ABB ACS 800 Series User manual

ACS800
Rittal TS 8 Cabinet Installation
ACS800-04 and ACS800-04M Drive Modules (45 to 560 kW)
ACS800-U4 Drives (60 to 600 HP)

ACS800 Single Drive Manuals
HARDWARE MANUALS (appropriate manual is included in the
delivery)
ACS800-01/U1 Hardware Manual 0.55 to 110 kW (0.75 to 150 HP)
3AFE64382101 (English)
ACS800-01/U1 Marine Supplement 3AFE64291275 (English)
ACS800-02/U2 Hardware Manual 90 to 500 kW (125 to 600 HP)
3AFE64567373 (English)
ACS800-11/U11 Hardware Manual 5.5 to110 kW (7.5 to 125 HP)
3AFE68367883 (English)
ACS800-04 Hardware Manual 0.55 to 132 kW
3AFE68372984 (English)
ACS800-04/04M/U4 Hardware Manual 45 to 560 kW (60 to
600 HP) 3AFE64671006 (English)
ACS800-04/04M/U4 Cabinet Installation 45 to 560 kW (60 to
600 HP) 3AFE68360323 (English)
ACS800-07/U7 Hardware Manual 45 to 560 kW (50 to 600 HP)
3AFE64702165 (English)
ACS800-07/U7 Dimensional Drawings 45 to 560 kW (50 to
600 HP) 3AFE64775421
ACS800-07 Hardware Manual 500 to 2800 kW
3AFE64731165 (English)
ACS800-17 Hardware Manual 75 to 1120 kW
3AFE64681338 (English)
• Safety instructions
• Electrical installation planning
• Mechanical and electrical installation
• Motor control and I/O board (RMIO)
• Maintenance
• Technical data
• Dimensional drawings
• Resistor braking
FIRMWARE MANUALS, SUPPLEMENTS AND GUIDES
(appropriate documents are included in the delivery)
Standard Application Program Firmware Manual
3AFE64527592 (English)
System Application Program Firmware Manual
3AFE63700177 (English)
Application Program Template Firmware Manual
3AFE64616340 (English)
Master/Follower 3AFE64590430 (English)
PFC Application Program Firmware Manual
3AFE64649337 (English)
Extruder Control Program Supplement 3AFE64648543 (English)
Centrifuge Control Program Supplement 3AFE64667246 (English)
Traverse Control Program Supplement 3AFE64618334 (English)
Crane Control Program Firmware Manual 3BSE11179 (English)
Adaptive Programming Application Guide
3AFE64527274 (English)
OPTION MANUALS (delivered with optional equipment)
Fieldbus Adapters, I/O Extension Modules etc.

ACS800-04 and ACS800-04M Drive Modules
45 to 560 kW
ACS800-U4 Drive Modules
60 to 600 HP
Rittal TS 8 Cabinet Installation
3AFE68372330 Rev A EN
EFFECTIVE: 1.2.2005
2005 ABB Oy. All Rights Reserved.

Table of contents
5
Table of contents
ACS800 Single Drive Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Table of contents
About this manual
What this chapter contains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Target audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
What this manual contains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Other related manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Component lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Categorization according to the frame size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Take care of sufficient cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Drive module of frame size R7 with bottom exit
What this chapter contains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Rittal parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
ACS800-04M parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Additional parts to be provided by the installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Moving, unpacking and assembling the drive module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Layout of the installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Installation steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Cable lead-through plates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Fastening of the back mounting plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Fastening of the RDCU Drive Control Unit to the side mounting plate . . . . . . . . . . . . . . . . . . . 22
Drive module of frame size R7 with bottom exit and Rittal cooling unit
What this chapter contains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Required Rittal parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
ACS800-04M parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Additional parts to be provided by the installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Moving, unpacking and assembling the drive module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
View of the installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Layout of the installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cooling air flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Installation steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Drive module of frame size R8 and Rittal cooling unit
Layout example with cooling unit on the side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Layout example with cooling unit on the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Table of contents
6
Drive module of frame size R8
What this chapter contains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Required Rittal parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
ACS800-04M parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Additional parts to be provided by the installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Moving, unpacking and assembling the drive module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Layout of the installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Installation steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
View of base plates and cable lead-throughs fastened . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Fastening of the punched sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Fastening the drive pedestal to the enclosure frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Fastening of the back mounting plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Dimensional drawings
What this chapter contains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Frame size R7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Frame size R8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Air baffles for the enclosure with drive module of frame size R7 and Rittal cooling unit . . . . . . . . 46
Air baffle at the right-hand side of the drive module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
EMC screen for the enclosure with drive module of frame size R7 . . . . . . . . . . . . . . . . . . . . . . . . 49
EMC screen mesh for the enclosure with drive module of frame size R7 and Rittal cooling unit . 50

