Accentronix Cellswitch INFINITY User manual

Cellswitch
INFINITY
Smart Access Control System
ACCENTRONIX
We provide the latest technology in access control and security
for your home and business.
CONTROL
MONITORING &
General Features
• Dual sim (Vodacom and MTN) with all airtime, data and
premium features included for 1 year. No activation and
registration fees. Simply install the device and start using it.
Both sim cards are online at the same time that is used as
a backup feature as well as being able to control separate
outputs by missed-call.
• Unlimited alerts and control with our Accentronix Smart Home
app.
• Monitor gate status and alarms as well as battery voltage.
• Get access control notifications.
• Integrated with Google Assistant and Google Home.
Smart Remotes & Tags
• Managing remotes couldn’t be easier with the ET NICE Cloud-
link receiver add-on.
• Have full control over your tags by connecting an Accentronix
MIFARE Tag Reader to your device.
• Monitor, manage and block remotes, tags and users.
• Restrict access for domestic, gardening and security services
to specific days and times.
• Eortlessly bulk learn remotes and tags o-site.
• Complete log reports.
• Replaces old tag readers and receivers.
Access Control
• Feature-rich, easy to use website for centralized management.
• Access control for up to 10 000 users by using the Accentronix
Smart Home app, missed-call, ET-Blu remotes, Tags, Google
Assistant, please-call-me or SMS.
• Visitor control with One-Time-Pin using wired or wireless
keypads.
• Guest house and restricted time-based access control for
domestic and gardening services.
• Daily peak-hour gate open/close timers with a calendar for
inactive days including Public and School Holidays.
• Detailed access control reports.
• Welcome sms’s to new residents. This message includes
specific instructions and a link to download the app.
Electric Fence Monitoring
• Seamlessly connects directly to the energizer’s keypad data
interface.
• Advanced integration with all popular brands and models.
• Monitor and control the energizer with buttons on the app,
voice (Google Assistant), missed-call or SMS.
• Monitor fence health, alarms and battery voltages. *Fence
voltages on certain models only.
• Automatically switch the energizer to high/low voltage or turn
it on and o during certain times and days.
1
2
3
4
5
5 SIMPLE STEPS
INSTALL YOUR DEVICE IN
Create an account and then download the Accentronix Smart
Home app onto your phone. (REMEMBER to add your admin
account log-in details in the ‘admin account’ section on the App
to be able to access all the setup features)
Connect the antenna and 12 or 24VDC (max 32V DC) to the
device and wait for the green LED on the device to start flashing
slowly.
Go to ‘Register Device’ and enter the cellphone number of sim 1,
give the device a name and click on ‘Register’.
Select ‘Access Control’ and add your name and mobile number in
the access control list, then click on ‘Update Device’.
Control the device with the buttons that will automatically appear
in the app. You can also control the device by giving it a missed-
call on sim one or sim two.
Notes:
• Installer-mode is activated while the device is not registered,
which means that anyone can call the device to open the
gate for commissioning purposes.
• A welcome SMS containing instructions is sent to each new
user whenever they are added to the system.*
E.T. NICE REMOTES
HOW TO LEARN A REMOTE
1. Connect an Accentronix ET Nice RX2-Micro to the Cellswitch.
2. Go to the ‘Remotes’ tab next to a user.
3. Click on ‘Quick learn remote’ and press any button on the remote 3
times.
4. Press ‘Update device’ after adding remotes and users.
• You do not have to be on-site to learn a remote. Simply change the
‘gateway’ option to the device you are the closest to. This allows you
to add remotes to a site while you are on a dierent site.
KEYPADS
HOW TO LEARN A WIRELESS KEYPAD
• The Keypad is learned the same way as a remote. Press the ‘0’ button
on the keypad 5 times after pressing ‘Quick learn’ in the keypad
section.
• Max range is 15 meters between the keypad and ET Nice receiver.
HOW TO CONNECT A WIRED KEYPAD
• Up to 3 wired keypads can be connected directly to the device.
• Wired keypads do not require batteries and have
illuminated buttons.
• Cable length can be up to 100 meters long.
Note: Remember to enable the ‘Visitor Keypad Access
Code’ option.
