ABB CHARGING STATION
Operation and installation manual
Terra 360 Series 2 - CE
Terra 60 - CE

2"Operation and installation manual" - "Terra 360 Series 2 - CE"
EN
ATTENTION – IMPORTANT SAFETY INSTRUCTIONS
This manual contains important safety instructions that must be followed during the installation
and maintenance of the equipment.
ATTENTION – SAVE THESE INSTRUCTIONS
This document is a part of the equipment, keep it in a safe place near the equipment for easy
reference during installation, operation and maintenance.
Copyright
©Copiright ABB E-mobility. All rights reserved
Data and images are not binding. Depending on technical development and the products, we reserve the right
to modify the content of this document without notice.
We reserve all rights in this document and in the subject matter and illustrations contained therein. Any
reproduction, disclosure to third parties or utilization of its contents – in whole or in parts – is forbidden
without prior written consent of ABB E-mobility.
Manufacturer and contact data
Manufacturer name and address Contact
ABB E-mobility,
Heertjeslaan 6
2629 JG Delft
The Netherlands
ABB E-mobility in your country can give you support on the EVSE.
The latest version of this document is available on the website:
https://new.abb.com/ev-charging

3
EN
Table of contents
1. Introduction and general information
1.1 Disclaimer and warranty conditions 5
1.2 Function and target of this document 5
1.3 Language 6
1.4 How to use this document 6
1.5 Abbreviations 6
1.6 Terminology 7
1.7 Document revision history 7
2. Safety
2.1 Liability 8
2.1.1 Responsibilities and qualifications for the Users 9
2.2 Intended use 9
2.2.1 Risks related to improper use or product defect 10
2.2.2 Residual risks 10
2.3 General signs and signal words 11
2.4 Personal protective equipment 12
2.5 Safety instructions 12
2.5.1 Safety instructions during transport 13
2.5.2 Safety instructions during installation 13
2.5.3 Safety instructions during cleaning or maintenance 13
2.5.4 Safety instructions during the use 13
2.6 Discard the EVSE or parts of the EVSE 14
2.7 Cyber security 14
2.8 Conformity 14
3. Description
3.1 Orientation agreements 16
3.2 Type plate - Identification of equipment 17
3.2.1 EVSE identification code 18
3.3 Terra 60 Overview 19
3.3.1 Overview outside - Terra 60 19
3.3.2 Overview inside - Terra 60 20
3.3.3 Overview air openings and filters - Terra 60 21
3.4 Terra 360 Overview 22
3.4.1 Overview outside - Terra 360 22
3.4.2 Overview inside - Terra 360 23
3.4.3 Overview air openings and filters - Terra 360 24
3.5 System Overview 25
3.6 RFID - Authorization to charge 25
3.7 Payment terminal 25
3.8 Cloud service portal 25
3.9 Description of the touchscreen 26
3.10 EVSE LEDs 27
3.11 Working principles 28
3.11.1 Block diagram - Terra 60 28
3.11.2 Block diagram - Terra 360 (simple power distribution) 29
3.12 Power allocation strategies 30
3.12.1 Sequential mode 30
3.12.2 Concurrent mode 30
3.12.3 Share mode 31
3.13 Internet access 31
3.13.1 Internet via cellular network connection 31
3.13.2 Internet via ethernet connection 31
3.14 Options 32
3.14.1 Fiscal metering system 32
3.14.2 Tilt sensors 32
4. Transport, handling and unpacking
4.1 Transport of the EVSE - Preliminary operation 33
4.1.1 Hoist the packaged EVSE 34
4.1.2 Move the packaged EVSE with a forklift truck 35
4.2 Unpacking 36
4.2.1 Unpacking procedure 36
4.2.2 Components supplied with the EVSE 37
5. Access to the internal parts
5.1 Open the doors - Terra 60 38
5.1.1 Open the front door - Terra 60 38
5.1.2 Open the rear door - Terra 60 39
5.1.3 Open the sides doors - Terra 60 40
5.2 Close the doors - Terra 60 40
5.3 Internal covers on the AC section - Terra 60 40
5.4 Open the doors - Terra 360 41
5.4.1 Open the front door - Terra 360 41
5.4.2 Open the rear door - Terra 360 41
5.4.3 Open the upper sides doors - Terra 360 42
5.4.4 Open the lower sides doors - Terra 360 42
5.5 Close the doors - Terra 360 43
5.6 Internal covers on the AC section - Terra 360 43

