Abocom SW800 User manual

SW800
8
88
8-
--
-Port Fast Ethernet N
Port Fast Ethernet NPort Fast Ethernet N
Port Fast Ethernet N-
--
-Way Switch
Way SwitchWay Switch
Way Switch
Introduction
The 8-port switch provides a flexible, reliable, and affordable way of giving Ethernet network solution. It comes with eight
independent 10BASE-T /100BASE-TX ports. Each port delivers up to 200Mbps throughput, and is able to operate in either half
or full-duplex modes.
It also processes an N-Way auto-negotiation function, which automatically adjusts the device for optimum operation;
“Store-and-Forward” architecture filters to eliminate error packets and improve efficiency.
Key Features & Specification
!" Compliant with IEEE 802.3 10Base-T and IEEE 802.3u
100Base-TX standards
!" “Store and Forward” architecture filters
!" 10/100Mbps port auto-detect on Full or Half Duplex
mode
!" IEEE 802.3x or Back Pressure (HDX) Flow Control
!" 8K MAC Address with automatic learning and 5-minute
aging
!" Eight 10/100Mbps Auto-Detection ports
!" Dimension (WxDxH) :
138mm x 76mm x 22mm
!" Power Feeding (Please do not use any other adapters
besides the one provided):
+6Vdc/1000mA
!" Automatic power saving
!" 8 x RJ45 STP/UTP network ports on rear panel
!" Maximum 100m per port Hub-to-Hub or Node-to-Hub
cable length
!" Emission Certification : FCC/CE Class A
!" Operating Environment :
Temperature : 0 ~ 40oC ; Humidity : 5 ~ 90 % RH
