Accu-Chek Softclix User manual

➋ Firmly insert a new ACCU-CHEK Softclix lancet in the lancet holder
until it snaps into place.
➌ Twist the protective cap on
the lancet several times
and pull gently to remove it.
➍ Snap on the cap after
lining up the notches.
The cap snaps easily
into place.
➎ Select the desired depth setting as instructed in the section
“Selecting the Depth”.Then, press the plunger on the end of the
device all the way down, and you will hear a “click.” When the device
is ready, you will see a yellow dot appear and remain in the center of
the clear release button.
➏ Now, wash your hands and dry them thoroughly. Also warm the
fingers to increase blood flow. If you are using alcohol wipes, make
sure your finger is completely dry before continuing.
➐ Grasp your finger near the area to be pricked and gently massage for
three seconds.
➑ Hold the lancing device
firmly against the side of
your fingertip, then press
the release button. Gently
squeeze your fingertip to
get a small drop of blood.
The best place to test on
the fingertip is the side,
because it has the best
blood supply, yet allows for
the least painful fingerstick. Any finger may be used for a fingerstick.
Lancet
Instructions for Use
The ACCU-CHEK Softclix lancing device uses ACCU-CHEK Softclix
lancets to obtain a drop of blood from the fingertip. The penetration
depth can be selected to match any type of skin.
This cap is for fingertip testing only.
The clear cap is for testing on sites
other than the Fingertip (AST).
Do not use the clear cap for fingertip
testing.
Note: The ACCU-CHEK Softclix cap was not designed to be replaced
after each use. The ACCU-CHEK Softclix lancing device is intended
for use by a single person and is not suitable for testing different
persons with the same device as this may lead to infections.
Selecting the Depth
The depth on the ACCU-CHEK Softclix device may be adjusted by turning
the Comfort Dial. The current depth selection is shown in the center of
the depth indicator window. You can find the depth indicator window as
a semi-circular cutout on the ejector.
The ACCU-CHEK Softclix lanc-
ing device offers 11 depth set-
tings. The settings are shown
in the depth indicator window
by the numbers 1 to 5 with
additional levels marked with
dots to enable you to precisely
adjust to your individual skin type. The higher the number visible in the
depth indicator window, the greater the depth setting.
Note: If you are using the ACCU-CHEK Softclix lancing device for the first
time, start by selecting 1 or 2 to see if the amount of blood obtained
is enough to perform a test. If your skin is calloused or thick, you may
need to try a higher setting.
➊ To select the desired depth setting, turn the Comfort Dial so that the
desired setting is in the center of the depth indicator window.
➋ Select a new depth setting
by turning the Comfort Dial.
The cap will snap into a
new position, preventing
any accidental change of
the depth setting.
Performing a Fingerstick
➊ Pull off the cap of the
lancing device. If there is
already a lancet in the
device, remove it by
sliding the ejector
forward. Refer to the
selection called
“Removing the Lancet”.
➒ Apply the drop to the test strip you are using.
➓ Immediately remove used lancet. To avoid accidental injury, do not
store lancet in device.
Removing the Lancet
➊ To remove the lancet, pull
off the cap of the ACCU-
CHEK Softclix device.
➋ Hold the meter so the lancet
points downward. Slide the
ejector forward to release
the lancet into a puncture-
proof container.
For least painful testing and to avoid infection, use a new lancet each
time you perform a fingerstick.
Getting Blood From A Site Other Than Your Fingertip
Testing on sites other than the fingertip is referred to as alternate site
testing (AST). These sites may be any of the following – palm, forearm,
upper arm, thigh, or calf. We suggest the palm as the non-fingertip test
site.
Please refer to your test strip insert or your blood glucose meter’s
owner’s booklet to see if your meter is designed to test blood glucose
from sites other than your fingertip as well as for specific AST testing
instructions.
IMPORTANT – There is a delay (lag time) in the delivery of blood glucose
to non-fingertip sites when compared to fingertip. Therefore, there is a
potential for a significant difference between fingertip and AST results.
The length of delay (lag time), is strongly impacted by lifestyle, foods
eaten, or any other event having impact on blood glucose levels. It is
important that people considering non-fingertip testing understand the
following:
● Talk to your doctor if you are considering testing on other sites than
your fingertip.
● AST testing is not recommended during periods of rapid decreases
or increases in blood glucose levels.
▼
▼
0 5104076001(01)
V1/R1 (black) – 2007-09
018035 Roche – RH 3109 – Frau Heiland
Cap with Comfort Dial
Depth Selection
Ejector Release Button
▼
Protective Cover
▼
pi_05104076001_01_EnUs_420x216.indd 1 23.01.2008 14:04:25

● AST testing is not recommended for people with a history of recur-
rent hypoglycemia, who suspect their blood glucose is extremely low,
or who are unaware of hypoglycemic events.
