ABB DCS800-EP Installation and operation manual

DCS800-EP
Installation and Start Up Manual
DCS800 Panel Drive (20-1000 Amps)
A supplement to the DCS800 Hardware manual
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

2 DCS800-EP Installation and Start-Up Manual
Safety instructions
What this chapter contains
This chapter contains the safety instructions which you must follow when installing,
operating and servicing the drive. If ignored, physical injury or death may follow, or
damage may occur to the drive, the motor or driven equipment. Read the safety
instructions before you work on the unit.
To which products this chapter applies
This chapter applies to the DCS800-EP... Size D1 to D4.
Use of warnings and notes
There are two types of safety instructions throughout this manual: warnings and
notes. Warnings caution you about conditions which can result in serious injury or
death and/or damage to the equipment. They also tell you how to avoid the danger.
Notes draw attention to a particular condition or fact, or give information on a
subject. The warning symbols are used as follows:
Dangerous voltage warning warns of high voltage which can cause physical
injury and/or damage to the equipment.
General warning warns about conditions, other than those caused by
electricity, which can result in physical injury and/or damage to the equipment.
Electrostatic discharge warning warns of electrostatic discharge which can
damage the equipment.
Installation and maintenance work
These warnings are intended for all who work on the drive, motor cable or motor.
Ignoring the instructions can cause physical injury or death.
Only qualified electricians are allowed to install and maintain the drive.
• Never work on the drive, motor cable or motor when main power is applied.
• Always ensure by measuring with a multimeter (impedance at least 1 Mohm) that:
1. Voltage between drive input phases U1, V1 and W1 and the frame is close to
0V.
2. Voltage between terminals C1 and D1 and the frame is close to 0 V.
• Do not work on the control cables when power is applied to the drive or to the
external control circuits. Externally supplied control circuits may cause dangerous
voltages inside the drive even when the main power on the drive is switched off.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

DCS800-EP Installation and Start-Up Manual 3
• Do not make any insulation or voltage withstand tests on the drive or drive
modules.
• When reconnecting the motor cable, always check that the C1 and D1 terminal is
correct.
Note:
• The motor cable terminals on the drive are at a dangerously high voltage when
the input power is on, regardless of whether the motor is running or not.
• Depending on the external wiring, dangerous voltages (115 V, 220 V or 230 V)
may be present on the terminals of relay outputs SDCS-IOB-2, RDIO.
• DCS800 with enclosure extension: Before working on the drive, isolate the whole
drive from the supply.
Grounding
WARNING! Printed circuit boards contain components sensitive to
electrostatic discharge. Wear a grounding wrist band when handling the
boards. Do not touch the boards unnecessarily.
These instructions are intended for all who are responsible for the grounding of the
drive. Incorrect grounding can cause physical injury, death or equipment malfunction
and increase electromagnetic interference.
• Ground the drive, motor and adjoining equipment to ensure personnel safety in all
circumstances, and to reduce electromagnetic emission and pick-up.
• Make sure that grounding conductors are adequately sized as required by safety
regulations.
• In a multiple-drive installation, connect each drive separately to protective earth
(PE).
• Minimize EMC emission and make a 360° high frequency grounding of screened
cable entries at the cabinet lead-through.
• Do not install a drive with EMC filter on an ungrounded power system or a high
resistance-grounded (over 30 ohms) power system.
Note:
• Power cable shields are suitable for equipment grounding conductors only when
adequately sized to meet safety regulations.
• As the normal leakage current of the drive is higher than 3.5 mA AC or 10 mA DC
(stated by EN 50178, 5.2.11.1), a fixed protective earth connection is required.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

4 DCS800-EP Installation and Start-Up Manual
Fiber optic cables
WARNING! Handle the fiber optic cables with care. When unplugging optic
cables, always grab the connector, not the cable itself. Do not touch the ends
of the fibers with bare hands as the fiber is extremely sensitive to dirt. The
minimum allowed bend radius is 35 mm (1.4 in.).
Mechanical installation
These notes are intended for all who install the drive. Handle the unit carefully to
avoid damage and injury.
• DCS800-EP Frames A and B: The drives are heavy and may require more than
one person to lift. Use appropriate lifting techniques. Do not lift the unit by the
front cover. Place the unit only on its back.
• DCS800-EP Frames C and D: The drive is heavy. Lift the drive by the lifting lugs
only.
• Make sure that dust from drilling does not enter the drive when installing.
Electrically conductive dust inside the unit may cause damage or lead to
malfunction.
• Ensure sufficient cooling.
• Do not fasten the drive by riveting or welding.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

