Universal Process Controllers
C300 and C310
Programming Guide
IM/C300–PG_7
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

ABB
EN ISO 9001:2000
Cert. No. Q5907
The Company
We are an established world force in the design and manufacture of
instrumentation for industrial process control, flow measurement, gas and
liquid analysis and environmental applications.
AsapartofABB,aworldleaderinprocessautomationtechnology,weoffer
customers application expertise, service and support worldwide.
We are committed to teamwork, high quality manufacturing, advanced
technology and unrivalled service and support.
The quality, accuracy and performance of the Company’s products result
from over 100 years experience, combined with a continuous program of
innovative design and development to incorporate the latest technology.
The UKAS Calibration Laboratory No. 0255 is just one of the ten flow
calibration plants operated by the Company, and is indicative of our
dedication to quality and accuracy.
EN 29001 (ISO 9001)
Lenno, Italy – Cert. No. 9/90A
R
E
G
I
S
T
E
R
E
D
Health and Safety
To ensure that our products are safe and without risk to health, the following points must be noted:
1. The relevant sections of these instructions must be read carefully before proceeding.
2. Warning labels on containers and packages must be observed.
3. Installation,operation,maintenanceandservicingmustonlybecarriedoutbysuitablytrainedpersonneland
in accordance with the information given.
4. Normal safety precautions must be taken to avoid the possibility of an accident occurring when operating in
conditions of high pressure and/or temperature.
5. Chemicals must be stored away from heat, protected from temperature extremes and powders kept dry.
Normal safe handling procedures must be used.
6. When disposing of chemicals ensure that no two chemicals are mixed.
Safetyadviceconcerning the useof the equipmentdescribed in thismanual or anyrelevanthazard data sheets
(where applicable) may be obtained from the Company address on the back cover, together with servicing and
spares information.
Electrical Safety
This equipment complies with the requirements of CEI/IEC 61010-1:2001-2 "Safety requirements for electrical
equipmentfor measurement,control, andlaboratory use".If theequipment isused ina mannerNOTspecifiedbythe
Company, the protection provided by the equipment may be impaired.
Symbols
One or more of the following symbols may appear on the equipment labelling:
Information in this manual is intended only to assist our customers in the efficient operation of our equipment. Use
of this manual for any other purpose is specifically prohibited and its contents are not to be reproduced in full or part
without prior approval of the Technical Communications Department.
Warning – Refer to the manual for instructions
Caution – Risk of electric shock
Protective earth (ground) terminal
Earth (ground) terminal
Direct current supply only
Alternating current supply only
Both direct and alternating current supply
The equipment is protected
through double insulation
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1
CONTENTS
Section Page
1 INTRODUCTION ................................. 2
2 GENERAL PROGRAMMING .............. 2
2.1 Preperation for Changes
to the Parameters ........................ 2
3 SELECTING THE CONTROL TYPE .. 3
4 CONFIGURATION ............................... 4
4.1 Profile Program Page .................. 4
4.2 Set Points Page ........................... 6
4.3 Motorized Valve Control .............11
4.3.1 Position
Feedback Page .............. 12
4.4 Motorized Valve Control
without Feedback (Boundless).. 13
4.4.1 Calculation for Control
Pulses Steps and
Deviation (Boundless
Control only)................... 13
4.4.2 Regulator Data Page ..... 14
4.5 Set Up Process Variable ........... 15
4.5.1 Set Up Process
Variable Input Page
(COMMANDER 300) ..... 16
4.6 Set Up Remote Set Point Page. 20
4.7 Set Up Position
Feedback Page ......................... 22
4.8 Set Up Display Page ................. 24
4.9 Current Proportioning
Output Page .............................. 25
4.10 Set Up Control Page ................. 28
4.11 Set Up Alarms Page .................. 37
4.12 Retransmission Output Page .... 44
4.13 Cool Output Page ...................... 44
4.14 Scale Adjustment Page ............. 45
4.15 Access Page.............................. 48
4.16 Set Up Process
Variable Input Page
(COMMANDER 301 only) ........ 49
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2
2.1 Preparation for
Changes to the Parameters
Ensure that the external alarm/control
circuits are isolated if inadvertent
operation during programming is
undesirable.
Any change to the operating parameters
are implemented using the or
switches – see Section 3 of the Operating
Guide .
Note. The instrument responds
instantly to parameter changes which
are saved when the switch is
pressed.
2 GENERAL PROGRAMMING1 INTRODUCTION
The COMMANDER 300 Series of
documentation is shown in Fig. 1.1. The
Standard Manuals, including the specification
sheet, are supplied with all instruments. The
Modbus Supplement is supplied with
instruments configured for Modbus Serial
Communication.
The Installation manual includes an
Installation Record which should be
completed as a log of the electrical
installation. The record is useful when
carrying out initial instrument programming
and can be retained for future reference
PROGRAMMING
Part No.
IM/C300–PG
Basic Config. Level
Advanced Config.
Level
OPERATION
Setting Up
Displays & Controls
Operating Level
Simple Fault Finding
Part No.
IM/C300–OG
Part No. IM/C300–INS
or IM/C310–INS
INSTALLATION
Product Identification
Siting
Mounting
Electrical Connections
Installation Record
MODBUS (RTU).
Serial Adaptors
Serial Connections
Programming Page
Part No. IM/C300–MOD
or IM/C310–MOD
SPECIFICATION SHT.
Full Specification
Part No. SS C300
or SS C310
Modbus Registers
Standard Manuals Modbus Supplement
Fig. 1.1 Commander 300 Documentation
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

