ABB eVD4 User manual

Equipped with Relion® technology
eVD4
Breaker Integrated Protection RBX615
Engineering Guide

Document ID: 1MRS757255
Issued: 2011-12-13
Revision: B
Product version: 2.0
© Copyright 2011 ABB. All rights reserved

Copyright
This document and parts thereof must not be reproduced or copied without written
permission from ABB, and the contents thereof must not be imparted to a third
party, nor used for any unauthorized purpose.
The software or hardware described in this document is furnished under a license
and may be used, copied, or disclosed only in accordance with the terms of such
license.
Trademarks
ABB and Relion are registered trademarks of the ABB Group. All other brand or
product names mentioned in this document may be trademarks or registered
trademarks of their respective holders.
Warranty
Please inquire about the terms of warranty from your nearest ABB representative.
ABB S.p.A.
Power Products Division
Unità Operativa Sace-MV
Via Friuli, 4
I-24044 Dalmine
Telephone: [phone]
Facsimile: [phone]
[email protected]
http://www.abb.com

Disclaimer
The data, examples and diagrams in this manual are included solely for the concept
or product description and are not to be deemed as a statement of guaranteed
properties. All persons responsible for applying the equipment addressed in this
manual must satisfy themselves that each intended application is suitable and
acceptable, including that any applicable safety or other operational requirements
are complied with. In particular, any risks in applications where a system failure and/
or product failure would create a risk for harm to property or persons (including but
not limited to personal injuries or death) shall be the sole responsibility of the
person or entity applying the equipment, and those so responsible are hereby
requested to ensure that all measures are taken to exclude or mitigate such risks.
This document has been carefully checked by ABB but deviations cannot be
completely ruled out. In case any errors are detected, the reader is kindly requested
to notify the manufacturer. Other than under explicit contractual commitments, in
no event shall ABB be responsible or liable for any loss or damage resulting from
the use of this manual or the application of the equipment.

Conformity
The IED is designed in accordance with the international standards of the IEC
60255 series, EMC Directive 2004/108/EC and MV circuit breaker standard IEC
62271-100.

Safety information
Dangerous voltages can occur on the connectors, even though the
auxiliary voltage has been disconnected.
Non-observance can result in death, personal injury or substantial
property damage.
Only a competent electrician is allowed to carry out the electrical
installation.
National and local electrical safety regulations must always be
followed.
The frames of the IED and of the HMI have to be carefully earthed.
When the plug-in unit has been detached from the docking unit, do
not touch the inside of the DU. The IED DU internals may contain
high voltage potential and touching these may cause personal injury.
The IED contains components which are sensitive to electrostatic
discharge. Unnecessary touching of electronic components must
therefore be avoided.
Whenever changes are made in the IED, measures should be taken
to avoid inadvertent tripping.

Table of contents
Section 1 Introduction.......................................................................3
This manual........................................................................................3
Intended audience..............................................................................3
Product documentation.......................................................................4
Product documentation set............................................................4
Document revision history.............................................................5
Related documentation..................................................................6
Symbols and conventions...................................................................6
Symbols.........................................................................................6
Document conventions..................................................................6
Section 2 IEC 61850 overview.........................................................9
Section 3 PCM600 tool...................................................................11
Connectivity packages......................................................................12
PCM600 and IED connectivity package version...............................12
CCT600 ...........................................................................................13
Section 4 615 series data model....................................................15
615 series implementation................................................................15
Information model.............................................................................15
Vertical and horizontal communication.............................................16
Predefined vertical communication data sets..............................17
Vertical communication diagnostic counters...............................17
Parameter setting and disturbance recorder....................................18
Section 5 GOOSE..........................................................................19
Horizontal communication................................................................19
Configuring horizontal communication........................................19
GOOSE publishing properties..........................................................20
Configuring GOOSE ........................................................................21
Defining IEDs and exporting the SCD file....................................21
Creating an empty project...........................................................22
Importing the SCD file.................................................................23
Configuring a GOOSE publisher.................................................25
Creating a GOOSE data set...................................................25
Configuring a GOOSE control block.......................................27
Configuring a GOOSE subscriber...............................................30
Configuring GOOSE inputs....................................................30
Finalizing GOOSE configuration..................................................32
Table of contents
Breaker Integrated Protection RBX615 1
Engineering Guide