DCS800-EP Installation and Start-Up Manual 5
Operation
These warnings are intended for all who plan the operation of the drive or operate
the drive. Ignoring the instructions can cause physical injury or death or damage the
equipment.
• Before adjusting the drive and putting it into service, make sure that the motor
and all driven equipment are suitable for operation throughout the speed range
provided by the drive. The drive can be adjusted to operate the motor at speeds
above and below the base speed.
• Do not activate automatic fault reset functions of the Standard Application
Program if dangerous situations can occur. When activated, these functions will
reset the drive and resume operation after a fault.
• Do not control the motor with the disconnecting device (disconnecting switch);
instead, use the control panel keys and , or commands via the I/O board of the
drive.
•Mains connection
You can use a switch disconnect in the power supply of the thyristor power
converter to disconnect the electrical components of the unit from the power
supply for installation and maintenance work. The type of disconnect used must
be a switch disconnect as per EN 60947-3, Class B, so as to comply with EU
regulations, or a circuit-breaker type which switches off the load circuit by means
of an auxiliary contact causing the breaker’s main contacts to open. The mains
disconnect must be locked in its “OPEN” position during any installation and
maintenance work.
• EMERGENCY STOP buttons must be installed at each control desk and at all
other control panels requiring an emergency stop function. Pressing the STOP
button on the control panel of the thyristor power converter will neither cause an
emergency motor stop, nor will the drive be disconnected from any dangerous
potential.
To avoid unintentional operating states, or to shut the unit down in case of any
imminent danger, according to the standards in the safety instructions it is not
sufficient to merely shut down the drive via signals “RUN”, “Drive OFF” or
“Emergency Stop” with “Control Panel” or “PC Tool”.
•Intended use
The operating instructions cannot take into consideration every possible system
configuration, operation or maintenance. Thus, they mainly give such advice only,
which is required by qualified personnel for normal operation of the machines and
devices in industrial installations.
If in special cases the electrical machines and devices are intended for use in
non-industrial installations - which may require stricter safety regulations (e.g.
protection against contact by children or similar). These additional safety
measures for the installation must be provided by the customer during assembly.
Note:
When the control location is not set to Local (L not shown in the PC tool status row),
the Stop key on the control panel WILL NOT stop the drive.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

6 DCS800-EP Installation and Start-Up Manual
Table of contents
Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Use of warnings and notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation and maintenance work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Mechanical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Table of contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
The DCS800-EP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Type codes and Plus Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Other DCS800 documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Mechanical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Unpacking the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Delivery check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Requirements for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cabinet cooling and air flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Panel heat dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Planning the electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Options for the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Typical cable sizing and tightening torque . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Checking the insulation of the assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
IT (ungrounded) systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Check supply voltages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting the power cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Electrical diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Connection diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Control circuit connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Alternate line voltage (converting to 230 Vac line) . . . . . . . . . . . . . . . . . . . . . . 24
Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Dimensional data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

DCS800-EP Installation and Start-Up Manual 7
Replacement Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Blower motor starter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Other replacement parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Electrical and environmental data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Line reactors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Diagrams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

8 DCS800-EP Installation and Start-Up Manual
The DCS800-EP
What this chapter contains
This chapter briefly describes the operating principle and construction of the
DCS800-EP Panel Drive.
The DCS800-EP
The DCS800-EP sizes D1 through D4 are intended as a pre-packaged or
“panelized” solution for controlling DC motors.
Size A
17...104 A Size B 125...205 A
Available at a later date Available at a later date
Size C
245...405 A Size D 480...950 A
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