4“Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
6. Installation
6.1 Installation of the EVSE - Terra 60 44
6.1.1 Floor space requirements - Terra 60 44
6.1.2 Prepare the foundation - Terra 60 45
6.1.3 Remove the base cover - Terra 60 46
6.1.4 Open the cable glands - Terra 60 46
6.1.5 Route the cables - Terra 60 46
6.1.6 Install the base - Terra 60 47
6.1.7 AC cables preparation - Terra 60 47
6.1.8 Install the base cover - Terra 60 47
6.1.9 Install the EVSE on the base - Terra 60 48
6.2 Installation of the EVSE - Terra 360 Series 2 50
6.2.1 Floor space requirements - Terra 360 50
6.2.2 Prepare the foundation - Terra 360 50
6.2.3 Assembly the base - Terra 360 51
6.2.4 Remove the base covers - Terra 360 51
6.2.5 Open the AC input cable inlets - Terra 360 52
6.2.6 Open the cable glands - Terra 360 52
6.2.7 Route the cables - Terra 360 52
6.2.8 Install the base - Terra 360 53
6.2.9 AC cables preparation - Terra 360 53
6.2.10 Install the base covers - Terra 360 54
6.2.11 Install the EVSE on the base - Terra 360 54
7. Electrical connection
7.1 Protective earth (PE) 56
7.1.1 Connect the PE wire 57
7.2 AC input 57
7.2.1 Supported low voltage network types 57
7.2.2 External AC input protections 59
7.2.3 Connect the AC wires - Terra 60 60
7.2.4 Connect and seal the AC wires - Terra 360 60
7.3 Ethernet 61
7.3.1 Connect the ethernet cable - Terra 60 61
7.4 Tilt sensor (optional) 62
7.4.1 Connect the tilt sensor 63
8. Operation and correct use
8.1 Prepare for commissioning 64
8.2 Prepare before use 65
8.3 Charge session 65
8.3.1 Charge an EV 65
8.3.2 Stop a charge session 66
9. Maintenance and troubleshooting
9.1 Maintenance schedule for the owner 67
9.2 Troubleshooting 68
10. Technical data
10.1 Technical data 69
10.1.1 Technical data table - Terra 60 69
10.1.2 Technical data table - Terra 360 71
10.2 Cable specifications 73
10.3 Torque specification 73
10.4 Charging interface 74
10.5 Output current Vs output voltage curve 75
10.5.1 Output current Vs output voltage - Terra 60 75
10.5.2 Output current (peak) Vs output voltage - Terra 360 75
10.6 Output power Vs output voltage curve 76
10.6.1 Output power Vs output voltage - Terra 60 76
10.6.2 Output power (peak) Vs output voltage - Terra 360 76
10.7 Height of user operable elements 77
11. Attachments
11.1 Footprint - Terra 60 79
11.2 Footprint - Terra 360 80
11.3 Prefabricated foundation - Terra 60 81
11.4 Prefabricated foundation - Terra 360 82
11.5 Messrichtigkeitshinweise gemäß
Baumusterprüfbescheinigung 83