3
3 SELECTING THE CONTROL TYPE
SEtUP
CONtrL
Page Header – Set Up Control.
C–tYPE Control Type – see Section 4.10
t–PrOP
P–PrOP
Select the control type required:
–
–
–
–
current proportioning.
time proportioning.
position proportioning –
motorised valve with
position feedback.
boundless – motorised
valve without position
feedback.
C–PrOP
t–PrOP
P–PrOP
bndLSS
Press then to return to the
Operating Page .
dISPLY
bndLSS
PAGE
C–ProP
OUtPUt
or
C–PrOP
100.3
110.5
ACKNLG
ALArMS
P-StAt
PAGE
PrOFLE
StAtES
SECOdE
PAGE
SELF
tunE
ContrL
PAGE
PrOFLE
PrOGr
SEt
POINtS
POStN
F-bACK
rEGLtr
dAtA
SEtUP
PrCESS
SEtUP
rSPt
SEtUP
PSN-Fb
or
SEtUP
ALArMS
ACCESS
PAGE
SCALE
AdJUSt
rEtrAN
COOL
OUtPUt
or
OUtPUt
Operating Page
Fig. 3.1 Selecting the Control Type
Note. It is recommended that the control
type is set up before the instrument is
configured.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4
4 CONFIGURATION
4.1 Profile Program Page
Information.
• This page is inaccessible when a profile is running.
• Up to 9 programs for the C300/C310 (3 for the C301, 20 for the C302).
• Total of 30 segments for the C300/C310 (12 for the C301, 99 for the C302).
• Guaranteed Ramp/Soak feature.
• Repeat facility for each program.
Page Header – Profile Program.
Eng.
Units
S1 S2 S3 S4 S5
L1 L2 L3 L4 L5
Program 1
Program 2
Start at S1
Start at S2 End at S5
Time
Overall Profile
End at S3
Segment
Numbers
L0
Levels:
Profile Enable
Select the profile function, on or OFF.
Program Select
Selecttheprogramrequired, between 1and9(3 forC301,20
for C302).
A program consists of up to 30 (12 for C301, 99 for C302)
segments. Each segment has a starting and finishing set
point level, giving a maximum of 31 (13 for C301, 100 for
C302) levels. For identification purposes these levels are
numbered 0 to 30 (12 for C301, 99 for C302), e.g.:
Level 1 is the finishing level of segment 1 and the
starting level of segment 2
Level 10 is the finishing level of segment 10 and the
starting level of segment 11.
Program Begin (start level)
This is the first level number of the program selected at
Program Select above.
Setthe program start level number for theprogram chosen
at Program Select, between 0 and 29 (11 for C301, 98 for
C302).
Continued on next page.
OFF
1
PrOFLE
PrOFLE
ON
OFF
0
PG–bEG
PrOGrM
PrOGrM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