If enabled, residents can press * or # followed by their
unique access code.
External keypads are used for access control and visitor OTP features. A
resident can use our app to invite guests. The guests will receive a sms
or whatsapp with a pin code that they can use at the gate.
HOW TO INVITE A GUEST USING THE APP
1. Firstly install the app from your app store.
2. Devices that is linked to the residents mobile number will
automatically appear in their app.
3. Click on the invite guest button to add visitors.
4. Visitors can be restricted to one entry and one exit or access for the
whole day.
5. The visitor will receive a sms or whatsapp containing their OTP as
well as instructions and a google maps link to the property.
6. As soon as the visitor uses the OTP the resident will immediately
receive a notification.
VISITOR ACCESS ONE-TIME-PIN
Wired Keypad

• 12Vdc to 24Vdc @ Idle: 40mA, Max: 100mA.
• 4 inputs and 2 outputs.
• Output 1 has an integrated relay. (Max 2 Amp @ 50V DC).
• Output 2 is an open collector output which can be connected directly
to the gate trigger (max 1 Amp @ 32V DC).
• Custom commands and buttons can be setup on the app to control the
outputs.
• Input 1 to 4 is triggered high by applying 12 or 24VDC to the input.
• Input trigger alert messages can be customized online.
• Energizer keypad data interface.
• E.T. NICE Cloud-Link receiver interface.
• Dimensions: 76 x 66 x 28mm
Get in Touch
Oce and Technical
[phone]
Technical support
Whatsapp line:
[phone]
Support hours:
Weekdays: 8:30-17:00
Saturday: 9:30-13:00
Sunday and Public holiday:
9:30-11:00
[email protected]
[email protected]
www.accentronix.co.za
• Two or more devices can eortlessly be linked together over the cloud to appear
as one device. This allows you to manage multiple devices connected to the
entrance, exit and pedestrian gates as one.
• A device can be linked to multiple accounts and dierent user levels can be
assigned by the owner.
• Use the output timers to automatically open the gate during peak-hours but keep
them closed during weekends and Public and School Holidays.
• Connect the entrance or exit loop through Output 1 to ensure a car must be at the
gate before allowing access.
• A missed-call on sim 1 control output 1 and a missed-call on sim 2 control output 1
or 2.
• Output 1 and 2 delay timers can be used to activate a mag-lock or activate
entrance and exit loops for an allocated time.
• Set the integrated output timers to trigger the exit loop for 120 seconds to allow for
enough time for a visitor to reach the exit gate.
• Connect a Mag Lock directly to Output 1 (n/c) and (com)terminals of the
integrated relay and set the integrated output delay timer to 10 seconds.
• Connect Output 2 directly to the pedestrian trigger. Output 2 is an ‘open collector’
output which means it gives 0V to whatever it is connected to while it is switched
on. To drive heavier loads, connect the one end of the coil of an external (12/24V
DC coil) relay to 12/24V DC and the other end of the external relay’s coil to Output
2. If Output 2 is switched on, it will supply 0V to the relay and turn it on.
• Default SMS commands: On, O, Pulse, On2, O2, Pulse2, Status. These commands
will only work if your mobile number is loaded onto the access control list.
• NOTE: When connecting the Status and Alarm outputs of an ET Gate controller to
Input 1 and 2, you need to connect a 10K resistor between 12/24Vdc and Input 1
as well as a resistor between 12/24Vdc and Input 2.
• During power-up and after an update the GREEN LED will be solid for a few
seconds.
• The GREEN LED start flashing fast when the device registers on the GSM
network. After the device is successfully logged onto the cloud the LED will
flash slowly. This can take up to a minute.
• If the GREEN LED stay solid or keeps on flashing fast for more than 5minutes,
none of the two sims can connect to the internet. Move the antenna to a
higher position and check the signal strength. Minimum recommended signal
is 14. Max is 31.
• Make sure the antenna is vertically mounted, not inside a metal enclosure or
close to any metal.
• To check the status, voltage and signal, sms 1234.status to sim one.
• The RED LED shows the on/o status of Output 2 as well as various error codes.
If connected to an energizer, a flashing RED LED indicates communication
with the keypad data connection.