5Introduction and general information
EN
1. Introduction and general information
This chapter will give instruction on the correct use of this document.
Chapter recipients:
• Owner
• Qualified installer
• User
1.1 Disclaimer and warranty conditions
ABB E-mobility shall not be liable for any damages, losses, costs or expenses resulting from the improper
handling of the EVSE, in particular resulting from non compliance with the instructions of this document and
other applicable regulations and standards (e.g. installation, transport, occupational health and other safety
standards).
The warranty Terms and Conditions are considered to be valid if all indications in this manual are adhered to.
ATTENTION
If the equipment is used in a manner not specified in this manual (any condition deviating from
those described herein must be expressly agreed with the manufacturer), the protections and
the certifications provided by the equipment may be impaired with the consequent loss of
warranty.
ATTENTION
Any modification, manipulation, or alteration not expressly agreed with the manufacturer,
concerning either hardware or software, shall result in the immediate cancellation of the
warranty.
1.2 Function and target of this document
The purpose of this document is to gives the information that are necessary to safely do these tasks:
• Install the EVSE
• Operate the EVSE
• Perform basic maintenance tasks
NOTE
This manual covers the EVSE only and NO other equipment (external protection devices,
electrical vehicles, etc) to which it is connected.
Some component’s information given in this manual is taken from the original supplier
documents. Please refer to the supplier websites for the complete and updated documentation.

6“Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
The document is applicable to these EVSE (Including all variants and options):
• Terra 360 - Series 2
• Terra 60 - Series 1
NOTE
“Terra xx0” is a generic name for the EVSE models to address the main types of the EVSE.
1.3 Language
The original instructions of this document are in English (EN-US). All other language versions are translations
of the original instructions and the manufacturer cannot be held liable for errors in the translation. Refer to
the original English version In case of doubts.
1.4 How to use this document
Make sure that you know the structure and contents of this document.
Read the safety chapter and make sure that you know all the instructions.
Do the steps in the procedures fully and in the correct sequence.
The document is intended for these groups:
• Owner of the EVSE
• Qualified installer of the EVSE
1.5 Abbreviations
Abbreviation / Termin Description
AC Alternating current
CAN Controller area network
CCS Combined Charging System, a standard charging method for electric vehicles
CHAdeMO Abbreviation of CHArge de MOve, a standard charging method for electric
vehicles
CPU Central processing unit
DC Direct current
EMC Electromagnetic compatibility
EV Electric vehicle
EVSE Electric vehicle supply equipment
HMI Human Machine Interface
HVC Heavy Vehicle Charger
MCB Miniature circuit breaker
MID Measuring Instruments Directive
NFC Near field communication
OCPP Open charge point protocol
PE Protective earth
PPE Personal protective equipment
RCD Residual current device
RFID Radio-frequency identification
SPD Surge protective devices

7Introduction and general information
EN
1.6 Terminology
Terminology Description
Network operating center
of ABB EV Infrastructure
Facility of the manufacturer to do a remote check on the correct operation of
the EVSE
Cabinet Enclosure of the EVSE, including the components on the inside
Power cabinet Intermediate unit that provides DC power to the Charge control set. Gets its
power from a power distribution board.
Interlock The Interlock is an isolated current loop and is a feature that makes the state
of two mechanisms or functions mutually dependent.
Cable slack Extra length of cable from the top of the foundation so that the cable length
is sufficient to connect to the correct terminal in the EVSE
Grid provider Company that is responsible for the transport and distribution of electricity
Local rules All rules that apply to the EVSE during the entire lifecycle of the EVSE. The
local rules also include the national laws and regulations
Open charge point
protocol Open standard for communication with charge stations
Protective devices
Devices for the personal protection of individuals against the risk of injury or
electrcial shock when they do commissioning, operation and maintenance
activities. Examples of protective devices are a door, the electrical parts
covers, the latches, etc.
Site operator Entity that is responsible for the day-to-day control of the EVSE. The site
operator does not have to be the owner
Qualified installer
The installer is a qualified person to install the EVSE according to the
applicable local rules and fully knows the EVSE and its safe installation.
The qualified installer obeys all local rules and the instructions in the
operation and installation manual.
Owner Legal owner of the EVSE
User Owner of an EV, who uses the EVSE to charge the EV
NOTE
it is possible that not all terms are present in this document.
1.7 Document revision history
Version Date Description
001 July 2022 Initial version
002 December 2022 Update of texts
003 February 2023 Update of Terra 360 base
004 July 2023 New manual layout
005 September 2023 Par. 11.3
Storage conditions