About this manual
7
About this manual
What this chapter contains
This chapter describes the intended audience and contents of the manual and refer
to other related manuals.
Target audience
The manual is intended for people who plan the installation and install the drive
module into a Rittal TS 8 cabinet. Read the manual before working on the drive
module. The reader is expected to know the fundamentals of electricity, wiring,
electrical components and electrical schematic symbols.
The manual is written for readers worldwide. Both SI and imperial units are shown.
Safety
WARNING! Follow the safety instructions given in ACS800-04/04M/U4 Hardware
Manual [3AFE64671006 (English)] when installing, operating and servicing the drive.
If ignored, physical injury or death may follow, or damage may occur to the drive,
motor or driven equipment. Read the safety instructions before you work on the unit.
What this manual contains
The manual shows a few installation examples on how to install the drive module
into a Rittal TS 8 cabinet.
The chapters of this manual are briefly described below.
About this manual introduces the manual.
Drive module of frame size R7 with bottom exit describes the installation of a drive
module of frame size R7 in an 800 mm × 2000 mm × 600 mm enclosure.
Drive module of frame size R7 with bottom exit and Rittal cooling unit describes the
installation of a drive module of frame size R7 in an 800 mm × 2000 mm × 600 mm
enclosure when the enclosure is cooled with a cooling unit.
Drive module of frame size R8 and Rittal cooling unit describes how to install a drive
module of frame size R8 into a 600 mm deep enclosure when the enclosure is
cooled with a cooling unit.

About this manual
8
Drive module of frame size R8 describes the installation of a drive module of frame
size R8 in an 800 mm × 2000 mm × 600 mm enclosure.
Dimensional drawings contains the dimensional drawings of the fastening points in
the drive modules used in the installation examples in this manual, and dimensional
drawings of air baffles and EMC screens.
Other related manuals
Refer to ACS800-04/04M/U4 Cabinet Installation [3AFE68360323 (English)] for
information concerning the drive module such as
• dimensional drawings
• assembling instructions
• general instructions on installing the drive module into a cabinet.
Refer to ACS800-04/04M/U4 Hardware Manual [3AFE64671006 (English)] for
information concerning the drive module such as
•safety
• moving and unpacking
• specifications of the drive, e.g. the ratings, sizes and technical requirements,
provisions for fulfilling the requirements for CE and other markings, warranty
policy etc.
For installation of ACS800-04M components, refer to their manuals:
•ARFI-10 EMC Filter Installation Guide [3AFE68317941 (English)
•RDCU Drive Control Unit Hardware Manual [3AFE64636324 (English)]
•RPMP-11/13 Control Panel Mounting Platform Kit Installation Guide
[3AFE68400643 (English)].
The manuals can be viewed on the Internet: www.abb.com under Motors, drives
and power electronics / Drives / Document library.
Component lists
ACS800-04M and Rittal parts used in the installation examples are listed in the
manual. A list of other components, such as the contactor, switch fuse etc., is
included in Modules Engineering Tool on www.abb.com under Motors, drives and
power electronics / Low Voltage AC Drives / Drives / Industrial drives,
modules.