• If you do not have the app installed on your phone, or if your phone lost its
internet connection, you will receive alerts by sms as a backup (max 30 sms’s
per month).
• Contact support on 087 550 3479 7 days a week for fast and friendly service or
go to our online HELP section for more info.
Trouble Shooting
Inputs, Outputs & Power Supply
ABOUT THE SIM CARDS AND SUBSCRIPTIONS
One year premium subscription is included when you buy this device.
The following premium features is included:
• The included Vodacom and MTN sim cards have already been RICA registered
and activated with data by Accentronix.*
• The Accentronix Smart Home app, E.T. Remotes management, Tag management
and Google Home. Please note these functions are ONLY available while the
device is on subscription.
• All Data, 30 free backup SMS’s per month and unlimited updates.*
• Welcome sms containing instructions is sent to each new user.
• After 1 year, you will receive an invoice for renewal.
• Security upgrades and premium support is also included.
• Please see our Subscription Terms of Service for pricing.
*Please see website for terms and
conditions and fair usage messaging
policy.
*Included sim cards and Free sms’ses
for South Africa only.
• Control your device by saying “Hey
Google, Is the garage closed?”,
“Turn the electric fence on” or “Turn
the sprinklers o”
• Simply download Google Home
from the app store and link
‘Accentronix Smart Home’ to your
account.
• This feature is available to anyone
who has their mobile numbers
added in the access control list.
• Go to the Google Home setup
section in the app for more info.
Download Our App
Accentronix Smart Home App
Using the App
• Control your gate and garage with a push of a
button.
• Use the app to invite a guest, learn a remote,
add a restricted access control user and
receive unlimited alerts and notifications.
• Devices and buttons will automatically appear
for any resident whose mobile number is linked
to the system. Residents will however not be
able to make any changes to the system or be
able to invite a guests if these features are not
enabled by admin.
App admin levels
• Dierent levels of admin privileges can be assigned depending on whether
you are the owner, access control administrator or a resident.
• Installers can use the app to set the device up, add and edit control buttons,
check status and test the device on site. Installers and admin need to link their
account in the ‘Admin Account’ section in the app to enable them to make
changes.
• As a backup service, you will receive alerts by normal SMS if your phone
temporarily lost its internet connection. You will also be able to control the
device by normal missed-call from within the app while you are oine.*
• All residents needs to download the Accentronix Smart Home App free of
charge.
Connection to Gate
ACCENTRONIX TAGS
HOW TO LEARN A TAG
1. Go to the ‘TAGS’ tab next to a user.
2. Click on ‘quick learn TAG’ and tap the
tag on the reader.
3. Press ‘Update device’ after adding
tags and users.
HOME AUTOMATION
Create custom buttons to control your lights, geyser, irrigation and
swimming pool pump. Monitor alarms, water tanks and even your
aquarium water level.
HOW TO CREATE CUSTOM BUTTONS ON THE APP
• Default buttons will automatically appear according to the
application type you selected when you registered the device.
• Customize names and commands of the buttons in the button
section.
• You can even set a button to control multiple outputs at the same
time i.e. “All lights o”.
• Expand the system by connecting an 8in/8out Expansion board.
HOW TO CONTROL YOUR ALARM PANEL
• Arm, disarm and monitor your alarm by connecting the device
directly to your alarm panel. See our online “How to” section for
connection diagrams and instruction on the most popular alarm
panels.
HOW TO SET THE DEVICE TO BE A STAND ALONE ALARM
SYSTEM
• Simply enable the “Alarm mode” option in the general setup
section. You will now be able to arm and disarm Input 1 to 3 of the
device for monitoring alarm and door sensors. Input 4 is used for a
panic button.
• Connect a siren to Output 1 and a status LED to Output 2.
• Arm and disarm by using the app, remote, tag reader or keypad.
• Remote buttons can be configured to arm/disarm, open a door
and panic.
ACCESS CONTROL
TIPS & FEATURES
Notes:
• You do not have to be on-site to learn a tag. Simply change
the ‘gateway’ option to the device you are the closest to. This
allows you to add tags to a site while you are on a dierent site.
Wireless Keypad
Google Home & Google
Assistant