8“Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
2. Safety
This chapter contains the safety instructions which must obey during installation, commissioning, operation
and maintenance of the equipment. Always obey and follow the reading order of instruction exactly as
described in this manual to prevent injury or damage to the equipment.
The manufacturer accepts no liability for failure to comply with the instructions for a correct installation and
cannot be held responsible for any other upstream or downstream equipments.
The instructions provided in the manual do not replace:
• the safety devices
• the technical and operative data labels on the product
• the safety regulations in force in the country of installation
NOTE
The operators must read and comply with the technical information and instruction provided in
the manual and in any additional attached documentation.
Chapter recipients:
• Owner
• Qualified installer
• User
2.1 Liability
The manufacturer declares that the equipment complies with the regulations currently in force in the country
of installation and has issued the corresponding declaration of conformity.
The manufacturer is not liable for damages, losses, costs or expenses incurred by any user of the EVSE (e.g.
the installation engineer or owner of the equipment) if such damages, losses, costs or expenses result from a
failure to comply with the applicable safety instructions given by the manufacturer, including, but not limited
to, the following:
• Comply with the local rules and the instructions in this manual. If the local rules contradict the instructions
in this manual, the local rules must be applied.
• Power outages or disruptions to the electrical supply to the equipment.
• Accumulation of dirt or ingress of foreign substances within the equipment.
• Corrosion of component parts.
• Damage to software or hardware due to any IT security problem, such as but not limited to a virus breakout
or malicious hacking of the system.
• Damage or failure of equipment caused by vermin, insect infestations or the like.
• Damage or failure resulting from faults in some other equipment connected to the EVSE.
• Damage or loss caused by hazards such as fire, flood, storm or the like or spillage or leakage of chemicals or
harmful substances onto the equipment.
• Fault tracing caused by problems from a source external to the scope of work.

9Safety
EN
• Unprofessional or incorrect installation, installation not complying to standards, or installation
not following the installation instructions contained in the product specific manual.
• Improper operation (in breach of the technical requirements or specifications or manuals of the product),
negligence or repairs carried out by the Owner (or any third party not authorized by the manufacturer).
It is absolutely forbidden to modify the equipment.
• Non-compliance with the applicable safety regulations or other legal standards by other parties than the
manufacturer.
• Insufficient ventilation of the equipment.
• Operation of the equipment outside of its design conditions.
• Damage or failure due to relocations or alterations of the equipment from the original installation location
or alteration of the overall normal condition of the system.
• Only make changes to the equipment if the manufacturer approves in writing of the changes.
• Damage or loss due to improper use of the equipment.
• EV low battery during use.
• Any check to make sure the battery is sufficiently recharged before using the EV.
• Deterioration resulting from transportation or particular environmental conditions;
• Performing maintenance incorrectly or not at all;
• The manufacturer is not responsible for disposal of the equipment, or part of it, which does not take place
on the basis of the regulations and laws in force in the country of installation.
2.1.1 Responsibilities and qualifications for the Users
Operators responsible of installation, operation, maintenance and service must:
• To know and implement the applicable laws and rules.
• To identify the hazards and do a risk assessment prior to commercing work that result from the working
conditions on the site.
• To operate the equipment with the protective devices installed and make sure that all protective devices are
re-installed after any installation or maintenance operation.
• To make an emergency plan that instructs people what to do in the event of an emergency relating to the
equipment or to another site emergency.
• To make sure that all employees, the owner and third parties are qualified according to the applicable local
laws and/or rules to do the work.
• To make sure that there is sufficient space around the equipment to safely do maintenance and installation
activities.
• To identify a site operator who is responsible for the safe operation of the equipment and for the coordination
of all work, if the owner does not do these tasks.
Moreover the qualified installer must:
• Fully knows the EVSE and its safe installation.
• Be qualified according to the applicable local rules to do the work.
• Obeys all local rules and the instructions in the installation procedures in this document.
2.2 Intended use
This equipment has the exclusive function of fast EV charging and it is intended to be used both in indoor and
outdoor environments.
DANGER
The manufacterer isn’t liable for any risk and damage related to its different use. Use the
equipment only for its intended use and do not change or alter the system under any
circumstances. If you use the EVSE in any other way than described in the related documents,
you can cause death, injury and damage.
Only use it in its original condition and with its proper aim.
NOTE
The equipment can be only connected to the electricity grid in countries for which it has been
certified.
The equipment may only be used in compliance with all its technical characteristics.
Only use the EVSE with accessories that the manufacturer provides and that obey the local rules.
NOTE
- DC fast charge: no additional cables are required.
- AC charge: the cable owned by the user must be used.