About this manual
9
Categorization according to the frame size
The instructions, technical data and dimensional drawings which concern only
certain frame sizes are marked with the symbol of the frame size R7 or R8. The
frame size is not marked on the drive designation label. To identify the frame size of
your drive, see the rating tables in ACS800-04/04M/U4 Hardware Manual
[3AFE64671006 (English)] in chapter Technical data.
Take care of sufficient cooling
The installation examples described in this manual have been tested for sufficient
cooling. When installing the drive module in another position (e.g. by the longer side,
or in a horizontal position), ensure that the cooling air gratings at the front panel of
the module will not be covered and the required cooling air flow is achieved.
For evaluating cooling, refer to Rittal Therm calculation program for climate control
of enclosures under www.rittal.com.
Liability
The installation examples in this manual are provided to help the installer in
designing his/her installation.
Note: The installation must always be designed and made according to applicable
local laws and regulations. ABB does not assume any liability whatsoever for any
installation which breaches the local laws and/or other regulations.

About this manual
10

Drive module of frame size R7 with bottom exit
11
Drive module of frame size R7 with bottom exit
What this chapter contains
This chapter describes the installation of a drive module of frame size R7 with
bottom exit into a 600 mm deep, 800 mm wide and 2000 mm high Rittal TS 8
enclosure. The installation is designed to comply with the limits of IEC/EN 61800-3
for immunity and emissions of electrical equipment in first environment (includes
establishments connected to a low-voltage network which supplies buildings used
for domestic purposes). This requires EMC screen and EMC cable lead-throughs,
which are otherwise not necessarily needed. The installer is responsible for the
verification. The degree of protection of the installaton is IP20.
Rittal parts
This table lists the Rittal parts used in the installation.
*for first environment EMC installations. In other installations SK 3326.200 air filter 323 mm for
292 mm × 292 mm door ventilation holes can be used.
For photos and specifications of the parts, refer to www.rittal.com.
ACS800-04M parts
The following ACS800-04M parts are used in the installation:
• drive module of type ACS800-04M-xxxx+B060+E202+H352+J400+J410. For
descriptions of the plus codes, refer to ACS800-04/04M/U4 Cabinet Installation
[3AFE68360323 (English)], chapter The ACS800-04/U4 and ACS800-04M: Type
code.
Rittal model no. Description Qty
(pcs)
TS 8806.500 Enclosure with mounting plate, width × height × depth: 800 mm × 2000 mm × 600 mm 1
TS 8106.235 Side panel for 2000 mm × 600 mm 2
TS 8612.160 Punched section with mounting flange, outer mounting level for 600 mm horizontal 2
TS 8614.240 Mounting plate 1100 mm × 300 mm 1
DK 7092.000 C-rail 390 mm 1
DK 7097.000 C-rail cable clamp for cable diameters of 18 to 22 mm 4
DK 7098.000 C-rail cable clamp for cable diameters of 38 to 42 mm 6
DK 7828.060 C-rail 600 mm 2
DK 7967.000 50 mm spacer for roof plate 4
PS 4944.000 Support rail 555 mm 1
SK 3326.267 * EMC compatible air filter 323 mm for 292 mm × 292 mm door ventilation holes 3
SK 3326.607 EMC compatible fan-and-air-filter unit 700/720 m3/h, 230 V, 50/60 Hz 1
SV 3568.000 Laminated copper bar Flexibar S. Dimensions: 15.5 mm × 4.8 mm, 2000 mm long 3