Exporting the SCL file.............................................................32
Importing the SCL file.............................................................33
Connecting GOOSE inputs to an IED application..................35
Received GOOSE message handling..............................................37
GOOSE supervision.........................................................................37
Background sending....................................................................37
Default value handling.................................................................38
Alarm supervision in application..................................................38
Diagnostic counters.....................................................................38
Section 6 Required CCT600 project modifications.........................41
Attaching the IEC 61850 clients to the bus.......................................41
Defining server IEDs.........................................................................43
Section 7 Glossary.........................................................................45
Table of contents
2Breaker Integrated Protection RBX615
Engineering Guide

Section 1 Introduction
1.1 This manual
The engineering guide provides information for IEC 61850 engineering of the 615
series protection IEDs with PCM600 and CCT600. This guide concentrates
especially on the configuration of GOOSE communication with these tools. The
guide can be used as a technical reference during the engineering phase,
installation and commissioning phase, and during normal service. For more details
on tool usage, see the PCM600 documentation.
1.2 Intended audience
This manual addresses the system engineers and installation and commissioning
personnel.
The system engineer must have a thorough knowledge of protection systems,
protection equipment, protection functions and the configured functional logic in
the IEDs. The installation and commissioning personnel must have basic
knowledge of how to handle the electronic equipment.
1MRS757255 B Section 1
Introduction
Breaker Integrated Protection RBX615 3
Engineering Guide

1.3 Product documentation
1.3.1 Product documentation set
Planning & purchase
Engineering
Installing
Commissioning
Operation
Maintenance
Decommissioning deinstalling & disposal
Application manual
Operation manual
Installation manual
Service manual
Engineering manual
Commissioning manual
Communication protocol
manual
Technical manual
Planning & purchase
Engineering
Installing
Commissioning
Operation
Maintenance
Decommissioning deinstalling & disposal
Planning & purchase
Engineering
Installing
Commissioning
Operation
Maintenance
Decommissioning deinstalling & disposal
Application manualApplication manual
Operation manualOperation manual
Installation manualInstallation manual
Service manualService manual
Engineering manualEngineering manual
Commissioning manualCommissioning manual
Communication protocol
manual
Communication protocol
manual
Technical manualTechnical manual
en07000220.vsd
IEC07000220 V1 EN
Figure 1: The intended use of manuals in different lifecycles
The engineering manual contains instructions on how to engineer the IEDs using
the different tools in PCM600. The manual provides instructions on how to set up a
PCM600 project and insert IEDs to the project structure. The manual also
recommends a sequence for engineering of protection and control functions, LHMI
functions as well as communication engineering for IEC 61850 and other
supported protocols.
The installation manual contains instructions on how to install the IED. The
manual provides procedures for mechanical and electrical installation. The chapters
are organized in chronological order in which the IED should be installed.
The commissioning manual contains instructions on how to commission the IED.
The manual can also be used by system engineers and maintenance personnel for
assistance during the testing phase. The manual provides procedures for checking
of external circuitry and energizing the IED, parameter setting and configuration as
Section 1 1MRS757255 B
Introduction
4Breaker Integrated Protection RBX615
Engineering Guide

well as verifying settings by secondary injection. The manual describes the process
of testing an IED in a substation which is not in service. The chapters are organized
in chronological order in which the IED should be commissioned.
The operation manual contains instructions on how to operate the IED once it has
been commissioned. The manual provides instructions for monitoring, controlling
and setting the IED. The manual also describes how to identify disturbances and
how to view calculated and measured power grid data to determine the cause of a
fault.
The troubleshooting manual contains quick answers to frequently asked questions
about the IED use. The manual provides instant solutions to the problems that the
end used might face while using the IED, both at commissioning and during the
eVD4 life.
The service manual contains instructions on how to service and maintain the IED.
The manual also provides procedures for de-energizing, de-commissioning and
disposal of the IED.
The application manual contains application descriptions and setting guidelines
sorted per function. The manual can be used to find out when and for what purpose
a typical protection function can be used. The manual can also be used when
calculating settings.
The technical manual contains application and functionality descriptions and lists
function blocks, logic diagrams, input and output signals, setting parameters and
technical data sorted per function. The manual can be used as a technical reference
during the engineering phase, installation and commissioning phase, and during
normal service.
The communication protocol manual describes a communication protocol
supported by the IED. The manual concentrates on vendor-specific implementations.
The point list manual describes the outlook and properties of the data points
specific to the IED. The manual should be used in conjunction with the
corresponding communication protocol manual.
Some of the manuals are not available yet.
1.3.2 Document revision history
Document revision/date Product series version History
A/2010-10-14 1.0 First release
B/2011-12-13 2.0 Content updated to correspond to the
product series version
1MRS757255 B Section 1
Introduction
Breaker Integrated Protection RBX615 5
Engineering Guide