10 “Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
2.2.1 Risks related to improper use or product defect
Any improper use of the device is forbidden, even for common other arrangement related to the final scope
and function.
To avoid any serious consequence on personal safety, please contact the service of the manufacturer in case
of need of further warnings concerning the ways in which the equipment must not be used and which could
occur.
In the event of residual risks which persist, despite the protection and safety measures integrated in the
machine and the complementary measures adopted, contact the service of the manufacturer immediately.
Do not proceed with installation if the integrity of the equipment is compromised.
Do not use the equipment if you find any operating anomalies.
To avoid risk related to improper use of the product, it is forbbiden:
• To install the equipment in environments subject to particular conditions of flammability or in adverse or
disallowed environmental conditions, (temperature and humidity).
• To use the equipment with safety devices which are faulty or disabled.
• To use the equipment or parts of the equipment by linking it to other machines or equipment, unless
expressly provided for.
• To modify operating parameters that are not accessible to the operator and/or parts of the equipment to
vary its performance or change its isolation.
• To clean with corrosive products that could corrode parts of the equipment or generate electrostatic
charges.
• To place any heavy object, sit or stand up on the device.
2.2.2 Residual risks
Despite the warnings and safety systems, there are still some residual risks that cannot be eliminated.These
risks are listed in the following table with some suggestions to prevent them:
Risk analysis and description Suggested action
Noise pollution due to installation in unsuitable
environments or where individuals routinely work
and/or animals dwell most of the time.
Reassess the environment or the place of
installation.
Adverse external climatic conditions, accumulations
of rainwater, low temperatures, high humidity, etc. Maintain ambient conditions suitable for the system.
Overheating of components (transformers,
accumulators, coils, etc.) which could cause burns.
Clogged equipment cooling slots or systems.
Use suitable PPE. Wait for the parts to cool down
before opening the equipment.
Do not block cooling vents or heat sinks.
Inadequate cleaning that:
- does not allow adequate air intake for cooling
- does not allows the reading of safety labels.
Clean the equipment, labels and installation
environment.
Stored energy in components that could generate
hazardous discharges.
Ensure that the components have discharged their
energy before working on them.
The EVSE contains components and circuit boards
that are sensitive to electrostatic discharge.
Take ESD prevention measures to protect the
electronic components during installation and
maintenance of the EVSE.
Inadequate training of staff. Ask for supplementary courses.
Incomplete installation, equipment or its
components temporarily mounted.
Prevent unauthorized access to the installation area.
Use a sufficient number employees and PPE.
No cable extensions, adapters, Y-cables or similar
may be used unless explicitly stated by the vehicle
manufacturer.
Manufacturer and national guidelines and
regulations about charging stations must be taken
into account.
The AC cable, owned by the user, could be damaged Check the integrity of the cable and connectors
before connecting the cable to the EVSE.
Not allowed to place in ATEX environment. Reassess the environment or the place of
installation.

11Safety
EN
2.3 General signs and signal words
In the manual and/or in some cases on the equipment, the danger or hazard zones/components are indicated
with signs, labels, symbols or icons.
Symbol Description
General risk
With signal word ‘Danger’: If you do not obey the instruction, this can cause injury or death
With signal word ‘Warning’: If you do not obey the instruction, this can cause injury
With signal word ‘Caution’: If you do not obey the instruction, this can cause damage to the EVSE
or to property
Hazardous voltage that gives risk of electrocution
Risk of pinching or crushing of body parts
Rotating parts that can cause a risk of entrapment
Hot surface that gives risk of burn injuries
With signal word ‘Note’: A note gives more data, to make it easier to do the steps, for example
Information about the condition of the EVSE before you start the procedure
Requirements for personnel for a procedure
General safety instructions for a procedure
Information about spare parts that are necessary for a procedure
Information about support equipment that is necessary for a procedure
Information about supplies (consumables) that are necessary for a procedure
Make sure that the power supply to the EVSE is disconnected
Electrotechnical expertise is required, according to the local rules
Alternate current