5
LEVL
– – – –
0
xx
Last segment
More
segments
to set up
rEPEAt
HYSt
0
SEt
POINtS
30
LEU.L
0
x
PG –ENd
1.0
xtIME
…4.1 Profile Program Page
4 CONFIGURATION…
Program End (finish level)
Set the program end level number for the program chosen
at Program Select, between 1 and 30 (12 for C301, 99 for
C302).
Program First Segment Start Level
The number shown in the upper display is the start level
number for the first segment.
Set the required value for the start level.
The units are display units between Display Zero and
Display Full Scale.
Segment Time Period
The time number of the currently selected segment is
shown in the upper display.
Setthe required time period, between 0 and999.9 minutes
in 0.1 minute increments.
Segment Finish/Start Level
The number shown in the upper display is the finish level
number for the currently selected segment and the start
number for the next segment.
Set the required value for the segment finish/start level. The
units are display units between display zero and full scale.
Advance to the next parameter, Segment Time Period, if
more segments are to be set-up or Repeat if the current
segment is the last segment.
Program Repeat
Each program can be set to repeat up to 99 times or
continuously.
Set the required repeat count, between 0 and 99, or
InFntE for continuous repeats.
Program Hysteresis Value (for guaranteed ramp/soak)
A hysteresis value can be set in engineering units. Setting
the value to zero turns the guaranteed ramp/soak facility
off. If the process variable deviates beyond the value set,
the program is suspended but continues automatically
whenthe process variable returns withinthe set limits. The
hysteresis value applies above and below set point under
all program conditions.
Set the hysteresis value required, within the display range
limits.
Return to top of Profile Program Page
or
advance to Set Points Page.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6
…4 CONFIGURATION
4.2 Set Points Page
Information.
• Two local set points – Local and Dual.
• Remote set point facility – with Ratio and Bias.
• Remote set point tracking options – for bumpless Remote-to-Local set point transfers.
• Adjustable high and low limits for all set point types.
• Set point tracking for bumpless Manual-to-Auto transfers.
90
10
Dual
Remote
Local Set Point
Programmable Set Point Types
Ratio Bias Limits
Fixed Set Point 1
Fixed Set Point 2
Digitally Selectable Set Points
Adjustable limits
Adjustable limits
Engineering Range
Ratio Setting
(0.010 to 9.999) Bias Setting (within Eng. range) Limits (within Eng. range)
100
Set
Point 50
0
1.5
0.1
1.0 SP = 50
SP = 5
SP = 75
SP = 10
SP = 30
SP = 85
+5
–20
+10
* Set Point cannot be adjusted outside the limits set
High Limit*
Low Limit*
Dual Second
Set Point
Control
Set Point
Limits
Limits
Fig. 4.1 Set Point Types
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

7
4 CONFIGURATION…
…4.2 Set Points Page
To gain access to this and subsequent pages the correct Configuration code must first be set
in the Security Code Page – see Section 5.5 of the Operating Guide .
SEt
SP–AdJ
YES
LSP–HI
1000
LSP–LO
0
LSPt
500
SPt–SL
YES
POINtS
SP–trK
no
Page Header – Set Points.
Set Point Adjustment Enable
Thisframeallows displayand adjustmentofthe setpointin
the Operating Page Displays (see Section 5.2 of the
Operating Guide ). Select YES to enable or no to disable.
Set Point High Limit
This is the maximum value to which the local set point can
be adjusted.
Set the value required. The decimal point position is set
automatically.
Set Point Low Limit
This is the minimum value to which the local set point can
be adjusted.
Set the value required. The decimal point position is set
automatically.
Local Set Point Value
Set the value required, within the limits set above. The
decimal point position is set automatically to that set in the
Set Up Display Page – see Section 4.8.
Set Point Tracking Enable
If Set Point Tracking is enabled and the controller is in
Manual mode the local set point tracks the process
variable. When the controller is in Set Point Tracking mode
the local set point limits can be exceeded. If the local set
point is outside of its limits when the tracking mode is
disabled, the local set point value can only be adjusted
towards its limits. Once within the limits they apply as
normal.
Select YES to enable or no to disable.
Set Point Select
This frame enables selection of set point type from the
Operating Page i.e., LOCAL, rEMOtE, or dUAL as
applicable–seeSet Point Type Selection ( Section5.2 ofthe
Operating Guide ).
Select YES to enable, or no to disable.
Continued on next page.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8
…4 CONFIGURATION
…4.2 Set Points Page
Second Set Point Type
This frame enables the setting up of a Second set point in
addition to the Local set point.
Select the second set point type, NONE (no Second set
point), dUAL (Dual set point) or rEMOtE (Remote set
point).
Dual Set Point High Limit
This is the maximum value to which the Dual set point can
be adjusted.
Select the value required. The decimal point position is set
automatically.
Dual Set Point Low Limit
This is the minimum value to which the Dual set point can
be adjusted.
Select the value required. The decimal point position is set
automatically.
Adjustable Dual Set Point Value
Setthevalue required,restrictedto thelimitsset in DualSet
Point High Limit and Dual Set Point Low Limit above.
Advance to Set Point Type Selection on page 10.
Remote Set Point Tracking Enable
If Remote Set Point Tracking is enabled and the controller is
in Remote mode the Local set point tracks the remote set
point. When the controller is in Remote Set Point Tracking
modethe local set pointlimits can be exceeded. If the local
set point is outside of its limits when the tracking mode is
disabled, the Local set point value can only be adjusted
towards its limits. Once within the limits they apply as
normal. With Remote set point tracking enabled; if the
controller is put into Manual mode, the set point reverts
from remote to Local.
Select YES to enable or no to disable.
Remote Set Point High Limit
This is the maximum value to which the Remote set point
can be adjusted.
Select the value required. The decimal point position is set
automatically.
Continued on next page.
dSP–HI
1000
dSP–LO
0
dUAL
NONE
or
rEMOtE
d–SPt
500
1000
NONE
rEMOtE
rSP–HI
YES
rSPtrK
nd–SP
rEMOtE
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

