter
Step 1:
Step 2:
Connect the opposite end of
the HDMI cable to your device.
Note: Apple devices require a specialized
HDMI adapter (Sold separately by
Apple)

Connecting to HDMI Video Cont.
Connectivity with multimedia devices
The P5 can connect to many media devices including: iPod, iPhone, iPad, VHS
players, DVD players, smart phones, cameras, video game consoles and other
peripherals with ease.
*Some smart phones require video out capabilities to be displayed with the P5. Check with
your phone manufacturer. 16
Step 3:
In the Main Menu
Turn on your multimedia device. If available select 1280x720 or 1920x1080.
Step 4:
Select “HDMI” iconSelect “INPUT” icon

Connecting Speakers / Headphones
17
Connect your speakers/headphones
to the projector’s audio port.
Step 1:
Step 2:
*CAUTION: Prolonged use of headphones at a high
volume may impair hearing.
Ensure that the projector and/or
the headphones are powered on.
Step 3: Place the headphones on and enjoy!