12 “Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
Symbol Description
Direct current
Protective Earth (PE)
Sign that means that you must read the manual before you install the EVSE
Waste from electrical and electronic equipment
NOTE
It is possible that not all symbols or signal words are present in this document
2.4 Personal protective equipment
A Personal Protective Equipment (PPE) is clothing or equipment designed to protect/reduce employees from
exposure to work place hazards and the risk of injury.
Symbol Description
Protecting clothing
Safety gloves
Safety shoes
Safety glasses
2.5 Safety instructions
• Only perform the procedures as indicated in this document.
• Only perform any services as installation engineer or use the EVSE when you are fully qualified to do so.
DANGER
If and to the extent permitted by law, in case of inconsistency or contradiction, between any
requirements or procedure contained in this document and any such local laws and/or rules,
comply with the stricter laws and/or rules, requirements and procedures specified in this
document.

13Safety
EN
2.5.1 Safety instructions during transport
• Make sure that the hoisting equipment or forklift truck can lift the EVSE
safely.
• Take into account the mass and the center of gravity of the EVSE.
• Obey the applicable safety instructions for the hoisting equipment or for the
forklift truck. For example, the instructions specified on the related shipment
label that is applied to the EVSE packaging.
• Put on the correct personal protective equipment.
2.5.2 Safety instructions during installation
• Make sure that there aren’t any supply voltages on the input cables during the
complete installation procedure.
• Keep unqualified personnel at a safe distance during installation.
• Only use electrical wires of sufficient gauge and insulation to handle the
rated current and voltage demand.
• Make sure that the load capacity of the grid is in accordance with the EVSE.
• Make sure that the wiring inside the EVSE is protected from damage and
cannot get trapped when you open or close the EVSE.
• Do not open any covers/doors of the equipment in case of adverse climatic
conditions. Infiltration of water or sand and presence of high humidity can
cause damage of the equipment. It is of paramount importance to evaluate
the weather conditions in the risk assessment prior any intervention on the
equipment.
• Protect the EVSE with safety devices and measures that the local rules
specify.
• Make sure that the EVSE is connected to a Protective Earth (PE).
• Make sure that the connections to the EVSE comply with all applicable local
rules.
• Put on the correct personal protective equipment.
Additional instructions during ground works
• Make sure that the equipments used during ground works are certified.
• Comply with all applicable local rules.
2.5.3 Safety instructions during cleaning or maintenance
• Make sure that there are any supply voltages on the input cables during the
complete cleaning or maintenance procedure.
• Keep unauthorized personnel at a safe distance during cleaning or
maintenance.
• If for cleaning or maintenance it is necessary to remove safety devices,
immediately install the safety devices after the work.
• Put on the correct personal protective equipment.
2.5.4 Safety instructions during the use
Do not use the EVSE and immediately get in contact with the manufacturer if the safety or the
safe use of the EVSE is at risk. This includes, but is not limited to, these conditions:
• An enclosure has damage.
• An EV charge cable or connector has damage.
• Lightning struck the EVSE.
• There was an accident or a fire at or near the EVSE.
• Water entered the EVSE