Drive module of frame size R7 with bottom exit
12
• EMC kit 64331116 containing two power cable lead-throughs with EMC sleeves
and rubber grommets, one control cable lead-through and gasket strip for EMC
shielding of the enclosure door. See also page 20.
Additional parts to be provided by the installer
The following parts, in addition to the Rittal and ACS800-04M parts listed above, are
needed in the installation:
• air baffle, see page 17.
• EMC screen, see page 16.
• 800 mm × 600 mm piece of wire mesh with max. 10 mm mesh size for fulfilling
IP20 degree of protection of the enclosure. The mesh is placed on the top of the
enclosure frame under the 50 mm spacers on which the enclosure roof lies. See
page 18.
• PE busbar of dimensions 70 mm × 50 mm × 10 mm, copper
• contactor (optional)
• auxiliary voltage transformer when a contactor is installed
• supply disconnecting device and input cable fuses. See ACS800-04/04M/U4
Hardware Manual [3AFE64671006 (English)], chapters Planning the electrical
installation and Technical data.
• terminal for grounding the control cable shields and self-adhesive strain reliefs to
be mounted next to the RDCU Drive Control Unit. See page 22
• shroud over the input cable terminal connections and output connections of the
disconnecting device.
Moving, unpacking and assembling the drive module
Follow the instructions given in ACS800-04/04M/U4 Cabinet Installation
[3AFE68360323 (English)]. Fasten the bottom exit kit (+H352) to the drive module
before beginning to install the drive module into the enclosure.
EMC power cable lead-
throughs
EMC control cable
lead-through
EMC gasket strip

Drive module of frame size R7 with bottom exit
13
Layout of the installation
This photo shows the final installation with component placing dimensions in
millimetres and (inches).
Base plate
570 (22.44)
837 (32.95)
910 (35.83)
1080 (42.52)
1420 (55.91)
220 (8.66)
320 (12.60)
455 (17.91)
1520 (59.84) to the fastening points
The drive module is placed 30 mm (1.18 in.) from
the right-hand side panel. Fastening point distances
from the bottom of the back mounting plate are
shown. The distance of the back mounting plate
from the base plate of the enclosure is 50 mm
(1.97 in.)
Contactor
EMC filter *
RDCU
Switch fuse
635 (25.00)
970 (38.19)
EMC compatible*
air filter
SK 3326.267
Cutting in the door:
292 × 292
(11.50 × 11.50)
430
95 (3.74)
from the
door edge
1387 (54.61)
235(9.25)
(16.93)
Note: A mirrored layout is advantageous for
servicing the drive module.
EMC screen *
Air baffle
Cutting in the door:
115 × 240
(4.53 × 9.45)
PE
C-rail 600 mm
Side mounting plate
TS 8614.240
1100 mm × 300 mm
Punched section
TS 8612.160
(600 mm)
Punched section
TS 8612.160
* required in first environment installations only
Support rail PS 4944.000
C-rail 390 mm
C-rail 600 mm
user’s cabling
EMC compatible*
fan-and-air-filter unit
SK 3326.607
Auxiliary voltage
transformer
Gasket strip
64331116

Drive module of frame size R7 with bottom exit
14
Installation steps
Step Instruction Photo
1 Fasten the base plates and lead-
through plates to the enclosure
frame. See also section Cable
lead-through plates on page 20.
2 Fasten the punched sections for
the side mounting plate fastening
to the vertical profiles of the
enclosure frame.
3 Fasten the devices to the side
mounting plate. See also section
Fastening of the RDCU Drive
Control Unit to the side mounting
plate on page 22.
4 Fasten the side mounting plate to
the punched sections.
5 Fasten the devices, and the drive
module if a lifting device is
available, to the back mounting
plate. See ARFI-10 EMC Filter
Installation Guide
[3AFE68317941 (English).
6 Connect the switch fuse to the
EMC filter, and the EMC filter to
the contactor with laminated
copper bars. Connect laminated
copper bars to the output of the
contactor.
7 Fasten the back mounting plate
to the enclosure frame 70 mm
from the back vertical profile. In
this location, the drive module will
face the enclosure door thus
allowing no hot air recirculation
into the drive module ventilation
grating from the inside of the
enclosure. See also Fastening of
the back mounting plate on page
21.
8 Fasten the drive module to the
back mounting plate if not
fastened already.
Side mounting plate
TS 8614.240
1100 mm × 300 mm
Punched section TS 8612.160
Punched section TS 8612.160
1025 (40.35)
C-rail 600 mm
Motor cable lead-throughs
Control cable lead-through
Input cable lead-throughs
Back mounting
plate (included in
the TS 8806.500
enclosure)
Base plates (included in the
TS 8806.500 enclosure)
820 (32.28)
1
3
4
1
1
1
2
BACK
2
FRONT
Left side view of the installation without side panel and EMC screen
5
5
5
5
6
6
7