9
…4.2 Set Points Page
4 CONFIGURATION…
Remote Set Point Low Limit
This is the minimum value to which the remote set point
can be adjusted.
Select the value required. The decimal point position is set
automatically.
Remote Set Point Ratio Adjust Enable
This frame enables or disables the display and adjustment
of the remote set point ratio in the Operating Page (see
Section 5.2 of the Operating Guide ).
Select YES to enable or no to disable.
Remote Set Point Ratio
This is a scaling factor, i.e. multiplies the remote set point
input by the ratio value set. Set the required remote set
point ratio, between 0.010 and 9.999 in 0.001 increments.
Remote Set Point Bias Adjust Enable
This frame enables or disables the display and adjustment
of the remote set point bias in the Operating Page (see
Section 5.2 of the Operating Guide ).
Select YES to enable or no to disable.
Remote Set Point Bias
This is an offset value set as a proportion of display span
(may be ±the span value).
Set the remote set point bias in engineering units.
Continued on next Page.
b–AdJ
bIAS
0
no
1.000
rAtIO
0
rSP–LO
r–AdJ
no
dUAL
NONE
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

10
– – – – – –
SEt UP
PrCESS
LOCAL
bALNCE
rEMOtE
or
dUAL
POStn
F–bACK
rEGLtr
dAtA
or or
– – – – – –
…4.2 Set Points Page
Set Point Type Selection
This frame displays the current set point type, or bALNCE
and value – see Set Point Type Selection frame in the
Operating Page – see Section 5.2 of the Operating Guide .
Upper Display – displays the set point type, or bALNCE:
LOCAL – Local set point
bALNCE – Balance, the difference between the
Local and Remote (or Dual) set point
values
rEMOtE – Remote set point on controllers with
Remote set point facility
dUAL – Dual set point
Lower Display – displays the value of the set point type
shown in the upper display, but if the set point type is
changedfrom Local to Remote(or Dual) the displayshows
the difference (bALNCE) between the Local set point
value and the Remote (or Dual) set point value.
When Remote set point is selected and if Remote set point
tracking is enabled the Local set point value tracks the
Remote set point value. The Local set point limits do not
apply in this mode. If the Local set point is outside of its
limits when Local set point type is re-selected, it can only
be adjusted towards its limits. Once within these limits,
they apply as normal.
Press to select LOCAL, bALNCE, rEMOtE (or
dUAL). rEMOtE and dUAL are dependent on the
selection made at Second Set Point Type parameter.
Return to the top of Set Points Page or advance to the next
page.
…4 CONFIGURATION
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

