Access Vanish Quick start guide

Thank you for purchasing an ACCESS Vanish roll-up cover. ACI has manufactured this roll-up cover
with pride using superior quality materials and craftsmanship. With proper care, your cover will
provide years of service and enjoyment.
NOTICE TO INSTALLER: It is recommended you take the time to read these instructions before
installing this cover even if already familiar with the product. Often improvements are made
without prior notice. Always handle cover and components with care to avoid damage. If you nd
a part missing or defective, or if you are having trouble installing this product, please have serial
number ready (found on decal under rear bar by tailgate) and call the customer service number on
the back page. When done, these instructions and warranty information must be given to the
consumer.
NOTICE TO CONSUMER: Before using this product, read the operating instructions, mainte-
nance and safety sections of this owners manual and save for future reference.
INSTALLATION INSTRUCTIONS
AND OWNER’S MANUAL

2
INSTALLATION INSTRUCTIONS:
(NOTE: For additional installation assistance visit us at www.vanishcover.com)
Unpack cover components.
Clean truck box if dirty.
COMPONENTS:
1 driver side rail
1 passenger side rail
6 clamps
1 left and 1 right tension adjuster with nuts & bolts
1 pre-rolled up cover
A. Align weatherstrip edge of side rail
against inside lip of box and push rail
forward until it stops against front
of box - nylon strike goes to rear.
See photo at left to determine how high up to
mount rail.
1. INSTALLING COVER SIDE RAILS
End with
nylon bracket
goes to rear
First clamp
at front B. Hold rail in place with spring clamp
and close tailgate to check height. Then
place 1st clamp as close to front as pos-
sible and use a 1/2” wrench to tighten.
Tip: Before using wrench on
clamp, make sure clamp teeth
engage grooves on rail, turn nut
nger tight and then use wrench.
Temporary
spring clamp
Align outside edge
of cover rail as
shown with top of
box rail at front,
center and rear
TOOLS NEEDED:
1 - 1/2” wrench (for rail clamps) 1 - Tape measure or ruler
2 - 9/16” wrenches Protective eyewear
1 - Spring clamp (to hold rails in place while clamping) optional
PREPARATION
Note: Some installs require drilling/bolting. See extra insert instruc-
tions included with kit for rail attachment. Then proceed to #3 of these
instructions.
NOTE ON BED LINERS: With an under-the-rail drop in bed liner, installation is
possible with minimal trim cutting of bed liner at front corner of box and back by
tailgate to allow side rail to install properly. Considerable trim cutting is required
with an over-the-rail drop in bed liner.

3
A. The cover comes pre-rolled to its
normal open position for ease of instal-
lation. Set pre-rolled cover on tailgate
with front bar facing up as shown. Align
EZ-Dial Tension Adjuster (marked L)
on driver side of cover - positioned as
shown in photo at left.
2. ASSEMBLING TENSION ADJUSTERS TO COVER
B. Turn 1-1/4” bolt with at washer
onto nut in bar. Leave loose for now. See
photo. Repeat for EZ-Dial (R) on pas-
senger side of cover, and leave that bolt
loose also.
C. Next install a 2nd clamp at midway
point of box and rail. Now check rail for
level. See photo at left and illustration below.
If rail tilts up, move clamps down and
tighten. If rail tilts down, move clamps
up and tighten.
1. INSTALLING COVER SIDE RAILS CONT’D.
Second
clamp
D. Install third clamp as close to tailgate
as possible. See photo. Make sure all clamps
are placed in best up or down position
for a level rail. Then recheck all clamps
to insure adequate tightness.
Third clamp last
Nut
“L” Left
EZ-Dial
Working from front to tailgate
match this point of cover rail
with top of pickup box as
clamps are installed
This part of rail
should be near
level
Inside lip of box
Adjust clamps
up or down
until they
hold rails
level when
tightened

4
A. Set rolled up cover on rails at front
of box (behind cab) with bar facing up.
Roll cover bar onto front of rails and
fold/tuck vinyl ap under. Now bar will
face down. Let straps hang to inside of
box. Push cover bar forward until it sets
at on front of side rails and overhangs
them.
3. MOUNTING COVER TO SIDE RAILS
B. Slide left tension adjuster over until
it engages under side rail. (See photo in
Step 3 E for tension adjuster tab under
side rail.) Push bar back and forth to line
up holes-do not turn dial wheel. Insert
bolt from top and nut from bottom.
C. Hold bolt at top and tighten nut
under side rail. Repeat procedure for
right hand tension adjuster.
D. Center the front bar between the two
side rails.
E. Then tighten bolt (left loose earlier)
under front bar on each tension adjuster.
Center front bar between
rails until space is equal
at both ends
Tab goes
under–then
tighten bolt

