Abtus AVA-CP28A/P User manual

AVA-CP SERIES
COMPONET SWITCHER 2 IN 8 OUT
USER GUIDE
Component/Audio/Switche
300 MHz
With Exte nal Cont ol I/O Po t
Component Video/Audio/Switche 2:1 x 8
AVA-CP24A/P, CP28A/P

DESCRIPTION
The 2:1x8 Component Video + Analog stereo Audio Switcher Distri ution Amplifier with
external control port is designed to work as a switcher for multiple Audio/Video sources and
displays. Capa le of switching Component Video and Stereo Audio signals etween two
sources and splitting them out in to eight displays with compati le inputs.
A maximum andwidth of 300MHz will support a sharp and highly defined video in multiple
resolutions of up to 1080p. Because it is two input switcher, it allows any input to e routed
to all the eight output at one go. It completely eliminates the need to constantly move around
video input and output ca les. External control allows the switcher to e controlled y any
I/O central controller system. The 2:8 Switcher Distri ution Amplifier works with all Video
equipment that has proper connections: such as Ca le and Satellite receivers, Video Scalers,
DVD players, VCR's and so on.
FEATURES
Allows connection of 2 sources and 8 displays.
Supports resolutions up to 1080p.
Easy Installation
Typical Applicatio
The ABtUS AVA-CP Series is part of the ABtUS series of high quality, high andwidth and cost effective Distri ution
Amplifiers and Switchers specially for professional installers. ABtUS products can e found in industrial, commercial,
educational, military and government applications like: Schools; Training rooms; Broadcast and duplication
studios; Workstation environment; Retail showrooms; CCTV and surveillance and Multipurpose Hall etc.
AVA-CP SERIES
300 MHz
2 IN 8 OUT COMPONENT SWITCHER
AVA-CP24A/P AVA-CP28A/P
(With Exte nal Cont ol)
Typical Applicatio AVA-CP24A/P, CP28A/P
VIDEO INPUT CONNECTORS 2 sets of 5-RCA (Y/P /Pr and AL/AR)
VIDEO OUTPUT CONNECTORS 4 sets of 5-RCA (Y/P /Pr and AL/AR)*CP24A/P
8 sets of 5-RCA (Y/P /Pr and AL/AR)*CP28A/P
VIDEO AMPLIFIER BANDWIDTH (-3dB) 300MHz
MAX RESOLUTION Up to 1080p
MAX. CABLE LENGTH 25 meter
POWER CONSUMPTION 500mA~3000mA (max.)*CP28A/P
POWER SUPPLY 100~240V AC, 50/60Hz *CP28A/P
DIMENSIONS (L/W/H) 310mm/114mm/44mm. (Rack Mounts)*CP24A/P
(L/W/H) 482mm/233mm/45mm. (Rack Mounts)*CP28A/P
Tech ical Specificatio s AVA-CP24A/P, CP28A/P