11
4.3 Motorized Valve Control
Information.
• Motorized valve control with or without feedback – position-proportioning (with
feedback) or boundless (without feedback).
• Ratio and bias settings can be applied to adjust the range of valve travel (position-
proportioning only).
• Deadband setting – adjustable to minimize hunting of the motorized valve.
4 CONFIGURATION…
P.I.D. Output Desired Valve Position
Engineering Range
Ratio Setting
(0.010 to 9.999) Bias Setting
(within Eng. range)
100
50
0
A 1.0
B 0.5
C –25%
B 0%
Ratio Bias
Proportional
Bandwidth*
80
20
A 0%
100%
0%
Valve
Travel
Limits
75%
25%
Valve
Travel
Limits
50%
0%
Valve
Travel
Limits
Valve
Open
Valve
Closed
C 0.5
AB C
Fig. 4.2 Position-Proportioning Schematic Diagram
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

12
…4 CONFIGURATION
4.3.1 Position Feedback Page
This page appears only if P–PrOP is selected at the Control Type parameter in the Set Up
Control Page – see Fig. 3.1 and Section 4.10.
rA tIO
1.00
bIAS
0
dEAdb
1.0
SEtUP
PrCESS
POStN
F–bACK
Page Header – Position Feedback Page
Ratio
Ratio is a scaling factor, i.e. multiplies the position
feedback input by the value set here.
Set the required feedback ratio, between 0.0 and 9.99 in
0.01 increments.
Bias
Bias is an offset as a percentage of the valve travel.
Set the required feedback bias, between –100.0 and
+100.0%.
Deadband
Deadband is set as a percentage of the position feedback
span, between 0.0 and 10.0%, to produce a deadband
around the valve control value. This gives minimum
‘hunting’ of the motorized valve.
Example – if the valve is to be driven to the 50% open
position and the deadband is set to 4.0%, the motor stops
drivingwhenthe positionfeedback is48%. In this example
the deadband is between 48% and 52%.
Return to the top of the Position Feedback Page or advance
to next page.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

13
4 CONFIGURATION…
4.4 Motorized Valve Control without Feedback (Boundless) –Fig. 4.3
A 'boundless' process controller provides an output that is effectively the time derivative of the
required regulator position, i.e. the controller signals the regulator, not where to go to (position
derivative), but in which direction to travel and how far to move, by a series of integral action
pulses. Thus, the controller does not need to know the absolute regulator position and is
unaffected when regulator reaches the upper or lower limit, as determined by the regulator's
limit switches (giving rise to the term 'boundless').
In this system, the final regulator must act as an integrator, integrating both the raise and lower
pulses in direction and duration so that the final position of the regulator reproduces the
required 2 or 3 term control function, and must remain stationary indefinitely in the absence of
raise or lower commands.
When a deviation from set point is introduced the regulator is driven, for a length of time
equivalent to the proportional step. The regulator is then driven by integral action pulses until
the deviation is within the deadband setting.
4.4.1 Calculation for Control Pulses,
Steps and Deviation (Boundless Control only)
Minimum 'ON' time of integral action pulses (for a fixed control deviation).
=
Travel Time x Deadband %
% Proportional Band
(in seconds)
Minimum (approximate) time between integral action pulses (for a fixed control deviation)
=
Integral Action Time x Deadband %
2 x % Control Deviation
(in seconds)
Duration of the proportional step
= 2 x
% Control Deviation
% Proportional Band
x Travel Time in Seconds
% Control Deviation =
Set Point – Process Variable
Span
Fig. 4.3 Boundless Control Action
Proportional
Step
Time
Control
Deviation
Raise
Lower
Time
Integral
Action Pulses
Proportional
Step Proportional
Step Integral
Action Pulses
+
–
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

14
…4 CONFIGURATION
4.4.2 Regulator Data Page
This page is displayed only when bndLESS is selected at Control Type frame in the Set Up
Control Page – see Fig. 3.1 and Section 4.10.
Page Header – Regulator Data
Regulator Travel Time
This is the time set for the regulator to travel from the fully
open to the fully closed position or from the fully closed to
the fully open position.
Set the value required in seconds, between 1 and 5000
seconds.
Deadband Setting
The deadband is set as a percentage of the engineering
range span to produce a deadband around the control set
point value. This reduces ‘hunting’ of the regulator.
Set the required value, between 0.0 and 10.0%.
Position Feedback Indication Enable
Select INdCtN to enable the Valve Position frame in the
Operating Page –see Section 5.2 of the Operating Guide .
Select NONE to disable the Valve Position frame.
Note. A value is only displayed in the Valve Position frame
if the frame is enabled and the regulator has a feedback
signal.
Return to top of Regulator Data Page,
or
Advance to Set-up Process Variable Input Page.
dAtA
600
dEAdb
1.0
rGL–t
rEGLtr
SEtUP
PrCESS
INdCtN
PSN–Fb
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

