AC Air Technology T1 User manual

Instruction Manual MODEL: T1 / T1X2 / T1.5 / T2
TRACKS
World’s First Portable, Remote-Control Aircraft Tugs
09844 Rev. A

Contents
1. Components
2. Installation Guide
2-1. Old Track Removal
2-2. New Track Installation
2-3. Warranty

1. Components
Tug
Track
Track Installation Tools
Install Tools
Part # 23194
Retainer Clip Tool
Part # 23193

2. Installation Guide
2-1. Old Track Removal
Torx Screws
1. Remove inside and outside plastic track guards by removing several Torx Screws.
Torx Screws
Plastic Track Guards
2. Loosen the 3 track rail screws and push the end of the track rail to relieve
the track tension. Retighten the track rail screws while pushing on rail end.
Note: The screws might be tight because of loctite glue.
Track Rail Screws
Push End of Track Rail

3. Remove a Rotoclip from one of the track pins and remove the track pin
from the track.
Trick: Tap the end of the track pin using a hammer to drive the pin through
the Rotoclip. The Rotoclip will not be reusable after removal.
4. Open the tug cover and remove the track from the tug.
Tap Track Pin Here
Open Tug Cover
