Abocom PLS322 User manual

AboCom Confidential
Page 1/2
UPA 200Mbps 2 ports Ethernet Switch
- One powerline port
- Two 10/100Mbps Ethernet ports
Description
The PLS322 provides convenient powerline access to
office/family users by sharing a simple AC power line
network. Embedded UPA DHS (200 Mbps) PLC interface
enables you to connect 2 PC Ethernet ports to another PC’s
at other end of power line connection, and not limited by the
wall or layer that block RF wireless communication.
Features
 One powerline port
 Two 10/100Mbps Ethernet ports
 One button security
 Three levels throughput indication

AboCom Confidential
Page 2/2
Product outlook
Specification
Main Chipset DS2 DSS9101+ DSS7800 + Realtek RTL8306
Standard support UPADHS (200 Mbps) PLC, IEEE802.3 & 802.3u
Interface One AC powerline port, two 10/100Mbps Ethernet Ports.
One security button, one factory-reset button.
Security 3DES 168 bits/ AES 128 bits/ AES 256 bits encryption
Power AC 100~240V/ 50~60Hz/ 0.15A; 6.5W/230V max.; 5.5W/110V max.
Dimension (W x D x L) 103.3 mm x 46 mm x 74.95 mm.
LED PWR/AP: Red & Green
Green On: Power On and Powerline-EP mode,
Orange On: Powerline-AP mode,
Orange-Green Blinking: Security setup mode.
Off: Power Off.
PLC/SPD: Red & Green
Green On: Powerline Link speed over 12Mbps,
Orange On: Powerline Link speed between 12Mbps and 6Mbps,
Red On: Powerline Link speed under 6Mbps,
Blink: Powerline in Activity.
Off: Powerline No-link.
LAN (1-2): Yellow-Green
On: Link
Blink: LAN in Activity.
Off: No-Link
Connection Range Up to 300 Meters
Operating Operating Temperature: 0~40ºC (32~104ºF)
Relative Humidity: 10%~90% non-condensing
Storage Temperature: -10~70ºC (14~158ºF)
Relevant Humidity: 5%~95% non-condensing
CERTIFICATIONS FCC Part 15B & 15C, Class B; CE Class B (EN55022/EN55024)
UL 60950-1(option), CB (option).