Download the latest documents from the ABB Web site
http://www.abb.com/mediumvoltage.
1.3.3 Related documentation
Product series- and product-specific manuals can be downloaded from the ABB
web site http://www.abb.com/mediumvoltage.
1.4 Symbols and conventions
1.4.1 Symbols
The caution icon indicates important information or warning related
to the concept discussed in the text. It might indicate the presence
of a hazard which could result in corruption of software or damage
to equipment or property.
The information icon alerts the reader of important facts and
conditions.
The tip icon indicates advice on, for example, how to design your
project or how to use a certain function.
Although warning hazards are related to personal injury, it is necessary to
understand that under certain operational conditions, operation of damaged
equipment may result in degraded process performance leading to personal injury
or death. Therefore, comply fully with all warning and caution notices.
1.4.2 Document conventions
A particular convention may not be used in this manual.
• Abbreviations and acronyms in this manual are spelled out in the glossary. The
glossary also contains definitions of important terms.
• Push-button navigation in the LHMI menu structure is presented by using the
push-button icons.
To navigate between the options, use and .
• HMI menu paths are presented in bold.
Select Main menu/Settings.
• WHMI menu names are presented in bold.
Click Information in the WHMI menu structure.
Section 1 1MRS757255 B
Introduction
6Breaker Integrated Protection RBX615
Engineering Guide

• LHMI messages are shown in Courier font.
To save the changes in non-volatile memory, select Yes and press .
• Parameter names are shown in italics.
The function can be enabled and disabled with the Operation setting.
• Parameter values are indicated with quotation marks.
The corresponding parameter values are "On" and "Off".
• IED input/output messages and monitored data names are shown in Courier font.
When the function starts, the START output is set to TRUE.
1MRS757255 B Section 1
Introduction
Breaker Integrated Protection RBX615 7
Engineering Guide

8

Section 2 IEC 61850 overview
The international IEC 61850 standard defines a framework for substation
communications networks and systems. The standard consists of several parts
ranging from the requirements on substation automation systems to the details of a
communication protocol.
One major difference between the other communication protocols applied in
substation automation and IEC 61850 is that the latter is not only a communication
protocol, but a whole framework for specifying, engineering and operating
substation automation systems. The communication part covers the connection
between the IEDs and the substation clients, for example, SCADA and gateways.
Table 1: Structure and parts of the IEC 61850 standard
Part Subject Description
1 Introduction and overview Information and understanding
2 Glossary
3 General requirements
4 System and project management Impact on tenders and project
management
5 Communication requirements for functions and
device models
Requirements
6 Configuration description language for
communication in electrical substations related to
IEDs
Impact on engineering
7-1…
7-4
Basic communication structure for substation and
feeder equipment (data model and services)
Modelling and services
8 Mapping; stack A, stack B Station bus mappings
9 Mapping; stack X, stack Y Process bus mappings
10 Conformance testing Impact on verification
The IEC 61850 standard specifies an expandable data model and services for
substation automation (standard parts 7-x). The standard does not specify any
protection or control functions, but specifies how the functions expose their
information to a communication network.
The standard supports free allocation of functions to devices. With efficient
communication facilities, the functions can be located anywhere in the system, that
is, an interlocking function can reside in the IED or on the station level.
Additionally, the standard is open for different system philosophies, that is,
different integration levels and allocation of functions to different devices is
supported.
1MRS757255 B Section 2
IEC 61850 overview
Breaker Integrated Protection RBX615 9
Engineering Guide