14 “Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
2.6 Discard the EVSE or parts of the EVSE
Incorrect waste handling can have a negative effect on the environment and human health due to potential
hazardous substances. With the correct disposal of this product, you contribute to reuse and recycling of
materials and protection of the environment.
• Obey the local law and rules when you discard parts, packaging material or the EVSE.
• Discard electrical and electronic equipment separately in compliance with the WEEE - 2012/19/
EU Directive on waste of electrical and electronic equipment.
• As the symbol of the crossed out wheeled-bin on your EVSE indicates, do not mix or dispose
the EVSE with your household waste, at the end of use. Instead, hand the EVSE over to your
local community waste collection point for recycling.
• For more information, contact the Government Waste-Disposal department in your country.
2.7 Cyber security
NOTE
This topic is valid for a wired Ethernet connection
This product is designed to be connected to and to communicate information and data via a network interface.
It is the Owner’s sole responsibility to provide and continuously ensure a secure connection between the
product and Owner’s network or any other network (as the case may be).The Owner shall establish and maintain
any appropriate measures (such as but not limited to the installation of firewalls, application of authentication
measures, encryption of data, installation of anti-virus programs, etc) to protect the product, the network, its
system and the interface against any kind of security breaches, unauthorized access, interference, intrusion,
leakage and/or theft of data or information. The manufacturer (ABB E-mobility) and its affiliates are not liable
for damages and/or losses related to such security breaches, any unauthorized access, interference, intrusion,
leakage and/or theft of data or information.
2.8 Conformity
This manual is compliant with the following directives and applicable regulations:
Standard Description
CE CE certification
CHAdeMO Standard for connections of fast charging systems for EV
EN17186 Directive on EV power supply
IEC 62262 International standard for impact protection rating
IEC 82079-1 International Standard on information/instruction for use of products
Directive 2001/95/EC General Product Safety Directive (“GPSD”)
Directive 85/374/EEC Product Liability Directive (“PLD”)
Directive (EU) 2019/771 EU Sales of Goods Directive
Directive 2011/65/EU Use of certain hazardous substances in electrical and electronic equipment
(“RoHS”)
Directive 2012/19/EU Waste of electrical and electronic equipment (“WEEE”)
Directive 2014/53/EU Market of radio equipment (“RED”)
Directive 2014/32/EU Market of measuring instruments
Directive IEC 61439-7 Low-voltage switchgear and controlgear assemblies
Directive IEC 61851-1 Electric vehicle conductive charging system
Directive 2006/42/CE Machinery directive
Blue Guide Implementation of EU products rules 2022

15Safety
EN
For the regulations of individual countries, refer to the national and international certification bodies as
follows:
Country Standard Description
USA ASTM American Society for Testing and Materials
EU CEN International Organization for Standardization
EU CENELEC European Committee for Electrotechnical Standardization
Italy CEI Comitato Elettrotecnico Italiano
International IEC International Electrotechnical Commission
International ISO International Organization Standard
International SAE International Society of Automotive Engineers
International UL Underwriters Laboratory
International FM Globa Global Factory Mutual Insurance Company

16 “Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
3. Description
This chapter contains information about the models, details of the equipment, characteristics and
technical data, overall dimensions and equipment identification.
A description of the equipment characteristics is provided to identify its main components and specify
the technical terminology used in the manual.
Chapter recipients:
• Owner
• Qualified installer
3.1 Orientation agreements
B
A
D
C
A. Front side: face forward to the EVSE during normal use
B. Left side
C. Right side
D. Rear side

17Description
EN
3.2 Type plate - Identification of equipment
IP54
SN: XXXX-XXX-XXXX-XXX
Part number XXXXXXXXXX
Prod. date XX XXXX XXXXXXXXXXXX
XX XXXXX XX
FOR USE WITH ELECTRICAL VEHICLES
Input xxxV x+PE-
DC Input xxx-xxxV Max xxxA
DC Output 1 CCS2 xxx-xxxV Max xxxA
DC Output 2 CHAdeMO xxx-xxxV Max xxxA
Max x.xkW/xxHz
DC AUX xxV xA
Heertjeslaan 6,
2629 JG Delft,
The Nederlands
MADE IN ITALY www.abb.com
Weight XXX Kg
XX-X
VDE - XXXXxxxx
Class X xxx. xx XX-XXXXX x
XX-XXXXX x
XX-XXXX
XXXXXXXXXX
XXXX-XXX-XXXX-XXX
H
G
F
E
D
C
K
J
I
L
M
N
B
A
Ref. Description
A. Address of the manufacturer
B. EVSE rating
C. EVSE identification code
D. Internal product code (for the manufacturer)
E. Production date
F. Part number of the EVSE
G. Serial number of the EVSE
H. Manufacturer
I. Additional EVSE rating data
J. Certified energy meter identification
K. EVSE weight
L. Barcode with the part number of the EVSE
M. Barcode with the serial number of the EVSE
N. CE mark
NOTE
Find the type plate on your EVSE to see the applicable data.