DCS800-EP Installation and Start-Up Manual 9
Type codes and Plus Codes
The type code contains information on the specifications and configuration of
the drive. The first digits from left express the basic configuration (e.g.
DCS800-EP2-0050). The optional selections are given thereafter, on the name
plate by plus code. The main selections are described below. Not all selections
are available for all types.
Type code: D C S 8 0 0 - EP X - Y Y Y Y - Z Z - plus code
The “P” in the type code designates the panel drive configuration. Further
explanation of the type code can be found in the DCS800 Hardware Manual in the
chapter “The DCS800.”
Power and current ratings above are based on Heavy Duty rating, 150% overload for
60 sec., except for 600 HP drive which is rated at 110% overload for 60 sec.
*DC Amps based on standard NEMA motor tables. AC Amps = DC Amps * 0.816
IMPORTANT:
Do not exceed the continuous and overload current ratings shown above. The drive
panel is not designed to withstand higher currents. Failure to adhere to this warning
can result in personal injury and/or damage to equipment.
Non-Regenerative
(2Q) Regenerative (4Q) Module Frame Panel Frame HP at 230V HP at 460V *Amps
AC in DC out
DCS800-EP1-0020-05 DCS800-EP2-0025-05 D1 A 5 10 14 17
DCS800-EP1-0045-05 DCS800-EP2-0050-05 D1 A 10 20 29 35
DCS800-EP1-0065-05 DCS800-EP2-0075-05 D1 A 15 30 43 53
DCS800-EP1-0090-05 DCS800-EP2-0100-05 D1 A 20 40 55 68
DCS800-EP1-0125-05 DCS800-EP2-0140-05 D1 A 30 60 85 104
DCS800-EP1-0180-05 – D2 B 35 75 102 125
– DCS800-EP2-0200-05 D2 B 50 100 134 164
DCS800-EP1-0230-05 DCS800-EP2-0260-05 D2 B 60 125 167 205
DCS800-EP1-0315-05 DCS800-EP2-0350-05 D3 B 75 150 200 245
DCS800-EP1-0405-05 DCS800-EP2-0450-05 D3 C 100 200 265 325
DCS800-EP1-0470-05 DCS800-EP2-0520-05 D3 C 125 250 330 405
DCS800-EP1-0610-05 DCS800-EP2-0680-05 D4 C 150 300 392 480
DCS800-EP1-0740-05 DCS800-EP2-0820-05 D4 D - 400 522 640
DCS800-EP1-0900-05 DCS800-EP2-1000-05 D4 D - 500 649 795
– DCS800-EP2-1010-05 D4 D - 600 775 950
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

10 DCS800-EP Installation and Start-Up Manual
Options
Other DCS800 documentation
This manual describes the unique features of the DCS800-EP Panel Drive. For
general information about the DCS800 module, please refer to the following:
DCS800 Quick Guide 3ADW000191
DCS800 Firmware Manual 3ADW000193
DCS800 Hardware Manual (modules) 3ADW000194
DCS800 Technical Catalog DCS800-PHTC01U-EN
*See the Firmware Manual or Hardware Manual for references to other DCS800
publications.
Plus Code Option Kit
1. Circuit Breaker (All Sizes) +F278 NA
2. AC Line Reactor
DCS800-EP1-0020-05 through DCS800-EP2-0350-05 +E213 NA
3. Without AC Line Contactor
DCS800-EP1-0020-05 through DCS800-EP2-0680-05 +0F250 NA
4. 230 Vac supply voltage +S235 DCS800-EP
230VAC Supply
5. Fan/blower motor starters
1.0 – 1.6 Amps
1.6 – 2.4 Amps
2.4 – 4.0 Amps
4.0 – 6.0 Amps
6.0 – 9.0 Amps
+M600
+M601
+M602
+M603
+M604
NA
NA
NA
NA
NA
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

DCS800-EP Installation and Start-Up Manual 11
Mechanical installation
Unpacking the unit
• Remove the corrugated paperboard box by
removing the shipping straps and lifting the
box up and off of the shipping pallet.
• Remove the screws holding the drive to the
wood pallet.
• For frame A, the drive can be lifted. All drives
have lifting holes to allow for mechanical lift.
Delivery check
• Check that there are no signs of damage.
• Before attempting installation and operation, check the information on the label of
the drive to verify that the unit is of the correct size and type. A typical label is
shown.
DCS800 PANEL DRIVE
781
775
See Hardware Manual
A (largest motor)
Amps Total
Model No.
Input (I1n)
SCCR
Output (I2n)
65
775
950
DCS800-EP1-0020-05+F278+E213+0F250+M602
Adc
A
KA RMS sym. @460V
Volts (U2)
Volts (U1)
240/500dc
230/460-3
Power (Pn)
Field (If)
Hz
600HP
6 Adc
50/60
450 kW
UL File #E165086
A
BC
D
E
F
G
A Input current for entire panel
B Input current for the drive module only
C Drive module rated input current
D Drive module rated output current
E Drive module rated input voltage
F Drive module rated output voltage
G Drive module rated power
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