5
A. Unroll cover and place rear bar into
strikes on side rails and press down on bar
to close (20-30 pounds pressure).
4. INITIAL OPERATION AND ADJUSTMENTS
B. Close tailgate slowly - top of tailgate
should t snug under cover bar. If tailgate
rubs bar too hard, raise rails by loosening
rear clamps, adjust rails up and retighten
clamps. If there is too much gap between
tailgate and cover bar, lower rails by
loosening rear clamps, adjust rails down
and retighten clamps. Check cover tension
by releasing trigger latch and open and
close rear bar several times. It should snap
down when closing.
C. Cover fabric should sound drumlike
when tapped on. If adjustment is needed,
roll cover open and to loosen turn EZ-
Dial Clockwise. To tighten turn EZ-
Dial Counter Clockwise. Always turn
Dials in Equal amounts. See photo at left.
NOTE: For detailed operating instructions see page 6.
D.When done, seal both sides of cover with
hook and loop system.
To loosen Cover
Turn Clockwise
To Tighten Cover
Turn Counter
Clockwise

6
Release retainer straps at front
and using both hands roll cover
out to rear of box.
Now along side of box, seal cover
edges with hook and loop sealing
system the full length of cover on
both sides. Pull with one hand -
seal with other hand.
Position roll-up bar against
strikes. Push down on bar until
autolatch locks in place.
Open tailgate on driver side
release trigger latch and lift up
on rear of roll bar.
Securely fasten retainer straps to
store the cover.
Using both hands, roll cover
toward front of box (not against
the cab).
OPERATING INSTRUCTIONS
TO OPEN
Note: view opening and closing demonstration video on www.vanishcover.com
Manual Slide Lock (use is optional) is
located under cover bar on passenger and
driver side - push slide lock to engage, pull
to disengage.
OPTIONAL USE
• Always keep cover closed when not in use.
• Keep hook and loop sealed when cover is closed.
• Keep the cover tight, cover vinyl should sound drum-like when tapped on.
• Engage manually operated slide locks while traveling and before entering automatic drive-through car washes.
• Avoid storing cover in its rolled-up position for long periods of time.
• When cleaning, for best results use mild liquid soap and water. Never clean with petroleum or citrus base products.
• Periodically treat cover with our Formula 2 cleaner instead of petroleum based products that may dry out and
damage the vinyl.
• Avoid allowing cargo to rub against cover while transporting, whether in open or closed position.
TIPS FOR A LONGER LASTING COVER

7
SAFETY INFORMATION
• Do not cover cargo that is higher than the cover.
• Do not place object(s) on or against the cover or its framework at any time.
• Always secure cargo so it cannot shift and damage the cover or its parts.
• Do not use the covers framework to tie down cargo.
• Never stand, sit or ride on the cover or allow others to do so.
• Do not leave valuables in an unattended vehicle as cover does not prevent theft of
contents in truck box.
• The cover does not eliminate moisture and dust from entering the truck box. Special
wrappings or packaging of the contents may be necessary.
• Due to poor ventilation, if you allow a pet/animal in the box, leave cover open. Do
not allow people or animals to occupy box with the cover closed.
• When towing vehicle backwards, cover must be rolled fully open and secured with
safety straps or fully closed and secured with manual slide lock.
• ALWAYS nish securing the cover. Use caution when operating cover in windy
conditions.
• Periodically check and/or retighten clamp bolts as needed.
• Periodically check and/or retighten front bar tensioning bolts as needed.
INSPECTION AND MAINTENANCE
• Inspection and much of the maintenance can be done by the operator. It may be
necessary to review the installation and operating instructions.
• Periodically inspect the cover assembly. Check for loose bolts and parts and tighten
if needed. Test the operation to ensure that the parts are functioning properly and
that the cover is in top operational condition.
• If latch has been damaged replace with new one. NOTE: Inspection and/or main-
tenance should also be performed anytime a malfunction is observed or suspected.
If you need assistance inspecting and/or servicing your cover, or if you want to order
a replacement part, call the customer service number on the back page. Always use
original equipment replacement parts for your cover.
• Vinyl cover can be treated with water base vinyl protectants. Avoid silicon base
products.
• When cleaning, for best results use mild liquid soap and water. Never clean cover
with petroleum or citrus based products.

8
PARTS DIAGRAM
TROUBLESHOOTING
PROBLEM SOLUTION
Cover too loose Turn both tension adjusters counter clockwise to move
front bar forward (Refer to #4C, see arrows next to adjuster)
Cover too tight Turn both tension adjusters clockwise to move front bar
forward (Refer to #4C, see arrows next to adjuster)
Gap between roll-up bar and tailgate Rails set too high (Refer to #4B)
Cover is too wide Check rails. Rails in - too wide - push all clamps to top of
rail
...too narrow Rails out - too narrow - pull all clamps down on rail (Refer
to #1D)
Lopsided cover too much on one side Check front bar. It must be centered side to side (Refer to
#3D)
Top of tailgate hits rear bar when Raise side rails at rear of box until tailgate closes without
attempting to close pushing rear bar up (Refer to #4B)
Manual slide locks too loose or Use 1/8” allen wrench and adjust set screw tighter or too
tight looser as desired. Lock performs best with some friction
3/8” x 3/4” bolt
& nut
(2 per cover)
EZ-Dial left
tension adjuster
3/8” x 1/4” bolt
& washer
(2 per cover)
Front bar
Quick release storage straps
(2 per cover) Support bows
Slide lock
Rear roll-up
bar
Right rail
passenger side
Side Lock
Left rail
drivers side
Rail clamps