The standard also defines a description language for substation automation
systems. The language facilitates efficient integration of devices into systems in an
automated fashion. Additionally the standard supports a comprehensive and
consistent system definition and engineering, which makes not only the devices,
but also their tools and systems interoperable (standard part 6).
The standard uses Ethernet and TCP/IP for communication. Since Ethernet and TCP/
IP are widely accepted and used, the application of these technologies provide a
broad range of features from mainstream communication (standard parts 8-1, 9-2).
Therefore, IEC 61850 is also open for possible new communication concepts in the
future.
Data model (objects, sevices)
Client server
communication GOOSE Sampled
values
Mapping
Real-time
communication
MMS
TCP
IP
Ethernet link layer
Ethernet physical layer with priority tagging (100 Mbit/s)
1
2
3
GUID-A9FD9579-37AD-4B03-935E-BF39D48B7211 V1 EN
Figure 2: Communication stacks and mapping used in IEC 61850
1Abstract communication services interface (ACSI)
2 Stack interface
3 ISO/OSI stack
Section 2 1MRS757255 B
IEC 61850 overview
10 Breaker Integrated Protection RBX615
Engineering Guide

Section 3 PCM600 tool
Protection and Control IED Manager PCM600 offers all the necessary functionality
to work throughout all stages of the IED life cycle.
• Planning
• Engineering
• Commissioning
• Operation and disturbance handling
• Functional analysis
With the individual tool components, you can perform different tasks and functions
and control the whole substation. PCM600 can operate with many different
topologies, depending on the customer needs.
PCM600 is used to conduct complete engineering and configuration activities
needed for the bay level IEDs.
Product type and version specific engineering data needed by PCM600 for
protection, control and communication engineering of a particular bay IED is
provided in an IED connectivity package.
PCM600 communicates with the bay IEDs via an Ethernet connection. The
connection allows to read and write all configuration data needed for proper
operation from or to the IED. The IEDs have communication interfaces for
protocols and media used for station communication. Bay IED IEC 61850 station
communication files can be exported from PCM600 to the station engineering tools
for engineering of station communication between the bay IEDs and station IEDs.
A PC with PCM600 can be connected to any 615 series IED within a station by
using the Ethernet connection. The Ethernet connection can later be used also for
service and maintenance purposes. In addition, the connection is used to handle
disturbance records from the protection IEDs using the IEC 61850 file transfer.
The modern-day IEDs are designed on the concept of the IEC 61850 standard. This
is mainly given for the organization of functions represented by an equivalent
logical node in the IEC 61850 standard. See the IEC 61850 parameter list for the
available logical nodes in the IED, following the structure and rules in part 7 of the
IEC 61850 standard in an IED configuration.
The engineering of the used communication protocols is a separate task and an
addition to the engineering of protection and control functions.
PCM600 can be used for different purposes throughout the IED life cycle. A set of
special tools is available for different applications.
1MRS757255 B Section 3
PCM600 tool
Breaker Integrated Protection RBX615 11
Engineering Guide

The applications can be organized into groups.
• IED product engineering
• IED communication engineering per protocol
• IED system monitoring
• IED product diagnostic
For more information, see PCM600 documentation.
3.1 Connectivity packages
Connectivity package is a collection of software and information related to a
specific protection and control terminal providing system products and tools to
connect and interact with the IED. Connectivity packages are used to create
configuration structures in PCM600. The latest PCM600 and connectivity packages
are backward compatible with older IED versions.
Update Manager is a tool that helps in defining the right connectivity package
versions for different system products and tools. Update Manager is included in
products supporting the connectivity concept.
In addition to other products supporting the connectivity concept, the connectivity
packages for PCM600 contain a description of IED's internal parameters and their
properties (such as data format, unit, setting range, visibility and access rights) as
well as software components that adapt the IED-specific interfaces to the standard
interfaces of system products and tools, such as IED-specific dispatchers for tools.
This means that there is a protocol-specific adaptation for the parameter setting and
disturbance handling tool components, for example, disturbance uploading
according to COMTRADE. The description texts can be translated into other
languages as well.
3.2 PCM600 and IED connectivity package version
• Protection and Control IED Manager PCM600 Ver. 2.4 or later
• RBX615 Connectivity Package Ver. 2.0 or later
Download connectivity packages from the ABB web site http://
www.abb.com/substationautomation
Section 3 1MRS757255 B
PCM600 tool
12 Breaker Integrated Protection RBX615
Engineering Guide