15
4.5 Set Up ProcessVariable
Information.
• Universal inputs – mV, mA, V, THC, RTD and resistance.
• Internal cold junction compensation.
• Linearization of temperature sensors to allow use of non-linearizing transmitters or any
electrical input.
• Programmable fault levels and actions.
• Digital filter reduces the effect of noise on inputs.
4 CONFIGURATION…
Input
Type Linearizer
Type Linearizer
Units Linearizer
Range Display Range
5/2
3/2
√
RTD
THC N
THC B
THC E
THC J
THC T
THC S
THC R
THC K
None
Programme
Filter
°F
°C
RTD
THC
Current
Voltage
Millivolts
Display Range
High Value set to 0
Value set low
Value set high
Fault
Detection
Level 10 %
200
0
Display Range
Low
Fault
Detection
Level 10 %
200
220
–20
0
Example – Type K thermocouple Range 0 to 200°F with 10% fault detection levels.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

16
…4 CONFIGURATION
4.5.1 Set Up ProcessVariable Input Page (COMMANDER 300)
If the custom linearizer is to be used (available on COMMANDER 301 only), refer to Section
4.16.
LNtYPI
NONE
tC-K
tC-r
tC-S
tC-J
tC-L
tC-E
rtd
SQrt
tC-t
3 2
5 2
SQrt
NONE
L–UNtI
dEG C
5
3
tC-b
tC-N
SEtUP
PrCESS
IntYPI
U.Lt
MAMP
VOLt
ohM
tCPL
rtd
(a)
(b)
Page Header – Set Up Process Variable Input.
Process Variable Input Type
Select the input type required:
MU.Lt – Millivolt (≤2000 mV)
MAMP – Current
V.OLt – Voltage
ohM – Resistance
tCPL – Thermocouple *
rtd – Resistance thermometer
*For thermocouple applications using an external fixed
cold junction, select millivolt input type.
Linearizer Type
Select the linearizer type required:
NONE – No linearizer
tC-K – Type K thermocouple
tC-r – Type R thermocouple
tC-S – Type S thermocouple
tC-t – Type T thermocouple
tC-J – Type J thermocouple
tC-L – Type L thermocouple
tC-E – Type E thermocouple
tC-b – Type B thermocouple
tC-N – Type N thermocouple
rtd – Resistance thermometer
SQrt – Square root
3 2 –x
3/2
2 –x
5/2
Linearizer Units
Select the temperature units required, °C or °F.
Continued on next page.
Continued on page 18.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

17
THC / RTD
Type
D
egrees
C
e
l
s
i
us
D
egrees
F
a
h
ren
h
e
i
t
Min. Max. Min. Span Min. Max. Min. Span
Type B* – 18 1800 710 0 3272 1278
Type E – 100 900 45 – 148 1652 81
T
ype
J
– 100 900 50 – 148 1652 90
T
ype
K
– 100 1300 65 – 148 2372 117
T
ype
L
– 100 900 50 – 148 1652 90
T
ype
N
– 200 1300 90 – 328 2372 162
T
ype
R
&
S*
– 18 1700 320 0 3092 576
T
ype
T
– 250 300 60 – 418 572 108
RTD – 200 600 25 – 328 1112 45
4 CONFIGURATION…
…4.5.1 Set Up ProcessVariable Input Page
Linearizer Full Scale
Set the range maximum temperature in °C or °F as
selected at Linearizer Units above, within the limits detailed
in Table 4.1. If these limits are exceeded, LIN–Or
(linearizer overrange) is displayed in the Operating Page –
see Table 5.1a of the Operating Guide .
Linearizer Zero
Settherangeminimum temperaturein°Cor°F asselected
at Linearizer Units above, within the limits detailed in Table
4.1.
Continued on next page. (for b and c)
Table 4.1 Temperature Limits
* Accuracy for type B,R and S is not guaranteed below 400°C.
Minimum span below zero Type T 70°C/126°F
THC standard DIN 43710 IEC 584
RTD standard DIN 43760 IEC 751
I000
0
LIN–LO
LIN–HI
(a)
(c)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
