Abbott DIGIVAL LFR-000 User manual

QUICK START GUIDE
DIGIVAL™

DIGIVALQuick Start Guide2
Contents
LFR-000 L22XWU1-200
LFR-024
DIGIVAL™Barcode scanner and holster
Barcode scanner bracket Power Supply
INLFR000 LFR-003
INLFR024
USER MANUAL
DIGIVAL™
User Manual Calibration Check Card Pack

Optional Accessories
MCP1810395 EQ004003
Printer Abbott USB Memory Stick
DIGIVALQuick Start Guide 3
Contents
LFR-004
DIGIVAL™Tray 1 Pack

DIGIVALQuick Start Guide4
Unpack the shipping container and check for any obvious damage.
DIGIVAL™Set Up
Place the DIGIVAL on a level bench top within access to a power supply.
1
2
1
345
Barcode scanner bracket location holes
3
4
5
1
2
USB port (x1)
Power connection
Ethernet
USB ports (x2)

DIGIVALQuick Start Guide 5
Assembly of barcode scanner holster.
Connect bracket assembly to back of the DIGIVAL. Attach barcode scanner to USB and
place onto holster.
Connect power supply and turn on the DIGIVAL.

DIGIVALQuick Start Guide6
Open drawer, remove tray, and place calibration check card into position as shown
onscreen.
Enter the admin password
Enter ‘admin’
Settings - Admin Password
Back Abc
? 123
ã
Ç
?
'
Õß
,
Enter New Admin Password
Set the Date
Settings - Date
Select Option
Back
DD/MM/YYYY
MM/DD/YYYY
YYYY/MM/DD
Year Month Day
2019 1 24
OK

DIGIVALQuick Start Guide 7
Set the Time
Settings - Time
Select Option
Back
12h
24h 4 : 9 pm
OK
Check Instrument Calibration
Read Test Read QC Test Calibration
Check Test History
PreferencesSettingsLog Out
Home admin 01/24/2019 04:37 pm