12 DCS800-EP Installation and Start-Up Manual
Requirements for installation
The drive must be installed in an upright position within a cabinet or other enclosure.
The cabinet size, heat dissipation capability and clearances must conform to the
requirements below.
Refer to Dimensional drawings for frame details.
See Cabinet cooling and air flow for the allowed ambient conditions of the drive.
Minimum clearances
When installing the panel in a cabinet, minimum clearances from the panel to the
cabinet walls, top and bottom must be maintained. This space is required for proper
cabling, cooling air flow, service and maintenance. If one drive is mounted directly
above another, see DCS800 Hardware Manual “Mechanical Installation” for
additional information.
See chapter Dimensional drawings.
Frame X1 (side) X2 (top) X3 (bottom)
A0.5 in.
(13 mm) 5.0 in. (13 mm) 4.0 in. (102 mm)
B0.5 in.
(13 mm) 10.0 in. (25 mm) 5.0 in. (127 mm)
CTBD
D
USFMCCUSFMCC
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

DCS800-EP Installation and Start-Up Manual 13
Cabinet cooling and air flow
Cabinets must be sized to accommodate minimum
clearances as described in the previous section and in the
DCS800 Hardware Manual.
The maximum interior cabinet ambient temperature must
not exceed 40°C.
See table below for heat dissipation requirements. Cooling air
enters the bottom of the drive module and exits at the top (see
diagram at right).
Panel heat dissipation
HP
Non-Regenerative (2Q) Regenerative (4Q)
Total panel
watts loss Total panel watts loss
Type Code without
inductor with inductor Type Code without inductor with inductor
10 DCS800-EP1-0020-05 162 182 DCS800-EP2-0025-05 170 190
20 DCS800-EP1-0045-05 228 283 DCS800-EP2-0050-05 246 301
30 DCS800-EP1-0065-05 291 350 DCS800-EP2-0075-05 319 378
40 DCS800-EP1-0090-05 356 426 DCS800-EP2-0100-05 387 457
60 DCS800-EP1-0125-05 483 578 DCS800-EP2-0140-05 530 625
75 DCS800-EP1-0180-05 656 751
100 DCS800-EP2-0200-05 776 903
125 DCS800-EP1-0230-05 882 1017 DCS800-EP2-0260-05 960 1095
150 DCS800-EP1-0315-05 1074 1209 DCS800-EP2-0350-05 1168 1303
200 DCS800-EP1-0405-05 1326 – DCS800-EP2-0450-05 1426 –
250 DCS800-EP1-0470-05 1551 – DCS800-EP2-0520-05 1695 –
300 DCS800-EP1-0610-05 1996 – DCS800-EP2-0680-05 2167 –
400 DCS800-EP1-0740-05 2334 – DCS800-EP2-0820-05 2552 –
500 DCS800-EP1-0900-05 2982 – DCS800-EP2-1000-05 3252 –
600 DCS800-EP2-1010-05 3305 –
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

14 DCS800-EP Installation and Start-Up Manual
Planning the electrical installation
What this chapter contains
This chapter contains the instructions for selecting the cables, cable routing and line
reactors for the drive panel. Always follow local regulations.
Note: If the recommendations given by ABB are not followed, the drive may
experience problems that are not necessarily covered by the warranty.
Reference: Technical Guide – publ. no.: 3ADW000163
Options for the drive
Line reactors
When thyristor power converters operate, the line voltage is short-circuited during
commutation from one thyristor to the next. This operation causes voltage dips in the
mains PCC (point of common coupling). Some ACS800-EP Panel Drives are
shipped with an internal 1.5% line reactor and some are not (as indicated by the
drive’s Plus Code). For the connection of a power converter system to the mains,
one of the following configurations should be applied:
Configuration A
When using the power converter, a minimum of impedance is required to
ensure proper performance of the snubber circuit. A line reactor can be
used to meet this minimum impedance requirement. The value must
therefore not drop below 1% uk(relative impedance voltage). It should
not exceed 10% uk, due to considerable voltage drops at converter
output.
Configuration B
If special requirements have to be met at the PCC (standards like EN
61800-3, DC and AC drives at the same line, etc), different criteria must be
applied for selecting a line reactor. These requirements are often defined
as a voltage dip in percent of the nominal supply voltage. The combined
impedance of ZLine and ZL1 constitute the total series impedance of the
installation. The ratio between the line impedance and the line reactor
impedance determines the voltage dip at the connecting point. In such
cases line chokes with an impedance around 4% are often used.
Example calculation with Uk Line=1%; Uk L1=4%; Voltage Dip = ZLine/
(ZLine+ZL1)=20%. Detailed calculation see Technical Guide.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