18 “Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
3.2.1 EVSE identification code
In the table is described the structure of the identification code of the EVSE.
TDC2L60 CE CJT 5N5 -5N2 B - 0 EXAMPLE
Main product Localization EV charge cable connection EV charge cable features EV charge cable features 1) User Interface features Customized design Field Description
TTT STPPP • TTT is the “charger identification”:
−TDC = Terra DC
• S is the “product series”:
−1 = Series 1
−2 = Series 2
• T is the “cabinet size”:
−S = Small
−M = Medium
−L = Large
• PPP is the “output power”:
−60 = 60 kW output power
−360 = 360 kW output power
MM • MM is the “localization”:
−CE = for IEC market
−UL = for North-American market
−JP = for Japan market
XXX • XXX is the “EV charging cable type”:
−CC = CCS2 + CCS2
−CCT = CCS2 + CCS2 + AC Type 2 socket 22 kW
2)
−CJT = CCS2 + CHAdeMO + AC Type 2 socket 22 kW
3)
Y X V -Y X V • Y is the “EV charging cable length”:
−5 = About 5 meters
• X is the “EV charging cable cooling method”:
−N = Non-cooled cable
• V is the “EV charging cable current rating”:
−1 = 150 A cable boost current rating
−2 = 200 A cable boost current rating
−5 = 500 A cable boost current rating
Z• Z is the “User Interface specification”:
−A = CCV VR payment terminal
−B = CCV payment terminal with BS Payone
−N = Nayax terminal
−P = Payter P66 payment terminal
−0 = If no option is selected (note that 15” display
and Mifare RFID reader are default)
V• V is the “EVSE customization”:
−C = Customized color for a specific customer
−Letters = Abbreviation of the customer name
−0 = If the product is not customized
1 Field not present if the connector on the 2 EV charging cables are the same.
2 Terra 60 model only
3 Terra 60 model only

19Description
EN
3.3 Terra 60 Overview
3.3.1 Overview outside - Terra 60
A
C
B
D
EH
G
I
J
L
O
B
K
N
D
F
M
P
D
Ref. Part Function
ARemovable base To cover the lower part of EVSE
BType plate Identification and technical data label
CTop left door Air inlet.
To filter the air and access the inside of EVSE
DCable management system (CMS) Cable management system retracts the cables and holds the
cables in position when the EVSE is not in use.
EAntenna To send and receive data via cellular signal
FAdvertisement screen Customizable advertising display
GTouchscreen To control and monitor the charge session
H RFID reader To read the information from an RFID card
I Meter display To read the meter data
JPayment terminal To pay for the charge session
K Type 2 socket To connect a type 2 EV charge cable
LConnector identification label Charging connector Identification (EN17186 directive)
MFront door Side of EVSE with EV connectors and UI (User Interface). To
access the inside of EVSE
NRear door To access the inside of EVSE
OTop right door Air outlet.
To access the inside of EVSE
PLifting points (eyebolts) To move the EVSE with hoisting equipment

20 “Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
3.3.2 Overview inside - Terra 60
1
2
3
B
A
I
K
E
J
C
L
D
F
G
H
P
Ref. Part Function
APower modules To provide power to the EVSE
BAcoustic baffle To reduce the airflow noise
CCable gland plate Plate with openings for power and signal cables
D PE busbar To connect Protective Earth (PE) cables
E Main AC switch To function as a AC main disconnector
FAuxiliary power supply breaker To connect or disconnect the AC auxiliary power supply
G AC surge protection device To protect the EVSE from voltage spikes due to lightning that
hits the AC power line
H 24V DC auxiliary power supply To supply internal 24V auxiliary power supply
I Meters for MRU To read the current values to be sent to the meter reading
unit
JCCB board Core control board
K CPI outlet 1 and 2 Charge Protocol Iterface
LInternal latch To unlock the rear door internally