● NEVER ignore symptoms of high or low blood sugar.
● Do not change your treatment based on one result.
● If the AST reading does not match how you feel, perform a fingertip
test to confirm your results. If your blood glucose still does not reflect
the way you feel, contact your doctor. For more information on AST
testing please contact ACCU-CHEK Customer Care Service Center at
1-800-858-8072.
➊ Wash the non-fingertip site with warm water.
➋ Make sure that you are using the clear cap specially designed for
AST testing with the ACCU-CHEK Softclix lancing device.
➌ Adjust the clear cap to the highest setting.
➍ Press and hold the lancing device against a fleshy area on the AST
site. Press the release button and continue to apply steady pressure
to the site.
Don’t be afraid to apply strong pressure to the area with the lancet
device to get a good blood drop.
Caring For Your Lancing Device
● Your lancing device requires very little care.
● Keep it away from extreme temperatures.
● Clean the outside of the lancing device regularly with 70% isopropyl
(rubbing) alcohol. Let it air dry.
● Do not dip the lancing device in liquid.
● Do not use bleach to clean the lancing device or caps.
Assistance Available
If you need assistance, please contact ACCU-CHEK Customer Care
Service Center toll-free, 24 hours a day, 7 days a week. We offer
assistance in Spanish and many other languages.
1-800-858-8072 phone
1-800-858-8074 TDD/TYY
(for the hearing impaired)
Also Available from Roche
ACCU-CHEK Softclix Lancets
Cat. No. 971, 100/box
Cat. No. 988, 200/box
ACCU-CHEK Advantage Diabetes Care Kit
Cat. No. 860
ACCU-CHEK Active Diabetes Care Kit
Cat. No. 3184501
One (1) Year Warranty
Roche warrants the ACCU-CHEK Softclix lancing device against defects
in materials and workmanship for a period of one (1) year from the date
of purchase. The liability of Roche under this warranty is limited to the
repair or replacement, at Roche’s option, of all parts or materials proven
to be defective.
This warranty does not cover repair or replacement of ACCU-CHEK
Softclix lancing devices which have been subjected to alteration,
misuse, tampering, or abuse.
THE FOREGOING WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES,
WHETHER EXPRESS, IMPLIED, OR STATUTORY. ROCHE DISCLAIMS ANY
AND ALL IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Roche entire liability with respect to the ACCU-CHEK Softclix lancing
device shall be the repair or replacement of nonconforming devices,
at Roche option. In no case shall Roche be liable for incidental, indirect,
special, or consequential damages, so the above limitation and
exclusion may not apply to you. This warranty gives you specific legal
rights, and you may have other rights which vary from state to state.
All inquiries about the ACCU-CHEK Softclix lancing device under the
above warranty or service policy must be directed to ACCU-CHEK
Customer Care Service Center by calling 1-800-858-8072.
You will be informed of the procedure necessary for replacement.
Please DO NOT return any device to Roche without authorization.
IMPORTANT – Read carefully before use. Caution: A restricted license
limits the use of this ACCU-CHEK Softclix lancing device.
This ACCU-CHEK Softclix lancing device and its use are protected by
U.S. Patent Nos. 4,924,879; 6,419,661; 7,077,828 and Re. 35,803.
A license to use this ACCU-CHEK Softclix lancing device is only granted
when ACCU-CHEK Softclix lancets are used as part of the ACCU-CHEK
Softclix lancing device.
Using the ACCU-CHEK Softclix lancing device indicates your acceptance
of the restricted license to use the ACCU-CHEK Softclix lancing device
with only ACCU-CHEK Softclix lancets. If you do not agree to the terms
and conditions of the restricted license, you may return the unused
ACCU-CHEK Softclix lancing device for a full refund.
ACCU-CHEK Softclix lancets are high-precision components that are
produced to the close tolerances required for satisfactory operation
with the ACCU-CHEK Softclix lancing device driver. Use of any other
lancet with the ACCU-CHEK Softclix lancing device driver may prevent or
impair proper function of the ACCU-CHEK Softclix lancing device.
Visit our website at www.accu-chek.com
This product is covered by the following U.S. Patents: 4,924,879;
6,419,661; 7,077,828; D429,814; 6,464,649; and RE. 35,803.
ACCU-CHEK ACTIVE, ACCU-CHEK ADVANTAGE and SOFTCLIX
are trademarks of Roche.
Roche Diagnostics GmbH
68298 Mannheim, Germany
www.accu-chek.com
Distributed in the U.S.A. by:
Roche Diagnostics,
9115 Hague Road, Indianapolis, IN 46256, USA
Made in Germany
©2007 Roche. All rights reserved.