DCS800-EP Installation and Start-Up Manual 15
Line reactors (cont)
Configuration C
If an isolation transformer is used, it is possible to comply with certain
connecting conditions per Configuration B without using an additional line
reactor. The condition described in Configuration A will then likewise be
satisfied, since the ukis >1 %.
Configuration C1
If 2 or more converters are supplied by one transformer, the
final configuration depends on the number of drives in use
and their power capability.
Either configuration A or B (which are based on commutation
chokes) has to be used, if the drive system consists of any of
the converters (D1, D2, D3, D4.)
With reference to the power converter:
The line reactors are listed in the table on page 30. They:
• have been sized to the units nominal current
• are based on a duty cycle
For further information in this publication:
See chapter Accessories - Line reactors.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

16 DCS800-EP Installation and Start-Up Manual
Typical cable sizing and tightening torque
Based on U.S. NEC Table 310.16. No more than three current carrying conductors per raceway.
Maximum Ambient Temperature - 40°C, Conductor Temperature Rating - 75°C except where noted.
The minimum ground cable recommendation assumes that the overcurrent protection for each drive is selected to
provide protection at 125% of the rated drive input current. If the overcurrent protection (e.g. circuit breaker) is sized larger
than this, then larger ground cables will need to be determined manually.
Drive Panel HP
AC input
L1, L2, L3 DC output C2, D2 Ground PE Tightening Torque (ft-lb)
IAC
(amps) Typical Cable IDC (amps) Typical Cable Minimum Cable 
L1-L2-L3
with
breaker
C2, D2, PE &
L1-L2-L3 with-
out breaker
DCS800-EP1-0020-05 10 14 12 AWG 17 10 AWG 12 AWG 35 in-lb 10
DCS800-EP2-0025-05 10 14 12 AWG 17 8 AWG 12 AWG 35-40 in-lb 10
DCS800-EP1-0045-05 20 29 8 AWG 35 8 AWG 10 AWG 45 in-lb 10
DCS800-EP2-0050-05 20 29 8 AWG 35 8 AWG 10 AWG 45 in-lb 10
DCS800-EP1-0065-05 30 43 6 AWG 53 6 AWG 10 AWG 45-50 in-lb 10
DCS800-EP2-0075-05 30 43 6 AWG 53 6 AWG 10 AWG 50 in-lb 10
DCS800-EP1-0090-05 40 55 4 AWG 68 4 AWG 8 AWG 50 in-lb 10
DCS800-EP2-0100-05 40 55 4 AWG 68 4 AWG 8 AWG 50 in-lb 10
DCS800-EP1-0125-05 60 85 2 AWG 104 1 AWG 6 AWG 50 in-lb 10
DCS800-EP2-0140-05 60 85 2 AWG 104 1 AWG 6 AWG 50 in-lb 10
DCS800-EP1-0180-05 75 102 1 AWG 125 2/0 AWG 6 AWG 23 23, 31 (PE)
DCS800-EP2-0200-05 100 134 3/0 MCM 164 4/0 AWG 6 AWG 23 23, 31 (PE)
DCS800-EP1-0230-05 125 167 4/0 MCM 205 300 MCM 4 AWG 23 23, 31 (PE)
DCS800-EP2-0260-05 125 167 4/0 MCM 205 300 MCM 4 AWG 23 23, 31 (PE)
DCS800-EP1-0315-05 150 200 250 MCM 245 350 MCM 4 AWG 23 23, 31 (PE)
DCS800-EP2-0350-05 150 200 250 AWG 245 350 MCM 4 AWG 23 23, 31 (PE)
DCS800-EP1-0405-05 200 265 350 AWG 325 2 x 4/0 AWG 2 AWG
TBD TBD
DCS800-EP2-0450-05 200 265 350 AWG 325 2 x 4/0 AWG 2 AWG
DCS800-EP1-0470-05 250 330 2 x 4/0 AWG 405 2 x 250 AWG 2 AWG
DCS800-EP2-0520-05 250 330 2 x 4/0 AWG 405 2 x 250 AWG 2 AWG
DCS800-EP1-0610-05 300 392 2 x 250 AWG 480 2 x 350 AWG 2 AWG
DCS800-EP2-0680-05 300 392 2 x 250 AWG 480 2 x 350 AWG 2 AWG
DCS800-EP1-0740-05 400 522
TBD
640
TBD TBD
DCS800-EP2-0820-05 400 522 640
DCS800-EP1-0900-05 500 649 795
DCS800-EP2-1000-05 500 649 795
DCS800-EP2-1010-05 600 775 950
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