Drive module of frame size R7 with bottom exit
15
9 Assemble the top entry clear plastic busbar shroud.
10 Connect the laminated copper bars to the input terminals of the drive module.
11 Fasten the top entry clear plastic busbar shroud to the drive module.
Step Instruction Photo
Remove the
protective film.
Step drill lead-throughs for the
busbars.
9a
9b
Press the top cover on
the sides inwards to
enable its tabs to enter
the slots in the lower
part of the shroud.
Top entry busbar shroud installed
Pass the laminated copper bars through the lead-
throughs and the lower part of the shroud
9c
9d
9d
10
11
11
11
11
11 11

Drive module of frame size R7 with bottom exit
16
12 Fasten the EMC screen and clear plastic shroud to the drive module.
Step Instruction Photo
Clear plastic shroud
(included in ACS800-04M bottom exit
shroud kit +B060)
252 (9.92)
215 (8.46)
470 (18.50)
Note: Remove the protective film from
the shroud surfaces.
If the EMC screen is not used, protect
the output terminals against contact at
the left-hand side also with the clear
plastic shroud.
EMC screen
See the
dimensional
drawing on page
49.

Drive module of frame size R7 with bottom exit
17
13 Fasten the air baffle to the fastening points of the drive module and to the support rail with screws.
14 Fasten the back panel of the enclosure.
15 Fasten the side panels of the enclosure.
Step Instruction Photo
Cutting
for door
wires and
top front
bar
Cutting for
laminated
copper
bars
The air baffle is needed for preventing
hot air from entering the cool area of the
cabinet.
Cooling air flow into
the drive module
Cooling air flow
(side view)
Air baffle
68484871 A

Drive module of frame size R7 with bottom exit
18
16 Fasten the roof plate:
1. Cut an opening to the roof
wire mesh for the upper edge
of the air baffle. Place the
mesh on the top of the
enclosure frame.
2. Fasten the enclosure roof
plate above the mesh with four
50 mm spacers at the corners.
17 Fasten the door devices. See RPMP-11/13 Control Panel Mounting Platform Kit Installation Guide [3AFE68400643
(English)].
Install the ventilation gratings on the door:
1. Cover the edges of the cuttings with copper tape.
2. Fasten the metal gratings (2a) and the EMC compatible fan-and-air-filter unit (2b).
3. Place the metal mesh between the lower grating and the outer louvred grating.
4. Push the louvred grating onto its place.
18 Fasten the EMC gasket strip to the door as shown on page 13.
Step Instruction Photo
1
2
1
3
4
Cutting
View of the EMC compatible
fan-and-air-filter unit on the
back side of the door
2a
2b
2a
2a

Drive module of frame size R7 with bottom exit
19
19 Install the C-rails and clamps for
cable strain relief.
20 Fasten the PE busbar.
The PE busbar is provided for
grounding of the input cable
shield and the motor cable shield
if the PE terminal of the drive
module is not used.
21 Fasten shrouds over all live parts.
Step Instruction Photo
PEbusbar

Drive module of frame size R7 with bottom exit
20
Cable lead-through plates
EMC kit 64331116 contains the lead-throughs without the strain relief plates shown
below.
EMC sleeve
Lead-through plate
Strip this part
of the cable
Cable shield
Base plate
PE terminal
Grommet
Installing the power cables
Entries for power cables (conductive sleeves inside
the grommets). Cut an adequate hole to the rubber
grommet. Lead the cable through the grommet and the
conductive sleeve as shown below.
In first environment installations, 360 degrees
grounding must be applied to motor cables and is also
recommended for input cables.
Recommended entry for control
cables in first environment
installations (360 degrees grounding
between the conductive cushions)
Note: Control cable lead-throughs
with rubber grommets only may also
be possible.
Grommet
EMI conductive
Lead-through
cushion
plate
Strain
relief