DCS800-EP Installation and Start-Up Manual 17
Electrical installation
What this chapter contains
This chapter describes the electrical installation procedure of the drive.
WARNING! The work described in this chapter may only be carried out by a
qualified electrician. Follow the Safety instructions on the first pages of this
manual. Ignoring the safety instructions can cause injury or death.
Make sure that the drive is disconnected from the mains (input power) during
installation. If the drive was already connected to the mains, wait for 5 min.
after disconnecting mains power.
Reference: Technical Guide - publ. no.: 3ADW000163
Checking the insulation of the assembly
Each drive is factory tested for insulation between the main circuit and the chassis
(2500 V rms 50 Hz for 1 second). DO NOT make any voltage tolerance or insulation
resistance tests (e.g. hi-pot or megger) on any part of the drive or drive damage will
occur. Check the insulation of the assembly as follows.
WARNING! Check the insulation before connecting the drive to the mains.
Make sure that the drive is disconnected from the mains (input power).
1. Check that the motor cable is disconnected from the drive output
terminals C1, D1, F+ and F-.
2. Measure the insulation resistances of the motor cable and the motor
between each circuit (C1, D1) or (F+, F-) and the Protective Earth by using
a measuring voltage of 1 kV DC. The insulation resistance must be higher
than 1 Mohm.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

18 DCS800-EP Installation and Start-Up Manual
IT (ungrounded) systems
Don’t use EMC filters.
The screen winding of dedicated transformers must be grounded.
For installation without low voltage switch (e.g. contactor, air-circuit-breaker) use
overvoltage protection.
The voltage shift of isolated supply must be limited of a range of an earth fault.
Check supply voltages
•AuxX99
• Fan Terminals
• AC voltage for armature circuit U1, V1, W1
Connecting the power cables
Grounding and screening of power cables see manual Technical Guide, see
Reference.
Cross sectional areas and tightening torques of power cable see chapter Planning
the electrical installation.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

DCS800-EP Installation and Start-Up Manual 19
Power/control connections
Typical location for input and output terminals.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

20 DCS800-EP Installation and Start-Up Manual
Electrical diagrams
The table below lists the correct electrical diagrams for each panel drive.
Non-Regenerative
(2Q) Regenerative (4Q) Frame HP Connection
Diagram
Pgs 21 - 22
Power
Diagram
Pgs 34 -
35
Control
Diagram
Pgs 36 -
37
DCS800-EP1-0020-05 DCS800-EP2-0025-05 A 10 CON-1 P1 C1
DCS800-EP1-0045-05 DCS800-EP2-0050-05 A 20 CON-1 P1 C1
DCS800-EP1-0065-05 DCS800-EP2-0075-05 A 30 CON-1 P1 C1
DCS800-EP1-0090-05 DCS800-EP2-0100-05 A 40 CON-1 P1 C1
DCS800-EP1-0125-05 DCS800-EP2-0140-05 A 60 CON-1 P1 C1
DCS800-EP1-0180-05 – B 75 CON-1 P1 C1
– DCS800-EP2-0200-05 B 100 CON-1 P1 C1
DCS800-EP1-0230-05 DCS800-EP2-0260-05 B 125 CON-1 P1 C1
DCS800-EP1-0315-05 DCS800-EP2-0350-05 B 150 CON-1 P1 C1
DCS800-EP1-0405-05 DCS800-EP2-0450-05 C 200 CON-1 P2 C1
DCS800-EP1-0470-05 DCS800-EP2-0520-05 C 250 CON-1 P2 C1
DCS800-EP1-0610-05 DCS800-EP2-0680-05 C 300 CON-1 P2 C1
DCS800-EP1-0740-05 DCS800-EP2-0820-05 D 400 CON-2 P3 C2
DCS800-EP1-0900-05 DCS800-EP2-1000-05 D 500 CON-2 P3 C2
– DCS800-EP2-1010-05 D 600 CON-2 P3 C2
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]
